Tips for assembling
1.Picures shown on the package may be slightly different from the actual product.
2.All the materials are taken in the operation step, put the remaining materials back into
the original pocket until the installation is completed.(Avoid material loss during installation)
3.The dimensions indicated in the step diagram are“cm”.
4.If there have template paper material, please cut the material according to the template
to avoid mistakes..
5.According to the part rule example at the bottom of this page, refer to the part on the part
number drawing, find the material object and compare with the material list, confirm and
install.(Wooden parts only)
6.Glue should not be applied too much, so as not to dry longer, overflow will affect the effect
of the finished product.
7..Part shapes may differ from the photographs depending on he production batch
Testing on LED function
Be sure to test the LED lights before making the lighting,
note that the LED white wire to the negative, gray wire
to the positive reference to the following figure
operation test.
DO NOT contact the
LED wire end direct
to the battery cell.
Use the provide battery
holder. Make sue the
correct polarity.
Product comes with tool:
Bring your own tools:
White glue:
It dries slowly and
can paste materials
firmly without trace.
Can be used to paste
wallpaper and
printed paper.
Ruler:
For measuring
materials to identify
the number of
materials so as to
enhance
work efficiency.
Scissors:
Can be used to
cut printed
paper,cloth,etc.
Cutter kinfe:
For peeling off power
wire skin and cutting
off materials.
Alcohol gel:
It dries fast and can paste
materials firmly,but may
leave some trace. Can
be used to paste small
metal materials and
small components of
furniture.
Tweezers:
For holding small
materials and
rolling up iron
wire.
Screw Driver:
For fixing screws,
mostly can be used
to install doors and
music components.
Drill:
Can be used to
drill holes in timbers,
roll up hard iron
wire or fix screws.
Needle-nose pliers:
For cutting, bending wire,
folding harder material
How to assemble the battery holder
1.Material and tools needed:
- Battery holder, LED bulb,
tape, screw driver and 2 piece
AAA size battery(not provided)
2. Use screw driver
and take the lid off
from the battery holder.
3. Insert the battery take
notes on the polarity.
4. Connect the red wire
to grey wire. Connect
the black wire to white wire.
5.Wrap the exposed
wire with the tapes.
6. Place the box lid and
fastness with screw driver.
“-”negative
“+”positive
Example of parts rule:
A01:The parts are directly in the box.;B01:parts in bag B;C01:part in bag C,and so on.
(Note: display the printing paper A10-01 in the step: the printing paper is placed directly in the box, part number is A10-01)

bag B+printing paper
bag B
bag B+printing paper
bag B
bag B+bag G+bag J+bag H+printing paer
bag C+bag G+bag H+printing paper
bag C+bag J+printing paper
bag C+bag G+bag H+bag H+printing paper
bag C+bagG
bag C+bag G+bag H
bag D
bag D+bag G+bag J+printing paper
bag D+bag G+bag J+bag H+printing paper
bag E+bag J
bag E+bag J+bag H+printing paper
bag E+J bag
bag E+bag G+bag J+bag H+printing paper
bag D+bag F+bag G+printing paper
bag F+bag J+bag H+printing paper
bag F+bag H
bag F+bag G
bag H+bag J+printing paper
bag C+bag J+bag H
bag A+printing paer
the material of H14 transparent film and G19 corrugated paper
in the bag of instructions and printing paper.
Name Material package
Bag A-A10(All printing and template papers are
shown on A10 paper,total 5pieces of A4 )
Printing paper
details of miniature kit
Thumbnail of material list( reference only)
Thumbnail of printing paper &template paper( reference only)
