HPRT HM-E200 Owner's manual

1
Mobile Printer
HM-E200
Programming Manual
Xiamen Hanin Electronic Technology Co.,Ltd.
ADD：
Room 305A,Angye Building, Pioneering Park,
Torch High-tech Zone, Xiamen, China 361009
Tel.：
[phone]
Fax：
[phone]
Web:
www.hprt.com

HM-E200 Programming Manual
2
REVISION RECORDS
REV.
DATE
DESCRIPTION
Drawn
Checked
Approved
1.0
2016.12.23
——
Wu zhenrong
Yang kaiqu
Lin yang

HM-E200 Programming Manual
3
Table of Contents
1. Overview.................................................................................................................................................................... 1
1.1 Key terms......................................................................................................................................................... 1
1.2 Command notation..........................................................................................................................................1
2. Printing command set................................................................................................................................................2
HT.......................................................................................................................................................................... 2
LF............................................................................................................................................................................2
FF............................................................................................................................................................................2
CAN........................................................................................................................................................................ 3
DLE EOT n...............................................................................................................................................................3
ESC SP n..................................................................................................................................................................5
ESC ! n.................................................................................................................................................................... 5
ESC $ nL nH............................................................................................................................................................ 6
ESC % n...................................................................................................................................................................6
ESC & y c1 c2 [x1 d1...d(y × x1)]...[xk d1...d(y × xk)].............................................................................................. 6
ESC * m nL nH d1... dk.......................................................................................................................................... 7
ESC - n.................................................................................................................................................................. 10
ESC 2.................................................................................................................................................................... 10
ESC 3 n................................................................................................................................................................. 10
ESC = n................................................................................................................................................................. 11
ESC ? n..................................................................................................................................................................11
ESC @...................................................................................................................................................................11
ESC D n1...nk NUL................................................................................................................................................ 11
ESC E n..................................................................................................................................................................12
ESC G n................................................................................................................................................................. 12
ESC J n.................................................................................................................................................................. 12
ESC M n................................................................................................................................................................ 13
ESC R n (It just allows to use on machines that provide international Characters)............................................ 13
ESC T n................................................................................................................................................................14
ESC V n............................................................................................................................................................... 14
ESC W xL xH yL yH dxL dxH dyL dyH.................................................................................................................... 15
ESC \ nL nH...........................................................................................................................................................16
ESC a n................................................................................................................................................................ 16
ESC d n................................................................................................................................................................. 17
ESC t n.................................................................................................................................................................. 17
ESC v...................................................................................................................................................................18
ESC { n................................................................................................................................................................ 19
FS p n m...............................................................................................................................................................19
FS q n [xL xH yL yH d1...dk]1...[xL xH yL yH d1...dk]n..................................................................................... 20
GS ! n...................................................................................................................................................................22
GS $ nL nH..........................................................................................................................................................23
GS * x y d1...d(x × y × 8).......................................................................................................................................24
GS / m.................................................................................................................................................................. 25
GS B n..................................................................................................................................................................25
GS H n................................................................................................................................................................. 26
GS L nL nH............................................................................................................................................................ 26
GS W nL nH.......................................................................................................................................................... 27
GS \ nL nH...........................................................................................................................................................27
GS a n.................................................................................................................................................................. 28
GS f n...................................................................................................................................................................28
GS h n...................................................................................................................................................................28
①GS k m d1 d2 …dk NUL②GS k m n d1 d2 … dn............................................................................................. 29
GS r n....................................................................................................................................................................29
GS v 0 m xL xH yL yH d1....dk............................................................................................................................... 30
GS w n.................................................................................................................................................................. 31
GS ‘....................................................................................................................................................................... 32
GS “...................................................................................................................................................................... 34

HM-E200 Programming Manual
4
3. Multi-byte code characters commands list....................................................................................................... 35
FS! n..................................................................................................................................................................... 35
FS &...................................................................................................................................................................... 36
FS .........................................................................................................................................................................36
FS S n1 n2.............................................................................................................................................................37
FS 2 c1 c2 d1...dk................................................................................................................................................. 37
FS W n.................................................................................................................................................................. 38
GS ( k pL p H cn fn n (cn = 48, fn = 65).............................................................................................................38
GS ( k pL p H cn fn n (cn = 48, fn = 66)............................................................................................................. 39
GS ( k pL p H cn fn n (cn = 48, fn = 67)............................................................................................................. 39
GS ( k pL p H cn fn n (cn = 48, fn = 68).............................................................................................................39
GS ( k pL p H cn fn m n (cn = 48, fn = 69)........................................................................................................ 40
GS ( k pL p H cn fn m (cn = 48, fn = 70)............................................................................................................ 41
GS ( k pL p H cn fn m d1 …dk (cn = 48, fn = 80)................................................................................................41
GS ( k pL p H cn fn m (cn = 48, fn = 81)........................................................................................................... 41
GS ( k p L p H cn fn m (cn = 48, fn = 82)..........................................................................................................42
GS ( k pL pH cn fn n (cn = 49, fn = 67)................................................................................................................. 42
GS ( k pL pH cn fn n (cn = 49, fn = 69)................................................................................................................. 42
GS ( k pL pH cn fn m d1…dk (cn = 49, fn = 80).................................................................................................... 43
GS ( k pL pH cn fn m (cn = 49, fn = 81)................................................................................................................43
4. Programming Process Guide................................................................................................................................... 44
Appendix...................................................................................................................................................................... 44
Appendix A: Code128 Bar Code...........................................................................................................................44
A.1 Description of the CODE128 Bar Code.......................................................................................................... 44
B.1 General Description.......................................................................................................................................48
B.2 Setting Values in Standard and Page Modes.................................................................................................48
B.3 Formatting of Print Data in the Printable Area............................................................................................. 48

HM-E200 Programming Manual
1
1. Overview
1.1 Key terms
Real-time commands:These commands are act ed on immediately upon being received by the printer ;
Page mode:Under this mode, the printer stores all data in a specified memory and thinks of this as a virtual page.
The page is printed when the printer receives print command either FF or ESC FF;
Standard mode:Standard mode is the default mode of printer, namely line mode. Under this mode, the printer
prints data and feeds paper upon print line buffer full (data is enough for one print line) or receiving print
command like LF;
HRI character:Barcode note character. Human Readable Interface;
NV:Non-volatile memory in which data stored does not loss when powered off. NV: Non- volatile;
RAM :Random Access Memory;
ASB：Auto Send Back
DPI: Print dots per inch (one inch equals to 25.4mm). It is us ed to identify the resolution of a printer.
Example, 203DPI means 203 print dots per inch. DPI: Dot Per Inch
1.2 Command notation
[Name] The name of the command.
[Format] The code sequence.
[ ]k indicates the contents in brackets [ ] should be repeated k times.
[Range] Gives the allowable ranges, if any, for the command parameters.
[Default] Gives the default values, if any, for the arguments.
[Description] Describes the function of the command.
” − “ in the table indicates 0 or 1.
[Notes] Provides important information on setting and using the printer command, if necessary.
[Reference] Gives references, if any.

HM-E200 Programming Manual
2
2. Printing command set
HT
[Name] Horizontal tab
[Format] ASCII HT
Hex 09
Decimal 9
[Dscription] Moves the print position to the next horizontal tab position.
[Notes] • This command is ignored unless the next horizontal tab position has been set.
• If the next horizontal tab position exceeds the printing area, the printer sets
the printing position to [printing area width + 1].
• Horizontal tab positions are set with ESC D.
• If this command is received when the printing position is at [printing area width+ 1],
the printer executes print buffer-full printing of the current line and horizontal tab
processing from the beginning of the next line.
• Set Horizontal tab default to 8 character width of character ASCII (12×24).
• When the print buffer is full，the printer performs the following actions：
In standard mode，the printer prints the current line and sets the print position to
the beginning of the line.
In page mode, the printer sets the print position to the beginning of the line.
LF
[Name] Print the contents in the print buffer
[Format] ASCII LF Hex
0A
Decimal 10
[Description] Prints the data in the print buffer and feeds one line, based on the current line spacing
[Notes] • This command sets the print position to the beginning of the line.
•When this command is processed in page mode, only the print position moves, and
the printer does not perform actual printing.
FF
[Name] Print and feed the paper to the next page
[Format] ASCII FF
Hex OC
Decimal 12
[Description ] Paper type is continuous paper :
• In page mode, prints all the data in the print buffer collectively and switches from
page mode to standard mode.
• This command is equivalent to LF in standard mode.
• This command returns the values set by ESC W to the default values.
Paper type is marked paper :
• In page mode, prints all the data in the print buffer,not to return to standard
mode ,not clear the data in the print buffer. The printer feeds the marked paper to
the next print starting position after finished printing.Don’t change horizontal and
vertical coordinates in the print buffer.
[Notes] • This command sets the print position to the beginning of the line.

HM-E200 Programming Manual
3
CAN
[Name] Cancel print data in page mode
[Format] ASCII CAN
Hex 18
Decimal 24
[Description] Delete all the print data for the current print job in page mode.
[Note] • This command is effective only in the page mode.
•If the regional set up previously overlaped with the current area, the overlap will
be deleted.
DLE EOT n
[Name] Real-time status transmission
[Format] ASCII DLE EOT n
Hex 10 04 n
Decimal 16 4 n
[Range] 1 ≤ n ≤ 4
[Description] nindicates the status function as follows:
n =1, transmit printer status
n =2, transmit printer status
n =3, transmit printer status
n =4, transmit paper sensor status
[Note] 1) Printer back to required status when received the command
2) Don’t put this command into command sequence which is with 2 Byte or more.
3) Even printer is prohibited by command ESC = (choose peripherals), this command
is effective
4) Printer transmitting current status, 1 byte stands for each status
5) Printer transmission value can make sure whether host computer receive or not
6) This command is executed once received by printer
7) This command is only effective with a serial interface mode. When received it, printer
execute it under any situation.
n = 1 Printer status
Bit
0/1
HEX
Decim
al
Function
0
0
00
0
Default 0
1
1
02
2
Default 0
2
0
00
0
Default 0
3
0
00
0
on-line
1
08
8
off-line
4
1
10
16
Default 0
5
0
00
0
Default 0
6
0
00
0
Printer normal status
1
40
64
Printer abnormal status
7
0
00
0
Default 0

HM-E200 Programming Manual
4
n = 2 Printer status
Bit
0/1
HEX
Decim
al
Function
0
0
00
0
Default 0
1
1
02
2
Default 1
2
0
00
0
Up cover closed
1
04
4
Up cover open
3
0
00
0
feed paper without push
1
08
8
feed paper with push
4
1
10
16
Default 1
5
0
00
0
Default 0
6
0
00
0
Printer normal status
1
40
64
Printer abnormal status
7
0
00
0
Default 0
n = 3 Printer status
Bit
0/1
HEX
Decim
al
Function
0
0
00
0
Default 0
1
1
02
2
Default 1
2
1
04
4
Default 0
3
0
00
0
Default 0
4
1
10
16
Default 1
5
0
00
0
Up cover closed
1
20
00
Up cover open
6
0
00
0
Thermal head temperature
1
40
64
Thermal head temperature
7
0
00
0
Default 0
n = 4 Printer status
Bit
1/0
HEX
Decim
al
Function
0
0
00
0
Default 0
1
1
02
2
Default 1
2,
3
0
00
0
Paper sensor test no paper
1
0C
12
Paper sensor test paper
4
1
10
16
Default 1
5,
6
0
00
0
With Paper
1
60
96
Paper end
7
0
00
0
Default 0

HM-E200 Programming Manual
5
ESC SP n
[Name] Set character spacing
[Format] ASCII ESC SP n
Hex 1B 20 n
Decimal 27 32 n
[Range] 0 ≤ n≤255
[Description] Sets the right-side character spacing to [n×0.125mm(n×0.0049 inch)]。
[Notes] •When characters are enlarged, the character spacing is n times normal value.
• This command sets values independently in each mode (standard and page
modes).
[Default] n = 0
ESC ! n
[Name] Select print mode(s)
[Format] ASCII ESC ! n
Hex 1B 21 n
Decimal 27 33 n
[Range] 0 ≤ n ≤ 255
[Description] Selects print mode(s) using n as follows:
[Notes] •When both double-height and double-width modes are selected, quadruple-size
characters are printed.
•The printer can underline all characters, but cannot underline the space set by
HT or 90clockwise rotated characters.
•The thickness of the underline is that selected by ESC , regardless of the character
size.
•When some characters in a line are double or more height, all the characters in the
line are aligned at the baseline.
•ESC E can also turn on or off emphasized mode. However, the setting of the last
received command is effective.
•ESC G print effect is the same with emphasized mode. However, the setting of the
last received command is effective.
•ESC can also turn on or off underline mode. However, the setting of the last
received command is effective.
•GS ! can also select character size. However, the setting of the last received
command is effective.
[Default] n = 0
Bit
1/0
HEX
Decimal
Function
0
0
00
0
Character font 0 selected.
1
01
1
Character font 1 selected.
1,2
Undefined.
3
0
00
0
Emphasized mode not selected.
1
08
8
Emphasized mode selected.
4
0
00
0
Double-height mode not selected.
1
10
16
Double-height mode selected.
5
0
00
0
Double-width mode not selected.
1
20
32
Double-width mode selected.
6
Undefined.
7
0
00
0
Underline mode not selected.
1
80
128
Underline mode selected.

HM-E200 Programming Manual
6
ESC $ nL nH
[Name] Set absolute print position
[Format] ASCII ESC $ nL nH
Hex 1B 24 nL nH Decimal
27 36 nL nH
[Range] 0≤nL ≤ 255
0 ≤nH≤255
[Description] The distance from the beginning of the line to the print position is
[(nL + nH ×256) ×0.125 mm].
[Notes] •Settings outside the specified printable area are ignored.
•ESC W can set horizontal starting position in page modes. However, the setting of
the last received command is effective.
ESC % n
[Name] Select/cancel user-defined character set
[Format] ASCII ESC % n
Hex 1B 25 n
Decimal 27 37 n
[Range] 0 ≤ n ≤255
[Description] Selects or cancels the user-defined character set.
•When the LSB of n is 0, the user-defined character set is canceled.
•When the LSB of n is 1, the user-defined character set is selected.
[Notes] •When the user-defined character set is canceled, the built-in character set is
automatically selected.
•n is available only for the least significant bit.
[Default] n = 0
ESC & y c1 c2 [x1 d1...d(y × x1)]...[xk d1...d(y × xk)]
[Name] Define user-defined characters
[Format] ASCII ESC & y c1 c2 [x1 d1...d(y × x1)]...[xk d1...d(y × xk)]
Hex 1B 26 y c1 c2 [x1 d1...d(y × x1)]...[xk d1...d(y × xk)]
Decimal 27 38 y c1 c2 [x1 d1...d(y × x1)]...[xk d1...d(y × xk)]
[Range] y = 3
32 ≤ c1 ≤ c2 ≤ 127
1 ≤ < x ≤ 24
0 ≤ d1 ... d(y × xk) ≤ 255
[Description] Defines user-defined characters.
•y specifies the number of bytes in the vertical direction.
•c1 specifies the beginning character code for the definition, and c2 specifies the
final code.
•x specifies the number of dots in the horizontal direction.
[Notes] •The allowable character code range is from ASCII code <20>H to <7E>H .
•It is possible to define multiple characters for consecutive character codes.
If only one character is desired, use c1 = c2.
•d is the dot data for the characters. The dot pattern is in the horizontal direction from
the left side.
•The data to define user-defined characters is (y × x) bytes.
• When x is less than 13, the user-defined character width by default into 13 points.
•Set a corresponding bit to 1 to print a dot or 0 not to print a dot.
• Can define up to 26 user-defined characters.

HM-E200 Programming Manual
7
•The user-defined character definition is cleared when:
①ESC ? is executed.
②The power is turned off.
[Default] The internal character set
[Example]
ESC * m nL nH d1... dk
[Name] Select bit-image mode
[Format] ASCII ESC * m nL nH d1...dk
Hex 1B 2A m nL nH d1...dk
Decimal 27 42 m nL nH d1...dk
[Range] m = 0, 1, 32, 33
0 ≤ nL ≤ 255
0 ≤ nH ≤ 3
0 ≤ d ≤255
[Description] Select a bit-image mode using m, bit-image dot is decided by nL and nH.
m
Mode
Vertical Direction
Horizontal Direction
Number of
Bits for
vertical data
Dot
Density
(DPI)
Dot
Density
(DPI)
Amount of Data(k)
0
8-dot single-density
8
67
DPI
101
DPI
nL + nH ×256
1
8-dot double-density
8
67
DPI
203
DPI
nL + nH ×256
32
24-dot single-density
24
203
DPI
101
DPI
( nL + nH ×256) ×3
33
24-dot double-density
24
203
DP
203
DPI
( nL + nH ×256) ×3
[Note] • If the value of m out of the specified range, nL and the subsequent data will be

HM-E200 Programming Manual
8
processed as normal one.
•The number of horizontal direction is up to nL and nH, the total number is nL + nH ×
256.
• The part which bit-image is beyond the current area will be amputated.
• d indicates the bit image data. Set a bit to 1 to print a dot, or set a bit to 0 to not print a
dot.
• After the bit-image is sent successfully, the printer will be back to the normal data
processing mode.
• If the width printing area set by GSL and GSW lee than the printing width of GS /
required by the data sent with the ESC* command, the following will be performed
on the line in question (but the printing cannot exceed the maximum printable area):
①The width of the printing area is extended to the right to accommodate the amount
of data.
②If step ¬ does not provide sufficient width for the data, the left margin is reduced to
accommodate the data. For each bit of data in single-density mode (m = 0, 32), the
printer prints two dots: for each bit of data in double-density mode (m = 1, 33), the
printer prints one dot. This must be considered in calculating the amount of data
that can be printed in one line.
• It back to the normal data processing mode after printing a bit-image.
• This command won't be influenced by other print modes (emphasized /double-strike
/underline /characters amplification /white / black reverse), except upside-down printing
mode.
• the relationship between data and the point to be print as follows:
Choosing 8-dot density:
Choosing 24-dot density:

HM-E200 Programming Manual
9

HM-E200 Programming Manual
10
ESC - n
[Name] Turn underline mode on /off
[Format] ASCII ESC -n
Hex 1B 2D n
Decimal 27 45 n
[Range] 0≤ n ≤ 2
48 ≤ n ≤ 50
[Description] turn underline mode on/off, nvalue as follows:
n
Function
0, 48
underline mode is turn off
1, 49
underline mode ( one dot width) is turn on
2, 50
underline mode ( two dot width) is turn on
[Note] 1) This command is effective for all characters (including the blank space), but not the
blank space set by HT.
2) When underline mode is on, 90°clock wise rotated characters and characters and
white / black reverse characters cannot be underline.
3) When underline mode is off, there is no underline for following characters. Underline
width stays the same, default width: one dot width.
4) Character size change has no effects on underline width.
5) Turn underline mode on / off can be set by ESC !, the command executed at last is
effective.
[Default] n = 0
ESC 2
[Name] Set character line spacing for 30
[Format] ASCII ESC 2
Hex 1B 32
Decimal 27 50
[Description] Selects 3.875 mm (31 0.125 mm) line spacing.
[Notes] The line spacing can be set independently in standard mode and in page mode.
ESC 3 n
[Name] Set character line spacing
[Format] ASCII ESC 3 n
Hex 18 33 n
Decimal 27 51 n
[Range] 0 ≤ n ≤ 255
[Description] Sets the line spacing to [n 0.125 mm].
[Notes] The line spacing can be set independently in standard mode and in page mode.
[Default] n =31.

HM-E200 Programming Manual
11
ESC = n
[Name] Select peripheral device
[Format] ASCII ESC = n
Hex 1B 3D n
Decimal 27 61 n
[Range] 0≤n≤1
[Description] selects the device to which the host computer sends data, based on the value of n
as follows:
Bit
1/0
Hex
Decima
l
Function
0
0
00
0
Printer disabled.
1
01
1
Printer enabled
1-7
Undefined.
[Notes] • When the printer is disabled, it ignores all received data with the exception of DLE
EOT 、DLE ENQ and ESC ＝.
[Default] n=1
ESC ? n
[Name] Cancel user-defined characters
[Format] ASCII ESC ? n
Hex 1B 3F n
Decimal 27 63 n
[Range] 32 ≤n ≤127
[Description] Cancels user-defined characters.
[Notes] This command cancels the patterns defined for the character codes specified by n.
After the user-defined characters are canceled, the corresponding patterns for the
internal characters are printed.
If a user-defined characters have not been defined, the printer ignores
this command.
ESC @
[Name] Initialize printer
[Format] ASCII ESC @
Hex 1B 40
Decimal 27 64
[Description] Clears the data in the print buffer and resets the printer mode to the mode that was
in effect when the power was turned on.
[Notes] • The bit image has been downloaded and custom characters in RAM is not
cleared.When the printer default is label paper, the print mode is page mode after
power-on.When the printer default is continuous paper, the print mode is standard
mode after power-on.
• The macro definition is not cleared.
ESC D n1...nk NUL
[Name] Set horizontal tab positions
[Format] ASCII ESC D n1…nk
Hex 1B 44 n1…nk
Decimal 27 68 n1…nk
[Range] k=8，n1 to nk must be according to the order from small to large
[Description] In sequence from n1 to nk as horizontal anchor point value.

HM-E200 Programming Manual
12
[Notes] If the value of n1 to nk are not from small to large,when back value are not big than
front, pls stop setting.
ESC E n
[Name] Turn emphasized mode on/off
[Format] ASCII ESC E n
Hex 1B 45 n
Decimal 27 69 n
[Range] 0 ≤ n ≤ 255
[Description] Turns emphasized mode on or off
When the LSB of n is 0, emphasized mode is turned off.
When the LSB of n is 1, emphasized mode is turned on.
[Notes] • Only the least significant bit of n is enabled.
•This command and ESC ! turn on and off emphasized mode in the same way.
however, that the last received command is effective.
•Emphasized mode and double-strike mode ESC G can cancel each other.However,
that the last received command is effective.
[Default] n = 0
ESC G n
[Name] Turn on/off double-strike mode
[Format] ASCII ESC G n
Hex 1B 47 n
Decimal 27 71 n
[Range] 0 ≤ n ≤ 255
[Description] Turns double-strike mode on or off.
•When the LSB of n is 0, double-strike mode is turned off.
•When the LSB of n is 1, double-strike mode is turned on.
[Notes] •Only the lowest bit of n is enabled.
•Printer output is the same in double-strike mode and in emphasized mode.
•Emphasized mode and double-strike mode ESC G can cancel each other.However,
that the last received command is effective.
[Default] n = 0
ESC J n
[Name] Print and feed paper
[Format] ASCII ESC J n
Hex 1B 4A n
Decimal 27 74 n
[Range] 0 ≤n ≤ 255
[Description] Prints the data in the print buffer and feeds the paper [n×0.125 mm (0.0049”)].
[Notes] After printing is completed, this command sets the print starting position to
the beginning of the line.
•The paper feed amount set by this command does not affect the values set by ESC
2or ESC 3.
•The maximum paper feed amount is 900 mm. If the paper feed amount (n × line
spacing) of more than 900 mm is specified, the printer feeds the paper only 900 mm .

HM-E200 Programming Manual
13
ESC M n
[Name] Select character font
[Format] ASCII ESC M n
Hex 1B 4D n
Decimal 27 77 n
[Range] 0 ≤ n ≤ 9, 48 ≤ n ≤ 57
[Description] select character font
n
Function
0, 48
Choose ASCII character font ( 12 * 24 )
1, 49
Choose ASCII character font ( 9 * 17 )
2,50
Choose user-defined character
3, 51
Choose Chinese character font 3 ( 24 * 24 )
[Note] 1) ESC ! can set character font too, the command received at last is effective.
2) If there is such font required in dot-matrix, this command is ineffective.
ESC R n (It just allows to use on machines that provide international Characters)
[Name] Select an international character set
[Format] ASCII ESC R n
Hex 1B 52 n
Decimal 27 82 n
[Range] 0≤n≤13
n
ASCII code
0
U.S.A.
1
France
2
Germany
3
U.K.
4
Denmark I
5
Sweden
6
Italy
7
Spain I
8
Japan
9
Norway
10
Denmark II
11
Spain II
12
Latin America
13
Korea
[Note] • Only character Font 0 and Font 1 has international character set. The command is
ineffective with other fonts.
[Default] n=0

HM-E200 Programming Manual
14
ESC T n
[Name] Select character font
[Format] ASCII ESC T n
Hex 1B 54 n
Decimal 27 84 n
[Range] 0 ≤ n ≤ 3, 48 ≤ n ≤ 51
[Description] Set the print direction and starting position in page mode specified by nas shown below:
n
Print Direction
Starting Position
0,48
Left to right
Upper left
(A in the figure)
1,49
Bottom to top
Lower left
(B in the figure)
2,50
Right to left
Lower right
(C in the figure)
3,51
Top to bottom
Upper right
(D in the figure)
[Note] 1) this command is processed in standard mode, an internal flag is activated and this
command is enabled when the printer returns to page mode.
2) this command set the starting position of printing data in the printing area.
[Default] n = 0
ESC V n
[Name] Turn 90° clockwise rotation mode on/off
[Format] ASCII ESC V n
Hex 1B 56 n
Decimal 27 86 n
[Range] 0 ≤ n ≤ 1, 48 ≤ n ≤ 49
[Description] Set the print direction and starting position in page mode specified by nas shown
bellow.
n
Function
0, 48
Turn 90° clockwise rotation mode off
1, 49
Turn 90° clockwise rotation mode on
[Note] 1) This command is effective only in standard mode.
2) When choosing underline mode, underline cannot clockwise 90 degrees.
3) When 90°clockwise rotation mode is on, the direction of double height and double
width reverse to that in normal mode (90°clockwise rotation mode is off).
[Default] n=0

HM-E200 Programming Manual
15
ESC W xL xH yL yH dxL dxH dyL dyH
[Name] Set printing area in page mode
[Format] ASCII ESC W xL xH yL yH dxL dxH dyL dyH
Hex 1B 57 xL xH yL yH dxL dxH dyL dyH
Decimal 27 87 xL xH yL yH dxL dxH dyL dyH
[Range] 0 ≤ xL, xH, yL, yH, dxL, dxH, dyL, dyH ≤ 255
(except for dxL= dxH=0 or dyL= dyH=0)
[Description] Set the size and position of the printing area in page mode as follows:
Horizontal starting position: x0= [( xL + xH × 256) × 0.125mm]
Vertical starting position: y0 = [( yL + yH × 256) × 0.125mm]
Printing area width: dx = [ (dxL + dxH × 256) ×0.125mm]
Printing area height: dy = [ (dyL + dyH × 256) ×0.125mm]
[Note] •This command is processed in standard mode to set an activated internal flag so that
don't influence printing.
• The printer stop processing this command once horizontal starting position or vertical
starting position ran out of the printing area, the subsequent data are processed as
normal one.
• The printer stop processing this command once printing area width or height was set
to 0, the subsequent data are processed as normal one.
• This command confirms the current printing position with command ESC T.
•The default set of printing area width is horizontal printable width - horizontal starting
position if the value of horizontal starting position + printing area width was beyond
printable area.
• The default set of printing area height is vertical printable height - vertical starting
position if the value of vertical starting position + printing area height was beyond
printable area.
• The default settings of the horizontal and vertical motion units are 0.125mm.
•Assuming horizontal starting position, vertical starting position, printing area width and
printing area height X, Y, Dx, Dy, set the printing area as shown below:
[Default] xL = xH = yL = yH = 0
dxL, dxH, dyL and dyH decided by printer settings

HM-E200 Programming Manual
16
ESC \ nL nH
[Name] Set relative horizontal print position
[Format] ASCII ESC \ nL nH
Hex 1B 5C nL nH
Decimal 27 92 nL nH
[Range] 0 ≤ nl ≤ 255 0 ≤ nH ≤ 255
[Description] Sets the relative horizontal print starting position from the current position.
This command sets the distance from the current position to [(nL + nH × 256)×
0.125 mm (0.0049”)].
[Notes] •The printer ignores any setting that exceeds the print area.
• When pitch N is specified for the movement to the right：nL+ nH × 256 = N。
• Use the complement of N for setting N pitch movement to the left: (nL + nH × 256) =
65536 – N.
• Print starting position from the current position to [N × 0.125mm].
ESC a n
[Name] Select justification
[Format] ASCII ESC a n
Hex 1B 61 n
Decimal 27 97 n
[Range] 0 ≤ n ≤ 2, 48 ≤ n ≤ 50
[Description] Aligns all the data in one line to the specified position.
n selects the justification as follows:
n
Justification
0,48
Left justification
1, 49
Centering
2, 50
Right justification
[Notes] The command is enabled only when processed at the beginning of the line in
standard mode. If this command is input in page mode, the printer performs only
internal flag operations This command justifies the space area according to HT,
ESC $ or ESC \.
[Default] n = 0
[Example]
