1 Installing the UIM Card and the
Battery
Install your User Identity Module (UIM) card before using your
phone. Remove the UIM card and the battery only after powering
off the phone.
When installing the UIM card, ensure that the gold contact area
on the UIM card faces down, and that the beveled edge of the
UIM card aligns with that of the UIM card slot.
a
b

2
2 Charging the Battery
1. Connect the charger to the phone's charger jack.
2. Plug the charger into a power outlet.
3. Wait until the battery is fully charged.
While the battery is charging, the charging icon blinks. When
the charging icon stops blinking, the battery is fully charged.
4. Unplug the charger from the power outlet and from the phone.

3
3 Your Phone
1. Earpiece
2. Navigation keys
3. Left soft key
4. Call/Answer key
5. Number keys
6. * key
7. Microphone
8. # key
9. Charger jack
10. End/Power key
11. Right soft key
12. Confirm key
13. Screen
14. Strap hole
The preceding figure is provided for your reference only. The appearance
of the actual product that you have purchased may differ slightly from that
shown.

4
4 Keys and Functions
In this guide, your phone's navigation keys are indicated by the following
icons: , , and .
Press... To...
Call/Answer
key
Make a call.
Answer a call.
View the call log in standby mode.
End/Power
key
Power the phone on or off (press and hold the
key for about 3 seconds).
End or reject a call.
Turn the phone backlight on or off in standby
mode.
Return to standby mode.
Left soft key
Select the option displayed directly above the key,
in the lower left corner of the screen.
Right soft
key
Select the option displayed directly above the key,
in the lower right corner of the screen.

5
Press... To...
Navigation
keys
Scroll through menu options.
Increase the volume (press or ) or
decrease the volume (press or )
during a call.
Access the corresponding functions assigned
to the navigation keys in standby mode.
To customize the function shortcuts assigned to
the navigation keys, select Menu > Settings >
Phone Settings > Shortcuts.
Confirm key
Confirm a selection.
Access My Tata Planet in standby mode.
through
Number keys
Enter numbers, letters, and symbols.
Call your voicemail in standby mode (press and
hold key).
Speed-dial phone numbers in standby mode
(press and hold –keys for about 3
seconds if speed dial numbers are assigned).
Access TATA Apps Store (press and hold
key for about 3 seconds).
Select an option labeled with the
corresponding number.

6
Press... To...
* key
Enter *, +, Por Tbefore dialing a phone
number.
Enable or disable the Meeting profile in
standby mode (press and hold the key for
about 3 seconds).
Display the symbol list in editing mode.
# key
Enter #.
Lock the keypad in standby mode (press and
hold the key for about 3 seconds).
Switch between text input methods in editing
mode.
5 Screen Icons
Icon Indicates... Icon Indicates...
Signal strength.
Battery level.
Code division multiple
access (CDMA) 1X
network.
Calling state.

7
Icon Indicates... Icon Indicates...
Domestic roaming state.
International roaming
state.
Memory for messages
full (orange icon).
Message received
(yellow icon).
Voice mail message
received.
Urgent message
received.
Alarm enabled.
General profile
activated.
Silence profile activated.
Meeting profile
activated.
Outdoor profile
activated.
My Profile 1 profile
activated.
My Profile 2 profile
activated.
Keypad locked.

8
6 Call Function
If the keypad is locked, you can only dial emergency numbers and answer
incoming calls. To make a call, first unlock the keypad.
Making a Call
1. In standby mode, press the number keys to enter a phone
number.
To make an international call, press twice to enter a
plus sign (+). Then enter the country or region code, area
code, and phone number.
To call an extension number, enter the phone number, press
three times to enter Por four times to enter T, and
enter the extension number.
2. Press to dial the number.
3. Press to end the call or cancel the dialing.
You can also make a call from Call Log, Phone Book, or Messages.
In standby mode, press to access Call Log, select a desired
number, and press to dial the number.
In Phone Book, select a desired number, and press to dial
the number.
In Messages > SMS > Inbox, select a desired message, and press
to call the message sender.

9
Answering a Call
When there is an incoming call, press to answer the call
or to reject it. If Answer Mode is set to By Any Key,
you can press any key except and to answer the
call.
7 Text Input
In editing mode, press to switch between text input
methods.
Entering an English Word (in "En" Mode)
To enter an English word in "En" mode:
1. Press each number key only once according to the spelling
sequence of the desired word. The phone displays candidate
words containing the entered letters.
2. Press or to scroll to the desired word.
3. Press to enter the desired word or press key to enter
the desired word followed by a space.
Entering English Letters (in "Abc" Mode)
In "Abc" mode, you can press the number key labeled with the
desired letter once to enter the first letter on the key, twice to
enter the second letter on the key, and so on.
If the letter that you want to enter is on the same key as the
previous letter, enter the desired letter after the cursor appears
again or after you press to move the cursor to the right of
the previous letter.

10
Entering a Hindi Word (in "" Mode)
You can enter Hindi words in "" text input mode.
The "" text input mode is similar to the English text input
mode. For details, see "Entering an English Word (in "En" Mode)".
Entering a Number
In "123" mode, press the number key labeled with the desired
number.
In "Abc" mode, press and hold the number key labeled with
the desired number, or repeatedly press it until the number
appears on the screen.
In "En" mode, press the number key labeled with the desired
number, and press or until the number appears on
the screen.
In "En" mode, press to enter a space. In "Abc" mode, press once
to enter a space, twice to enter 0, and three times to start a new line.
Entering a Symbol
1. In any text input mode, press to display the symbol list.
2. Press to scroll to the desired symbol, and press to
enter it. You can also press the number key corresponding to
the desired symbol to enter it.

11
8 Creating and Sending a Text
Message
1. In standby mode, select Menu > Messages > SMS > Create
Message.
2. Write the message. Then select Options > Send.
3. Enter the message recipient(s).
4. Press to send the message.
9 Creating a Contact
1. In standby mode, select Menu > Phone Book > Add New.
2. Enter the contact information.
3. Press (Save) to save the contact.
10 Profiles
You can customize the profiles and other sound or vibration-
related features on the phone. The phone provides six profiles:
General, Silence, Meeting, Outdoor, My Profile 1 and My
Profile 2.
1. In standby mode, select Menu > Profiles.
2. Select a profile.
3. Select Options > Edit to modify Volume, Alert Type and
Sound Settings of the selected profile.

12
11 Locking and Unlocking the
Keypad
To prevent unintentional operations, press and hold in
standby mode to lock the keypad. When the keypad is locked, you
can press to answer an incoming call and dial an
emergency number.
To unlock the keypad, press then .
If the Auto Keyguard function is enabled and the phone is idle
for a preset period in standby mode, the keypad locks
automatically.
12 Enabling the Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled.
To enable the phone lock, select Menu > Settings > Security
Settings > Phone Lock. You can then choose:
Immediate: to enable the phone lock immediately.
Power On: to enable the phone lock when the phone is
powered on next time.
When you enable the phone lock, you are prompted to enter the
phone code. The default phone code is 0000. You can change the
code to any numeric string of one to eight digits.

13
13 PIN and PUK
The personal identification number (PIN) protects your UIM card
from unauthorized use.
If you enter the PIN incorrectly 3 times consecutively, the PIN is
blocked and the phone prompts you to enter the PIN unblocking
key (PUK). If this occurs, enter the PUK to unlock the blocked PIN.
If you enter the PUK incorrectly 10 times consecutively, the UIM
card will become permanently invalid, and you must contact your
service provider for a new UIM card.
Both the PIN and the PUK are provided with the UIM card. For
details, contact your service provider.

14
14 Warnings and Precautions
This section contains important information pertaining to the
operating instructions of your device. It also contains information
about how to use the device safely. Read this information carefully
before using your device.
Electronic Device
Power off your device if using the device is prohibited. Do not use
the device when using the device causes danger or interference
with electronic devices.
Medical Device
Follow rules and regulations set forth by hospitals and health
care facilities. Do not use your device when using the device is
prohibited.
Pacemaker manufacturers recommend that a minimum
distance of 15 cm be maintained between a device and a
pacemaker to prevent potential interference with the
pacemaker. If you are using a pacemaker, use the device on the
opposite side of the pacemaker and do not carry the device in
your front pocket.
Potentially Explosive Atmosphere
Power off your device in any area with a potentially explosive
atmosphere, and comply with all signs and instructions. Areas that
may have potentially explosive atmospheres include the areas
where you would normally be advised to turn off your vehicle
engine. Triggering of sparks in such areas could cause an

15
explosion or a fire, resulting in bodily injuries or even deaths. Do
not power on your device at refueling points such as service
stations. Comply with restrictions on the use of radio equipment in
fuel depots, storage, and distribution areas, and chemical plants.
In addition, adhere to restrictions in areas where blasting
operations are in progress. Before using the device, watch out for
areas that have potentially explosive atmospheres that are often,
but not always, clearly marked. Such locations include areas below
the deck on boats, chemical transfer or storage facilities, and areas
where the air contains chemicals or particles such as grain, dust,
or metal powders. Ask the manufacturers of vehicles using
liquefied petroleum gas (such as propane or butane) whether this
device can be safely used in their vicinity.
Traffic Security
Observe local laws and regulations while using the device. In
addition, if using the device while driving a vehicle, comply with
the following guidelines:
Concentrate on driving. Your first responsibility is to drive safely.
Do not talk on the device while driving. Use hands-free
accessories.
When you have to make or answer a call, park the vehicle at
the road side before using your device.
RF signals may affect electronic systems of motor vehicles. For
more information, consult the vehicle manufacturer.
In a motor vehicle, do not place the device over the air bag or

16
in the air bag deployment area. Otherwise, the device may hurt
you owing to the strong force when the air bag inflates.
Do not use your device while flying in an aircraft. Power off
your device before boarding an aircraft. Using wireless devices
in an aircraft may cause danger to the operation of the aircraft
and disrupt the wireless telephone network. It may also be
considered illegal.
Operating Environment
Do not use or charge the device in dusty, damp, and dirty
places or places with magnetic fields. Otherwise, it may result
in a malfunction of the circuit.
The device complies with the RF specifications when the device
is used near your ear or at a distance of 1.5 cm from your body.
Ensure that the device accessories such as a device case and a
device holster are not composed of metal components. Keep
your device 1.5 cm away from your body to meet the
requirement earlier mentioned.
On a stormy day with thunder, do not use your device when it
is being charged, to prevent any danger caused by lightning.
When you are on a call, do not touch the antenna. Touching
the antenna affects the call quality and results in increase in
power consumption. As a result, the talk time and the standby
time are reduced.
While using the device, observe the local laws and regulations,
and respect others' privacy and legal rights.

17
Keep the ambient temperature between 0°C and 40°C while
the device is being charged. Keep the ambient temperature
between 0°C to 40°C for using the device powered by a battery.
Prevention of Hearing Damage
Using a headset at high volume can damage your hearing. To
reduce the risk of damage to hearing, lower the headset volume
to a safe and comfortable level.
Safety of Children
Comply with all precautions with regard to children's safety.
Letting the child play with your device or its accessories, which
may include parts that can be detached from the device, may be
dangerous, as it may present a choking hazard. Ensure that small
children are kept away from the device and accessories.
Accessories
Choose only batteries, chargers, and accessories approved for use
with this model by the device manufacturer. The use of any other
type of battery, charger, or accessory may invalidate any warranty
for the device, may be in violation of local rules or laws, and may
be dangerous. Please contact your dealer for information about
the availability of approved batteries, chargers, and accessories in
your area.
Battery and Charger
Unplug the charger from the electrical plug and the device
when not in use.
The battery can be charged and discharged hundreds of times
