Hydac VibrationSensor VS 3000 Quick start guide

VS 3000
VibrationSensor
Operation and Installation Guide
English (translation of original instructions)
Documentation no.: 4443496a

Content
VS 3000
en-US
Page 2 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Content
Content ..........................................................................................................2
General ..........................................................................................................4
Imprint..........................................................................................................4
Documentation Representative ...................................................................4
Purpose of this manual................................................................................4
Target group of the manual .........................................................................5
Target group - Required qualifications/training............................................6
Illustrations in the manual............................................................................7
Illustration on the title page ......................................................................7
Illustration of the layout ............................................................................8
Representation of requirements...............................................................8
Representation of procedural instructions................................................9
Representation of warning/general safety information .............................9
Signal words and their meaning in the general safety information .........10
Representation/explanation of pictograms.................................................10
Supplementary symbols ............................................................................12
Exclusion of liability/warranty.....................................................................12
Notes on copyright.....................................................................................12
Validity of this manual................................................................................12
General Safety Information........................................................................13
Product overview........................................................................................18
Scope of delivery.......................................................................................19
Scope of delivery for VS3x10 and VS3x20.............................................19
Scope of delivery for VS3x11 and VS3x21.............................................19
Dimensions................................................................................................20
Dimensions VS3xx0-x-x-0/-xxx...............................................................20
Dimensions VS3xx0-x-x-1/-xxx...............................................................20
Dimensions VS3xx1-x-x-0/-xxx...............................................................21
Dimensions VS3xx1-x-x-1/-xxx...............................................................21
Proper/designated use...............................................................................22
Improper use or use deviating from intended use......................................24
Technical Data...........................................................................................25
Decoding the model code label .................................................................28
Model code.............................................................................................29
Storage and transport ................................................................................30
Assembly, installation and commissioning..............................................31
Mechanical installation/assembly ..............................................................31
Selecting an appropriate assembly point...................................................31
Selecting the appropriate assembly method..............................................32

Content
VS 3000
en-US
Page 3 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Preparations for assembly.........................................................................34
Required tools........................................................................................36
Sensor assembly, screwed.....................................................................38
Sensor assembly by means of adhesive adapter...................................39
Sensor assembly by means of magnetic adapter...................................42
Electrical Installation..................................................................................44
Plug pin assignment...............................................................................44
Wire up the sensor.................................................................................45
Factory settings..........................................................................................45
Operation.....................................................................................................46
Reading out measured values...................................................................46
FluMoS expert –Fluid Monitoring Software ...........................................46
Evaluating measured values......................................................................47
FluMoS expert software enhancement –vibration analysis
module ...................................................................................................47
Maintenance................................................................................................49
Calibrating the sensor................................................................................49
Customer Service / Service.......................................................................49
Troubleshooting/fault rectification............................................................50
Removing / Disposal...................................................................................51
Appendix .....................................................................................................52
Spare Parts and Accessories ....................................................................52
Glossary ......................................................................................................53
Absolute sensor.........................................................................................53
Bias voltage...............................................................................................53
CREST factor (crest factor) .......................................................................53
Thickness oscillator (principle of compression) .........................................53
Effective value of a vibration (RMS) ..........................................................53
Frequency analysis....................................................................................54
Pulse signal (envelope) .............................................................................54
HYDAC Machine Condition Monitoring System MCMS 2000....................54
IEPE (Integrated Electronics Piezo-Electric)..............................................54
Mass spring system...................................................................................54
Piezo element / piezo electrical effect........................................................55
Damage frequencies .................................................................................55
Shear oscillator (shearing principle) ..........................................................55
Seismic mass ............................................................................................55
Peak-to-peak value (Peak-to-Peak)...........................................................55
Index ............................................................................................................56

General
VS 3000
en-US
Page 4 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
General
In this chapter, you will find helpful notes on handling these instructions.
Imprint
Publisher and responsible for the content:
HYDAC FILTER SYSTEMS GMBH
Postfach 1251
66273 Sulzbach / Saarland
Germany
Phone:
[phone]
Fax:
[phone]
E-mail:
[email protected]
Homepage:
www.hydac.com
Court of Registration:
Saarbrücken, HRB 17216
Executive directors:
Mathias Dieter,
Dipl.Kfm. Wolfgang Haering
Documentation Representative
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280 Sulzbach / Saar
Phone:
[phone]
Fax:
[phone]
E-mail:
[email protected]
Purpose of this manual
Read this manual before using the product for the first time or if you are assigned
other work on the product.
The use and handling of the product described below, as well as its operation, are
not self-explanatory and are described in detail in this manual and the associated
technical documentation.
This manual will help you to use the product as intended, properly, effectively, and
safely. Therefore, please read the following chapters attentively and carefully. Please
refer to it every time you require decisive details.

General
VS 3000
en-US
Page 5 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
This manual informs and warns you of risks, against which the risk reduction through
the design and protective measures may not be effective or not fully effective.
Target group of the manual
This manual was created for the following target group.
Target group
Tasks
Owner
This manual and the associated documents must be kept
accessible at the installation location of the product and
also for later use.
Ask the employees to read and follow the manual and the
documents delivered along with it, in particular, the safety
and warning instructions.
Observe the additional product-related instructions and
requirements.
Specialist
personnel
Read, observe and follow this manual and the associated
documents, in particular, the safety and warning
instructions.

General
VS 3000
en-US
Page 6 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Target group - Required qualifications/training
Persons who work on the product must be aware of the hazards associated with its
use.
These operating instructions are intended for:
Auxiliary personnel: such persons have been instructed about the sensor and are
aware of potential hazards due to improper use.
Specialist personnel: such persons with corresponding specialist training and
several years' work experience. They are able to assess and perform the work
assigned to them, they are also able to recognize potential dangers.
Activity
Person
Knowledge
Transport / storage
Forwarding
agent
Auxiliary
personnel
No specialist knowledge
required
Electric installation,
Mechanical installation
First commissioning,
Maintenance
Troubleshooting
Decommissioning
Specialist
electrician
Mechanics
specialist
Safe handling/use of tools
Fitting and connection of
electrical lines,
Knowledge with regards to
product related measuring
system and measuring cards
Product-specific knowledge
Operation
Operations control
Specialist
Product-specific knowledge
Dismantling, disposal
Specialist
Proper and environmentally-
friendly disposal of materials
and substances.
Knowledge on recycling.

General
VS 3000
en-US
Page 7 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Illustrations in the manual
Illustration on the title page
You will find the following information on the title page of this manual:
1
Short name of the product / product name
2
Type of document
3
Language
4
Document no./Index Date of printing
5
Supplementary instructions regarding the validity of the manual
(optional)

General
VS 3000
en-US
Page 8 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Illustration of the layout
de
HYDACFiltertechnikGmbH
BeWa123456ade
Seite x
Produkt/Kapitel
200x-xx-xx
The documentation number with its index enables you to order another copy of the
operating and maintenance instructions. The index is incremented every time the
manual is revised or changed.
Note that the method described for locating specific information
does not release you from your responsibility of carefully reading
all these instructions prior to starting the unit up for the first time
and at regular intervals in the future.
The manual contains a table of contents, an index and a glossary.
Representation of requirements
These are absolutely required for carrying out a work activity on the product, are
marked with a check mark and are in bold in the text.
Example for the presentation of the prerequisites:

The product is assembled and connected

The product is switched off
Chapter description
Page number
Edition date
Document language
Documentation no.
with index/
file name

General
VS 3000
en-US
Page 9 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Representation of procedural instructions
There are these two following representations in the case of procedural instructions:
Procedural instructions with a fixed sequence
Procedural instructions, whose sequence must be complied with without fail are listed
with sequential numbering (1., 2., 3., etc.).
An example for procedural instructions with a fixed sequence:
1. Remove the transport securing device.
2. First fill the product.
3. Switch the product on.
Procedural instructions with a random sequence
Procedural instructions that have a random sequence are listed as bullet points (-).
An example of a procedural instruction with a random sequence:
- Clean the display
- Rinse the product
Representation of warning/general safety information
All the warning / general safety information in this manual are highlighted with
pictograms and signal words. The pictogram and the signal word indicate the severity
of the danger.
Warning/general safety information is listed before an activity and is laid out as
follows.
HAZARD SYMBOL
SIGNAL WORD
Type and source of danger
Consequence of the danger
►Measures to avert danger

General
VS 3000
en-US
Page 10 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Signal words and their meaning in the general safety information
In these instructions you will find the following signal words:
DANGER
DANGER –The signal word indicates a hazardous situation with a high level
of risk, which, if not avoided, will result lethal or serious injury.
WARNING
WARNING –The signal word indicates a hazardous situation with a medium
level of risk, which, if not avoided, can result lethal or serious injury.
CAUTION
CAUTION –The signal word indicates a hazardous situation with a low level
of risk, which, if not avoided, can result in minor or moderate injury.
NOTICE
NOTICE –The signal word indicates a hazardous situation with a high level
of risk, which, if not avoided, will result in damage to property.
Representation/explanation of pictograms
The following are the safety symbols / pictograms in this manual. They indicate
specific dangers to persons, property or to the environment. Observe these safety
symbols / pictograms and act with particular caution in such cases. Always keep all
symbols / pictograms intact and legible.

General
VS 3000
en-US
Page 11 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Warning signs used
These signs are listed for all general safety information and instructions in these
operating instructions which indicate particular dangers to persons, property or the
environment.
General hazard
Dangerous electrical voltage warning.
Hot surface warning.
Signs used for giving orders
These symbols are listed for all general safety information and instructions in these
operating instructions which indicate particular dangers to persons, property or the
environment.
Follow the instructions.
Signs used for the required specialist personnel
These symbols show the required training/knowledge for installation work and/or
maintenance work.
Specialist personnel - Electrical
Such persons have specific specialist training and several
years' work experience. They are able to assess and
perform the work assigned to them, they are also able to
recognize potential dangers.
Specialist personnel - Mechanical
Such persons have specific specialist training and several
years' work experience. They are able to assess and
perform the work assigned to them, they are also able to
recognize potential dangers.

General
VS 3000
en-US
Page 12 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Supplementary symbols
You will find the following symbols in the manual as additional details:
Tip for handling the product
Required tools
Exclusion of liability/warranty
For the warranty provided by us, please refer to our terms of delivery. They are made
available to you at the conclusion of the contract at the latest. In addition, you will find
these under www.hydac.com -> General terms and conditions.
This manual was prepared to the best of our knowledge. Nevertheless and despite
the greatest care, it cannot be excluded that mistakes could have crept in. Therefore
please understand that, in the absence of any provisions to the contrary hereinafter,
our warranty and liability –for any legal reasons whatsoever –are excluded in
respect of the information in these instructions. In particular, we shall not be liable for
lost profit or other financial loss.
This exclusion of liability does not apply in cases of intent and gross negligence.
Moreover, it does not apply to defects which have been deceitfully concealed or
whose absence has been guaranteed, nor in cases of culpable harm to life, physical
injury and damage to health. If we negligently breach any material contractual
obligation, our liability shall be limited to foreseeable damage. Claims due to the
Product Liability shall remain unaffected.
Notes on copyright
All rights to this documentation, in particular to the right to reproduction and
distribution, as well as to the translation, are property of HYDAC FILTER SYSTEMS
GMBH.
Distributing and copying this document and utilizing and disclosing its content is not
permitted, except where this has been agreed upon explicitly. Any infringement will
entail liability for damages. All rights reserved in the case of a patent being granted or
a utility model or the design being registered.
Validity of this manual
The diagrams and visualizations in this manual are meant for general illustration
purposes. Therefore, representations and functional options can deviate from those
of the delivered product.
We reserve the right to changes to the contents of this manual without prior notice.

General Safety Information
VS 3000
en-US
Page 13 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
General Safety Information
The following residual risks can occur through intended use:
NOTICE
Impermissible operating media
The sensor will be destroyed
►Only use the sensor with mineral oils or mineral oil-based raffinates
when assembling in fluid.
►Do not use the sensor in environments with aggressive or explosive
media.
NOTICE
Faulty mechanical installation on the machine
No or faulty signals
►Ensure that the mechanical connection between the sensor and the
machine to be monitored is strong and as rigid as possible. Use the
appropriate assembly material for assembling the sensor. Amongst
others, this is available as an accessory with HYDAC.
NOTICE
Exceeding the maximum permissible line length
Erroneous or no communication
►Observe the maximum permissible line lengths.

General Safety Information
VS 3000
en-US
Page 14 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
NOTICE
Impermissible operating conditions
No/faulty signals or the sensor is destroyed
►Operate the sensor within the technically permissible conditions only.
►Observe the basis expansion of the measuring object
(for example, temperature-based expansion).
►Do not use the sensor at high or low temperatures outside the
specified operating and storage conditions.
►Avoid major sudden changes in temperature.
►Avoid a high ambient humidity if assembled within the fluid (suitable
sensor type required).
►Avoid shock loads outside of the technically permissible conditions.
►Avoid high sound level outside the technically permissible conditions.
►Do not use the sensor in a radiating environment.
►Do not use the sensor around strong electromagnetic fields.
►Do not use the sensor in environments with aggressive or explosive
media.
►Only use the sensor with mineral oils or mineral oil-based raffinates
when assembling in fluid.
►Avoid side rocking during operation.
►Ensure that the assembly is correct and firm.
NOTICE
Unsafe transport
The connection plug or the connecting cable will be damaged
►Transport the sensor in its original packaging.
►Secure the sensor during transport.

General Safety Information
VS 3000
en-US
Page 15 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
NOTICE
Improper storage
The sensor will be damaged
►Store the sensor in its original packaging at a clean and dry place.
►Do NOT store the sensor at locations with extreme temperatures,
high humidity, close to magnetic fields or in locations with strong
vibrations or impact loading (shocks).
NOTICE
Improper installation and treatment
The sensor is damaged and is limited in its function
►Do not let the sensor fall and do not use it for non-applicable and non-
operating purposes (for example as a climbing aid).
►Ensure that the limits of operating temperature are maintained
according to the technical data.
►The wiring of the sensor should be correct and in keeping with this
manual.
►Install the sensor as close as possible to the vibration source or
component to be monitored and ensure a clean, smooth, flat
mounting surface that is larger than the contact surfaces of the
vibrations sensor.
►Use the specified connection and cable. Keep the wiring away from
power supply and control and bus lines respectively.
►Do not make any structural changes to the sensor; this will void the
warranty.
►Do not disassemble the sensor in hazardous areas (unless it is
permitted for operating in hazardous areas) and do not use any
sensor with a damaged housing.

General Safety Information
VS 3000
en-US
Page 16 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
NOTICE
Use of assembly adapters
The sensor has a limited function and signal quality
►The use of assembly adapters results in a less favorable mechanical
coupling of the vibrations sensor to the machine to be monitored. This
causes a restricted signal quality of the vibration to be measured –
primarily in the upper frequency area.
►The use of assembly adapters can lead to the fact that certain
anomalies in the vibration characteristics of machines and the
machine elements to be monitored are detected late or cannot be
detected at all.
►HYDAC explicitly recommends assembling the vibrations sensors as
a threaded connection.
NOTICE
Design specific use of assembly adapters
Design-related limitations during the sensor assembly
►A sensor assembly by means of adhesive adapter is not possible for
the "side entry" design.

General Safety Information
VS 3000
en-US
Page 17 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
NOTICE
Use of magnet adapters
The sensor has a limited function and signal quality
►An incorrect handling of assembly adapters can strongly damage the
vibrations sensor and limit its function and signal quality. This is valid
especially in case of excessive tightening torque and shocks, such as
e.g. may occur when placing the magnet adapters carelessly
(mechanical "snapping").
►Magnet adapters without ridges are not suitable for use/mounting on
curved surfaces.
►Permanent magnets of magnet adapters occasionally develop strong
magnetic fields and are to be kept away from items and instruments
which are influenced by them.
NOTICE
Improper wiring/electrical connection of sensors
The sensor has a limited function and signal quality
►A cable length of 300 meters between electronic evaluation unit (e.g.
HYDAC MCMS 2000) and vibrations sensor should not be exceeded,
as an excessive length of cable can limit the signal quality (frequency
response) of system.
►Keep the sensor cable away from power lines and signal lines to
prevent errors in sensor signal (e.g. from noise).
►Avoid excessive bending, twisting, snapping, knotting and straining
the sensor cable so as not to damage it. The recommended minimum
bending radius of 80 mm is mandatory.
►Protect the cable form external, mechanical and thermal influences,
e.g. by using the cable ducts and heat protection sheets.

Product overview
VS 3000
en-US
Page 18 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Product overview
The HYDAC VibrationSensor VS 3000 is an industrial sensor for recording the
vibration acceleration of system and machines. The piezo-based measurement
procedure, in combination with a suitable signal evaluation unit such as the HYDAC
Machine ConditionMonitoring System MCMS 2000 or the standard vibration
measuring systems and modules with signal inputs for IEPE accelerometers (IEPE =
Integrated Electronics Piezo Electric), enables an early detection of damage to
rotating machine elements (for example roller bearings, gear tooth systems –such as
in gear pumps or gear units) as well as misalignment (for example misaligned belt
transmission), imbalance (for example, missing rotor blade in fans) or an absent
fixing of machines (for example loose bolted connections between machines and
machine base).
The special features of HYDAC VibrationSensor VS 3000 are as follows:
Wide industry and application focus
Compact design
Direct connection to HYDAC Condition Monitoring Systems using M12x1
plug connector
Simple connection to commercially available vibration measurement
systems or modules thanks to IEPE technology
Also suitable for assembly in fluids (immersed assembly) thanks to a high
protection class and variants with integrated, oil-resistant cable
Also available as a premium variant with lower sensitivity to cross
acceleration

Product overview
VS 3000
en-US
Page 19 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Scope of delivery
Scope of delivery for VS3x10 and VS3x20
The HYDAC VibrationSensor VS3x10 as well as the VS3x20 are delivered in a
packaged and ready for use state. Before commissioning the unit, check the contents
of the package to make sure everything is present.
The following items are included in the scope of delivery:
Qty
Designation
1
HYDAC VibrationSensor VS3x10 or VS3x20 with connector
plug or integrated connecting cable
1
Stud bolts set comprising stud bolts with threads:
¼“-28 UNF on ¼“-28 UNF, ¼“-28 UNF on M6 (already pre-
assembled in sensor), ¼“-28 UNF to M8
1
Technical documentation, consisting of:
- Brief instruction VS 3000 series
Scope of delivery for VS3x11 and VS3x21
The HYDAC VibrationSensor VS3x11 as well as the VS3x21 are delivered in a
packaged and ready for use state. Before commissioning the unit, check the contents
of the package to make sure everything is present.
The following items are included in the scope of delivery:
Qty
Designation
1
HYDAC VibrationSensor VS3x11 or VS3x21 with connector
plug or integrated connecting cable
1
Technical documentation, consisting of:
- Brief instruction VS 3000 series

Product overview
VS 3000
en-US
Page 20 / 60
BeWa VS3000 4443496a V1-1 en-us 2019-10-22.docx
2019-10-22
Dimensions
Dimensions VS3xx0-x-x-0/-xxx
All dimensions in mm.
Dimensions VS3xx0-x-x-1/-xxx
All dimensions in mm.
