Hybrid+ HH3000 User manual

PAGE 1
USER MANUAL
HH3000
PROFESSIONAL
STAGE HAZE EFFECT

PAGE 1
WELCOME
Congratulations on the purchase of your HH3000 Hybrid Haze machine, engineered and
designed by Hybrid.
PRODUCT DESCRIPTION
The HH3000 is a flight case design Haze machine. The HH3000 is a powerful and easily
portable Haze machine, it reduces maintenance costs and creates a professional stage
Haze effect.
Features:
The HH3000 is a quiet machine, which is suitable for reduced noise environments, with a
noise level of ± 70dB
The HH3000 has a long operating time.
The HH3000 produces refined and dry Haze.
Low Haze fluid consumption. 1L of liquid can be used for 20 hours.
The HH3000 has a adjustable fan for both the angle and speed.
This machine has a leak proof bottle, that keeps the contents intact when transporting.
The HH3000 comes with a wireless remote control, that covers a distance of 150m.
Haze output is not adjustable.

PAGE 2
NOTES BEFORE USE
1. Place the Haze machine horizontally, and check whether it is damaged or not. If damaged
please contact the supplier at once. Unscrew the lid of the oil tank and pour in the Hybrid
Haze liquid, and then fasten the lid.
2. Before putting the power on, please verify that the power supply adheres to the rated
voltage of the Haze machine. The power supply should be connected to the ground socket.
When power is on, the indicator light will turn on, and the Haze machine will begin to work.
Connect the machine to the different controllers for different functions.
3. Initially, it is normal for the Haze machine to create some Haze or steam.
4. Place the Haze machine in a ventilated area, one may run the risk of the temperature fuse
over-heating and bursting, if kept in a confined area.
5. Place the Haze machine on the ground in a horizontally position. The Haze machine
should keep a minimum of 50cm radius away from people. Keep away from children, fire,
as well as flammables and explosive materials. Keep nozzle within a 40cm radius to
prevent scalding.
6. Continue adding liquid to avoid damage to the Haze machine’s pump and heater.
Turn off the power before adding liquid as overflowing may cause a short-circuit.
7. In the event of:
haze finishing
there is noise from pump
or the machine stops producing haze, please disconnect the power at once, and
check the liquid deposit, fuse, cable and power plug. If the problem is still not solved,
please contact the supplier.
8. Keep away from children. Do not add flammables such as oils or gas. Do not touch the wire
when the machine is running.
9. Moisture may collect around the nozzle of the machine. There may be some excess liquid
emitted from any Haze machine during activity or after shut down.
10.Please make sure there is no liquid and metals inside machine before turning on the
power each time. Do not modify or repair the machine by yourself.
If there is any problem, please contact the supplier.

USER MANUAL - HH3000 PROFESSIONAL STAGE HAZE EFFECT
PAGE 3
INTRODUCTION
Important environmental information about this product:
The symbol on this device indicates that disposal of the device after life-cycle could harm
thet environment.
Do not dispose of the device (or batteries) as unsorted municipal waste; it should be taken
to a specialised company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authority.
Thank you for choosing this machine. If the device was damaged in transit, do not install or
use, contact your dealer.
SAFETY INSTRUCTIONS
Be very careful during the installation: touching live wires can be life-threating.
Do not touch the device during activity as the casing heats up.
Keep this device away from rain and moisture.
Unplug the main lead before opening the casing.
Damage caused by disregarding certain guidelines in this manual, is not covered by the
warranty and the dealer will not accept responsibility for any deformity or problem.
It is recommended that a qualified technician do the installation and service
of this device.
Do not switch the device on immediately after it’s temperature has been changed.
Avoid damage by leaving it switched off until it has reached room temperature.
This device falls under protection CLASS 1. Have a qualified technician carry out
the electrical connection.
Make sure that the electrical supply voltage does not exceed the voltage stated in the
specifications of this manual.
Do not pinch the power cord. Have an authorised dealer replace it of necessary.

PAGE 4
GENERAL GUIDELINES
This device is designed for professional use on stages, in clubs, theaters, etc. The device
should only be used indoors with an alternating current of max 230V AC / 50Hz.
Do not shake the device. Avoid force when installing or operating the device.
Select a location where the device is protected against extreme heat, dust and moisture.
Familiarize yourself with the function of the device before actually using it. Do not allow
operation by unqualified people. Any damage that may occur is the user’s responsibility.
Use the original packaging if the device is to be transported.
All modifications of the device are forbidden for safety reasons.
Only use the device for its intended purpose. All other uses may lead to short circuits,
burns, electric shocks, etc. Using the device in an unauthorised way will void the warranty.
This device is not suited for permanent operation. Frequent activity breaks will protect the
lifespan of your Haze machine.
Disconnect the device from the electrical supply to clean it. Alternatively clean the smoke
machine when it is not in use. Handle the power cord by the plug only.
Do not switch the device on immediately after it has been exposed to extreme
temperature changes. Protect the device against damage by leaving it switched off until it
has reached room temperature.
Note that damage caused by user modification to the device is not covered by the warranty.
Keep the device away from children and unauthorised users.

USER MANUAL - HH3000 PROFESSIONAL STAGE HAZE EFFECT
PAGE 5
INSTALLATION GUIDELINES
Have the device installed by a qualified person, respecting EN 60598-2-17 and all
other procedures.
Install the device in a location with little traffic and that is inaccessible to
unauthorized persons.
Make sure there is no flammable material within a 50cm radius of the device.
Connect the device to the main electrical supply with the power socket.
The installation needs to be approved by an expert before the device is active or
taken into service.
Model HH3000
Voltage 220V AC / 50Hz
Power 750W
Current-limited safety device 5A at 220V or 10A at 120V
Smoke output 3 000Cu ft/min
Capacity of haze fluid tank 3.2L
DMX 2ch
Adjust the fan speed Supported
Adjust the fan angle Supported
Wireless Controller Supported
Gross weight 34.92kg
Packaging 485 x 365 x 240mm (including flight case)
TECHNICAL SPECIFICATIONS

PAGE 6
USE
HH3000 Operation
Place the Haze machine on a dry flat surface.
Add liquid carefully to the tank, and do not overfill. This device only uses Hybrid HZL -1
and HZL – 2
HZL-2 is higher density than HZL-1.
Plug the power cord into an electrical supply.
The device will take a couple of minutes to warm up. During this time the machine cannot
generate Haze.
WIRELESS CONTROL INSTRUCTION
There are two icons on the wireless controller.
=
“Lock”
=
Starts smoke Stops smoke
“Unlock”

USER MANUAL - HH3000 PROFESSIONAL STAGE HAZE EFFECT
PAGE 7
Once smoke machine has been turned on, the display board will show the words “read”
as well as the model of the machine.
Press the “Menu” button to choose your preferred setting.
The DMX control setting on this machine uses 2 channels. One for smoke output and the
other for the fan output.
Interval set: 1 - 255 seconds
Duration set: 1 - 255 seconds
Fan output: 1% to 100%
Language: English and Chinese
Attention: The HH3000 with automatically exit and save the data, after 10
seconds of it being idle.
HH3000
DMX Interval
Set Duration Set Fan Output Wireless Language

PAGE 8
PRODUCT WARRANTY INSTRUCTIONS
The warranty card and purchase invoice is required as Hybrid / distributors will require
documentary evidence when a warranty service is needed. Please keep your warranty
card in good condition.
Instructions:
Warranty period: maintenance free for one year (The warranty is valid from the
date of purchase.)
If the product does not use Hybrid liquid, the warranty period will be shorten
to three months. The cost of replacing spare parts will be the responsability
of the user.
The warranty is void when:
The device has been misused or incorrectly managed, e.g. blow fuses caused by
overload or the excess of voltage
The device has been damaged due to the transportation of it.
The machine is faulty due to poor use, e.g. moisture, unstable voltage etc.
The product has been altered by anyone other than a qualified Hybrid technician.
Exclusions: Packaging, casing and bracket of the product and battery inside
wireless remote controller.
Hybrid will not charge for the maintenance and spare parts of the product,
provided that it has remained within the guidelines of the user manual, as well as
with the terms of the warranty. In regard to the products which exceed their
warranty period, Hybrid will only charge for the cost of the spare parts accordingly.
Hybrid reserves the right of final explanation for the content of the warranty card.
If there is anything unclear, please contact the dealer.

USER MANUAL - HH3000 PROFESSIONAL STAGE HAZE EFFECT
PAGE 9
WARRANTY CARD
Model:..................................................................................................................................................
Name:..................................................................................................................................................
Date of purchase:.................................................................................................................................
Dealer name:.......................................................................................................................................
Address of dealer: ....................................................... Province:.......................................................
NOTE: Fill out the warrant card clearly so that we can assist you. Please send back the
machine with warranty card for repairs.
RECORD CARD FOR MAINTENANCE
Maintenance Indicator (for user):......................................................................................................
Maintenance time (for Manufacturer):..............................................................................................
Fault (for Manufacturer):....................................................................................................................
Maintenance Indicator (for user):......................................................................................................
Maintenance time (for Manufacturer):..............................................................................................
Fault (for Manufacturer):....................................................................................................................
Maintenance Indicator (for user):......................................................................................................
Maintenance time (for Manufacturer):..............................................................................................
Fault (for Manufacturer):....................................................................................................................
