Ideal-Standard E206567 Installation instructions

| 2

| 4
3. SAFETY AND GUIDELINES
ELECTRICAL
•The equipment must be installed by qualified personnel in compliance with current
standards and with those standards in force relevant to civil electric and hydraulic systems.
The product must be installed in dedicated rooms and must NOT be installed outdoors.
The appliance must be connected correctly to the mains power supply, i.e. to the termi-
nals marked L (line), N (Neutral), otherwise correct operation cannot be assured.
• Precautions
In order to ensure correct installation and maintenance of the product, the manufacturer
recommends careful attention to the instructions contained in this manual. Compliance
with safety norms and the suggestions described in this manual will ensure that the prod-
uct functions perfectly and that the manufacturer’s warranty will be fully applicable.
• Installer
A person who is capable of demonstrating to pertinent authorities that he has the knowl-
edge and skill in the application of national regulatory requirements concerning safety, i.e.
electricity, water supply, and disposal.
•Prior to installation, check that the electrical system is compliant with standards and laws
in eect and that it is equipped with a magneto-thermal dierential switch with an
adequate breaking capacity and a dierential of 30mA. Connection must be made in a fixed
and permanent manner, with no intermediate connections, by installing an adequate
omnipolar disconnecting switch with minimum aperture distance of contacts which allows
complete disconnection in conditions of category III, outside of zones 0-1-2-3. (fig. 1).
•The power cord must be protected inside the wall by a corrugated tube other means
compliant with current standards and certified as per the EC directive up to the connector
(fig. 2).
• Ensure mains power supply is switched o before commencing.
•This product must only be used with the manufacturers AC/DC adapter or battery
supplied with the product. This product is not intended for use with other types of adapter
or battery.
•Mains powered sensor Bluetooth operated products are only guaranteed fully opera-
tional with a maximum of one metre extension cable length between AC adapter and
Bluetooth module.

| 7
4. KEY FUNCTION AND FEATURES
PRODUCT OVERVIEW
•The smart sensor is designed to detect a dierence between air, water and urine. This
enables it to detect the beginning and ending of every use. It then can determine usage
count and pattern. The installer or maintenance personnel can adjust the flushing volume
of the sensor using a direct override button or with the recorded counter information,
optimise flush count, pattern and water volume via a Bluetooth application.
OVERFLOW PROTECTION
• In case of a blockage before or after the sensor, the urinal will not flush.
MAINTENANCE DETECTION
•The sensor detects low battery power, counts usage and warning of cartridge expiry,
also waste outlet slow flow or blockage.
•All maintenance requirements are communicated via the app and directly on site with
the warning LED in the urinal water spreader.
SPREADER WARNING LED
•The warning LED in the spreader is used to give feedback to maintenance personnel with
dierent flashing patterns.
PASSWORD PROTECTED
• Default password: IS000, can be changed to save settings.
HYBRID MODE
•The sensor will flush the urinal after a set time interval starting from the first use. After
every flush the time interval will start with the first consecutive usage. Therefore flushing
will only occur if the urinal has been used.
STANDARD MODE
• The sensor will flush the urinal after every use.
WATERLESS MODE
• The sensor will not flush the urinal, but count usage for maintenance of cartridge.
STADIUM MODE
•If the urinal is used more than two times, with less than one minute between uses, the
sensor will go into stadium mode. The urinal still flushes after every use, but with greatly
reduced flush volume. If the urinal is not used for more than one minute, the sensor will
perform a regular maintenance flush. This feature is only available within standard mode
setting.
HYGIENE FLUSH
• Flushes the urinal if it has not been used for a set time period.
FORCED FLUSH
•It is possible for the installer or maintenance personnel to flush the urinal at any time
using the app, the reset button on the sensor or optional override button.

7.1 DEVICES MENU
Device Name
•Selected urinal
Status
•Device Status - Ok / Error
•Ok = Sensor is working
•Error = Sensor or Bluetooth not responding
•Battery Status - Ok / Error
•Ok = Battery is Ok
•Error = Less then 4.5 voltage
•Cartridge Status - Ok / Error
•Ok = Cartridge life is below set usage
•Error = Cartridge life has reached end of set usage
•Flow Detection - Ok / Error / Warning
•Ok = No flow rate issue
•Error = Blocked. No flow rate
•Warning = Slow flow rate
| 10

| 12
Standard Mode
• Flush Volume = 0.85L
Options: 0.85, 1.5, 2, 3L
• Water Pressure = Medium
Options: Low, Medium, High
•Hygiene Flush = On
Options: On, O
• Interval = 24h
Flushes once in 24h if not used
Options: 12, 24h
•Flush Time Delay = 8s
•Flushes 8s after each usage
•Stadium Mode is auto detected if number of usages in one minute > 2
• After each usage only rinses
•Returns to Standard Mode if usage frequency reduces but with a full flush
•Options: 6, 8, 10s
• Cartridge Lifecycle = N/A
Statistics
•Usage Count
•Flush Count
•Waterless / Hybrid Cartridge usage

| 19
HYDRAULISCHER ANSCHLUSS
•Installationen am Trinkwassersystemen dürfen nur von zugelassenen Handwerkern
durchgeführt werden
• Beim Anschluss der Elektroventile darf keine übermäßige Kraft aufgewendet werden.
•Überprüfen Sie, ob alle Verbindungen fest angezogen sind und prüfen Sie auf Undichtig-
keiten.
