IBASE Technology UPC-7210 Series User manual

UPC-7210
Industrial Panel PC
User’s Manual
Version 1.0
(Nov. 2018)

ii
UPC-7210 Series User Manual
Copyright
©2018 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

UPC-7210 Series User Manual
iii
Compliance
This product may cause radio interference in which case users may be required to
take adequate measures.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
Operation is subject to the following two conditions:
•This product may not cause harmful interference
•This product must accept any interference received including interference that may cause
undesired operation.
However, there is no guarantee that interference will not occur in an installation. If this
equipment causes harmful interference to radio or television reception which can be
determined by turning the equipment off and on, you may correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
•Consult the distributor or an experienced radio/TV technician for help.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.

iv
UPC-7210 Series User Manual
Green IBASE
This product complies with the current RoHS restrictions that prohibit
the use of the following substances in concentrations exceeding 0.1%
by weight (1000 ppm) except for cadmium, limited to 0.01% by weight
(100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
•Put the device horizontally on a stable and solid surface during installation in
case the device may fall, causing serious damage.
•Leave plenty of space around the device for ventilation.
•Use this product in environments with ambient temperatures between 0˚C and
50˚C.
•DO NOT LEAVE THIS DEVICE IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY BE BELOW -20°C OR ABOVE 70°C. To
prevent from damages, the device must be used in a controlled environment.
•Keep the device away from humidity to avoid fog or condensation from
accumulating on the inner surface of the panel.
Care for your IBASE products:
•Before cleaning the device, turn it off and unplug all cables in case a small
amount of electrical current may still flow.
•Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
•Use a computer vacuum cleaner to remove dust to prevent the air vent or slots
from getting clogged.

UPC-7210 Series User Manual
v
WARNING
Attention during use:
•Do not use this product near water.
•Do not spill water or any other liquids on your device.
•Do not place heavy objects on the top of the device.
•Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local
power company.
•Ensure to use the correct power supply voltage.
•Do not walk on the power cord or allow anything to rest on it.
•If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
Disassembly, modification, or any attempt at repair could generate hazards and
cause damage to the device, even bodily injury or property damage, and will void any
warranty on the product.
CAUTION
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, CPU cooler, memory, storage devices,
power adapter, panel and touch screen.
＊Products, however, that fail due to misuse, accident, improper installation or
unauthorized repair shall be treated as out of warranty and customers shall be
billed for repair and shipping charges.

vi
UPC-7210 Series User Manual
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any assistance from your distributor or sales representative
concerning problems that you may have encountered, please prepare the
following information:
•Product model name
•Product serial number
•Detailed description of the problem
•Error messages in text or in screenshots if there is any
•The arrangement of the peripherals
•Software used (such as OS and application software, including the version
numbers)
3. For repair service, please download the RMA form from
http://www.ibase.com.tw/english/Supports/RMAService/.
Fill out the form and contact your distributor or sales representative.

UPC-7210 Series User Manual
vii
Table of Contents
Compliance....................................................................................................iii
Important Safety Information.......................................................................iv
WARNING .......................................................................................................v
CAUTION ........................................................................................................v
Warranty Policy..............................................................................................v
Technical Support & Services .....................................................................vi
Chapter 1 General Information................................................................1
1.1 Introduction.............................................................................................2
1.2 Features..................................................................................................2
1.3 Packing List ............................................................................................2
1.4 Specifications..........................................................................................3
1.5 Overview.................................................................................................5
1.6 Dimensions.............................................................................................7
Chapter 2 Hardware Configuration.........................................................8
2.1 Rear Cover Disassembly ........................................................................9
2.2 Memory Replacement.............................................................................9
2.5VESA Mounting Installation...................................................................12
2.6 Pin out for COM1..................................................................................13
2.7 Setting the Jumpers..............................................................................14
How to Set the Jumpers.........................................................................14
2.8 Jumper & Connector Locations.............................................................15
Chapter 3 Driver Installation .................................................................26
Chapter 4 BIOS Setup............................................................................37
Appendix ......................................................................................................63
A. I/O Port Address Map ..........................................................................64
B. Interrupt Request Lines (IRQ)..............................................................66
C. Watchdog Timer Configuration ............................................................67
D. Onboard Connector Reference Types .................................................70

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Specifications
•Overview
•Dimensions

2
UPC-7210 Series User Manual
1.1 Introduction
UPC-7210” is a 21.5” touch panel PCs based on the Intel®7th Core i™ultra
low power processor. It features IP65 ingress protection for the front bezel
and can be operated at ambient operating temperature ranging from 0°C to
50°C.
1.2 Features
•Intel®7th Core i™U series processor
•Projected capacitive touch screen
•Low power consumption
•IP65 front-bezel waterproof protection
1.3 Packing List
Your product package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
have purchased the product.
•UPC-7210 system x 1
•Power adapter x 1
•Motherboard Driver DVD x 1
•Power core x 1

General Information
UPC-7210 Series User Manual
3
1
1.4 Specifications
Product Name
UPC-7210 -I76
UPC-7210 -I73
UPC-7210 -I71
Display & Touch Screen
Display Size
21.5” TFT-LCD
Max. Resolution
1920 x 1080
Luminance (cd/m2)
250
Contrast
1000:1
Max. Color
16.7M
View Angle (H°/V°)
178/178
Backlight Lifetime (hrs)
30,000
Touch Type
Projected capacitive
Touch Interface
USB
Light Transmission (%)
88
Point of Touch
Up to 10
I/O Interface
USB 3.0
4, Type A
RS-232/422/485
(Selectable under BIOS)
1, DSUB9
LAN
2 x GbE ,RJ45
Additional Graphics
DP & VGA
Audio
1 x Mic/ 1 x Lin-in, 3.5 mmAudio Jack
Digital I/O
N/A
Power Connector
Power Jack
Power Button
Rock Switch
Mechanical
Dimensions (mm)
529.5 x 321 x 59
Net Weight (kg)
7.7
System
Processor
Intel® i7 7600U UPC-7210 -I76
Intel® i5 7300U UPC-7210 -I73
Intel® i3 7100U UPC-7210 -I71

4
UPC-7210 Series User Manual
Memory
2 x DDR4 SO-DIMM, up to 32 GB, default 4GB
Thermal Design
Fanless
Membrane Control
N/A
Built-in Speaker / Mic
N/A
Motherboard
IB917
Operating System
•Windows 10 (32/64-bit)
Expansion
Internal Expansion Bus
1 x Mini-PCIe full size
Expansion Slot
N/A
Wireless
Optional
Storage Space
HDD
1 x 2.5” SATA
Removable
N/A
Power
Power Input Range
10~24V DC Input
Construction
Chassis Material
Aluminum
Color (Front /Back)
Black / Black
IP Rating
IP65 rated front bezel
Mounting
VESA 100 x100
Environment
Operating Temperature
0 ~ 50 °C (32 ~ 122 °F)
Storage Temperature
-20 ~ 70 °C (-4 ~ 158 °F)
Storage Humidity
10 ~ 90% (non-condensing)
Certification
CE, FCC Class B, LVD
All specifications are subject to change without prior notice.

General Information
UPC-7210 Series User Manual
5
1
1.5 Overview
Front View
Oblique View
I/O View
No.
Name
No.
Name
1
Power Switch
6
Display Port
2
COM1 RS-232/422/485 Port
7
Mic In
3
USB 3.0 Port x 4
8
Line in
4
GbE LANｘ2
9
Power input
5
HDMI

6
UPC-7210 Series User Manual
No.
Name
A
Optional SMA anttena hole
B
Optional SMA anttena hole
C
Built-in speaker
D
Built-in speaker
E
SSD/HDD cover

General Information
UPC-7210 Series User Manual
7
1
1.6 Dimensions
Unit: mm

8
Chapter 2
Hardware Configuration
The information provided in this chapter includes:
•Memory installation and membrane keypad extension
•Information and locations of connectors

Hardware Configuration
UPC-7210 Series User Manual
9
2
Avoid device disassembly: Disassembly, modification, or any attempt at repair
could generate hazards and cause damage to the device, injury, or property damage,
and will void any warranty. If you need to make any changes to the device, be sure to
unplug the power cord of the device and have qualified engineers or technicians do
the disassembly or installation.
2.1 Rear Cover Disassembly
In case you need to remove the rear cover to install or replace a memory
module or a mini-PCIe card, unscrew the 16 screws as shown below to
remove the rear cover. Take extra care to open the rear cover.
2.2 Memory Replacement
To replace or install memory modules, perform the following steps after
removing the system rear cover.
1. Locate the memory slot and align the key of the memory module with
that on the memory slot.
2. Insert the module slantwise and gently push the module straight down
until the clips of the slot close to hold the module in place when the
module touches the bottom of the slot.
.
To remove the module, press the clips outwards with both hands.

10
UPC-7210 Series User Manual
2.3 Mini-PCIe Card Installation
To replace or install a mini-PCIe card, perform the following steps after
removing the rear cover.
1. Locate the mini-PCIe, align the key of the card to the interface, and
insert the card slantwise.
2. Push the card down and fix it with the supplied flat head screw.
2.4 SSD/HDD Replacement
1. For changing SSD/HDD, unscrew the following 2 screws to open-up
the SSD/HDD tray.
2. Once open-up the storage cover, you will see the SSD/HDD device,
Please gentle release the SATA cable at first

Hardware Configuration
UPC-7210 Series User Manual
11
2
Then unscrew 4 screw as following:
(Be careful, don’t let the screw drop into the system)
3. Then you are possible to take the SSD/HDD device with bracket up,
please unscrew 4 screw at right and left side to change/install the
new SSD/HDD.
Finally, please reverse procedures to fix the SSD/HDD device.

12
UPC-7210 Series User Manual
2.5 VESA Mounting Installation
You will need to prepare the VESA mount bracket in advance. Tighten 4
screws as shown below to attach the mounting brackets to the system.

Hardware Configuration
UPC-7210 Series User Manual
13
2
2.6 Pin out for COM1
•COM1 RS232/422/485 Port
COM 1 features jumperless selection for RS-232/422/485, which is configurable
in BIOS.
Pin
Signal Name
Pin
Signal Name
1
DCD, Data carrier detect
6
DSR, Data set ready
2
RXD, Receive data
7
RTS, Request to send
3
TXD, Transmit data
8
CTS, Clear to send
4
DTR, Data terminal ready
9
RI, Ring indicator
5
Ground
Pin
Signal Name
RS-232
RS-422
RS-485
1
DCD
TX-
DATA-
2
RX
TX+
DATA+
3
TX
RX+
NC
4
DTR
RX-
NC
5
Ground
Ground
Ground
6
DSR
NC
NC
7
RTS
NC
NC
8
CTS
NC
NC
9
RI
NC
NC
1
65 9
