Hypercom S9 User manual

S9 PIN Pad
Connector Cord
P/N 810022-010 (6 ft)
or
P/N 810022-009 (15 ft)
Installation
Insert the end of the PIN pad
connector cord into the
Hypercom POS terminal port
labeled PIN.
Eq ipment Check List
S9 Installation G ide
Connector cord
PIN port
Compliance
This equipment is compliant with the following
 FCC Part 15 (ICES-003)  EN60950
 CISPR-22  EN55022
 EN55024
World Headq arters
2851 West Kathleen Road  Phoenix, AZ 85053
Tel [phone]
 877.HYPERCOM within USA  Fax [phone]
e-mail [email protected]
 web www.hypercom.com
© Hypercom Corporation, 2004. All rights reserved. Hypercom, the Hypercom logo are registered trademarks of Hypercom
Corporation. All other products or services mentioned are trademarks, service marks, registered trademarks or registered service
marks of their respective owners.
40414-002 Rev. C 04/04
