Huawei TE50 Operating and safety instructions

TE50 Videoconferencing Endpoint
Product Overview
Issue 04
Date 2018-06-30
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2018. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://e.huawei.com
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. i

About This Document
Purpose
This document provides the positioning, features, networking schemes, and technical
specifications of the HUAWEI TE50 videoconferencing endpoint (TE50 or endpoint for
short).
Intended Audience
This document is intended for:
lEnd users
lAgents
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates an imminently hazardous situation which, if
not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to
personal injury.
TE50 Videoconferencing Endpoint
Product Overview About This Document
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. ii

Symbol Description
Calls attention to important information, best practices
and tips.
NOTE is used to address information not related to
personal injury, equipment damage, and environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all the
changes made in earlier issues.
Issue 04 (2018-06-30)
This issue is the fourth official release.
Add 5.16 Custom Background Picture.
Modified 5.6 Multi-View.
Issue 03 (2018-03-23)
This issue is the third official release.
Added 5.13 AirPresence Key.
Added 6.6 CHR Collection.
Modified 4.2 Front Panel and Rear Panel.
Modified 5.1 Intelligent Tracking.
Issue 02 (2018-02-05)
This issue is the second official release.
Modified 4.2 Front Panel and Rear Panel.
Issue 01 (2017-12-25)
This issue is the first official release.
TE50 Videoconferencing Endpoint
Product Overview About This Document
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. iii

Contents
About This Document.....................................................................................................................ii
1 Product Positioning.......................................................................................................................1
2 Product Highlights........................................................................................................................ 2
3 Application Scenarios...................................................................................................................5
3.1 On-Premises/IMS Hosted/SP Hosted Network.............................................................................................................. 5
3.2 Built-in MCU-based Network........................................................................................................................................ 5
3.3 Built-in MCU Networking with the RSE6500............................................................................................................... 7
3.4 Videxio Interconnection Network...................................................................................................................................7
3.5 Networking with the ACS.............................................................................................................................................. 8
4 Product Structure......................................................................................................................... 10
4.1 Appearance................................................................................................................................................................... 10
4.2 Front Panel and Rear Panel.......................................................................................................................................... 10
4.3 Checking Indicator Status.............................................................................................................................................14
4.4 Intelligent Camera........................................................................................................................................................ 15
5 Functions and Features...............................................................................................................16
5.1 Intelligent Tracking.......................................................................................................................................................16
5.2 Voice Dialing................................................................................................................................................................ 17
5.3 SiteCall......................................................................................................................................................................... 18
5.4 P2P to Multipoint..........................................................................................................................................................18
5.5 Conference Control.......................................................................................................................................................19
5.6 Multi-View....................................................................................................................................................................21
5.7 Screen Layout Adjustment........................................................................................................................................... 21
5.8 Simultaneous Transmission of Video and Presentation................................................................................................22
5.9 Multi-Language User Interface.....................................................................................................................................22
5.10 Conference Recording................................................................................................................................................ 23
5.11 Wi-Fi Connectivity..................................................................................................................................................... 23
5.12 Wireless Data Sharing................................................................................................................................................ 24
5.13 AirPresence Key......................................................................................................................................................... 25
5.14 Automatic Configuration Via a USB Device..............................................................................................................25
5.15 Startup Video Customization......................................................................................................................................25
5.16 Custom Background Picture.......................................................................................................................................26
TE50 Videoconferencing Endpoint
Product Overview Contents
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. iv

5.17 Network Address Book.............................................................................................................................................. 26
5.18 Real-time Viewing of HD Images.............................................................................................................................. 26
5.19 Adaptation of and Conversion Between the 16:9 and 4:3 Display Modes.................................................................27
5.20 VGA Bypass............................................................................................................................................................... 27
5.21 Microphone Array Cascading.....................................................................................................................................27
5.22 Seamless Convergence with IMS and USM...............................................................................................................27
5.23 Registering with the SC Using the Same SIP Number as the TE Desktop&TE Mobile............................................28
5.24 Interworking with the Lync System............................................................................................................................28
5.25 Interconnection with the Videxio................................................................................................................................28
5.26 Interconnection with the ACS.................................................................................................................................... 28
5.27 Interconnection with the BroadSoft Platform.............................................................................................................28
5.28 Interconnection with the DDNS................................................................................................................................. 29
5.29 PSTN.......................................................................................................................................................................... 29
5.30 Third-Party APIs.........................................................................................................................................................29
5.31 Network Adaptability................................................................................................................................................. 29
5.32 Security.......................................................................................................................................................................29
6 Operation and Maintenance......................................................................................................33
6.1 Using the Touch Panel.................................................................................................................................................. 33
6.2 Using the Remote Control............................................................................................................................................ 34
6.3 Using the Web Interface............................................................................................................................................... 34
6.4 Log Management..........................................................................................................................................................35
6.5 Inspection......................................................................................................................................................................35
6.6 CHR Collection............................................................................................................................................................ 35
6.7 System Upgrade............................................................................................................................................................36
6.8 Disaster Recovery.........................................................................................................................................................36
7 Technical Specifications.............................................................................................................37
7.1 Physical Specifications................................................................................................................................................. 37
7.2 Performance and Capacity............................................................................................................................................38
7.3 Ports and Protocols....................................................................................................................................................... 40
7.4 Standards Compliance.................................................................................................................................................. 42
A Glossary........................................................................................................................................44
TE50 Videoconferencing Endpoint
Product Overview Contents
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. v

1 Product Positioning
The TE50, an HD videoconferencing endpoint ideal for kinds of conference rooms, supports
H.264 Scalable Video Coding (SVC), H.264 HP, IPv4 and IPv6 as well as Wi-Fi.
Table 1-1 describes the appearance, features, and application scenarios of the TE50.
Table 1-1 Appearance, features, and application scenarios of the TE50
Appearance Feature Application Scenario
A maximum of 1080p 60 fps is
supported.
Small- and medium-sized
conference rooms and
executive offices
TE50 Videoconferencing Endpoint
Product Overview 1 Product Positioning
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 1

2 Product Highlights
Next-Generation H.264 HP and VME Dual-Core Technologies
lDual streams (video + presentation) of up to 1080p 60 fps are supported.
lThe H.264 HP technology, combined with Huawei's proprietary Video Motion
Enhancement (VME) technology, optimizes video images to be more pleasing to eyes
while reducing the bandwidth consumption by 50%.
lThrough intelligent face recognition and back-end video enhancement, the VME
technology improves light adaptability, reduces bandwidth consumption, improves image
definition, and enhances motion images.
lThe endpoint provides users with high-fi audio using MPEG-4 Low Delay Audio Coder
(AAC-LD), acoustic echo cancellation (AEC), and automatic noise suppression (ANS)
technologies.
Feature-rich, Intelligent, and Easy to Use
lNew participants can be directly added to an active P2P or multipoint call, facilitating
smooth communication.
lThe endpoint and TE Desktop&TE Mobile can be registered using the same SIP number,
so fewer numbers are required.
lWith the voice dialing function, users can quickly initiate or join a conference by
speaking the name of a site in Chinese or English.
lWithout any intervention of the MCU, the local endpoint can combine video captured by
several cameras and send the video to the remote endpoint as continuous presence, which
meets the requirements of viewing a site from every angle and reduces the bandwidth
usage.
lThe endpoint with a built-in Wi-Fi module can connect to a Wi-Fi network, serve as a
Wi-Fi hotspot, or both.
lThe endpoint allows multiple sites to simultaneously share content in Live mode at
1080p 60 fps. Other sites select the shared content to view on demand.
lThe wireless data sharing client is provided for connecting a PC to the endpoint over Wi-
Fi. Then you can use the client to easily share the PC desktop as well as files stored on
the PC.
TE50 Videoconferencing Endpoint
Product Overview 2 Product Highlights
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 2

lThe AirPresence mobile client can be installed on a mobile device and paired with the
endpoint through the projection code. Then you can use the AirPresence mobile client to
push content on the mobile device to the endpoint.
lThe endpoint can automatically import configuration data from a USB flash drive,
without any manual intervention.
lVGA loopback is supported. You can connect your PC to the endpoint and then connect
the endpoint to a projector. Then you can directly push the PC desktop to the projector
when the endpoint is shut down, without plugging and unplugging cables.
User Interface Easily Operated Using the Remote Control
lThe remote control has a compact design and integrates the most commonly used
buttons.
lA touch panel can be used if necessary.
lA wizard is provided to help you easily complete the installation.
lThe 3D user interface is available and different modules are visible to users of different
roles. You can use the remote control to initiate calls or join conferences from the user
interface.
lThe LCD screen on the endpoint shows the local site information (including the IP
address and number) in real time.
High Network Adaptability and Security
lUsing H.264 SVC, the endpoint excellently adapts to different line bandwidths, device
capabilities, and network environments.
lThe endpoint utilizes Huawei's exclusive Super Error Concealment (SEC) and Intelligent
Rate Control (IRC) technologies.
lThe endpoint supports firewall traversal through the standard H.460 protocol or
Huawei's proprietary Super Network Passport (SNP) protocol.
lMedia and signaling streams are encrypted in multiple ways, ensuring secure and stable
running of the videoconferencing system.
Extensive System Integration
lThe endpoint can interwork with industry's mainstream standard endpoints,
infrastructures, the IP Multimedia Subsystem (IMS), the BroadSoft platform, and the
Videxio cloud videoconferencing platform (referred to as Videxio platform hereinafter),
delivering an intelligent, easy-to-use conference experience.
lThe endpoint can be seamlessly integrated into the IMS or SP hosted network.
lThe endpoint can interwork with Microsoft Skype for Business (next-generation Lync
client), Lync 2013/2010, and Lync Online (Office 365) through the Lync gateway or
PXP Integrated Media Server.
lThe endpoint is the industry's first videoconferencing endpoint that enables you to
schedule or start a multipoint video conference as easily as making a call.
lThe endpoint provides rich APIs for third parties to facilitate system integration and
customization.
lendpoints connected to the same third-party Dynamic Domain Name System (DDNS)
can call each other by domain name.
TE50 Videoconferencing Endpoint
Product Overview 2 Product Highlights
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 3

(Optional) Built-in MCU
The endpoint with the built-in MCU can hold multipoint conferences without any intervention
of the SMC or standalone MCU.
This enables users to call multiple sites one by one, or use a predefined conference template to
call multiple sites at a time. After a conference starts, sites can dial the number or IP address
of the endpoint that houses the built-in MCU to join in the conference.
lMaximum connected sites allowed by a non-encrypted conference: 6 720p 30 fps video
sites (local site included) + 3 audio sites
lMaximum connected sites allowed by an encrypted conference: 6 720p 30 fps video sites
(local site included)
lMaximum bandwidth required for a conference: 5 Mbit/s (1 Mbit/s for each video site)
lOne conference can be simultaneously joined by different types of endpoints, including
SD terminals, HD terminals, VoIP terminals, H.323 terminals, SIP terminals, and
terminals supporting different audio and video formats and bandwidths.
lContinuous presence per port: supports a maximum of 7 video panes.
lSupports rich functions, including voice activation, floor request, dual-stream
transmission through H.239, and Binary Floor Control Protocol (BFCP), and can
collaborate with the Huawei RSE6500 to support multipoint conference recording,
meeting the requirements of small- and medium-sized enterprises in terms of equipment
price and maintenance costs.
lAdds local video and presentation to continuous presence.
TE50 Videoconferencing Endpoint
Product Overview 2 Product Highlights
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 4

3 Application Scenarios
3.1 On-Premises/IMS Hosted/SP Hosted Network
The endpoint connects to on-premises, IMS hosted, or SP hosted CloudVC/CloudEC
networks, enabling video communication for enterprises and carriers. Figure 3-1 shows the
network diagram.
Figure 3-1 Networking diagram
The network is described as follows:
lThe endpoint connects to the on-premises network through the standard SIP or H.323
protocol.
lThe standard SIP protocol is used for connecting the endpoint to the IMS or SP hosted
network.
lVideo, data, and presentation sharing can be implemented between the endpoint and
various kinds of terminals and clients to deliver the optimal communications experience.
3.2 Built-in MCU-based Network
TE50 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 5

In the CloudVC on-premises networking scheme, the endpoint TE50 can hold multipoint
conferences using its built-in MCU, without any intervention of the SMC2.0 or MCU. The
built-in MCU makes conference rooms of small- and medium-sized enterprises video-
enabled. Figure 3-2 shows the built-in MCU-based network of the endpoint.
Figure 3-2 Built-in MCU-based network
The network is described as follows:
lAfter having the built-in MCU enabled, the endpoint TE50 can hold both encrypted and
unencrypted conferences.
–An unencrypted conference can hold a maximum of five 720p 30 fps HD video
sites and three audio sites, besides the site that initiates the conference. Each video
site occupies 1 Mbit/s bandwidth. The total bandwidth occupied by the conference
cannot exceed 5 Mbit/s.
–An encrypted conference can hold a maximum of five 720p 30 fps HD video sites,
besides the site that initiates the conference. Each video site occupies 1 Mbit/s
bandwidth. The total bandwidth occupied by the conference cannot exceed 5
Mbit/s.
lSD and HD video sites and audio-only sites of the H.323 or SIP type can join
conferences on this network.
NOTE
Audio-only sites can join conferences using IP phones only when the SC is deployed on the
network.
lThis network supports presentation sharing through the H.239 protocol, as well as
simultaneous video and presentation sharing through the Binary Floor Control Protocol
(BFCP).
lWhen a site joins a conference, the endpoint automatically adjusts the continuous
presence layout to display the video of that site. For example, when there are only two
video sites, the continuous presence layout is 2-pane . If a third video site joins in,
TE50 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 6

the continuous presence layout is automatically adjusted to 3-pane . The site that
generates the loudest volume is displayed in the largest pane. The local site is not
displayed by default.
lThe endpoint with a built-in MCU provides conference control functions, including
requesting or releasing chair control rights, allowing or forbidding the chair site, locking
or unlocking a conference, and selecting a screen layout.
3.3 Built-in MCU Networking with the RSE6500
In the CloudVC on-premises network, the endpoint TE50 that has a built-in MCU can be
separately interconnected with the Recording & Streaming Engine (RSE), without the
intervention of the SMC2.0 or MCU. Figure 3-3 shows how the endpoint TE50 with the
built-in MCU is networked with the RSE6500.
Figure 3-3 Built-in MCU networking with the RSE6500
The network is described as follows:
lThe MCU-embedded endpoint is deployed on the same IPv4 or IPv6 network as the
RSE6500. It can contact the RSE6500 using the IP address.
lThe MCU-embedded endpoint exchanges media streams with the RSE6500 to
implement simultaneous recording of conference voice, video, and presentation.
Recording control can be performed on either the endpoint or the RSE6500.
lUsers can view live broadcast or VoD either from the endpoint web interface or from the
RSE6500 web interface on their PCs, smartphones, or tablets.
NOTE
On this network, the endpoint with the built-in MCU works with the RSE6500 in the simplest way.
Without any intervention of the GK or SIP server, they are connected by their IP addresses.
3.4 Videxio Interconnection Network
To interconnect your endpoint with the Videxio platform, click the activation button on the
Videxio web page and choose to automatically scan your endpoint or manually search for
TE50 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 7

your endpoint by IP address. Figure 3-4 shows the network where the endpoint is
interconnected with the Videxio platform.
Figure 3-4 Videxio interconnection network
The network is described as follows:
lBy interacting with the activation server, registrar server, and configuration server on the
Videxio platform, the endpoint gets activated, obtains SIP configuration data, acquires its
own site name, and automatically registers with the Videxio platform based on the
obtained data.
lThe endpoint communicates with the Videxio platform only through the SIP protocol to
get registered and convene conferences.
lFor video conferences that are held on the Videxio cloud videoconferencing platform,
only presentation sharing is supported.
3.5 Networking with the ACS
The endpoint can interconnect with the Auto-Configuration Server (ACS) to implement
management functions through the TR-069 service offered by the ACS.
Figure 3-5 shows the interconnection between the endpoint and the ACS.
Figure 3-5 Interconnecting with the ACS
TE50 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 8

On this network:
lThe endpoint communicates with the TR-069 server through the TR-069 protocol.
lThe HTTP server is used to upload and download configuration files and download
upgrade files.
lThe Simple Traversal of UDP through NAT (STUN) server implements traversal
between private and public networks and delivers management over all devices on both
networks.
lThe endpoint can be deployed on a public or private network, while the ACS must be
deployed on a public network.
–If the endpoint is deployed on a public network, it can be managed by the ACS
through the TR-069 protocol.
–If the endpoint is deployed on a private network, the STUN server needs to be
deployed for traversal between private and public networks. After the deployment,
the TR-111 protocol, an extension of the TR-069 protocol, will be available for the
ACS to manage the endpoint.
TE50 Videoconferencing Endpoint
Product Overview 3 Application Scenarios
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 9

4 Product Structure
4.1 Appearance
Its all-metal shell feels durable and shows the quality of the product.
Figure 4-1 Appearance
4.2 Front Panel and Rear Panel
Figure 4-2 shows the front panel. Figure 4-3 shows the ports on the rear panel, and Table 4-1
provides the detailed description of these ports. For details about the status of the indicators,
see 4.3 Checking Indicator Status.
TE50 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 10

Figure 4-2 Front panel
No. Component Description
1 OLED display Displays the IP address, site number, and indications for startup, upgrade, sleep,
and malfunction.
2 Alarm
indicator
Turns on when an alarm is generated.
3 Status
indicator
Indicates the endpoint status, such as running and standby.
NOTE
Ports on the real panel may slightly differ for the endpoints of different batches.
Figure 4-3 Rear panel
Table 4-1 Port description
Port
Type
No. Description Function
Audio
input
1 Microphone input port, that is,
XLR port
Connects the XLR port on a
microphone for audio collection
and input at a site.
2 RCA port
lL: left audio channel
lR: right audio channel
Connects to an audio input
source, such as a computer or
mobile phone.
TE50 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 11

Port
Type
No. Description Function
5 Microphone array port Connects to a microphone array,
for example, HUAWEI
VPM220.
24 Line audio input port, which
consists of left and right audio
channels
Connects to a tuning console.
Audio
output
3 RCA port
lL: left audio channel
lR: right audio channel
Connects to an external speaker
as a Line 1 port. It is a reserved
audio output port.
Connects to the 3.5 mm audio
input port on the Huawei
VPT300 intelligent camera.
4 RCA port
lL: left audio channel
lR: right audio channel
Connects to a recording device
as a Line 2 port, and records
sounds of the local and remote
sites.
Connects to the 3.5 mm audio
input port on the Huawei
VPT300 intelligent camera.
Video
input
9 Proprietary camera port, which
consists of two layers
Connects to the Huawei
VPC620/600 HD camera or the
Huawei VPT300 intelligent
camera as the first input.
10 VGA port, which supports VGA
and YPbPr
Connects to a presentation
source, such as a computer, as
the second input.
Connects to the Huawei VPT300
intelligent camera through two
conversion cables.
11 HDMI port, which supports a
resolution of up to 1080p 60 fps
20 3G-SDI port, which supports
SDI signal input, the 3G-SDI
standard, and a resolution of up
to 1080p 60 fps
Connects to a secondary camera
as the third input.
The 3G-SDI port is connected to
Huawei's coaxial cable to
support a maximum
transmission distance of 60 m.
21 CVBS port, which supports SD
signal input
Connects to a video input device
as the first input.
Video
output
6 VGA port, which exports VGA
or YPbPr signals
Connects to a presentation
output device as the third output.
TE50 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 12

Port
Type
No. Description Function
7 HDMI HD video output port,
which supports a resolution of
up to 1080p 60 fps and does not
support YPbPr output
Delivers the shared presentation
or video of the remote sites by
default as the second output.
8 HDMI HD video output port,
which supports a resolution of
up to 1080p 60 fps and does not
support YPbPr output
Connects to a device for
displaying video of the local site
as the first output.
22 CVBS port Connects to an SD display
device as the fifth output.
23 3G-SDI connector, which
supports the 3G-SDI standard
and a resolution of up to 1080p
60 fps
Connects to a display device as
the fourth output.
The 3G-SDI port is connected to
Huawei's coaxial cable to
support a maximum
transmission distance of 60 m.
Others 12 2 x USB port Connects to a USB device, such
as a removable hard disk, USB
flash drive, or data card.
13 Dual-mode serial
communication port
Connects to a camera control
cable and can be used for
diagnostics and maintenance.
Connects to the HUAWEI
VPT300 intelligent camera
through a serial cable when the
camera is connected through the
HDMI port.
14 10 Mbit/s, 100 Mbit/s, or 1000
Mbit/s full duplex Ethernet
ports, which support IP network
transparent transmission and
network port backup
lLAN1: functions as the main
network port.
lLAN2: is used for
transparent transmission and
network port backup.
15 PSTN port Connects to a PSTN cable.
Currently, this port can be used
in China only.
16 Reset button lWhen the endpoint is
powering on, press and hold
this button for 10s to enter
the mini system.
lWhen the endpoint is
running, press and hold this
button for 10s to reset the
endpoint to factory settings.
TE50 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 13

Port
Type
No. Description Function
17 Power input port (100–240 V
AC, 50 Hz to 60 Hz)
Connects to a power supply.
18 Power switch Powers on or off the endpoint.
19 Grounding port Connects to a ground cable.
4.3 Checking Indicator Status
By checking the status of indicators on an endpoint, you can know its running status and
ensure that it works well with other videoconferencing devices.
When all cables are connected correctly, connect the TE50 to a power supply and turn the
power switch to ON.
Table 4-2 describes the TE50 indicator status.
Table 4-2 TE50 indicator status
The Indicator Is... The Endpoint Is...
Off Disconnected from the power supply.
Blinking blue twice per second Powering on.
Steady blue Working properly.
Steady purple Powered off. (Press on the remote
control to power off the TE50.)
Blinking green (on for 1s, off for 2s) Standby.
Blinking blue four times per second Upgrading.
Blinking blue once Responding to a press on a remote control
button. (The TE50 responds to remote
control operations only when working
properly.)
Blinking red twice per second Overheated.
Blinking red four times per second Encountering a temperature fault. For
example, the temperature sensor inside the
endpoint cannot sense the operating
temperature, causing fast fan rotation speed
and loud fan noise.
Steady red Faulty.
TE50 Videoconferencing Endpoint
Product Overview 4 Product Structure
Issue 04 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 14
