Hored PS3024S User manual

User manual:
PS3024S
24 Port Layer 2 PoE Switch

1
Installation manual introduction
The Product installation manual mainly describes PS3024SPoE switch
hardware features, installation methods, and precautions during the
installation
This manual includes the following chapters:
Chapter 1: Product Introduction. Briefly describes the basic
features, Detailed hardware & software specifications of the switch
and the appearance details.
Chapter 2: Product Installation. Guide the switch hardware
installation methods and precautions.
Chapter 3: Hardware Connections. Guide the connection between
switches and other devices and precautions.
Chapter 4: Packaging and product usage suggestions.

2
Chapter 1: Product Introduction
1.1 Products description
PS3024S is managed PoE switch for security transmission and
WIFI coverage, meet the need of PoE power supply for WIFI AP,
IP-camera, WIFI bridge, IP phones and other types of
equipment. New generation of high-performance hardware
and software platforms are used, providing flexible, cost-
effective full Gigabit access and uplink ports, complete security
mechanisms, improved ACL / QoS strategy and rich VLAN
capabilities. It is easy to manage and maintain, meet the users'
requirements for network equipment easy to manage, high
security and low cost. Supporting Apollo Cloud One-stop
Management Platform, realizing status checking and
management monitoring functions, suitable for campus, Hotel
and enterprise park network access, convergence, core multi-
application scenarios

3
1.2 Product Features
Full Gigabit Port
16 1000Mbps RJ45 ports (support PoE power supply) with 2
Gigabit SFP ports, Data transmission is not jammed.
Realtek chip, the performance is more stable and powerful
Realtek high-performance chip can greatly improve network
data processing rate
Convenient operation
·AI VLAN mode: Separating 1-8 ports from each other, can
effectively restrain network storm and improve network
performance.
·AI Extend mode: Designed for monitoring application
scenarios, 1-8 ports support 250 meters long distance power
supply.
·AI PoE mode：automatically check, reboot the device while
find it fake dead
·AI QoS mode：video data first, more fluent transmission
Support Apollo Cloud Platform One-stop Management
Support cloud platform for resource visualization management

4
of switches and downloaded PD devices, make operation and
maintenance management easy
1.3 product specification
Hardware Specifications
Chipset
RealtekHigh Performance Chipset
Flash
16MB
RAM
128M DDR
Network
IEEE 802.3i IEEE 802.3u IEEE 802.3x
IEEE 802.3ab IEEE 802.3af IEEE
802.3at
Port
2410/100Mbps RJ45 ports
210/100/1000Mbps RJ45 ports
2 Gigabit SFP ports
1 Console port
PoE
24 10/100Mbps RJ45 port support
PoE+
Max 250W
Single port max 46W
LEDs
26 Link/Act LEDs
24 POE LEDs
1 Power LED
1 SYS LED

5
Performance
Forwarding mode: store and forward
Switch Volume (Full-duplex) ：
8.8Gbps
Packet forwarding rate：6.55Mpps
8K MAC address table
lightning protection
±6KV
ESD
No barrier: ±6KV Air：±8KV
Input
100-240V/50-60Hz
Dimension
（L×W×H）
440mm×180mm×44mm
Software Specifications
Network standard
IEEE 802.3: Ethernet Media Access
Control (MAC) protocol
IEEE 802.3i:10BASE-T Ethernet
IEEE 802.3u:100BASE-TX fast Ethernet
IEEE 802.3ab:1000BASE-T gigabit
Ethernet
IEEE 802.3z:1000BASE-X gigabit Ethernet
（fiber）
IEEE 802.3ad: comply link aggregation
standard
IEEE 802.3x: flow control
IEEE 802.1p: About the traffic priority of
the second layer of Qos / Cos protocol
(multicast filtering)

6
IEEE 802.1q:VLAN Bridge operation
IEEE 802.1d:STP spanning tree
IEEE 802.1s:MSTP spanning tree
IEEE 802.1w:RSTP spanning tree
IEEE 802.3af
IEEE 802.3at
Shortcut function
One key VLAN
One key Exnted(1-8 port 250meters PoE
distance)
One key QoS (Video priority)
One key AI power supply
DHCP
DHCP Snooping
VLAN
Support 4K VLAN
Support 802.1Q VLAN、Port VLAN、
Voice VLAN
MAC address table
Comply the IEEE 802.1d standard
Support MAC address learning and
aging automatically
Support static, dynamic, filter address
table
Safety
Password protection
Support based on the port number, IP
address, MAC address restrictions on
user access

7
Support HTTPS、SSL V3、TLS V1、SSH
V1/V2
Based on user rating management and
password protection
Support IP-MAC-PORT
Support ARP protection, IP sources
protection, DoS protection
Support DHCP Snooping、DHCP attack
protection
Support 802.1X AAA
Support port security, port isolation
Support CPU protection
PoE
Support setting the PoE port priority
Support viewing POE Chip Status
Support setting PoE power supply
period
Support setting port power
Access control (ACL)
Support L2(Layer 2)～L4(Layer 4) packet
filtering function
Support port mirroring, port redirection,
flow rate limit, QoS re-marking
QoS
Support 8 port queue
Support port priority, 802.1p priority,
DSCP priority

8
Support SP、RR、WRR、WFQ Priority
scheduling algorithm
Support automatically identify, manage
and acquire of connected equipment
information
Multicast
Support IGMP v1/v2 Snooping
Support static multicast
Support multicast VLAN
Support multicast filtering, message
statistics, unknown multicast discarding
Spanning Tree
Support STP(IEEE 802.1d)，RSTP(IEEE
802.1w) and MSTP(IEEE 802.1s) protocol
Support loop protection, BPDU
protection
Storm suppression
Support for multicast suppression
Support broadcast suppression
Support for unknown unicast
suppression
Link aggregation
Support static aggregation
Support dynamic aggregation
Support IP, MAC, hybrid load balancing
mode

9
Supports up to 32 aggregation groups
IPv6
Support IPv6 Ping、IPv6 Tracert、IPv6
Telnet
Support IPv6 SSH 、IPv6 SSL
Management and
maintenance
Support WEB management（HTTP、
HTTPS、SSL V3）
Support CLI（Telnet、SSH V1/V2，local
serial port）
Support SNMP V1/V2/V3
Support LLDP、RMON
Support SNMP
Support ARP Protection, IP Source
protection、DoS protection
Support CPU monitor、memory
monitoring
Support system log
Support Ping, Tracert detect cable
testing

10
1.4 Appearance
Front Panel
Including indicators, RJ45 port, DIP switch, RST button, SFP port,
CONSOLE port, as shown below
indicator
PS3024S The indicator working status is shown as
the following table
PS3024S The indicator working status is shown as
the following table
Indic
ators
Title
Color
Work
status
Description
POW
ER
Power
indicator
Red
Solid
Power is normal
Off
No power, the power
switch is not turned
on, power supply is
abnormal
POE
The corresponding

11
POE power
indicator
Yellow
Solid
RJ45 port is
connected to the
powered device and
the power supply is
normal
Off
The corresponding
RJ45 port is not
connected to the
powered device or
the power supply is
abnormal
LINK/
ACT
Connection
indicator
Green
Blinkin
g
A valid link is
established
Off
An invalid link is
established
SYS
System
indicator
Green
Blinkin
g
System is functioning
properly
Off
System is functioning
improperly Software
is damaged
Shortcut button
AI QoS: Improve video data processing capabilities
and improve the monitoring of Caton and Mosaic
phenomena in the network
AI Extend: 1-8 port rate down to 10Mbps, but the
transmission distance up to 250 meters

12
AI VLAN: Isolating ports 1-8 from each other,
suppress network storms effectively and improve
network performance
AI power supply: Detect PD, power failure and restart
dead equipment
RJ45 Port
PS3024S with 16 10/100/1000Mbps PoE port, all
ports support IEEE802.3af and IEEE802.3at standard
PS3024E also provides two 10/100/1000Mbps RJ45
ports as up-link ports, forming a Combo port in SFP1
and SFP2 respectively. At the same time, the two
ports of the Combo port can only use one two
Combo ports to share 25 and 26 indicator lights.
SFP Port
PS3024S provides two Gigabit SFP optical module
expansion slots (SFP1, SFP2), which can be inserted
into Gigabit SFP module.
RST Button
When the switch is powered on, press the button
with the needle to release the device and enter the

13
restarting state. When the SYS lamp restarts, the
device restarts. When the switch is powered on, press
and hold the button for more than 5s to release the
button and enter the reset state. When SYS is re-lit,
the device is reset successfully
Console port
Console port used to connect to computer or other
terminal to manage or configure the switch.
Back Panel
Including: power socket, ground terminal
Power socket
A 100-240VAC 50/60 Hz power receptacle for
accommodating the supplied power cord
Ground terminal
Please use the grounding wire to prevent lightning.
To avoid product lightning strikes and extend
product life

14
Chapter2 Hardware connection
2.1 RJ45 port connection
Connect the RJ45 port of the switch and the corresponding
network device via cables, the POE power supply function of the
switch is default enabled on the downlink port of the switch,
which can be used for IEEE802.3af or IEEE802.3at standards
powered devices such as APs, bridges, and network cameras
Note：
When the switch connected workstations, servers, routers or
other ethernet devices the cable length should be within 100
meters;
The Auto-MDI / MDIX ethernet interface is enabled by default.
Category 5,the standard network cable or crossover cable can

15
be used for Ethernet connection.
Do not connect the RJ45 port to the phone line
2.2 SFP Port connection
PS3024S SFP port only support Gigabit fiber module.
Recommended use of standard SFP module products
The process of installing a fiber module on a switch is as
follows:
1、grasp the optic fiber module from the side, insert it
smoothly along the SFP port slot until the optic fiber module
and switch are in close contact;
2、confirm the Rx and Tx ports of the fiber module when
connecting, insert one end of the fiber into the Rx and Tx
ports correspondingly, ensure that the Tx and Rx ends of the
interface are connected correctly and the other end of the
fiber is connected to another device;
3、 please check the corresponding indicator light status
after power on. If the light blinking that the link is properly
connected, if the light is off , the link is failure, please check
the line to confirm that the corresponding equipment is
enabled.

16
Note：
DO NOT excessive bending fiber, the radius of curvature
should not be lessthan 10cm;
Ensure the cleanliness of the fiber surface;
Please DO NOT look directly into the optical fiber connector
with your eyes as this may cause eye injury
2.3 Check before power on
Check whether the outlet power supply meets the switch
specifications;
Check the power, switches, racks and other equipment have
been properly grounded;
Check whether the switch and other network devices are
connected properly
2.4 Device initialization
The switch automatically initializes when the power switch is
turned on.
Indicator will appear the following situation:
After the power is turned on, the power indicator remains on,
the other indicator is off at this time;
After about 1 second, all lights except for the power light turn
on for about 35 seconds and then turn off; when the SYS light
goes flashing, the system runs normally

17
Port LEDs indicates the connection status of each port,
indicating that the switch has started to work normally
Chapter3 Installation
3.1 Installation Precautions
Note：To avoid improper use of equipment damage and
personal injury, please observe the following precautions
Installation safety precautions
The power should be kept off during the installation, while
wearing anti-static wrist, and to ensure well touch between
anti-static wrist and skin to avoid potential safety hazard;
The switch just works normally when it is powered by the
correct power supply. Make sure that the power supply
voltage matches the voltage indicated by the switch
Before powering on the switch, make sure that the power
circuit is not overloaded, which may affect the normal
operation of the switch and even cause unnecessary
damage
To avoid the risk of electric shock, do not open the case
while the switch is working. Do not open the case even
when it is not powered
Before cleaning the switch, unplug the switch from the

18
power cord and do not wipe it with wet cloth. Do not wash
it with liquid
Temperature and humidity
To ensure the long-term stability working of the switch ,
please maintain a certain temperature and humidity
environment. High or low humidity easily lead to leakage of
insulation materials, deformation and even the corrosion of
metal parts, the temperature is too high will accelerate the
aging process of insulating materials, seriously affecting the
service life of equipment. The normal operation of this
series of switches and storage temperature / humidity are
as follows
Environmental
description
temperature
Relative humidity
Working
environment
0℃~40℃
10%～90% RH no
condensation
Storage
environment
-40℃～70℃
5%～90% RH no
condensation
Altitude
Products with this logo are only for safe use in areas below
2000m altitude
Dust-proof
Dust on the switch surface will cause electrostatic

19
adsorption, poor contact of the metal contacts. Although
the device itself has done some measures in anti-static, but
when the static electricity exceeds a certain intensity, it will
still cause fatal damage to the electronic components on
the internal circuit board.
In order to prevent static electricity from affecting the
normal operation of the equipment, please note the
following:
1. Regular dust, keep the indoor air clean;
2. Make sure the equipment is well grounded to ensure
smooth transfer of static electricity
Electromagnetic interference
Electromagnetic interference have an impact on the device
capacitance, inductance and other electronic components
by capacitance, inductive coupling, impedance coupling
and other conductive, in order to reduce the adverse effects
caused by electromagnetic interference, please note the
following：
1. Power supply system to take the necessary anti-grid
interference measures;
2. Switches should be far away from high-frequency
high-power, high-current devices, such as wireless
transmitters;
3. If necessary, take electromagnetic shielding measures
