Hored IS108S-4F User manual

User Manual
IS108S-4F
12-port Gigabit Managed Industry Switch

1
Installation Manual Introduction
<User Manual> mainly introduces the hardware features,
installation methods, and precautions during the installation of
IS108GS-4F.
This manual includes the following sections:
Chapter 1: Product introduction. Briefly describe the basic functions
and features of the switch, detailed hardware and software
specifications and appearance information.
Chapter 2: Hardware Connections. Guide the connection of switch
with other devices and precautions.
Chapter 3: Product Installation. Guide the hardware installation
method and precautions.
Chapter 4: Product Packaging and Use Recommendations.

2
Chapter 1 Product Introduction
1.1 Product introduction
The IS108GS-4F is a 12-port Gigabit-managed industrial
Ethernet switch that provides 8 Gigabit ports and 4 Gigabit SFP
ports. It is especially suitable for applications where AC power is
not easily available or high wiring costs. It support EMC industrial
grade 4 protection; corrugated high-strength aluminum profile
housing, IP40 grade, low power design, seismic rail mounting,
-40°C-75°C operating temperature, can work in harsh
environments; IS108GS-4F also supports Apollo cloud one-stop
management platform for status checking and management
monitoring,to make itbecome a reliable solution for intelligent
transportation, video surveillance and other harsh industrial
environments.
1.2 Features
Full Gigabit Ethernet port

3
8 full Gigabit RJ45 network port, and 4 Gigabit SFP ports,
breaking the traditional 100M limitation, data transmission will not
stuck
Broadcom high performance industrial grade chip for more
stable performance
Broadcom high-performance industrial-grade chips that
dramatically increase network data processing rates
Powerful working environment
EMC industrial grade 4 protection; corrugated high-strength
aluminum profile housing, IP40 grade, low power design, seismic
rail mounting, -40°C-75°C operating temperature, can work in
harsh environments
Support Apollo cloud platform one-stop management
Support cloud platform to visualize management of switches and
attached power devices, making operation and maintenance
management easier

4
1.3 Software and hardware specifications
Hardware specification
Chip
Broadcom high performance chip
Flash
16MB
RAM
64MBDDR
Port
8 x10/100/1000M RJ45 Port
4 x 1000M SFP Port
Indicator
12 Link/Act Indicator
ALM Alarm indicator
P1、P2 Power Indicator 1 SYS Indicator
Performance
Forward mode: store and forward
Backplane bandwidth: 24Gbps
Packet forwarding rate: 17.8Mpps
Support 8K MAC address table depth
Standard
protocol
IEEE 802.3: Ethernet Media Access Control (MAC)
Protocol
IEEE 802.3i: 10BASE-T Ethernet

5
IEEE 802.3u: 100BASE-TX Fast Ethernet
IEEE 802.3ab: 1000BASE-T Gigabit Ethernet
IEEE 802.3z: 1000BASE-X Gigabit Ethernet
(optical fiber)
IEEE 802.3ad: Standard method for performing
link aggregation
IEEE 802.3x: Flow Control
IEEE 802.1p: LAN Layer 2 Qos/Cos protocol for
traffic prioritization (multicast filtering)
IEEE 802.1q: VLAN Bridge Operation
IEEE 802.1d: STP spanning tree
IEEE 802.1s: MSTP Spanning Tree
IEEE 802.1w: RSTP Spanning Tree
Industry
Standard
EMI:FCC CFR47 Part 15, EN55022/CISPR22, Class
A
EMS:
IEC61000-4-2 (ESD): ±8kV (contact), ±15kV (air)

6
IEC61000-4-3 (RS): 10V/m (80MHz-2GHz)
IEC61000-4-4 (EFT): Power Port: ±4kV; Data Port:
±2kV
IEC61000-4-5 (Surge): Power Port: ±2kV/DM,
±4kV/CM; Data Port: ±6kV
IEC61000-4-6 (CS): 3V (10kHz-150kHz); 10V
(150kHz-80MHz)
IEC60068-2-6 (Vibration)
IEC60068-2-27 (Shock)
IEC60068-2-32 (Free Fall)
Operation
environment
Working temperature: -40 ~ 75 ° C
Storage temperature: -40 to 75 ° C
Relative humidity: 5% to 95% (no condensation)
Certification
CE, FCC, RoHS
Mean time
between
failures(MTBF)
100,000 hrs

7
Warranty
3 years
Lightning
protection
Network port: ±6KV power port: ±4KV
ESD
Contact: ±8KV Air: ±15KV
Physical
specification
Input:12-56VDC
Housing: IP40 grade protection, corrugated high
strength metal housing
Installation: DIN rail mounting
Size:163mm×46.5mm×110mm，weight：1kg
Software specification

8
Global control
button
AI Loop Protect
AI Extend
Hardware watchdog
Support
Traffic Statistics
Support
Port energy saving
Support
DHCP
Support DHCP Snooping
VLAN
Support 4KVLANs
Support 802.1QVLAN、MAC VLAN ,IP VLAN
Voice VLAN
MAC address
Follow the IEEE 802.1d standard
Support MAC address automatic learning
and aging
Support static, dynamic, filtering address
table
Safety features
Password protection
Support restrict user access based on port
number, IP address, and MAC address

9
Support HTTPS、SSLV3、TLS V1、SSHV1/V2
Support IP-MAC-PORT ternary binding
Support ARP protection, IP source
protection, DoS protection
Support DHCP Snooping and DHCP attack
protection
Support 802.1X authentication, AAA
Support port security, port isolation
Support CPU protection
QoS
Support 8 port queues
Support port priority, 802.1P priority, DSCP
priority
Supports SP, WRR, and RR priority
scheduling algorithms
Supports automatic identification,
management and retrieval of information
about attached devices

10
Spanning tree
Supports STP (IEEE 802.1d), RSTP (IEEE
802.1w) and MSTP (IEEE 802.1s) protocols
Support loop protection, root bridge
protection, TC protection, BPDU
protection, BPDU filtering
Multicast
SupporIGMPv1/v2 Snooping
Support fast leave mechanism
Support multicast VLAN
Supports multicast filtering, packet
statistics, and unknown multicast discards.
Storm suppression
Support multicast suppression
Support broadcast suppression
Support unknown unicast suppression
Link aggregation
Support static aggregation
Support dynamic aggregation
Support IP, MAC, hybrid load balancing
mode

11
Support up to 32 aggregation groups
IPv6
Support IPv6 Ping、IPv6 Tracert、IPv6 Telnet
Support IPv6 SSH 、IPv6 SSL
Management and
maintenance
Support WEB network management (HTTP,
HTTPS, SSLV3)
Support CLI (Telnet, SSHV1/V2, local serial
port)
Support SNMP V1/V2/V3,
Support LLDP、RMON
Support ARP protection, IP source
protection, DoS protection
Support SNMP protocol
Support Apollo cloud platform one-stop
management and maintenance
Support CPU monitoring, memory
monitoring
Support system log, grading warning

12
1.4 Appearance
Support Ping, Tracert detection, cable
detection

13
Indicator
Status
Description
P1、P2
On
The corresponding power supply
working normally.
Off
The corresponding power supply is
not connected or working abnormal.
SYS
Blinking
System is running normally
Off /
always
bright
System operation is abnormal / start
unsuccessful
ALM
On
Alarm start up
Off
Alarm not triggered
Link/ACT
F1-F4
Blinking
SFP port is working normal
Off
SFP port is working abnormally /
port is not connected

14
Chapter 2. Hardware Connection
2.1 Connect to RJ45 port
Connect the switch and the RJ45 port of the network device
with a network cable.
2.2 Connect to the SFP port
The SFP port of the IS108GS-4F supports only Gigabit fiber
modules. It is recommended to use standard SFP module products.
The process of installing a fiber module on a switch is as follows:
1. Grasp the fiber module from the side and insert it smoothly

15
along the SFP port slot of the switch until the fiber module is in
close contact with the switch;
2. Confirm the Rx and Tx ports of the fiber module when
connecting. Insert one end of the fiber into the Rx and Tx ports to
ensure that the Tx and Rx ends of the interface are correctly
connected, and the other end of the fiber is connected to another
device.
3. After power-on, check the status of the corresponding
indicator. If the indicator is on, the link is up. If not, please check the
line and confirm that the peer device is enabled.
Attention:
It is not allowed to excessively bend the fiber, and its radius of
curvature should be no less than 10cm;
Ensure the cleanliness of the fiber end face;
Please do not look directly into the fiber optic connector with your
eyes, as this may cause eye damage.

16
2.3 Check before power-on
Check that the power supply of the power outlet meets the
switch specifications.
Check that the power supply, switch, and rack are properly
grounded.
Check whether the switch is connected to other network
devices.
2.4 Device initialization
The switch will automatically initialize after the power is turned on
and the power switch is turned on.
The indicator light will appear as follows:
After the power is turned on, the power indicator remains steady,
the SYS light enters the blinking state, and the system runs
normally.
The indicator of each port indicates the connection status of each
port, indicating that the switch has started to work normally.

17
Chapter 3, Product Installation
Before installation, confirm the operating environment of the
equipment: power supply voltage, installation space, installation
method, etc. Please carefully confirm the following installation
requirements:
- Check for cables and connectors required for
installation
- Check whether the cable is in place (not more than
100m) according to reasonable configuration requirements.
- The product does not provide mounting
components, the user must prepare the components of the
selected installation type: screws, nuts and tools to ensure reliable
installation
Power requirements: 12-56V DC
Environmental requirements:
Working temperature: -40 ~ 75 ° C
Storage temperature: -40 to 75 ° C

18
Relative humidity: 5% to 95% (no condensation)
Power input
5pin 5.08mm terminal
Input range: 12-56V DC
P1&P2 dual redundant power supply,
Support reverse connection protection
Ground protection
Connect to ground
Rail mounting

19
Chapter 4, Packing list and use recommendations
4. 1 Product packaging
Item
Quantity
Description
Switch
1 set
\
Phoenix terminal
1*5,1*2
each per
one unit
Connect to power and alarm
switch
Warranty card
1 piece
For after-sales maintenance
User Manual
1 copy
Used to guide users to install
switches
4.2 Recommendations
1. For safety reasons, non-professionals should not open the
product casing;
2. Pay attention to the danger of strong electricity and safe
protection when the product is powered on;
