IBASE Technology AGS100T User manual

AGS100/
AGS100T/
AGS102/
AGS102T
Advanced Gateway &
Ultra-Compact Fanless System
User’s Manual
Version 1.3
(September 2021)

ii AGS100/T & AGS102/T User Manua
l
Copyright
© 2021 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in this
document without prior notice. Every effort has been made to ensure the information in the
document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

A
GS100/T & AGS102/T User Manual ii
i
Compliance
This product has passed CE tests for environmental specifications and limits. This
product is in accordance with the directives of the Union European (EU). If users
modify and/or install other devices in this equipment, the CE conformity declaration
may no longer apply.
This product has been tested and found to comply with the limits for a Class B device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause harmful
interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS restrictions and
prohibits use of the following substances in concentrations exceeding
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by
weight (100 ppm).
• Lead (Pb)
• Mercury (Hg)
• Cadmium (Cd)
• Hexavalent chromium (Cr6+)
• Polybrominated biphenyls (PBB)
• Polybrominated diphenyl ether (PBDE)

iv AGS100/T & AGS102/T User Manua
l
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
 Lay the device horizontally on a stable and solid surface in case the device may
fall, causing serious damage.
 Make sure you leave plenty of space around the device for ventilation.
 Use this product in environments with ambient temperatures -40˚C ~ 70˚C for
E-series CPU and -20˚C ~ 60˚C for N-series CPU.
 Do not leave this device in an environment where the storage temperature may
go below -40˚C or above 85˚C. This could damage the device. The device must
be used in a controlled environment.
Care for your IBASE products:
 Before cleaning the device, turn it off and unplug all cables such as power in case
a small amount of electrical current may still flow.
 Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
 Vacuum the dust with a computer vacuum cleaner to prevent the air vent or slots
from being clogged.
WARNING
Attention during use:
 Do not use this product near water.
 Do not spill water or any other liquids on your device.
 Do not place heavy objects on the top of the device.
 Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local power
company.
 Ensure that you apply correctly the power supply voltage.
 Do not walk on the power cord or allow anything to rest on it.
 If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
You are not suggested to disassemble, repair or make any modification to the device.
Disassembly, modification, or any attempt at repair could generate hazards and cause
damage to the device, even bodily injury or property damage, and will void any
warranty.

A
GS100/T & AGS102/
T
User Manual
v
CAUTION
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
 IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine the
approximate shipping date.
 3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, memory, storage device, power
adapter, panel and touchscreen.
＊ PRODUCTS, HOWEVER, THAT FAILS DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any further assistance from your distributor or sales representative,
prepare the following information of your product and elaborate upon the
problem.
 Product model name
 Product serial number
 Detailed description of the problem
 The error messages in text or in screenshots if there is any
 The arrangement of the peripherals
 Software in use (such as OS and application software, including the version
numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi AGS100/T & AGS102/T User Manua
l
TableofContents

Chapter 1 General Information ................................................................. 1
1.1Introduction ................................................................................................ 2
1.2Features .................................................................................................... 2
1.3Packing List ............................................................................................... 3
1.4Optional Accessories ................................................................................. 3
1.5Specifications ............................................................................................ 4
1.6Product View – AGS100 ............................................................................ 6
1.7Product View – AGS100T .......................................................................... 8
1.8Product View – AGS102 .......................................................................... 10
1.9Product View – AGS102T ........................................................................ 12
1.10Dimensions – AGS100 / AGS100T ......................................................... 14
1.11Dimensions – AGS102 / AGS102T ......................................................... 14
Chapter 2 Hardware Configuration ........................................................ 15
2.1Installations .............................................................................................. 16
2.1.1Memory Installation / Replacement .......................................... 16
2.1.2Mini-PCIe & M.2 Cards Installation / Replacement ................... 17
2.1.3WiFi / 3G / 4G Antenna Installation .......................................... 17
2.1.4Mounting Installation ................................................................. 18
2.1.5Pinout for COM Ports, DC-In Power Connector &
Line-Out Jack ............................................................................ 20
2.2Setting the Jumpers ................................................................................. 23
2.3Motherboard Jumper & Connector Locations .......................................... 24
2.4Motherboard Jumpers Quick Reference .................................................. 26
2.4.1Clear ME Register (JP1) ........................................................ 26
2.4.2Clear CMOS Data (JP2) ......................................................... 26
2.5Motherboard Connectors Quick Reference ............................................. 27
2.5.1Battery Connector (BAT1) ...................................................... 28
2.5.2Reset Button Connector (J1) .................................................. 28
2.5.3Power Button Connector (J3) ................................................. 28
2.5.4Board-to-Board Connector (J11) ............................................ 29
2.6Carrier Board Connectors Quick Reference
(for AGS102 / AGS102T only) ................................................................. 30

A
GS100/T & AGS102/
T
User Manual vi
i
Chapter 3 Driver Installation .................................................................. 31
3.1Introduction .............................................................................................. 32
3.2Intel® Chipset Software Installation Utility ................................................ 32
3.3Graphics Driver Installation ..................................................................... 34
3.4HD Audio Driver Installation .................................................................... 36
3.5Intel® Trusted Execution Engine Driver Installation ................................. 37
3.6USB 3.1 Driver Installation ...................................................................... 38
3.7LAN Driver Installation ............................................................................. 39
Chapter 4 BIOS Setup ............................................................................. 41
4.1Introduction .............................................................................................. 42
4.2BIOS Setup .............................................................................................. 42
4.3Main Settings ........................................................................................... 43
4.4Advanced Settings ................................................................................... 44
4.5Chipset Settings ...................................................................................... 56
4.6Security Settings ...................................................................................... 61
4.7Boot Settings ........................................................................................... 62
4.8Save & Exit Settings ................................................................................ 63
Appendix ....................................................................................................... 64
A.I/O Port Address Map .............................................................................. 65
B.Interrupt Request Lines (IRQ) ................................................................. 67
C.Watchdog Timer Configuration ................................................................ 68

1
Chapter 1
General Information
The information provided in this chapter includes:
 Features
 Packing List
 Optional Accessories
 Specifications
 Product View
 Dimensions

2 AGS100/T & AGS102/T User Manua
l
1.1 Introduction
AGS100, AGS102, AGS100T, and AGS102T are embedded computing
systems designed for thin clients, smart industrial automation or controller, and
retail equipment. It is based on Intel® Atom™ / Pentium® / Celeron® processors
and features iSMART that enables auto-scheduling for general applications
and energy savings. It has a wide-range operating temperature range from
-40°C to 70°C or -20 to 60°C (for N-series processor).
AGS100 AGS102
AGS100T AGS102T
1.2 Features
 Ultra-Compact, rugged and fanless system with Intel® Atom™ E3950 /
E3940 / E3930, Pentium® N4200 or Celeron® N3350 series processor
 Over/Under/Reverse voltage protection
 9V~36V DC wide-range power input
 Display output through DisplayPort and DVI-I
 DIN-rail mount & wall mount support
 GPIO 4-in & 4-out with isolation function for AGS102 and AGS102T
 iSMART power management
 1 x mini-PCIe

General Information
A
GS100/T & AGS102/T User Manual 3
1
1.3 Packing List
Your product package should include the items listed below. If any of the items
below is missing, contact the distributor or the dealer from whom you
purchased the product.
 AGS100 / AGS102 / AGS100T/ AGS102T x 1
 Wall Mount Kit x 1
 Round Head Screw (for Wall Mount Kit) x 4
 Terminal Block for DC-In Power Adapter (3-pin) x 1
 Thermal Pad
19 x 19 x 2 mm x 1
28 x 18 x 2 mm x 1
 Disk (including drivers and this user manual) x 1
1.4 Optional Accessories
IBASE provide optional accessories as follows. Please contact us or your
dealer if you need any.
 DC-In Power Adapter
 Power Cord
 WiFi Antenna Kit
 4G/LTE or GPS Antenna Kit
 DIN Rail Bracket

4 AGS100/T & AGS102/T User Manua
l
1.5 Specifications
Product Name AGS100 AGS102 AGS100T AGS102T
System
Motherboard IB801 IB802T
Carrier Board N/A IP801 N/A IP801
Operating
System
 Windows10 (64-bit)
 Linux Ubuntu
CPU Intel® Atom™ E3950 / E3940 / E3930, Pentium® N4200,
Celeron® N3350 / E3940 Series
CPU Speed Up to 2.5 GHz
Memory 1 x DDR3-1866 SO-DIMM
4GB, expandable to 8 GB
(Non-ECC)
1 x DDR3-1866/1600
SO-DIMM 4GB, expandable to
8 GB (Non-ECC)
Storage  1 slot for M.2 B3042 SSD
 1 slot for mSATA
Super I/O Fintek F81964D-I
Audio Codec Realtek ALC283 Realtek ALC269
Network For E-series CPU: Intel® I210IT GbE LAN
For N-series CPU: Intel® I211AT GbE LAN
Power Supply DC-In 9 ~ 36V (3-pin terminal block)
BIOS AMI BIOS
Watchdog Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
TPM N/A 2.0
iSMART Yes
Chassis Aluminum & steel, silver
Mounting  Desktop mount / Wall mount (wall mount kit included)
 DIN rail mount (optional)
Dimensions
(W x H x D)
160 x 44 x 110 mm (6.3" x 1.73" x 4.33")
Weight 0.9 kg (1.98 lb) 1 kg (2.2 lb) 0.9 kg (1.98 lb) 1 kg (2.2 lb)
Certificate CE / LVD / FCC Class B
I/O Ports
Left External
I/O
 2 x RS232/422/485 port: COM1 & COM2, selectable from
BIOS
 1 x Antenna hole for WLAN module
 1 x Speaker-out connector
Right External 1 x Nano SIM card slot

General Information
A
GS100/T & AGS102/T User Manual
5
1
I/O * The socket signal is from the M.2 B3042 4G/LTE card.
Rear External
I/O
 1 x DVI-I
 1 x DisplayPort
 4 x USB 3.0
 2 x RJ45 GbE LAN port
 3 x LED indicators (HDD, WLAN, WWAN)
 1 x power button with LED (Green for AGS100 / AGS102, and
blue for AGS100T / AGS102T)
 1 x 3-pin DC-in terminal block type for 9-36V
 1 x Antenna hole for WLAN module
 2 x RS-232 port: COM3 & COM4 (for AGS102 only)
 2 x RS-232/422/485 port: COM3 & COM4 (for AGS102T
only)
 1 x USB 2.0 port (for AGS102 & AGS102T only)
 1 x Isolated 4-In & 4-Out GPIO connector (for AGS102 &
AGS102T only)
 LED indicators: Red for HDD, Blue for WLAN, Yellow for
WWAN
Expansion
slots
 1 x full-size Mini-PCIe socket with USB 2.0 & PCIe & SATA
 1 x M.2 E2230 socket with USB 2.0 & PCIe for WLAN & BT
 1 x M.2 B3042 socket with USB 2.0 & SATA for WWAN &
SSD
Environment
Temperature  Operating:
For E-series CPU: -40°C ~ 70°C (-40°F ~ 158°F)
For N-series CPU: -20°C ~ 60°C (-4°F ~ 140°F)
 Storage: -40°C ~ 85°C (-40°F ~ 185°F)
Relative
Humidity 5 ~ 90% at 45 °C (non-condensing)
Vibration With IEC 60068-2-64
 Operating: 2 Grms / 5 ~ 500 Hz (Random operation)
 Non-operating: 3 Grms / 5 ~ 500Hz (Random operation)
Shock With MIL-STD-810G
 Operating: 30 g / 11 ms duration
 Non-operating: 40 g / 11 ms duration
All specifications are subject to change without prior notice.

6 AGS100/T & AGS102/T User Manua
l
1.6 Product View – AGS100
Front View
Side View
No. Name No. Name
1 Power Button
(Silver for AGS100) 7 DVI-I Port
2
LED Indicatorss
(Red for HDD, Blue for WLAN,
Yellow for WWAN)
8 Wall Mount Kit
3 DC-In Power Connector (3- pin) 9 Antenna Holes
4 USB 3.0 Ports 10 Audio Line-Out Jack (supports
2W mono speaker)
5 GbE LAN Ports 11 COM1 & COM2 RS-232/422/485
Ports
6 DisplayPort 12 Nano SIM Slot Door

General Information
A
GS100/T & AGS102/T User Manual
7
1
Wall Mount
DIN Rail Mount (Optional)

8 AGS100/T & AGS102/T User Manua
l
1.7 Product View – AGS100T
Front View
Side View
No. Name No. Name
1 Power Button
(Black for AGS100T) 7 DVI-I Port
2
LED Indicatorss
(Red for HDD, Blue for WLAN,
Yellow for WWAN)
8 Wall Mount Kit
3 DC-In Power Connector (3-pin) 9 Antenna Holes
4 USB 3.0 Ports 10 Audio Line-Out Jack (supports
stereo output)
5 GbE LAN Ports 11 COM1 & COM2 RS-232/422/485
Ports
6 DisplayPort 12 Nano SIM Slot Door

General Information
A
GS100/T & AGS102/T User Manual 9
1
Wall Mount
DIN Rail Mount (Optional)

10 AGS100/T & AGS102/T User Manua
l
1.8 Product View – AGS102
Front View
Rear View
No. Name No. Name
1 Power Button
(Silver for AGS102) 8 GPIO Port
2
LED Indicatorss
(Red for HDD, Blue for WLAN,
Yellow for WWAN)
9 DVI-I Port
3 USB 2.0 Port 10 Wall Mount Kit
4 DC-In Power Connector (3-pin) 11 Antenna Holes
5 USB 3.0 Ports 12 Audio Line-Out Jack (supports
2W mono speaker)
6 GbE LAN Ports 13
COM1 ~ COM4 Ports
(COM1 & COM2 RS-232/422/485,
COM3 & COM4 RS-232 Ports)
7 DisplayPort 14 Nano SIM Slot Door

General Information
A
GS100/T & AGS102/T User Manual 11
1
Wall Mount
DIN Rail Mount (Optional)

12 AGS100/T & AGS102/T User Manua
l
1.9 Product View – AGS102T
Front View
Rear View
No. Name No. Name
1 Power Button
(Black for AGS102T) 8 GPIO Port
2
LED Indicatorss
(Red for HDD, Blue for WLAN,
Yellow for WWAN)
9 DVI-I Port
3 USB 2.0 Port 10 Wall Mount Kit
4 DC-In Power Connector (3-pin) 11 Antenna Holes
5 USB 3.0 Ports 12 Audio Line-Out Jack (supports
stereo output)
6 GbE LAN Ports 13 COM1 ~ COM4 Ports
(RS-232/422/485)
7 DisplayPort 14 Nano SIM Slot Door
