IBASE Technology IPPC1501-RE User manual

www.ibase.com.tw
IBASE Technology Inc.
IPPC1501-RE
User Manual

Copyright © 2013 IBASE Technology Inc. All Rights Reserved. 2
2
IPPC1501-RE User Manual
Revision
Release Date
V1.0
2014/12/02

i
IPPC1501-RE User Manual
Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
No part of thismanual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE”).
Products and corporate names mentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of thismanual are correct and
up to date. However, themanufacturermakes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

ii
IPPC1501-RE User Manual
Table of Contents
Setting up your system ....................................................................................................... iii
Care during use ................................................................................................................... iv
Acknowledgments ............................................................................................................... v
CHAPTER 1 INTRODUCTION .................................................. 1
1.1 General Description .......................................................................................................1
1.2 System Specification ......................................................................................................2
1.2.1 Hardware Specifications .............................................................................................2
1.2.2 Dimensions .................................................................................................................3
1.2.3 I/O View......................................................................................................................4
1.3 Packing List.....................................................................................................................4
1.4 Installation .....................................................................................................................5
1.4.1 Installing the VESA Mount..........................................................................................5
CHAPTER 2 MOTHERBOARD INTRODUCTION......................... 6
2.1 Introduction...................................................................................................................6
Board Dimensions................................................................................................................8
2.2 Installing the Memory ...................................................................................................9
2.3 Setting Jumpers............................................................................................................10
2.4 Connectors ...................................................................................................................13
CHAPTER 3 BIOS SETUP .......................................................20
3.1 BIOS Introduction.........................................................................................................20
3.2 BIOS Setup....................................................................................................................20
3.3 Advanced Settings........................................................................................................22
3.4 Chipset Settings............................................................................................................32
3.5 Security Settings ..........................................................................................................39
3.6 Save & Exit Settings .....................................................................................................40
CHAPTER 4 DRIVERS INSTALLATION .....................................41
4.1 Intel Chipset Software Installation Utility ...................................................................41
4.2 VGA Drivers Installation...............................................................................................42
4.3 Realtek HD Audio Driver Installation...........................................................................43
4.4 LAN Drivers Installation ...............................................................................................44
Appendix............................................................................49
A. I/O Port Address Map....................................................................................................49
B. Interrupt Request Lines (IRQ)........................................................................................51
C. Digital I/O Sample Code.................................................................................................52
D. Watchdog Timer Configuration.....................................................................................60

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
iii
IBASE Technology Inc.
Safety Information
Your IPPC1501-RE is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions.
Setting up your system
Read and follow all instructions in the documentation before you operate your
system.
Do not use this product near water.
Set up the system on a stable surface. Do not secure the system on any unstable
plane.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
This system should be operated from the type ofpower indicated on themarking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
Use this product in environments with ambient temperatures between -5˚C and
50˚C.
If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENTWHERE
THESTORAGE TEMPERATURE MAY GO BELOW -20°C OR ABOVE 60°C.
THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN
A CONTROLLED ENVIRONMENT.

iv
IPPC1501-RE User Manual
Care during use
Do not walk on the power cord or allow anything to rest on it.
Do not spill water or any other liquids on your system.
When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
The power cord or plug is damaged.
Liquid has been spilled into the system.
The system does not function properly even if you follow the operating
instructions.
The system was dropped or the cabinet is damaged.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by themanufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
NO DISASSEMBLY
The warranty does not apply to the products that have been disassembled by users
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
v
IBASE Technology Inc.
Acknowledgments
AMI is a registered trademark ofAMI Software International, Inc.
AMD and ATI are registered trademarks ofAMD Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
FINTEK is a registered trademark of FINTEK Electronics Corporation.
REALTEK is a registered trademark of REALTEK Electronics Corporation.
All other product names or trademarks are properties of their respective owners.

1
IPPC1501-RE User Manual
CHAPTER 1 INTRODUCTION
1.1 General Description
The IPPC1501-RE is a fanless design panel pc, powered by an Intel Atom
processor D2550 with a speed of 1.86GHz. It supports one SO-DIMM slot that can
accommodate up to 4GB DDRIII 1066MHz FSB memory. Some of the main features
include 4x USB connector, 2x COM port, 1x SATA HDD space support and 12V~24V
DC power input. It is ideal for industrial automation, and factory automation
applications.
IPPC1501-RE front side view
IPPC1501-RE rear side view

2
IPPC1501-RE User Manual
1.2 System Specification
1.2.1 Hardware Specifications
Model Name
IPPC1501-RE
System Mainboard
IB895
CPU
Intel Atom Process D2550 1M Cache, 1.86GHz
Chipset
Intel NM10 Express Chipset
Memory
1 x DDR3 1333 SO-DIMM, maximum 4GB. Default 2GB
I/O Interface
1 x DVI-I
2 x 10/100/1000 Base-T LAN w/ RJ45 connector
4 x USB2.0 w/ type-Aconnector
1 x RS-232/422/485 (Default: RS-232) w/ DB9M connector
1 x RS-232 w/ DB9M connector
1 x 3 pin DC power terminal
1 x power rock switch (ATX)
Storage
1 x 2.5” SATA interface device bay, default 500GB
Expansion Slots
None
Power Supply
12V~24V DC-in, 60W power adaptor
LCD Size
15” TFT LCD
LCD Color
16.2M colors
LCD Resolution
1024 x 768
LCD Brightness
400 cd/m2
LCD ViewingAngle
160(H)/140(V)
Backlight MTBF
50,000 hrs
Touch Screen
Resistive Touch Screen
Construction
Black sheet metal
Mounting
VESAmount 75x75 and 100x100 mm
Dimensions
(W)x(H)x(D) mm
398 x 316 x 75 mm
Operating
Temperature
-5°C~ 50°C (23°F~140°F)
Storage Temperature
-20°C ~ 60°C (-4°F~176°F)
Relative Humidity
10~90% (non-condensing)
Protection Class
Front panel IP65
‧ This specification is subject to change without prior notice.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
3
IBASE Technology Inc.
1.2.2 Dimensions
IPPC1501-RE

4
IPPC1501-RE User Manual
1.2.3 I/O View
1.3 Packing List
Part No.
Description
Qty
1
Terminal block for power input
1 pc
2
Driver CD
1 pc

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
5
IBASE Technology Inc.
1.4 Installation
1.4.1 Installing the VESA Mount
1. The VESA mount holes are compatible with VESA standard - 75x75 and
100x100
2. Put your VESA mounting kit on the orange area as shown above.
3. Lock the screws from A to D.

6
IPPC1501-RE User Manual
CHAPTER 2 MOTHERBOARD INTRODUCTION
2.1 Introduction
The IB895 is a 3.5-inch single board computer based on the Intel® Atom
Cedarview chipset. The Cedar Trail is a platform that uses the Intel Cedarview-D or
Cedarview -M Processor and Intel NM10 Express Chipset family in the desktop
platforms.
The role of the processor in the system is to manage the flow of information
between the following interfaces: DDR3 System Memory interface, DVI display
interface, VGA graphics interface, Low Voltage Differential Signaling (LVDS) and the
Direct Media Interface (DMI). The processor supports single channel, one DDR3
SODIMMs.
The Intel® processors provide advanced performance in both computing and
graphics quality. This meets the requirement of customers in the gaming, POS, digital
signage and server market segment. The processor is built on 32-nanometer Hi-K
process technology with Micro-FCBGA11 packaging.
Specifications –Mainboard
Model
IB895 [default silk screen model # on PCB]
IB895N(N2600 onboard)
Form Factor
3.5”
CPU Type
Intel® AtomTM DC D2550 / 1MB cache / 1.86 GHz [TDP=10W] (IB895)
Intel® AtomTM DC N2600 / 1MB cache / 1.60 GHz [TDP=3.5W] (IB895N)
Package = FCBGA437 [22 mm x 22 mm] ; Cores / Threads = 2 / 4
Chipset
Intel® CG82NM10 PCH [TDP = 2.1W]
Package = BGA360, 17mm x 17 mm
BIOS
AMI BIOS, support ACPI Function
Memory
Intel® Atom TM on-die memory controller
1x DDR3-1066 SO-DIMM socket [Horizontal type]
Maximum memory: 4GB for D2550; 2GB for N2600
Non-ECC, Unbuffered, 1.5V
LVDS
24-bit dual channel via CH7511thru eDP
VGA
Intel® GMA 3650 (Gfx freq @ 640MHz) for D2550
Intel® Graphics MediaAcc GMA accelerator 3600 (Gfxfreq @ 400MHz) for
N2600
Supports DirectX 9 Graphics, OpenGL 3.0
DVI-I x 1 (Thru VGA + ASM1422 for DVI-D via D2550 or N2600)
LAN
Intel 82583V PCIe Gigabit LAN x 2

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
7
IBASE Technology Inc.
Audio
Intel® NM10 PCH built-in HD Audio controller + Realtek ALC269QHD
Codec w/class-D speaker amplifier(2.3W per channel @ 5V power
supply) [7mm x 7mm @ 48-QFN] ; support 2-channel audio out + amp
USB
NM10 built-in USB 2.0 host controller, support 6 ports
LPC I / O
Nuvoton NCT6627UD [128-pin QFP, 14x14x1.4mm]
- COM #1 (RS232/422/485) support ring-in with power @500 mA
(selectable for 5V or 12V) [EXAR SP339EER1 232/422/485 transceiver x
1 for jumper-less]
- COM #2 (RS232 only)
- COM #3 / COM #4 (RS-232 only)
[Hardware Monitor]
2 x Thermal inputs; 2 x Voltage monitoring
1 x Fan Header(DC Fan type)
Serial ATA Ports
NM10 built-in SATA II controller, supports 2 ports
Expansion Slot
Mini PCI-e socket x 2 (1x Full-sized+1xHalf-sized)
**Full-sized MiniPCIe(1x) support mSATA**
Digital IO
4 in & 4 out
Keyboard/
Mouse Connector
Pin headers
Edge Connector
DVI-I, 2x RJ45, 2x USB, COM1
Onboard
Header/Connector
Keyboard/mouse, 4x USB 2.0, 2x DF13 for 24-bit dual channel LVDS,
Audio, speaker, COM2, COM3/4, LPC (80-port card debugging purpose),
2x Mini PCI-e(1x), smart battery, backlight/brightness control, 2x power
connector SATA HDD [JST type]
Watchdog Timer
Yes (256 segments, 0, 1, 2…255 sec/min)
Power Connector
+12V ~ +24V DC-in
Others
- i-Smart function (TI MSP430G2433 MCU)
- AT24C02C EEPROM [SO8 type] via SMbus (Optional)
OS Support
- Windows 7 (32-bit only)
- Linux
RoHS
Yes
Board Size
102mm x 147mm

8
IPPC1501-RE User Manual
Board Dimensions

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
9
IBASE Technology Inc.
2.2 Installing the Memory
The IB895 board supports one DDR3 memory socket for a maximum total memory of
2GB or 4GB DDR3 memory type.
Note: IB895 with Intel Atom DC D2550 supports up to 4GB and IB895N with Intel
Atom DC N2600 supports up to 2GB.
Installing and Removing Memory Modules
To install the DDR3 modules, locate the memory slot on the board and perform the
following steps:
1. Hold the DDR3 module so that the key of the DDR3 module aligned with that on
the memory slot.
2. Gently push the DDR3 module in an upright position until the clips of the slot close
to hold the DDR3 module in place when the DDR3 module touches the bottom of
the slot.
3. To remove the DDR3 module, press the clips with both hands.

10
IPPC1501-RE User Manual
2.3 Setting Jumpers
Jumpers are used on IB895 to select various settings and features according to
your needs and applications. Contact your supplier if you have doubts about the best
configuration for your needs. The following lists the connectors on IB895 and their
respective functions.
Jumper Locations on IB895
JP2: Clear CMOS Contents
JP2
Setting
Function
Pin 1-2
Short/Closed
Normal
Pin 2-3
Short/Closed
Clear CMOS

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
11
IBASE Technology Inc.
JP3: BL Voltage Setting
JP3
Setting
Function
Pin 1-2
Short/Closed
+3.3V
Pin 3-4
Short/Closed
+5V
Pin 5-6
Short/Closed
+12V(Default)
JP5: COM1 RS232 RI/+5V/+12V Power Setting
JP5
Setting
Function
Pin 1-2
Short/Closed
+12V
Pin 3-4
Short/Closed
RI
Pin 5-6
Short/Closed
+5V
JP6: LVDS Panel Power Selection
JP6
Setting
Panel Voltage
Pin 1-2
Short/Closed
3.3V (default)
Pin 2-3
Short/Closed
5V

12
IPPC1501-RE User Manual
JP7: BL_ADJ_LEVEL Setting (PWM Mode)
JP7
Setting
Voltage
Open
3.3V (default)
Close
5V
JP8: Factory use only
SW1: LVDS Panel Type Setting
SW1-4
SW1-3
SW1-2
SW1-1
Panel Type
ON
ON
ON
ON
800*600 18bit 1ch
ON
ON
ON
OFF
1024*768 18bit 1ch
ON
ON
OFF
ON
1024*768 24bit 1ch
ON
ON
OFF
OFF
1280*768 18bit 1ch
ON
OFF
ON
ON
1280*800 18bit 1ch
ON
OFF
ON
OFF
1280*960 18bit 1ch
ON
OFF
OFF
ON
1280*1024 24bit 2ch
ON
OFF
OFF
OFF
1366*768 18bit 1ch
OFF
ON
ON
ON
1366*768 24bit 1ch
OFF
ON
ON
OFF
1440*900 24bit 2ch
OFF
ON
OFF
ON
1440*1050 24bit 2ch
OFF
ON
OFF
OFF
1600*900 24bit 2ch
OFF
OFF
ON
ON
1680*1050 24bit 2ch
OFF
OFF
ON
OFF
1600*1200 24bit 2ch
OFF
OFF
OFF
ON
1920*1080 24bit 2ch
OFF
OFF
OFF
OFF
1920*1200 24bit 2ch
