IBASE Technology CSB200-822 User manual

CSB200-822
Fanless System with
3.5” Disk-Size SBC
User’s Manual
Version 1.0
(Feb. 2019)

ii
CSB200-822 User Manual
Copyright
©2019 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

CSB200-822 User Manual
iii
Compliance
This product has passed CE tests for environmental specifications and limits. This
product is in accordance with the directives of the Union European (EU). If users
modify and/or install other devices in this equipment, the CE conformity declaration
may no longer apply.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS restrictions and
prohibits use of the following substances in concentrations exceeding
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by
weight (100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
CSB200-822 User Manual
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
•Lay the device horizontally on a stable and solid surface in case the device may
fall, causing serious damage.
•Make sure you leave plenty of space around the device for ventilation.
•Use this product in environments with ambient temperatures 0˚C ~ 50˚C for SSD,
and 0˚C ~ 45˚C for HDD.
•Do not leave this device in an environment where the storage temperature may
go below -40˚C or above 85˚C. This could damage the device. The device must
be used in a controlled environment.
Care for your IBASE products:
•Before cleaning the device, turn it off and unplug all cables such as power in case
a small amount of electrical current may still flow.
•Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
•Vacuum the dust with a computer vacuum cleaner to prevent the air vent or slots
from being clogged.
WARNING
Attention during use:
•Do not use this product near water.
•Do not spill water or any other liquids on your device.
•Do not place heavy objects on the top of the device.
•Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local
power company.
•Do not walk on the power cord or allow anything to rest on it.
•If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
Do not disassemble, repair or make any modification to the device. Disassembly,
modification, or any attempt at repair could generate hazards and cause damage to
the device, even bodily injury or property damage, and will void any warranty.

CSB200-822 User Manual
v
CAUTION
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, memory, HDD, power adapter, panel
and touchscreen.
＊PRODUCTS, HOWEVER, THAT FAILS DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any further assistance from your distributor or sales representative,
prepare the following information of your product and elaborate upon the
problem.
•Product model name
•Product serial number
•Detailed description of the problem
•The error messages in text or in screenshots if there is any
•The arrangement of the peripherals
•Software in use (such as OS and application software, including the version
numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi
CSB200-822 User Manual
Table of Contents
Compliance....................................................................................................iii
Important Safety Information.......................................................................iv
WARNING ......................................................................................................iv
CAUTION ........................................................................................................v
Warranty Policy..............................................................................................v
Technical Support & Services ......................................................................v
Chapter 1 General Information................................................................1
1.1 Introduction.............................................................................................2
1.2 Features..................................................................................................2
1.3 Packing List ............................................................................................3
1.4 Optional Accessories ..............................................................................3
1.5 Specifications..........................................................................................4
1.6 Overview.................................................................................................6
1.7 Dimensions.............................................................................................7
Chapter 2 Hardware Configuration.........................................................8
2.1 Installations.............................................................................................9
2.1.1 Memory Installation / Replacement...........................................9
2.1.2 M.2 Card Installation / Replacement.......................................10
2.1.3 HDD/SSD Installation / Replacement......................................11
2.1.4 M.2 Card Installation...............................................................12
2.1.5 WiFi / 3G / 4G Antenna Installation.........................................12
2.1.6 Mounting Installation...............................................................13
2.1.7 Pinout for COM Ports & DC Power Connectors......................14
2.2 Setting the Jumpers..............................................................................16
2.2.1 How to Set Jumpers ...............................................................16
2.3 Jumper & Connector Locations on Motherboard...................................17
2.4 Jumpers Quick Reference.....................................................................18
2.4.1 LVDS Panel Brightness Selection (JP1)...............................18
2.4.2 LVDS Panel Power Selection (JP2) .....................................19
2.4.3 eDP Panel Power Selection (JP3)........................................19
2.4.4 eDP / LVDS Panel Selection (JP4).......................................20
2.4.5 Clearing CMOS Data (JP5)..................................................20

CSB200-822 User Manual
vii
2.4.6 Clearing ME Register (JP6)..................................................21
2.4.7 ATX / AT Power Selection (JP8) ..........................................21
2.5 Connectors Quick Reference................................................................22
2.5.1 eDP Connector (CN1)..........................................................23
2.5.2 LCD Backlight Connector (J2)..............................................24
2.5.3 LVDS Connector (J1, J3) .....................................................24
2.5.4 Audio Connector (J4)...........................................................25
2.5.5 USB 2.0 Connector (J8).......................................................25
2.5.6 Amplifier Connector (J6) ......................................................26
2.5.7 SATA HDD Power Connector (J11) .....................................26
2.5.8 Front Panel Connector (J13)................................................27
2.5.9 Digital I/O Connector (J19)...................................................28
2.5.10 DC Power Input Connector (J20) .........................................28
2.5.11 Battery Connector (BAT1)....................................................29
Chapter 3 Driver Installation .................................................................30
3.1 Introduction...........................................................................................31
3.2 Intel®Chipset Software Installation Utility..............................................31
3.3 Graphics Driver Installation...................................................................33
3.4 HD Audio Driver Installation..................................................................34
3.5 Intel®Trusted Execution Engine Drivers Installation..............................35
3.6 Intel®Serial I/O Drivers .........................................................................37
3.7 LAN Driver Installation ..........................................................................38
Chapter 4 BIOS Setup............................................................................40
4.1 Introduction...........................................................................................41
4.2 BIOS Setup...........................................................................................41
4.3 Main Settings........................................................................................42
4.4 Advanced Settings................................................................................43
4.4.1 ACPI Settings.........................................................................43
4.4.2 LVDS (eDP/DP) Configuration................................................44
4.4.3 iSmart Controller.....................................................................45
4.4.4 Fintek Super IO Configuration ................................................46
4.4.5 Fintek Super IO Hardware Monitor .........................................51
4.4.6 M.2 Setup...............................................................................51
4.4.7 CPU Configuration..................................................................52
4.4.8 AMI Graphic Output Protocol Policy........................................53
4.4.9 Network Stack Configuration ..................................................54
4.4.10 CSM Configuration.................................................................55
4.4.11 USB Configuration..................................................................56
4.5 Chipset Settings....................................................................................57

viii
CSB200-822 User Manual
4.5.1 South Cluster Configuration....................................................57
4.6 Security Settings...................................................................................61
4.6.1 Secure Boot............................................................................62
4.7 Boot Settings.........................................................................................64
4.8 Save & Exit Settings..............................................................................65
Appendix ......................................................................................................66
A. I/O Port Address Map............................................................................67
B. Interrupt Request Lines (IRQ)...............................................................69
C. Watchdog Timer Configuration..............................................................70

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Optional Accessories
•Specifications
•Overview
•Dimensions

2
CSB200-822 User Manual
1.1 Introduction
The CSB200-822 is a compact and fanless design applicable to thin clients,
smart industrial automation or controller, and retail equipment. This product
comes with an Intel®Pentium®J5005 QC or Celeron®J4005 DC processor
and features iSmart, the IBASE’s unique technique, which allows the device
capable of auto-scheduling for general applications and gives energy savings
on power. With rich peripheral I/O ports or onboard sockets, this product is
multifunctional for video display, data transmission, and wireless connection.
1.2 Features
•Fanless system with IBASE 3.5” disk-size SBC
•Onboard Intel®Pentium®J5005 QC / Celeron®J4005 DC processor
•iSmart for auto-scheduler and power resume
•1 x outside-removable 2.5” SATA HDD, 1 x M.2 B2242 for storage,
1 x M.2 E2230 for WiFi / BT / GPS
•Rich variability of I/O ports such as serial COM ports, GbE LAN,
DisplayPort, HDMI 1.4, USB 3.0, USB 2.0, and audio jacks
•12V DC power input
•Wall mount kit included

General Information
CSB200-822 User Manual
3
1
1.3 Packing List
Your product package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
purchased the product.
•CSB200-822 x 1
•3-Pin Female Terminal Block x 1
(For power connector. If the optional DC Jack is used, this
terminal block will not be enclosed.)
•Wall Mount Kit (with 2 brackets) x 1
•Screws for Wall Mount Kit x 4
•DVD Disk (including drivers and this user manual) x 1
•Motherboard IB822 User’s Manual x 1
(You can download CSB200-822 User’s Manual from our
website.)
1.4 Optional Accessories
IBASE provide optional accessories as follows. Please contact us or your
dealer if you need any.
•DC Power Jack
•Power Adapter and Power Cord (for DC power jack)
•WiFi Cable Kit (KIT-16)

4
CSB200-822 User Manual
1.5 Specifications
Product Name
CSB200-822
Motherboard
IB822
MB Form Factor
3.5” disk-size SBC
System
Operating
System
•Windows 10 Enterprise (64-bit)
•Linux
CPU
•Intel®Pentium®J5005 QC, 1.5 GHz ~ 2.5 GHz, 4MB
cache, 10W
•Intel®Celeron®J4005 DC, 2 GHz ~ 2.7 GHz, 4MB
cache, 10W
Memory
1 x DDR4-2400 SO-DIMM 4 GB, expandable to 8 GB,
Non-ECC
Storage
1 x 2.5” HDD or SSD drive bay
Super I/O
Fintek F81964AD-I
Audio Codec
Intel®SoC built-in HD audio controller
Realtek ALC269-VC3 codec with class-D speaker amplifier
Network
2 x Intel®I211AT PCIe GbE
Power Supply
60W power adaptor (Optional)
BIOS
AMI BIOS
Watchdog
Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
Chassis
Aluminum & steel, black
Mounting
•Desktop mount
•Wall mount
Dimensions
(W x H x D)
172 x 53 x 111.6 mm (6.77”x 2.09”x 4.39”)
Weight
1.1 kg (2.43 lb)
RoHS
Yes
Certificate
CE / FCC Class B / LVD
I/O Ports
DC Input
12V DC-in through a 3-pin terminal block
(Optional: a locking DC Jack)
LAN
2 x RJ45 GbE LAN
USB
•2 x USB 2.0
•4 x USB 3.0

General Information
CSB200-822 User Manual
5
1
Serial
4 x COM ports:
•COM1 RS-232/422/485 port (through DB9 connector,
selectable from BIOS)
•COM2/3/4 RS-232 port (through onboard headers)
Display
•1 x DisplayPort
•1 x HDMI (1.4)
Audio Jack
•1 x Mic-In
•1 x Line-Out
SATA
1 x SATA III connector
Expansion
•1 x M.2 B2242 slot for storage
•1 x M.2 E2230 slot for WiFi, BT, GPS options
Environment
Temperature
•Operating (with air flow) :
with SSD: 0 ~ 50 °C (32 ~ 122 °F)
with HDD: 0 ~ 45 °C (32 ~ 113 °F)
•Storage: -40~ 85 °C (-40 ~ 185 °F)
Relative
Humidity
5 ~ 90% at 45 °C (non-condensing)
Vibration
Protection
•Operating: 0.25 Grms / 5 ~ 500 Hz
•Non-operating: 1 Grms / 5 ~ 500Hz
Shock
Protection
•Operating: 20 g / 11 ms
•Non-operating: 40 g / 11 ms
All specifications are subject to change without prior notice.

6
CSB200-822 User Manual
1.6 Overview
Front View
No.
Name
No.
Name
1
Power Button
5
Audio Line-Out Jack
2
Reset Button
6
Microphone Input Jack
3
HDD & Power LED Indicators
7
Antenna Hole
4
USB 2.0 Ports
8
Wall Mounting Kit (2 brackets)
Rear View
No.
Name
No.
Name
1
3-Pin DC-In Power Connector
5
HDMI Port
2
USB 3.0 Ports
6
COM1 RS-232/422/485 Port
3
GbE LAN Ports
7
COM2 ~ COM4 RS-232 Ports
4
DisplayPort
8
Antenna Holes

General Information
CSB200-822 User Manual
7
1
Oblique View
1.7 Dimensions
Unit: mm

8
Chapter 2
Hardware Configuration
The information provided in this chapter includes:
•Installations
•Information and locations of connectors

Hardware Configuration
CSB200-822 User Manual
9
2
2.1 Installations
Before installations, you need to turn your device upside down and remove
the bottom chassis base by removing 6 screws as indicated below.
2.1.1 Memory Installation / Replacement
If you need to install or replace a memory module, you will have to remove the
interior plate carrying a small PCB with I/O module locating above the memory
slot as shown below. Follow the instructions to remove the plate.
1. Loosen the 3 screws to free up interior plate.
2. Take out the interior plate along with the small PCB and I/O module
carefully.
3. Align the key of your memory module with that on the memory slot and
insert the module slantwise.

10
CSB200-822 User Manual
4. Gently push the module in an upright position until the clips of the slot click
to hold the module in place when the module touches the bottom of the
slot.
.
To remove the module, press the clips outwards with your thumb and index
finger of both hands.
2.1.2 M.2 Card Installation / Replacement
If you are using a model type of CSB200-822 that doesn’t include any M.2
card, you will have to remove the interior plate carrying a small PCB with I/O
module locating above the M.2 slots as shown below. Follow the instructions
to remove the plate.
1. Loosen 6 screws to from the bottom chassis and remove it carefully.
2. Loosen the 3 screws to free up interior plate.
3. Take out the interior plate along with the small PCB and I/O module
carefully.
4. Locate the M.2 slot. Align the key of the M.2 card to the M.2 interface, and
insert the card slantwise.

Hardware Configuration
CSB200-822 User Manual
11
2
5. Push the M.2 card down, fix it onto the standoff with a screw.
6. Secure the interior plate along with the small PCB and I/O module, and
then secure the bottom chassis back.
2.1.3 HDD/SSD Installation / Replacement
1. Remove one screw as indicated below to remove the HDD/SSD plate.
2. Remove 4 screws to free the HDD/SSD from the plate.
3. Unplug all the SATA cables if a HDD/SSD is pre-installed.
4. Attach a new HDD/SSD and tighten these screws to fix the HDD/SSD.
Then connect the SATA cables.
5. Secure the plate along with the new HDD/SSD back to the system.

12
CSB200-822 User Manual
2.1.4 M.2 Card Installation
If you need to use a M.2 card for expansion slots, follow the instructions below
for installation after you remove the device bottom chassis cover.
1. Align the key of the M.2 card to the M.2 interface, and insert the card
slantwise.
2. Push the M.2 card down, fix it onto the standoff with a screw.
2.1.5 WiFi / 3G / 4G Antenna Installation
Thread the WiFi / 3G / 4G antenna extension cable through an antenna hole
of the front I/O cover and fasten the antenna as shown below. Then apply
adhesive to the edge of the hex nut behind the front I/O cover to prevent the
extension cable from falling if the cable becomes loose.
1. Thread and fasten the hex nut and the
washer. Then install the antenna.
2. Apply adhesive around here.
Info: The diameter of the nut is around 6.35 mm (0.25”-36UNC).
