Welcome to HUAWEI
Quick Start Guide
HUAWEI Ascend Y210D

1
Dual-Card Dual-Standby
Your mobile phone supports dual-card dual-standby mode, which
can significantly reduce power consumption and increase your
phone's standby time. Note that two restrictions exist:
• When you make calls using one SIM card, the other SIM card is
disabled.
For example, when you make calls using SIM card 1, SIM card
2 cannot be used to answer calls or access the Internet. If
someone calls SIM card 2, the caller will hear a voice message
like "The subscriber you dialed is out of the service zone" or "The
subscriber you dialed is not able to answer your call, please try
again later." This is because your mobile phone cannot access
the network with both SIM cards at the same time and has
nothing to do with your service provider's network condition. It is
recommended that you subscribe to services such as voicemail
or missed-call reminders from your service provider to avoid the
inconvenience caused by missed calls.
• When you are using one SIM card's data services, you can
receive calls and messages using the other SIM card, but data
services will be interrupted.
For example, when SIM card 1's data services are in use, you
can use SIM card 2 for calling and messaging, but SIM card 1's
data services will be interrupted as a result. When the call using
SIM card 2 is terminated, or the message is received or sent, you
can resume using SIM card 1's data services.

2
Phone at a Glance
All the pictures in this guide are for your reference only. Your
phone’s actual display features may be different to those
described here, depending on its software version.
Key Functions at Your Fingertips
• Press and hold to power on your mobile phone.
• Press and hold to open the Phone options menu.
• Press to lock the screen when your mobile phone is
active.
• Touch to return to the previous screen or exit the
application you are running.
• Touch to hide the keyboard.
Touch to open the menu on an active screen.
Volume
key
Speaker
Earpiece
Camera
Charger/
Data port
Headset jack
Back
Menu
Home
Power key

3
Installing the SIM Card
• Touch to return to the Home screen.
• Touch and hold to show the most recently used
applications.
12
3Insert SIMcard
Remove the battery cover
Insert WCDMA/GSM card Insert GSM card
Remove the battery

4
Dual-Card Management
Your mobile phone supports access to both WCDMA and GSM
networks. Follow the onscreen instructions or the quick start guide to
install SIM cards.
1. Touch >
Settings .
2. Touch Dual Card Settings to activate the SIM cards.
(Optional) Installing the microSD
Card
If you want to expand your phone memory, you can also insert a
microSD card.
1. Remove the battery cover.
2. Remove the battery.
3. Insert the microSD card into the card slot as shown in the
diagram.
Enable Enable
Preferred Preferred
Card1 Card2

5
Installing the Battery
1. Angle the edge labeled a (with the contacts) into the bottom end
of the battery compartment.
2. Push the edge labeled
b into the compartment until the battery
clicks firmly into place.
Charging the Battery
Before charging the battery, ensure that it has been properly installed
on your phone.
1. Connect the USB cable that came with your mobile phone to
the charger.
2. Connect the other end of the USB cable to your mobile phone.
Then, to start charging, plug the charger into an electrical outlet.
If you charge your mobile phone while it is powered on, the battery
icon on the notification bar indicates the charging status. When the
battery icon changes to , your mobile phone is fully charged.
a
b

6
Status Indicator
The color of the status indicator tells you the status of your mobile
phone’s battery.
Touchscreen Actions
Using your finger on the touchscreen, you can operate your phone
conveniently.
Status Indicator
Green: Fully charged (when connected to charger).
Orange: Charging in progress (when connected to charger).
Red: Battery low.
Drag
TouchTouch & hold Double touch
Flick

7
Home Screen
You can set up the Home screen according to your own
preferences, for example by adding a shortcut or a widget to your
Home screen or changing the wallpaper.
To return to the Home screen from any of its extensions, press .
When a new notification icon appears on the notification bar, place
your finger on the notification bar and flick down to open the
notification panel.
Adding a New Home Screen Item
1. Touch and hold a blank area on the Home screen until the Add
to home screen menu is displayed.
2. Select an item to add it to the Home screen.
Removing a Home Screen Item
1. Touch and hold an item on the Home screen until the item
expands and the mobile phone vibrates.
2. Without lifting your finger, drag the item to the trash can. When
the item and the trash can turn red, the item is ready to be
removed.
3. Release the item to remove it from the Home screen.
10:23
Flick your finger left or
right across the Home
screen.
Touch to view thumbnails
of the Home screen and its
extensions. Touch a thumbnail
to open the screen.
10:23

8
Importing Contacts from a SIM
Card
1. In the contact list, touch > Manage contacts .
2. Touch Copy contacts from card 1 or Copy contacts from
card 2 .
3. Wait for the SIM card contents to be loaded. Select the contacts
you want to import or touch
Select All to select all contacts.
4. Touch
Copy .
5. If you have more than one account on your phone, touch the
account into which you want to import the contacts.
Adding a Contact
1. In the contact list, touch > Create contact .
2. If you have more than one account with contacts, touch the
account to which you want to add the contact.
3. Enter the contact's name, and then add detailed information
such as phone number and address.
4. When you are finished, touch Save to save the contact
information.
Making a Call with the Dialer
Application
On the home screen, touch to open the Dialer .
Your mobile phone supports the SmartDial function, that is, when
you touch numbers on the dialer, the phone automatically searches
among your contacts and lists the matching results ordered
according to the accuracy of the match. If no contacts match the
information entered, the phone will not display any result.

9
Creating and Sending a
Multimedia Message
You can use multimedia messages to make everyday
communications very special. You can record a message and send
it as an audio file, sing 'Happy Birthday' and send it to friend, or send
a slideshow of photographs of a special event. The possibilities are
endless.
1. Touch > Messaging > New message .
2. Enter a phone number in the
To field, or touch to select a
contact from
Contacts or Groups .
3. Touch the composition text box to start entering your message.
4. When the message is ready to be sent, touch Card 1 MMS or
Card 2 MMS .
10:23
