iDPRT iE4P User manual

Packing List
Appearance and Components
USB Connec�on
Xiamen Hanin Electronic Technology Co.,Ltd.
ADD：5F, 8#, Aide Airport Industrial Park, Huli District, Xiamen, China.
TEL：[phone]
WEB：www.idprt.com
Quick Start Guide
！Note: The packing materials are actually based on the order.
Printer(eg:iD4P) AC Adapter
Power Cord
USB Cable
Label Roll
CD
Quick Start Guide
Quick Start Guide
Front View(eg.:iE4P)
Rear View
Inside View
Note: The views above are for your reference. Ports vary by
your choice.
！
iE4P iE4S
Cover Open Levers

Status Indicator

Printer Cover
Display

USB Port (Type A)
USB Port (Type B) Ethernet Port
Serial Port
Power Receptacle
12
3
Varies by regions
3.Connect the other end of power cord to the outlet.
2.Connect the power cord to AC adapter.
1.Connect the AC adapter to power receptacle.
Label Sensor
Platen
Moveable Label Guides
Printhead Module
Ribbon Supply Pin
Ribbon Supply Wheel
Moveable Roll Holders 
Locking Tab
RibboRn

Loading the Media
Loading the Ribbon
！Note: Please refer to windows driver installa�on in iE4 Series User Manual.
 2.Pull the roll holders open and place the
roll between them, then press down the
locking tab.
3.Pass the labels through label guides
and adjust label guides to adapt to
the label width.
1.Insert the right part of supply spindle,  2.Press and release the printhead module.
Ribbon Rewind Wheel Ribbon
Rewind Pin
 
5.Close the printhead module. Then press the lock and close
the cover slightly.

