C2930T
CDMA 1X Mobile Phone
USER GUIDE

Copyright © Huawei Technologies Co., Ltd. 2011. All
rights reserved.
No part of this document may be reproduced or transmitted in any
form or by any means without prior written consent of Huawei
Technologies Co., Ltd.
The product described in this manual may include copyrighted
software of Huawei Technologies Co., Ltd and possible licensors.
Customers shall not in any manner reproduce, distribute, modify,
decompile, disassemble, decrypt, extract, reverse engineer, lease,
assign, or sublicense the said software, unless such restrictions are
prohibited by applicable laws or such actions are approved by
respective copyright holders under licenses.
Trademarks and Permissions
, HUAWEI, and
are trademarks or registered
trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned
are the property of their respective owners.
Notice
Some features of the product and its accessories described herein rely
on the software installed, capacities and settings of local network,
and may not be activated or may be limited by local network
operators or network service providers, thus the descriptions herein
may not exactly match the product or its accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify
any information or specifications contained in this manual without
prior notice or obligation.

NO WARRANTY
THE CONTENTS OF THIS MANUALARE PROVIDED "AS IS".
EXCEPT AS REQUIRED BYAPPLICABLE LAWS, NO
WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITYAND FITNESS FOR A
PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS
MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BYAPPLICABLE
LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD
BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS,
REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and
regulations and will obtain all necessary governmental permits and
licenses in order to export, re-export or import the product mentioned
in this manual including the software and technical data therein.

i
Table of Contents
1Installing the UIM Card and the Battery...............................1
2Charging the Battery.....................................................................1
3Your Phone.....................................................................................2
4Keys and Functions........................................................................3
5Screen Icons....................................................................................5
6Locking the Keypad.......................................................................5
7Profiles ............................................................................................6
8Call Function..................................................................................6
Making a Call.................................................................................6
Answering a Call ...........................................................................7
9Creating and Sending a Text Message.........................................7
10 Enabling the Phone Lock............................................................7
11 PIN and PUK ...............................................................................8
12 Input Text.....................................................................................8
Entering an English Word (in En Mode).......................................8
Entering English Letters (in Abc Mode) .......................................8
Entering an Hindi Word (in  Mode)......................................9
Entering a Digit..............................................................................9
Entering a Symbol .........................................................................9
13 Warnings and Precautions........................................................10

1 Installing the UIM Card and the
Battery
When installing the User Identity Module (UIM) card, ensure that
the golden contact area on the UIM card is facing downward and
that the beveled edge of the UIM card is properly aligned with that
of the UIM card slot.
2 Charging the Battery
1. Connect the charger to the phone.
2. Connect the charger to a power socket. The charging starts and
the charging icon is displayed in animation.
3. When the charging icon becomes static, indicating that the
charging is complete, disconnect the charger from the phone.
1

3 Your Phone
1. Earpiece
2. Navigation keys
3. Right soft key
4. Call key
5. Number keys
6. * key
7. Microphone
8. # key
9. Charger interface
10. End key
11. Left soft key
12. Confirm key
13. Screen
14. Starp hole
Note
The preceding figure is provided for your reference only.
The appearance of the actual product may differ.
2

4 Keys and Functions
Press… To…
Call key Dial a number or answer a call.
End key
Power on or off the phone (by pressing and
holding the key).
End or reject a call.
Left soft
key
In standby mode, access the main menu by
pressing this key.
Select the option displayed in the lower left corner
of the screen.
Right soft
key
Return to the upper-level menu or exit the
function menu from a menu screen.
Select the option displayed in the lower right
corner of the screen.
Confirm
Key
Confirm a selection or display a menu.
In standby mode, access T World by pressing this
key.
3

Press… To…
Navigation
keys
In standby mode,
Access Settings (by pressing the Up navigation
key).
Access Phone Book (by pressing the Down
navigation key).
Access Messages (by pressing the Left navigation
key).
Access Calendar (by pressing the Right
navigation key).
During a call,
Increase the volume (by pressing the Up
navigation key or the Right navigation key during
a call).
Decrease the volume (by pressing the Left
navigation key or the Down navigation key during
a call).
Number
keys
Enter digits, letters, and symbols.
Speed-dial phone numbers (by pressing and
holding the 2-9keys in standby mode if speed dial
numbers are set).
Access TATA Apps Store by pressing and holding
0key.
Access the submenu labeled with the
corresponding number.
* key Enable or disable the Meeting profile (by pressing
and holding the key in standby mode).
4

Press… To…
# key Lock the keypad (by pressing and holding the key in
standby mode).
5 Screen Icons
Icon Indicates... Icon Indicates...
Signal strength. Battery power level.
No signal is available. Calling state.
CDMA 1X network. Alarm clock on
Domestic roaming state. General profile
International roaming state. Silence profile
Memory for messages full
(orange) Meeting profile
Message received (yellow) Outdoor profile
Voice mail received My Profile
Urgent message received Keypad locked
6 Locking the Keypad
To prevent misoperations, you can press and hold the # key in
standby mode to lock the keypad. When the keypad is locked, you
can press the Call key to answer an incoming call and dial an
emergency call.
To unlock the keypad, press the Left soft key and then the * key.
5

7 Profiles
You can set the profile and other sound-related or vibration-related
features on the phone. The phone provide six profiles, including
General, Silence, Meeting, Outdoor, My Profile 1 and My Profile
2.
Select Profiles > Options > Edit to modify the Volume, Alert Type
and Sound Settings of the preset profile.
8 Call Function
Note
If the keypad is locked, you must unlock the keypad first. Otherwise,
you can only dial emergency numbers and answer incoming calls.
Making a Call
1. In standby mode, press the Number keys to enter a phone number.
To make an international call, press the * key twice consecutively
to enter a plus sign (+), and then enter the country or region code,
area code, and phone number in sequence.
To call an extension, enter the phone number, press the * key
three times consecutively to enter P or four times consecutively to
enter T, and then enter the extension number.
2. Press the Call key to dial the number.
3. Press the End key to end the call or cancel the dialing.
Note
In standby mode, you can press the Call key to access the call log,
select a desired number, and then press the Call key to dial the
number.
In Phone Book, select a desired number, and then press the Call
key to dial the number.
6
