Hybrid+ HMH100B User manual

User Manual
Please read the instructions carefully before use

1A
TABLE OF CONTENTS
1. Safety Instructions
2. Technical Specifications
3. Installation
4. How to set the unit
5. How to control the fixture
6. DMX512 Configuration
7. DMX512 Connections
8. Trouble shooting
9. Fixture Cleaning

2A
1. Safety Introductions
WARNING
Please keep this User Manual for future consultation. If you sell the fixture to another
user, be sure that they also receive this instruction booklet.
Unpack and check carefully there is no transportation damage before using the fixture.
Before operating, ensure that the voltage and frequency of power supply match the
power requirements of the fixture.
It’s important to ground the yellow/green conductor to earth in order to avoid electric
shock.
Disconnect main power before servicing and maintenance.
Use safety chain when fixes this fixture. Don’t handle the fixture by taking its head only,
but always by taking its base.
Maximum ambient temperature is Ta : 40℃. Don’t operate it where the temperature is
higher than this.
In the event of serious operating problem, stop using the fixture immediately. Never try
to repair the fixture by yourself. Repairs carried out by unskilled people can lead to
damage or malfunction. Please contact the nearest authorized technical assistance
center.Always use the same type spare parts.
Do not connect the device to any dimmer pack.
Do not touch any wire during operation and there might be a hazard of electric shock.
To prevent or reduce the risk of electrical shock or fire, do not expose the fixture to rain
or moisture.
The housing must be replaced if they are visibly damaged.
Do not look directly at the LED light beam while the fixture is on.
Warning
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or
moisture.
Do not open the unit within five minutes after switching off.
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly
damaged.
Please read the instructions carefully which includes important
information about the installation, operation and maintenance.

3A
Caution
There are no user serviceable parts inside the fixture. Do not open the housing or attempt
any repairs yourself. In the unlikely situation, your unit may require service, please contact
your nearest dealer.
2. Technical Specifications
●11 and 13 DMXchannels
●Pan : 540degree Tilt : 270degree
●4 Operational Modes: DMX, Master/Slave, auto , soundactivated
●
Gobo wheel : 11 static gobos + open
●Color wheel: 9 fixed colors + White
●Prism : 8 facet prism with rotation
●Light Source: 1x80W Ultra Brightness White LED
●Power supply: 100 - 240Vac, 50-60Hz
●Power consumption: 120 W
●Dimensions Size: L236×W 172×H363mm
●Net Weight: 6.14kg
3. Installation
The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is
firmly fixed to avoid vibration and slipping while operating. Always ensure that the structure
to which you are attaching the unit is secure and is able to support a weight of 10 times of
the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the
unit when installing the fixture. The equipment must be fixed by professionals. And it must
be fixed at a place where is out of the touch of people and has no one pass by or under it.
4. How To Set The Unit
Turn on the unit, press the MENU button to go into menu mode and press the
UP/DOWN button until the required function is shown on the monitor. Select the
function by the ENTER button. Use the UP/DOWN button to choose the submenu,
press the ENTER button to store and automatically return to the last menu.

5A
4.1 Main Function Chart
Display Value Noted
DmxAddr 001- 512 DMX address select
WorkMod
DMX512 DMX Mode
AUTO Auto Mode
SOUND Sound Mode
MS
MS Mode
Master Master Mode
Slave Slave Mode
ChanMod 11Ch 11channels Mode
13Ch 13 channels Mode
Control CH01-CH45 Manual control Mode
Tool
Display ON LCD Display ON
60S LCD Display Off after 60s no operate
SundHig 0-32 Sound sensitive
IR SW
OFF Remote turn off
YES Remote turn on
MotorST
ColrREV 0-255
GoboREV 0-255
PrimREV 0-255
FousREV 0-255
Pan REV 0-255
TiltREV 0-255
Xreverse NO Pan Forward
YES Pan Reverse
Yreverse NO Tilt Forward
YES Tilt Reverse
Xyfbstin NO XY Optical Coupling Closed
YES XY Optical Coupling Open
Info
Version Software Version
RDM UID UID Code
Runtime Units: hours
Rest
NO
YES Reset

6A
4.1 Address Setting
If you use a universal DMX controller to control the units, you have to set the DMX
address from 1 to 512 so that the units can receive DMX signal.
Press the MENU button to enter menu mode, select DMX Functions. Press the ENTER
button to confirm, use the UP/DOWN button to select DMX Address. Press the ENTER
button to confirm. The present address will blink the display, use the UP/DOWN button
to adjust the address from 001 to 512. Press the ENTER button to store. Press the
MENU button back to the last menu or idling let the unit idle one minute to exit menu
mode.
Please refer to the following table to address your DMX512 channel for the first 4 units.
Channel
mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
11channels
1
12
23
34
13channels
1
14
27
40

7A
5. DMX512 Configuration
11CH
13CH
Value
Function
1
1
0-255
Pan
2
0-255
Pan fine
2
3
0-255
Tilt
4
0-255
Tilt fine
3
5
0-255
Pan/Tilt speed from fast to slow
4
6
0-4
Reserved
5-255
Mater Dimmer
5
7
0-19
Shutter Closed
20 -49
Shutter Open
50- 64
Strobe-effect from fast to slow
65-69
Shutter Open
70 -84
Strobe-effect from fast off to slow open
85 -89
Shutter Open
90 -104
Strobe-effect from fast open to slow off
105 -109
Shutter Open
110-124
Random Pluse Strobe-effect
125-129
Shutter Open
130-144
Random Strobe-effect
145-149
Shutter Open
150-164
Random Strobe-effect
165-169
Shutter Open
170-184
pulse strobe-effect from fast to slow
185-189
Shutter Open
190-204
pulse strobe-effect from slow to fast
205-209
Shutter Open
210-224
Strobe-effect from slow to fast
225-229
Shutter Open
230-244
Strobe-effect by Continual positioning
245 -255
Shutter Open

8A
6 8
0 -127 Continual positioning
128 -130 Colour half
131 -133 Color 1
134 -136 Colour half
137 -139 Color 2
140 -142 Colour half
143 -145 Color 3
146 -148 Colour half
149 -151 Color 4
152 -154 Colour half
155 -157 Color 5
158 -160 Colour half
161 -163 Color 6
164 -166 Colour half
167 -169 Color 7
170 -172 Colour half
173 -175 Color 8
176 -178 Colour half
179 -181 Color 9
182 -184 Colour half
185 -194 White
195 - 219 Forwards rainbow effect from fast to slow
220 -224 No rotation (White)
225 -249 Backwards rainbow effect from slow to fast
250 -255 Colour Macro
7 9
0 - 4 Open
5 - 9 Gobo 1
10 -14 Gobo 2
15 -19 Gobo 3
20 - 24 Gobo 4
25- 29 Gobo 5
30 -34 Gobo 6

9A
35 -39 Gobo 7
40-44 Gobo 8
45-49 Gobo 9
50-54 Gobo 10
55-59 Gobo 11
60-64 Open
65-74 Gobo 1 Shake
75-84 Gobo 2 Shake
85-94 Gobo 3 Shake
95-104 Gobo 4 Shake
105-114 Gobo 5 Shake
115 -124 Gobo 6 Shake
125 -134 Gobo 7 Shake
135 -144 Gobo 8 Shake
145 -154 Gobo 9 Shake
155-159 Gobo 10 Shake
160-174 Gobo 11 Shake
175 -179 No rotation (open)
180 -204 Forwards gobo wheel rotation from fast to slow
205 -214 No rotation (Stop)
215 -239 Backwards gobo wheel rotation from slow to fast
240 -255 Gobo Macro
8 10
0 -15 Open
16 -127 Prism indexing
128 -255 Prism Counter-clockwise rotation slow to fast
9 11 0 -255 Focus Continuous adjustment from far to near
10
Macro
function
12
0 -19 Custom Control by CH1-CH9 / CH1-CH11
20 -99 Auto (all of other CH invalid)
100-199 Sound (all of other CH invalid)
200-255 Custom Control by CH1-CH9 / CH1-CH11
11 13 0 -249 Custom Control by CH1-CH10 / CH1-CH12
250-255 Reset

10
A
6. DMX512 Connections
The DMX512 is widely used in intelligent lighting control, with a maximum of 512 channels.
1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin
adapter-cable.
2. Connect the fixture together in a “daisy chain” by XLR plug cable from the output
of the fixture to the input of the next fixture. The cable cannot be branched or
split to a “Y” cable. Inadequate or damaged cables, soldered joints or corroded
connectors can easily distort the signal and shut down the system
3. The DMX output and input connectors are pass-through to maintain the DMX
circuit when one of the units’ power is disconnected.
4. At last fixture, the DMX cable has to be terminated with a terminator to reduce
signal errors. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin
3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last fixture.
5. Each lighting fixture needs to have an address set to receive the data sent by
the controller. The address number is between 0-511 (usually 0 & 1 are equal to
1).
6. 3 pin XLR connectors are more popular than 5 pin XLR.
3 pin XLR: Pin1: GND, Pin2: Negative signal (-), Pin3: Positive signal (+)
5 pin XLR: Pin1: GND, Pin2: Negative signal (-), Pin3: Positive signal (+)
Pin4/5: Not Used.
7.Troubleshooting
Following are a few common problems that may occur during operation. Here are some
suggestions for easy troubleshooting:
A. The fixture does not work, no light
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.

11
A
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly.
2. If the DMX LED is on and no response to the channel, check the address settings and DMX
polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of the
fixture or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage cables that may cause
damage or interference to DMX interface circuit.
C. Some fixtures don’t respond to the easy controller
1. You may have a break in the DMX cabling. Check the LED for the response of the master/
slave mode signal.
2. Wrong DMX address in the fixture. Set the properaddress.
D. No response to the sound
1. Make sure the fixture does not receive DMX signal.
2. Check microphone to see if it is good by tapping the microphone.
9. Fixture Cleaning
The cleaning of internal must be carried out periodically to optimize light output. Cleaning frequency
depends on the environment in which the fixture operates: damp, smoky or particularly dirty
surrounding can cause greater accumulation of dirt on the fixture’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60
days.
