HWAM 4410 Technical manual

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
1
IN1198 Edition A
Installation and planning Instructions For
Hwam
4410
3320
3310
This Manual Must Always be Available to the Stove Operator
Serial Number
Part No.
Model Name
This manual must be used in conjunction with document IN1173.
The Wood and Multifuel Chimney and Installation Guide.
Since April 2002 only Registered Competent Engineers may install solid fuel fired appliances without involving
the Local Authority Building Control Department. For more details contact HETAS.
Euroheat would suggest only Registered Competent Engineers such as HETAS approved engineers install
Euroheat appliances.
If a competent approved engineer is not employed to install your appliance building control must to contacted
and a building control number is issued.

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
2
IMPORTANT
.
The installation of this appliance must comply with all local regulations, including those referring to
national and European Standards before it can be operated. The stove is not suitable for a shared flue.
However, for England and Wales, only, the coming into force on 1st April 2002 of SI 2002 No 440 exempts
the householder from this legal requirement for the installation of solid fuel fired appliance whose rated heat
output is 50kW or less in a building having no more than 3 storeys (excluding any basement) if a Competent
Engineer is employed who is registered under the Registration Scheme for Companies and Engineers involved
in the Installation and Maintenance of Domestic Solid Fuel Fired Equipment operated by HETAS Ltd. These
registered Competent Engineers may also carry out associated building work necessary to ensure that the
installed appliance complies with Building Regulations without involving the Local Authority Building Control
Department.
Improper adjustment, alteration, maintenance or the fitting of replacement parts not recommended by the
manufacturer can cause injury or property damage. Do not operate the stove with faulty seals or damaged
glass.
 Due to the high operating temperatures of this appliance it should be located away from pedestrian traffic
and away from furniture and draperies. Do not store paper or wood near the appliance. Any mats and rugs put
in front of the stove should be fire proof and secured to prevent the possibility of tripping.
Advise all persons as to the stove’s high surface temperatures. If it is possible for children or infirm adults to
come into contact with the stove, fit a suitable fire guard.
It is imperative that all air passageways into, out of, and within the appliance are kept clean. All permanent
ventilation into the room provided for the stove must remain clear and unobstructed at all times. Consideration
must be given to the need for extra ventilation if another heating source needing air is to be operated
simultaneously. If an extraction fan is proposed to be fitted to a connecting area of the house, after the stove
has been installed, professional advice should be sought from a qualified engineer.
The user should be advised that the appliance should be inspected regularly and the chimney cleaned at
least annually.
More frequent cleaning may be required and the advice of a qualified chimney sweep should be sought.
 Our range of stoves is capable of operating with outstanding efficiency if the flue system is correct. Because
so little heat is wasted to the flue it is possible that moisture within the products of combustion will condense
if the heat losses within the flue way are too great and allow the flue gasses to cool. For this reason we
recommend that the stove is fitted with a suitable flue liner, the same diameter as the flue spigot, to prevent
the possibility of acidic damage to the fabric of the chimney and damage to the stove which will reduce the
longevity of the stove.
 When correctly installed, the stove is designed to produce heat, safely. It cannot do so if the installation is
less than absolutely stable, constructed of materials suitable for such an installation and consideration has not
been given to the possibility of people with less than ideal common sense operating it.
Has the existing chimney swept by a chimney sweep? Although you will be lining the chimney, any deposits
left in the chimney will cause problems and may become a fire hazard.
 Your attention is drawn to the precautions and responsibilities under the Health and Safety at Work Acts,
and whatever new legislation being introduced during the life of this document.

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
3
The Hwam 4410, 3320 and 3310 Range Explained
Hwam and Euroheat insist on progressive development to produce products which are market leading. Our
aims are to have stoves with the latest innovations, user friendly operation and highly efficient for lower cost
operation.
All three models can either be floor mounted on a stand or wall mounted with a hanging bracket. They have
swing up and drop down access door to the ash and control system area.
Important
Please ensure the warranty registration form is completed if you are the installer and confirm with the user
that it is there responsibility to return it to Euroheat. In this way the model and its history will be recorded for
reference in the future.
For the latest versions of manuals, technical information, accessories and spare parts visit the euroheat web
site. www.euroheat.co.uk
The part number and edition of this manual is listed on the front page and at the bottom of each page.
Stoves Supplied Through Euroheat Authorized Retailers.
For England, Wales, Scotland and Ireland
Euroheat Distributors (H.B.S). Ltd.
Unit 2,
Court Farm Business Park,
Bishops Frome,
Worcestershire. WR6 5AY.
www.euroheat.co.uk
[e-mail]
Whilst Euroheat are always happy to assist, please ensure you have read this manual and the chimney and
installation guide IN1173.
First contact your supplying retailer for assistance. If you find this unsuccessful contact the Euroheat Technical
support team. Technical support telephone Number [phone]. E-mail [e-mail].
Before telephoning ensure you have the stoves serial number to hand and that you are a Registered Competent
Engineer. If you are not a registered engineer seek one for assistance. A list of engineers can be obtained from
HETAS. www.hetas.co.uk
Euroheat unfortunately are unable to offer support for appliances which were not supplied by Euroheat.
Hwam
Nydamsvej 53 Dk -8362 Horning Denmark
www.hwam.com

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
4
Technical Details Intermittent Operation
Model
Name
Model
Number
Heat Output
Nominal
Wood
Weight
KG
Flue
Draught
Nominal
Flue Gas
Mass
Flow g/s
Flue Gas
Temperature
Efficiency
with
Top Flue
Connection
Flue
Size
Air
Requirement
Equivalent
Area as
Approved
Document J
Hwam
4410 4410* 6kW
109kg
125kg
with plinth
12pa 7.49 291 81.6% Net
74.6% Gross 6” (152mm) 550mm2
Hwam
3320 3320* 5kW
95kg
110 kg
with plinth
12pa 7.4 280 81.6% Net
74.6% Gross 6” (152mm) 0mm2
Hwam
3310 3310* 5kW
92kg
107kg
with plinth
12pa 7.4 280 81.6% Net
74.6% Gross 6” (152mm) 0mm2
* HETAS Approved
Models indicated above as HETAS approved to a certain flue position are indicated by **
Intermittent operation is when the appliance is used for short firing periods for example 45 minutes to 2 hours.
This is a common operation in warmer weather such as cold spring evenings. The information provided below
where indicated as HETAS approved is from the current CE standards EN 13240:2001 and EN 13240 A2:2004.
The test fuel is wood.
* Air requirement equivalent area. Building regulations Document J, advises that an air supply should be
installed for appliances with a heating output over 5kW. Document J indicates that there should be sufficient
advantageous air for heating outputs below this amount. With modern properties this may not always be the
case and/or more free air may be required. Continuous or intermittent operation will result in different heating
outputs due to the nature of the fuel and the appliance. If in doubt increase the suggested area listed or contact
your HETAS approved engineer for assistance.
Useful Organizations UK
Solid Fuel Association 0845 601 4406 www.solidfuel.co.uk
The National Association of Chimney Sweeps 01785 811732 www.chimneyworks.co.uk
HETAS Ltd. 0845 634 5626 www.hetas.co.uk

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
5
Load Bearing Surface
Before installing the stove, make sure that the surface it will stand on can carry the weight of the stove and
any flue connecting pipe.
Installation Clearances
5
7
4
2
1
6
5
4
7
3
3
Diagram Number Description 3310 3320 4410
1 To inflammable surface at rear 0mm 0mm 0mm
1 To flammable wall at rear 150mm 150mm 150mm
2 To inflammable surface at side 100mm 100mm 100mm
2 To flammable surface at side 250mm 250mm 250mm
3 To inflammable surface at the side/corner 100mm 100mm 100mm
3 To flammable surface at the side/corner 150mm 150mm 100mm
4 Hearth in front of stove 300mm 300mm 300mm
5 Fire proof area in front width 800mm 800mm 950mm
6 From opening edge of door to edge of hearth 150mm 150mm 150mm
7 Distance to furniture or draperies in front of stove 800mm 800mm 900mm
All installations surrounding flammable materials must not exceed 65°C.
Curtains and furnishings should be a minimum of 1m from the stove or the surface temperature and must not
exceed 65°C.
* When installed as a free standing appliance or in a pre-fabricated fireplace. All other applications must
conform to current constructional fireplace requirements per Building regulations with a constructional hearth.

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
6
Hearths
The stove should stand wholly above a hearth constructed of suitably robust materials and should be able to
accommodate the weight of the appliance and its unsupported flue components. The materials should conform
to local Building Regulations and British Standards.
If the stove is not to stand in an appliance recess, a hearth made of non-combustible board/sheet material or
tiles of at least 12mm thick may be used as long as the floor can accommodate the weight of the appliance
and its unsupported flue components. If it is installed on a wooden floor or similar, the floor must be covered
with a non-combustible material, a minimum of 12mm thick, to a distance of 300mm in front of the stove and
150mm to each side measuring from the closed door of the combustion chamber.
The Hwam range of wood and multifuel stoves have been tested and conform to standards DIN18891 and DIN
18891-A1 where the hearth temperature does not exceed 100°C
For further information on hearths of either glass, granite or slate visit our web site
www.euroheat.co.uk
Appliance independently tested to verify that the hearth temperature does not exceed 100°C
Non-combustable board
sheet material or tile
Combustible
material 300mm
12mm

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
7
Do not be tempted to fit the stove into an unsuitable fireplace. Beyond the requirements of Building
Regulations and access to facilitate servicing the stove, providing a setting which will compliment a stove is
not a luxury, it is the practicality of making the most of an investment. A good builder or fireplace specialist
will be able to transform even the most utilitarian of fireplaces. Whether altering its proportions to those of the
“Golden Mean” ideal, see below, or exposing a wooden or stone lintel or simply removing superfluous detailing
for a comparatively small cost, and the result will be a pleasure for many years.
“Golden Mean”
1. The stove must always stand perfectly level. Adjustment screws and/or triangular plastic levelling spacers
may be provided with the stove. The provision of a suitable level hearth within the recess is an important
consideration when planning a fireplace.
2. Sufficient space should be allowed for service work.
3. At least the minimum clearance from inflammable materials and conforming to the current Building
Regulations.
4. Sufficient space around the stove so that the controls may be operated without the risk of injury to the
operator.
5. Mounting brackets should be installed to facilitate the secure fitting of a fire guard, if one is to be fitted to
protect the young, elderly or infirm.
6. Curtains and soft furnishings should be a minimum of 1m from the stoves body or the surface temperature of
these furnishings must not exceed 65°C.
7. The mounting of expensive paintings, mirrors and plasma screen televisions above a fireplace is not
recommended.
Fireplace Design
1
2/3 2/3
1/3 2/3

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
8
Fresh Air System
Instead of letting the air from the room into the stove for combustion, it is possible to take in fresh air from
outside and introduce this directly via a duct into the back of the stove.
Today, many modern dwellings are so airtight to conform with building regulations that it is an advantage to
attach a fresh air intake to the stove. This continually supplies the air for combustion while the stove is in use
but as the air is ducted directly into the back of the stove it stops cold fresh air mixing with the warm air in the
room chilling the room or causing draughts.
This ensures that the air extracter fan outlets in the kitchen and bathroom function optimally without affecting
the air required for combustion. The advantage of this is that a multifuel stove may now be fitted into a room
where an air extracter fan is fitted, however a flue draught test must be carried out with the extracter fan
running at its maximum setting to ensure that the fan is not drawing air from the stove.
The 3310 and 3320 can be equipped with an optional fresh air system. Further information can be found in
the fresh air system’s instruction manual. If you wish to install a fresh air system on your stove, you have the
following options:
1) Stove mounted on the wall: connect the fresh air system on the lower back of the stove.
2) Stove mounted on a plinth: connect the fresh air system either on the lower back of the stove or on the back
of the plinth.
The HWAM 4410 can be equipped with an optional fresh air system. Further information can be found in the
fresh air system’s instruction manual. The following connection options are available:
1) Stove mounted on the wall: connect the fresh air system on the lower back of the stove.
2) Stove mounted on the wall: connect the fresh air system on the lower bottom of the stove.
3) Stove mounted on a plinth: connect the fresh air system either on the lower back of the stove or on the back
of the plinth.
5

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
9
Mounting Stove onto a Plinth
2
2
1
3
1
3310/3320 4410
When mounting your wood-burning stove on the wall or on a plinth, it must be placed a minimum of 100mm
above the ground, as measured from the lower edge of the stove.
Note: HWAM 3310 HWAM 3320 and HWAM 4410 must always be mounted on the wall or on a plinth.
Mount the plinth with the open side facing forwards at the location where the stove is to be placed. Place the
stove on top of the plinth so that the two guide pins (1) on top of the plinth fit into the two holes (2) in the
bottom of the stove, and the guide block (3) (3310 & 3320) fits into the hole (4) at the bottom rear edge of the
stove.

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
10
Wall Mounting
The Hwam 4410, 3320 and 3310 can be wall mounted with an optional wall hanging bracket. Full fitting
instructions are included with the hanging bracket.

© EUROHEAT DISTRIBUTORS (H.B.S) LTD. April 2008 E & OE Instructions Part number IN1198 Edition A
11
Door Lifting Mechanism
The door lift mechanism consists of a chain pull placed on either side of the stove and a spring placed beneath
the stove. Note: always let a professional grease and repair these parts.
Surface
Normally, additional surface treatment will not be required. However, damage to the coating may be repaired
with approved Hwam spray paint.
2
1
2
1
4
3
If the door opens with difficulty, you may correct
this by greasing the chain wheel boxes (1) and door
hinges (2) with copper grease. You should do this
once every year. Tighten the spring with a special
tool, which can be bought separately. Ask your local
HWAM dealer for assistance.
Hwam 3310 and 3320
If the door opens with difficulty, you may correct
this by greasing the chain wheel boxes (1) and door
hinges (2) with copper grease. You should do this
once every year. If the door slides too easily, the
spring has loosened. Tighten the spring with a special
tool, which can be bought separately. Ask your local
HWAM dealer for assistance.
Hwam 4410
