Horizon Fitness PARAGON X User manual

PARAGON X
Read the TREADMILL GUIDE before using this OPERATION GUIDE.
OPERATION GUIDE
HZ19_OG_Paragon X v1_1_D.indd 1 7/29/19 8:57 AM

32
TREADMILL OPERATION
This section explains how to use your treadmill’s console and programming.
2
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 2-3 7/29/19 8:57 AM

54
go
stop
1 2 3 4
PARAGON X CONSOLE OPERATION
Note: There is a thin protective sheet of clear plastic on the overlay
of the console that should be removed before use.
A) LED DISPLAY WINDOWS: Time, Speed, Incline, Distance,
Calories, Heart Rate
B) LED INDICATOR: Incline, Time, Speed
C) LED INDICATOR: Calories, Distance, Heart Rate
D) LED INDICATOR: Bluetooth and ErP
E) INCLINE INSTANT KEY: Press to increase or decrease
incline range
F) INCLINE KEYS: Touch keys, gentle touch to adjust incline in
small increments (0.5% increments)
G) ACCESSORY TRAY: Holds personal equipment
H) BLUETOOTH CHEST BELT CONNECTION: Press and hold for
3 seconds to connect Bluetooth chest belt
I) CUSHION FIRMNESS CONTROL: There are four levels of
cushion firmness, 1 to 4 from soft to hard. Press the left
hand side of this button, select level 1, press the right hand
side of this button, select level 2.
J) SAFETY KEY POSITION: Enables treadmill when safety key
is inserted
K) GO/STOP: Press to start exercise, during workout press to
pause/end your workout. Hold for 3 seconds to reset the
console
L) CUSHION FIRMNESS CONTROL: There are four levels of
cushion firmness, 1 to 4 from soft to hard. Press the left
hand side of this button, select level 3, press the right hand
side of this button, select level 4.
M) ENTER/CHANGE DISPLAY: Press to confirm the setting.
Press to change the display from Speed, Time, Incline to
Heart Rate, Distance, Calories during workout
B
E Q RF G I L O PJ K M NH
N) ENERGY SAVER MODE: Press to quickly enter sleep mode. Under
sleep model, press any key to wake the console up
O) SPEED KEYS: Touch keys, gentle touch to adjust speed in small
increment (0.1 km/h increments)
P) WATER BOTTLE HOLDER: Holds water bottle
Q) SPEED INSTANT KEY: Press to increase or decrease speed range
R) HEART RATE SENSOR: Hold the sensor in the both side of
handlebar to get your heart rate data
A
CD
ENGLISH
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 4-5 7/29/19 8:57 AM

76
TIME: Shown as minutes : seconds. View the time remaining or the time elapsed in your workout.
SPEED: Shown as KM/H. Indicates how fast the foot pads is moving.
CALORIES: Total calories burned or remaining for your workout.
DISTANCE: Shown as KM. Indicates distance traveled or distance remaining during your workout.
INCLINE: Shown as percent.
HEART RATE: Shown as BPM (beats per minute). Used to monitor your heart rate (displayed when contact is made with both pulse grips).
DISPLAYS WINDOW GETTING STARTED
1) Check to make sure no objects are placed on the belt that will hinder the movement of the treadmill.
2) Plug in the power cord and turn the treadmill ON.
3) Stand on the side rails of the treadmill.
4) Attach the safety key clip to part of your clothing making sure that it is secure and will not become detached during operation.
Insert the safety key into the safety keyhole in the console.
5) Select user, U1-U4 using up and down key and press ENTER to confirm
A) QUICK START
Simply press START to begin working out. Time will count up from 0:00.
The speed will default to 0.8 KM. Incline will default to 0%.
B) SELECT A PROGRAM
1) Select a PROGRAM using and press ENTER.
2) Set workout program information using and press ENTER after each selection.
3) Press START to begin workout.
NOTE: You can adjust the speed and incline levels during your workout.
C) FINISHING YOUR WORKOUT
When your workout is complete, your workout information will stay displayed on the console for 30 seconds.
TO CLEAR CURRENT SELECTION
To clear the current program selection or screen, press and hold STOP for 3 seconds.
ENGLISH
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 6-7 7/29/19 8:57 AM

98
PROGRAM INFORMATION
SPRINT 8:The SPRINT 8 program is an anaerobic High Intensity Interval Training program designed to build muscle, improve
speed, and naturally increase the release of Human Growth Hormone (HGH) in your body.
DISTANCE: Push yourself and go further during your workout with five distance workouts. Choose from 1K, 5K, 10K, half
marathon, marathon.
CALORIES: Set goals for burning calories with three workouts. Choose from 300, 500, 700. User sets starting speed and
incline levels. Calories burned are calculated using weight input of user profile.
INTERVALS: An effective fat-burning workout that helps you improves your fitness level. Choose from speed intervals, peak
intervals, endurance intervals.
PERFORMANCE: Include Weight Loss and Gerkin. Promote weight loss by increasing and decreasing the speed and incline,
while keeping you in your fat burning zone. And Gerkin Protocol tests cardiopulmonary health.
STEPS: Promotes healthy activity with 2 step-based workouts calculated using average stride length. Choose from 5000 and
10000 step workouts. User sets starting speed and incline levels.
HEART RATE ZONE INCLUDES TARGET HR, % TARGET HR:
A workout designed to keep you in your specified heart rate zone. This workout requires you to wear a wireless heart rate
strap.
TARGET HEART RATE:
The first step is knowing the right intensity for your training is to find out your maximum heart rate (max HR=220-age). The
age-based method provides an average statistical prediction of your max. HR is a good method for the majority of people.
Take 30 year old person for instance, the max HR is 220 - 30 =190 bpm. So 190 bpm is the target of this program, incline
ranges very automatically based on your heart rate changes during workout.
% TARGET HR:
There are 3 percentage values can be chosen, %55 (weight management and active recovery), %70 (moderately long
workouts) and %85 (fit persons and for athletic training). Target heart rate is calculated by (220-age)*%HR, for example 30
year-old person would like to take the weight management and active recovery (%55), target heart rate is (220-30) * 55% = 105
bmp.
Heart Rate Incline Function Incline Very
20+ under target Increase every 10 seconds 0.50%
6-19 under target Increase every 35 seconds 0.50%
+/- 5 of target No change 0
6-19 over target Decrease every 35 seconds -0.50%
20-24 over target Decrease every 10 seconds -0.50%
25+ over target Program stop Console reset
PROGRAM
P0 P1 P2 P3
MANUAL SPRINT9 DISTANCE CALORIES
P2.1 P2.2 P2.3 P2.4 P3.1 P3.2 P3.3
1K 5K 10K Half Marathon 300K 500K 700K
P4 P5 P6 P7
INTERVALS PERFORMANCE HEART RATE STEPS
P4.1 P4.2 P5.1 P5.2 P6.1 P6.2 P7.1 P7.2
Speed Intervals Peak Intervals Weight Loss Gerkin Target HR %Target HR 5000 10000
P8
AIR TRAIN
P8.1 P8.2 P8.3 P8.4 P8.5 P8.6 P8.7 P8.8 P8.9 P8.10
Beginner Obstacle Challenge 5K (1) 5K (2) 5K (3) 5K (4) 10K (1) 10K (2) 50K
P9
CUSTOM
P9.1 P9.2
Custom 1 Custom 2
ENGLISH
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 8-9 7/29/19 8:57 AM

1110
AIR TRAIN:
Our exclusive design features an air-cell cushion system beneath the deck that inflates along with preprogrammed changes in
speed and incline to simulate different running surfaces. P8.1-P8.3, the level of air-cell cushion is fixed, only speed and incline
are adjustable. The incline range and level of air-cell cushion are fixed of P8.4-P8.10, only speed is adjustable.
P8.1
Mins 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Incline 0 0 1 1 1 0 0 0 1 1 1 1 1 1 1
Firmness 1 1 1 1 2 2 2 2 3 3 3 3 4 4 4
Speed 1 1 2 2 2 3 3 3 4 4 4 5 5 5 5
P8.2
Mins 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Incline 0 0 1 1 2 2 3 3 4 4 4 4 3 3 3
Firmness 3 3 2 2 2 1 1 1 4 4 4 4 1 1 1
Speed 1 1 2 2 5 5 2 2 6 6 3 3 6 6 4
P8.3
Mins 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Incline 1 1 1 2 2 3 4 3 4 5 4 4 5 4 4
Firmness 2 2 2 4 4 4 4 3 3 3 3 1 1 1 1
Speed 1 1 3 3 4 5 6 6 7 7 7 6 6 7 7
P8.4
Distance 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
Incline 1 1 1 1 1 1 1 1 3 3 3 3 5 5 5 5 7 7 7 7 9 9 9 9 7
Firmness 1 1 1 1 1 1 1 1 2 2 2 2 3 3 3 3 3 3 3 3 4 4 4 4 3
Speed 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 6
P8.4
Distance 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
Incline 7 7 7 5 5 5 5 7 7 7 7 7 7 7 7 5 5 5 5 3 3 3 3 1 1
Firmness 3 3 3 3 3 3 3 4 4 4 4 4 4 4 4 2 2 2 2 1 1 1 1 1 1
Speed 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8
P8.5
Distance 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
Incline 1 1 3 3 5 5 2 2 1 4 8 10 12 10 8 4 1 1 1 1 1 1 3 3 5
Firmness 1 1 1 1 1 1 1 1 2 2 2 2 4 4 4 4 4 4 4 4 3 3 3 3 3
Speed 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 6
P8.5
Distance 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
Incline 7 9 9 12 8 4 2 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Firmness 3 3 3 3 3 3 3 4 4 4 4 1 1 1 1 3 3 3 3 3 3 3 3 3 3
Speed 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8
P8.6
Distance 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
Incline 6 6 6 6 6 6 4 4 3 5 5 7 10 10 9 9 8 8 10 10 12 10 8 6 5
Firmness 2 2 2 2 2 2 2 2 1 1 1 1 4 4 4 4 4 4 4 4 4 4 4 4 2
Speed 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 6
P8.6
Distance 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
Incline 5 3 3 1 1 1 1 2 2 4 4 6 6 6 6 6 6 6 6 6 6 6 6 6 6
Firmness 2 2 2 1 1 1 1 1 1 1 1 3 3 3 3 3 3 3 3 3 3 3 3 3 3
Speed 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8
P8.7
Distance 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
Incline 1 1 1 1 2 2 2 2 3 3 3 3 3 4 4 4 5 5 6 6 7 7 7 7 8
Firmness 1 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 4 4 4 4 4 4 4 4 3
Speed 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 6
P8.7
Distance 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
Incline 8 8 8 10 10 10 10 12 10 10 9 9 7 7 7 5 5 5 3 3 3 3 3 3 3
Firmness 3 3 3 3 3 3 3 4 4 4 4 1 1 1 1 3 3 3 3 3 1 1 1 1 1
Speed 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8
P8.8
Distance 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200
Incline 1 3 5 10 12 12 11 11 10 10 10 10 10 10 7 7 7 8 8 8 10 8 6 2 1
Firmness 1 1 1 1 4 4 4 4 4 4 4 4 4 4 4 4 3 3 3 3 4 4 4 4 1
Speed 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 6
P8.8
Distance 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200
Incline 1 1 1 2 2 2 2 3 3 3 3 3 3 3 3 4 4 4 4 3 3 3 3 3 3
Firmness 1 1 1 1 1 1 1 2 2 2 2 2 2 2 2 3 3 3 3 2 2 2 2 2 2
Speed 6 6 6 6 6 6 6 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8
AIR TRAIN TABLE
AIR TRAIN TABLE
ENGLISH
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 10-11 7/29/19 8:57 AM

1312
PROGRAM CHARTSAIR TRAIN TABLE
Speed Intervals - Speed only
Segment Warm Up 1 2 Cool Down
Time 4:00 Mins 90 sec 30 sec 4:00 Mins
Level 1 Speed(MPH) 1 1.5 2 4 1.5 1
Speed(KMH) 1.6 2.4 3.2 6.4 2.4 1.6
Level 2 Speed(MPH) 1 1.5 2 4.5 1.5 1
Speed(KMH) 1.6 2.4 3.2 7.2 2.4 1.6
Level 3 Speed(MPH) 1.3 1.9 2.5 5 1.9 1.3
Speed(KMH) 2 3 4 8 3 2
Level 4 Speed(MPH) 1.3 1.9 2.5 5.5 1.9 1.3
Speed(KMH) 2 3 4 8.8 3 2
Level 5 Speed(MPH) 1.5 2.3 3 6 2.3 1.5
Speed(KMH) 2.4 3.7 4.8 9.6 3.7 2.4
Level 6 Speed(MPH) 1.5 2.3 3 6.5 2.3 1.5
Speed(KMH) 2.4 3.7 4.8 10.4 3.7 2.4
Level 7 Speed(MPH) 1.8 2.6 3.5 7 2.6 1.8
Speed(KMH) 2.8 4.1 5.6 11.2 4.1 2.8
Level 8 Speed(MPH) 1.8 2.6 3.5 7.5 2.6 1.8
Speed(KMH) 2.8 4.1 5.6 12 4.1 2.8
Level 9 Speed(MPH) 2 3 4 8 3 2
Speed(KMH) 3.2 4.8 6.4 12.8 4.8 3.2
Level 10 Speed(MPH) 2 3 4 8.5 3 2
Speed(KMH) 3.2 4.8 6.4 13.6 4.8 3.2
Peak Intervals-Speed and Incline changes
Segment Warm Up 1 2 Cool Down
Time 4:00 Mins 90 sec 30 sec 4:00 Mins
Level 1
Speed(MPH) 1 1.5 2 4 1.5 1
Speed(KMH) 1.6 2.4 3.2 6.4 2.4 1.6
Incline 1 1.5 0.5 1.5 1.5 0
Level 2
Speed(MPH) 1 1.5 2 4.5 1.5 1
Speed(KMH) 1.6 2.4 3.2 7.2 2.4 1.6
Incline 1.5 2.5 3 6.5 2.5 1.5
Level 3
Speed(MPH) 1.3 1.9 2.5 5 1.9 1.3
Speed(KMH) 2 3 4 8 3 2
Incline 2 3 4 7.5 3 2
Level 4
Speed(MPH) 1.3 1.9 2.5 5.5 1.9 1.3
Speed(KMH) 2 3 4 8.8 3 2
Incline 2 3 4 8.5 3 2
Level 5
Speed(MPH) 1.5 2.3 3 6 2.3 1.5
Speed(KMH) 2.4 3.7 4.8 9.6 3.7 2.4
Incline 2.5 3.5 4.5 9 3.5 2.5
Level 6
Speed(MPH) 1.5 2.3 3 6.5 2.3 1.5
Speed(KMH) 2.4 3.7 4.8 10.4 3.7 2.4
Incline 2.5 3.5 4.5 10 3.5 2.5
Level 7
Speed(MPH) 1.8 2.6 3.5 7 2.6 1.8
Speed(KMH) 2.8 4.1 5.6 11.2 4.1 2.8
Incline 2.5 4 5.5 10.5 4 3
Level 8
Speed(MPH) 1.8 2.6 3.5 7.5 2.6 1.8
Speed(KMH) 2.8 4.1 5.6 12 4.1 2.8
Incline 3 4 5.5 11.5 4 3
Level 9
Speed(MPH) 2 3 4 8 3 2
Speed(KMH) 3.2 4.8 6.4 12.8 4.8 3.2
Incline 3 4.5 6 12 5 3
Level 10
Speed(MPH) 2 3 4 8.5 3 2
Speed(KMH) 3.2 4.8 6.4 13.6 4.8 3.2
Incline 3 4.5 6 12 5 3
CUSTOM : Lets you create and reuse a perfect workout for you with specific speed, incline, firmness of cushion and time
combination. The ultimate in personal programming. Time-based goal. Your custom workout will be saved automatically.
P8.9
Distance 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200
Incline 1 3 5 7 10 7 5 3 1 2 3 4 5 5 6 6 7 7 7 8 8 9 10 11 12
Firmness 1 1 1 1 4 4 4 4 4 4 4 4 2 2 2 2 2 2 2 2 3 3 3 3 4
Speed 6 6 6 6 6 6 6 6 7 7 7 7 7 7 7 7 8 8 8 8 8 8 8 8 7
P8.9
Distance 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200 200
Incline 8 4 2 1 1 1 1 1 4 8 10 12 10 8 4 1 1 1 1 1 1 1 1 1 1
Firmness 4 4 4 4 4 4 4 2 2 2 2 4 4 4 4 1 1 1 1 1 1 1 1 1 1
Speed 7 7 7 7 7 7 7 6 6 6 6 8 8 8 8 8 8 8 8 8 8 8 8 8 8
P8.10
Distance 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Incline 1 3 5 7 10 7 5 3 1 3 5 7 10 10 10 10 10 7 5 3 1 2 3 4 5
Firmness 1 1 1 1 3 3 3 3 1 1 1 1 3 3 3 3 3 3 3 3 2 2 2 2 2
Speed 5 5 5 5 6 6 6 6 6 6 6 6 7 7 7 7 6 6 6 6 7 7 7 7 7
P8.10
Distance 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000
Incline 6 7 8 10 10 11 11 12 12 12 12 12 12 11 11 10 7 5 2 1 1 1 1 1 1
Firmness 2 2 2 4 4 4 4 4 4 4 4 4 4 4 4 3 3 3 3 1 1 1 1 1 1
Speed 7 7 7 6 6 6 6 7 7 7 7 7 7 7 7 8 8 8 8 8 8 8 8 8 8
ENGLISH
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 12-13 7/29/19 8:58 AM

1514
PROGRAM CHARTS
Weight Loss - Speed and Incline changes
Segment Warm Up 1 2 3 4 5 6 7 8 Cool Down
Time 4:00 Mins 30 sec 30 sec 30 sec 30 sec 30 sec 30 sec 30 sec 30 sec 4:00 Mins
Level 1
Speed(MPH) 1 1.5 2 2.5 3 3.5 4 3.5 3 2.5 2.3 1.5
Speed(KMH) 1.6 2.4 3.2 4 4.8 5.6 6.4 5.6 4.8 4 3.7 2.4
Incline 0 0.5 1.5 1.5 1 0.5 0.5 0.5 1 1.5 0.5 0
Level 2
Speed(MPH) 1.3 1.9 2.5 3 3.5 4 4.5 4 3.5 3 2.6 1.8
Speed(KMH) 2 3 4 4.8 5.6 6.4 7.2 6.4 5.6 4.8 4.1 2.8
Incline 0 0.5 1.5 1.5 1 0.5 1 0.5 1 1.5 0.5 0
Level 3
Speed(MPH) 1.5 2.3 3 3.5 4 4.5 5 4.5 4 3.5 3 2
Speed(KMH) 2.4 3.7 4.8 5.6 6.4 7.2 8 7.2 6.4 5.6 4.8 3.2
Incline 0.5 1 2 2 1.5 1 1 1 1.5 2 1 0.5
Level 4
Speed(MPH) 1.8 2.6 3.5 4 4.5 5 5.5 5 4.5 4 3.4 2.3
Speed(KMH) 2.8 4.1 5.6 6.4 7.2 8 8.8 8 7.2 6.4 5.4 3.7
Incline 0.5 1 2 2 1.5 1 1 1 1.5 2 1 0.5
Level 5
Speed(MPH) 2 3 4 4.5 5 5.5 6 5.5 5 4.5 3.8 2.5
Speed(KMH) 3.2 4.8 6.4 7.2 8 8.8 9.6 8.8 8 7.2 6.1 4
Incline 1 1.5 2.5 2.5 2 1.5 1.5 1.5 2 2.5 1.5 1
Level 6
Speed(MPH) 2.3 3.4 4.5 5 5.5 6 6.5 6 5.5 5 4.1 2.8
Speed(KMH) 3.7 5.4 7.2 8 8.8 9.6 10.4 9.6 8.8 8 6.5 4.5
Incline 1 1.5 2.5 2.5 2 1.5 1.5 1.5 2 2.5 1.5 1
Level 7
Speed(MPH) 2.5 3.8 5 5.5 6 6.5 7 6.5 6 5.5 4.5 3
Speed(KMH) 4 6.1 8 8.8 9.6 10.4 11.2 10.4 9.6 8.8 7.2 4.8
Incline 1.5 2 3 3 2.5 2 2 2 2.5 3 2 1.5
Level 8
Speed(MPH) 2.8 4.1 5.5 6 6.5 7 7.5 7 6.5 6 4.9 3.3
Speed(KMH) 4.5 6.5 8.8 9.6 10.4 11.2 12 11.2 10.4 9.6 7.8 5.3
Incline 1.5 2 3 3 2.5 2 2 2 2.5 3 2 1.5
Level 9
Speed(MPH) 3 4.5 6 6.5 7 7.5 8 7.5 7 6.5 5.3 3.5
Speed(KMH) 4.8 7.2 9.6 10.4 11.2 12 12.8 12 11.2 10.4 8.5 5.6
Incline 2 2.5 3.5 3.5 3 2.5 2.5 2.5 3 3.5 2.5 2
Level 10
Speed(MPH) 3.3 4.9 6.5 7 7.5 8 8.5 8 7.5 7 5.6 3.8
Speed(KMH) 5.3 7.8 10.4 11.2 12 12.8 13.6 12.8 12 11.2 9 6.1
Incline 2 2.5 3.5 3.5 3 2.5 2.5 2.5 3 3.5 2.5 2
SPTINT 8
Time 180 (Warm up) 30 90 30 90 30 90 30 90 30 90 30 90 30 90 30 150 (Cool Down)
Level 1 Speed(MPH) 0.5 3.2 1.5 3.2 1.5 3.5 1.5 3.5 1.5 3.7 1.5 3.7 1.5 3.7 1.5 3.7 1.5
Speed(KMH) 0.8 5.1 2.4 5.1 2.4 5.6 2.4 5.6 2.4 5.9 2.4 5.9 2.4 5.9 2.4 5.9 2.4
Incline 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0
Level 2 Speed(MPH) 0.5 3.7 1.5 3.7 1.5 4 1.5 4 1.5 4.2 1.5 4.2 1.5 4.2 1.5 4.2 1.5
Speed(KMH) 0.8 5.9 2.4 5.9 2.4 6.4 2.4 6.4 2.4 6.7 2.4 6.7 2.4 6.7 2.4 6.7 2.4
Incline 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0
Level 3 Speed(MPH) 0.5 4.2 1.5 4.2 1.5 4.4 1.5 4.4 1.5 4.6 1.5 4.6 1.5 4.6 1.5 4.6 1.5
Speed(KMH) 0.8 6.7 2.4 6.7 2.4 7 2.4 7 2.4 7.4 2.4 7.4 2.4 7.4 2.4 7.4 2.4
Incline 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0
Level 6 Speed(MPH) 0.5 4.6 1.5 4.6 1.5 4.8 1.5 4.8 1.5 5 1.5 5 1.5 5 1.5 5 1.5
Speed(KMH) 0.8 7.4 2.4 7.4 2.4 7.7 2.4 7.7 2.4 8 2.4 8 2.4 8 2.4 8 2.4
Incline 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0
Level 5 Speed(MPH) 0.5 4.9 1.5 4.9 1.5 5.1 1.5 5.1 1.5 5.3 1.5 5.3 1.5 5.3 1.5 5.3 1.5
Speed(KMH) 0.8 7.8 2.4 7.8 2.4 8.2 2.4 8.2 2.4 8.5 2.4 8.5 2.4 8.5 2.4 8.5 2.4
Incline 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0 3 0
Level 6 Speed(MPH) 0.5 5 2 5 2 5.2 2 5.2 2 5.5 2 5.5 2 5.5 2 5.5 2
Speed(KMH) 0.8 8 3.2 8 3.2 8.3 3.2 8.3 3.2 8.8 3.2 8.8 3.2 8.8 3.2 8.8 3.2
Incline 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0
Level 7 Speed(MPH) 0.5 5.3 2 5.3 2 5.5 2 5.5 2 5.8 2 5.8 2 5.8 2 5.8 2
Speed(KMH) 0.8 8.5 3.2 8.5 3.2 8.8 3.2 8.8 3.2 9.3 3.2 9.3 3.2 9.3 3.2 9.3 3.2
Incline 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0
Level 8 Speed(MPH) 0.5 5.8 2 5.8 2 6 2 6 2 6.3 2 6.3 2 6.3 2 6.3 2
Speed(KMH) 0.8 9.3 3.2 9.3 3.2 9.6 3.2 9.6 3.2 10.1 3.2 10.1 3.2 10.1 3.2 10.1 3.2
Incline 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0
Level 9 Speed(MPH) 0.5 6 2 6 2 6.3 2 6.3 2 6.5 2 6.5 2 6.5 2 6.5 2
Speed(KMH) 0.8 9.6 3.2 9.6 3.2 10.1 3.2 10.1 3.2 10.4 3.2 10.4 3.2 10.4 3.2 10.4 3.2
Incline 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0
Level 10 Speed(MPH) 0.5 6.5 2 6.5 2 6.7 2 6.7 2 7 2 7 2 7 2 7 2
Speed(KMH) 0.8 10.4 3.2 10.4 3.2 10.7 3.2 10.7 3.2 11.2 3.2 11.2 3.2 11.2 3.2 11.2 3.2
Incline 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0 4 0
Level 11 Speed(MPH) 0.5 7 2.5 7 2.5 7.2 2.5 7.2 2.5 7.5 2.5 7.5 2.5 7.5 2.5 7.5 2.5 Speed(KMH) 0.8 11.2 4 11.2 4 11.5 4 11.5 4 12 4 12 4 12 4 12 4
Incline 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0
Level 12 Speed(MPH) 0.5 7.5 2.5 7.5 2.5 7.7 2.5 7.7 2.5 8 2.5 8 2.5 8 2.5 8 2.5 Speed(KMH) 0.8 12 4 12 4 12.3 4 12.3 4 12.8 4 12.8 4 12.8 4 12.8 4
Incline 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0
Level 13 Speed(MPH) 0.5 8 2.5 8 2.5 8.2 2.5 8.2 2.5 8.5 2.5 8.5 2.5 8.5 2.5 8.5 2.5 Speed(KMH) 0.8 12.8 4 12.8 4 13.1 4 13.1 4 13.6 4 13.6 4 13.6 4 13.6 4
Incline 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0
Level 14 Speed(MPH) 0.5 8.5 2.5 8.5 2.5 8.7 2.5 8.7 2.5 9 2.5 9 2.5 9 2.5 9 2.5 Speed(KMH) 0.8 13.6 4 13.6 4 13.9 4 13.9 4 14.4 4 14.4 4 14.4 4 14.4 4
Incline 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0
Level 15 Speed(MPH) 0.5 9 2.5 9 2.5 9.2 2.5 9.2 2.5 9.5 2.5 9.5 2.5 9.5 2.5 9.5 2.5 Speed(KMH) 0.8 14.4 4 14.4 4 14.7 4 14.7 4 15.2 4 15.2 4 15.2 4 15.2 4
Incline 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0 5 0
Level 16 Speed(MPH) 0.5 9.5 3 9.5 3 9.7 3 9.7 3 10 3 10 3 10 3 10 3 Speed(KMH) 0.8 15.2 4.8 15.2 4.8 15.5 4.8 15.5 4.8 16 4.8 16 4.8 16 4.8 16 4.8
Incline 0 6 1 6 1 6 1 6 1 6 1 6 1 6 1 6 1
Level 17 Speed(MPH) 0.5 10 3 10 3 10.2 3 10.2 3 10.5 3 10.5 3 10.5 3 10.5 3 Speed(KMH) 0.8 16 4.8 16 4.8 16.3 4.8 16.3 4.8 16.8 4.8 16.8 4.8 16.8 4.8 16.8 4.8
Incline 0 6 1 6 1 6 1 6 1 6 1 6 1 6 1 6 1
Level 18 Speed(MPH) 0.5 10.5 3 10.5 3 10.7 3 10.7 3 11 3 11 3 11 3 11 3 Speed(KMH) 0.8 16.8 4.8 16.8 4.8 17.1 4.8 17.1 4.8 17.6 4.8 17.6 4.8 17.6 4.8 17.6 4.8
Incline 0 6 1 6 1 6 1 6 1 6 1 6 1 6 1 6 1
Level 19 Speed(MPH) 0.5 11 3 11 3 11.2 3 11.2 3 11.5 3 11.5 3 11.5 3 11.5 3 Speed(KMH) 0.8 17.6 4.8 17.6 4.8 17.9 4.8 17.9 4.8 18.4 4.8 18.4 4.8 18.4 4.8 18.4 4.8
Incline 0 6 2 6 2 6 2 6 2 6 2 6 2 6 2 6 2
Level 20 Speed(MPH) 0.5 11.5 6 11.5 6 11.7 6 11.7 6 12 6 12 6 12 6 12 6
Speed(KMH) 0.8 18.4 9.6 18.4 9.6 18.7 9.6 18.7 9.6 19.2 9.6 19.2 9.6 19.2 9.6 19.2 9.6
Incline 0 6 2 6 2 6 2 6 2 6 2 6 2 6 2 6 2
ENGLISH
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 14-15 7/29/19 8:58 AM

1716
Gerkin Scoring
Males: Females:
VO2 max (ml/kg/min) VO2 max (ml/kg/min)
Age Age
Percentile 20-29 30-39 40-49 50-59 Percentile 20-29 30-39 40-49 50-59
SUPERIOR
99 >58.8 >58.9 >55.4 >52.5 99 >53.0 >48.7 >46.8 >42.0
95 54.0 52.5 50.4 47.1 95 46.8 43.9 41.0 36.8
EXCELLENT
90 53.9 52.4 50.3 47.0 90 46.7 43.8 40.9 36.7
80 48.2 46.8 44.1 41.0 80 41.0 38.6 36.3 32.3
GOOD
70 48.1 46.7 44.0 40.9 70 40.9 38.5 36.2 32.2
60 44.2 42.4 39.9 36.7 60 36.7 34.6 32.3 29.4
FAIR
50 44.1 42.3 39.8 36.6 50 36.6 34.5 32.2 29.3
40 41.0 38.9 36.7 33.8 40 33.8 32.3 29.5 26.9
POOR
30 40.9 38.8 36.6 33.7 30 33.7 32.2 29.4 26.8
20 37.1 35.4 33.0 30.2 20 30.6 28.7 26.5 24.3
VERY POOR
10 37.0 35.3 32.9 30.1 10 30.5 28.6 26.4 24.2
5 31.6 30.9 28.3 25.1 5 25.9 25.1 23.5 21.1
PROGRAM CHARTS
Conversion Table for Gerkin Protocol
Stage Total Time Predicted VO2 max ml/kg/min Speed (mph) % Grade
0 (warm-up)
0:00 - 0:30 13.3 1.0 0.0
0:30 - 1:00 13.3 1.5 0.0
1:30 - 2:00 13.3 2.0 0.0
2:00 - 2:30 13.3 2.5 0.0
2:30 - 3:00 13.3 3.0 0.0
13:00 - 3:30 15.3 4.5 0.0
3:30 - 4:00 17.4
24:00 - 4:30 19.4 4.5 2.0
4:30 - 5:00 21.5
35:00 - 5:30 23.6 5.0 2.0
5:30 - 6:00 27.6
46:00 - 6:30 28.7 5.0 4.0
6:30 - 7:00 29.8
57:00 - 7:30 31.2 5.5 4.0
7:30 - 8:00 32.7
68:00 - 8:30 33.9 5.5 6.0
8:30 - 9:00 35.1
79:00 - 9:30 36.6 6.0 6.0
9:30 - 10:00 38.2
810:00 - 10:30 39.5 6.0 8.0
10:30 - 11:00 40.9
911:00 - 11:30 42.6 6.5 8.0
11:30 - 12:00 44.3
10 12:00 - 12:30 45.7 6.5 10.0
12:30 - 13:00 47.2
11 13:00 - 13:30 49.0 7.0 10.0
13:30 - 14:00 50.8
12 14:00 - 14:30 52.3 7.0 12.0
14:30 - 15:00 53.9
13 15:00 - 15:30 55.8 7.5 12.0
15:30 - 16:00 57.8
14 16:00 - 16:30 59.5 7.5 14.0
16:30 - 17:00 61.2
15 17:00-17:30 63.2 8.0 14.0
17:30-18:00 65.3
16 18:00-18:30 67.1 8.0 16.0
18:30-19:00 68.9
17 19:00-19:30 71.1 8.5 16.0
19:00-19:30 71.1
ENGLISH
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 16-17 7/29/19 8:58 AM

1918
APP CONNECTION (if supported)
FitDisplay
FitDisplay will enable you to control your treadmill’s operating functions via your device.
Kinomap
Kinomap turns your bike trainer, exercise bike, treadmill or rowing machine into a powerful and fun fitness device.
www.kinomap.com
Zwift
Zwift is an at home training app connecting cyclists around the world.
www.zwift.com
Download from App Store for IOS or from Google Play for Android.
You can find more Horizon machine compatible apps on Horizon website.
ENERGY SAVER (STANDBY MODE)
This machine has a special feature called Energy Saver mode. This mode is NOT automatically activated. When Energy Saver mode
is activated, the display will automatically enter standby mode (Energy Saver mode) after 15 minutes of inactivity. This feature saves
energy by disabling most power to the machine until a key is pressed on the console.
CODE TIME ZONE TIME
36 Greenwich Standard Time (GMT) Casablanca, Monrovia
34 GMT Standard Time (GMT) Greenwich Mean Time : Dublin, Edinburgh, Lisbon, London
75 W. Europe Standard Time (GMT+01:00) Amsterdam, Berlin, Bern, Rome, Stockholm, Vienna
18 Central Europe Standard Time (GMT+01:00) Belgrade, Bratislava, Budapest, Ljubljana, Prague
56 Romance Standard Time (GMT+01:00) Brussels, Copenhagen, Madrid, Paris
19 Central European Standard Time (GMT+01:00) Sarajevo, Skopje, Warsaw, Zagreb
74 W. Central Africa Standard Time (GMT+01:00) West Central Africa
37 GTB Standard Time (GMT+02:00) Athens, Bucharest, Istanbul
29 Egypt Standard Time (GMT+02:00) Cairo
64 South Africa Standard Time (GMT+02:00) Harare, Pretoria
32 FLE Standard Time (GMT+02:00) Helsinki, Kiev, Riga, Sofia, Tallinn, Vilnius
41 Israel Standard Time (GMT+02:00) Jerusalem
26 E. Europe Standard Time (GMT+02:00) Minsk
48 Namibia Standard Time (GMT+02:00) Windhoek
05 Arabic Standard Time (GMT+03:00) Baghdad
03 Arab Standard Time (GMT+03:00) Kuwait, Riyadh
57 Russian Standard Time (GMT+03:00) Moscow, St. Petersburg, Volgograd
24 E. Africa Standard Time (GMT+03:00) Nairobi
40 Iran Standard Time (GMT+03:30) Tehran
04 Arabian Standard Time (GMT+04:00) Abu Dhabi, Muscat
09 Azerbaijan Standard Time (GMT+04:00) Baku
33 Georgian Standard Time (GMT+04:00) Tblisi
13 Caucasus Standard Time (GMT+04:00) Yerevan
01 Afghanistan Standard Time (GMT+04:30) Kabul
30 Ekaterinburg Standard Time (GMT+05:00) Ekaterinburg
CODE TIME ZONE TIME
10 Azores Standard Time (GMT-01:00) Azores
12 Cape Verde Standard Time (GMT-01:00) Cape Verde Islands
43 Mid-Atlantic Standard Time (GMT-02:00) Mid-Atlantic
27 E. South America Standard Time (GMT-03:00) Brasilia
58 SA Eastern Standard Time (GMT-03:00) Buenos Aires, Georgetown
35 Greenland Standard Time (GMT-03:00) Greenland
51 Newfoundland Standard Time (GMT-03:30) Newfoundland and Labrador
06 Atlantic Standard Time (GMT-04:00) Atlantic Time (Canada)
60 SA Western Standard Time (GMT-04:00) Caracas, La Paz
17 Central Brazilian Standard Time (GMT-04:00) Manaus
54 Pacific SA Standard Time (GMT-04:00) Santiago
59 SA Pacific Standard Time (GMT-05:00) Bogota, Lima, Quito
28 Eastern Standard Time (GMT-05:00) Eastern Time (US and Canada)
70 US Eastern Standard Time (GMT-05:00) Indiana (East)
15 Central America Standard Time (GMT-06:00) Central America
21 Central Standard Time (GMT-06:00) Central Time (US and Canada)
22 Central Standard Time (Mexico) (GMT-06:00) Guadalajara, Mexico City, Monterrey
11 Canada Central Standard Time (GMT-06:00) Saskatchewan
71 US Mountain Standard Time (GMT-07:00) Arizona
45 Mountain Standard Time (Mexico) (GMT-07:00) Chihuahua, La Paz, Mazatlan
44 Mountain Standard Time (GMT-07:00) Mountain Time (US and Canada)
55 Pacific Standard Time (GMT-08:00) Pacific Time (US and Canada); Tijuana
02 Alaskan Standard Time (GMT-09:00) Alaska
38 Hawaiian Standard Time (GMT-10:00) Hawaii
61 Samoa Standard Time (GMT-11:00) Midway Island, Samoa
TIME ZONE LIST
ENGLISH
ENGLISH
HZ19_OG_Paragon X v1_1_D.indd 18-19 7/29/19 8:58 AM

20
CODE TIME ZONE TIME
76 West Asia Standard Time (GMT+05:00) Islamabad, Karachi, Tashkent
39 India Standard Time (GMT+05:30) Chennai, Kolkata, Mumbai, New Delhi
49 Nepal Standard Time (GMT+05:45) Kathmandu
47 N. Central Asia Standard Time (GMT+06:00) Almaty, Novosibirsk
16 Central Asia Standard Time (GMT+06:00) Astana, Dhaka
65 Sri Lanka Standard Time (GMT+06:00) Sri Jayawardenepura
46 Myanmar Standard Time (GMT+06:30) Yangon (Rangoon)
62 SE Asia Standard Time (GMT+07:00) Bangkok, Hanoi, Jakarta
53 North Asia Standard Time (GMT+07:00) Krasnoyarsk
23 China Standard Time (GMT+08:00) Beijing, Chongqing, Hong Kong SAR, Urumqi
52 North Asia East Standard Time (GMT+08:00) Irkutsk, Ulaanbaatar
63 Singapore Standard Time (GMT+08:00) Kuala Lumpur, Singapore
73 W. Australia Standard Time (GMT+08:00) Perth
66 Taipei Standard Time (GMT+08:00) Taipei
68 Tokyo Standard Time (GMT+09:00) Osaka, Sapporo, Tokyo
42 Korea Standard Time (GMT+09:00) Seoul
78 Yakutsk Standard Time (GMT+09:00) Yakutsk
14 Cen. Australia Standard Time (GMT+09:30) Adelaide
07 AUS Central Standard Time (GMT+09:30) Darwin
25 E. Australia Standard Time (GMT+10:00) Brisbane
08 AUS Eastern Standard Time (GMT+10:00) Canberra, Melbourne, Sydney
77 West Pacific Standard Time (GMT+10:00) Guam, Port Moresby
67 Tasmania Standard Time (GMT+10:00) Hobart
72 Vladivostok Standard Time (GMT+10:00) Vladivostok
20 Central Pacific Standard Time (GMT+11:00) Magadan, Solomon Islands, New Caledonia
CODE TIME ZONE TIME
50 New Zealand Standard Time (GMT+12:00) Auckland, Wellington
31 Fiji Standard Time (GMT+12:00) Fiji Islands, Kamchatka, Marshall Islands
69 Tonga Standard Time (GMT+13:00) Nuku'alofa
TIME ZONE LIST
Traitement des déchets
Les produits VISION Fitness / HORIZON Fitness /
TEMPO Fitness / TREO Fitness sont recyclables.
À la fin de sa vie utile, veuillez vous débarrasser
de cet article correctement et en toute sécurité
(déchetteries locales).
HZ19_OG_Paragon X v1_1_D.indd 20-21 7/29/19 8:58 AM

HZ19_OG_Paragon X v1_1_D.indd 22-23 7/29/19 8:58 AM

Horizon Paragon X | Rev. 1.1 D ©2019 Johnson Health Tech
Made in China
OPERATION GUIDE
HZ19_OG_Paragon X v1_1_D.indd 24 7/29/19 8:58 AM
