IDTECK Star RFK505 User manual
차례
ii
차례
1 Safety Information
1 IMPORTANT SAFETY INSTRUCTIONS
2 General
3 Features
4 Specifications
5 Identifying Supplied Parts
6 Product Overview
1 Functions
2 Product Explanation
2.1 Front Panel Description
2.2 Back Panel Description
3 Wire Color Table
7 Installation Checkpoints & Tips
1 Check Point before Installation
1.1 Selection of Cable
1.2 Recommended Cable Type and Permissible Length Cable
2 Check Point during Installation
2.1 Termination Resistors
2.2 How to Connect Termination Resistors
Termination Resistors for 2 Wire RS485 Communication System
Termination Resistors for 4 Wire RS422 Communication System
2.3 Grounding System for Communication Cable
................................................................. ii
................................................... 1
......................................... 3
........................................................... 4
........................................................... 5
...................................................... 6
............................................. 8
................................................... 9
.............................................................. 9
...................................................... 9
................................................. 10
.................................................. 11
......................................................... 12
......................................... 14
.............................................. 14
..................................................... 14
....................... 15
.............................................. 15
................................................... 16
..................................... 16
................... 16
................... 17
................................ 17
p.iii
8 Installation
1 Installation of the Product
2 System Initialization
3 Wiring
3.1 Power
3.2 Wiegand Data Connection
4 Wire Connection to Access Controller
4.1 Reader Connections (External Reader)
Compatible Readers(External Reader)
RFK505/IPK505:
SRK505
9 Communication
1 RS232 Communiction Port Connection
2 RS422 Communication Port Connection
2.1 RS422 Connection (Single RFK505 Connection)
2.2 RS422 Connection (Multiple RFK505s Connections)
3 TCP/IP Communication Port Connection (Optional)
4 TCP/IP Converter (External Version)
10 Initial Setup
1 System Initialization
2 Entering Setup Mode
3 Time / Date Setting
11 Operation
1 Normal Operation
2 Default Setting
12 Setting Changes
1 SETUP MENU F1
1.1 Time Setting
1.2 Communication Address
1.3 BAUD RATE
1.4 Reader 1 (Internal Reader) Mode
1.5 Reader 2 (External Reader) Mode
1.6 Master ID Registration or Change
1.7 System Initialization
2 SETUP MENU F2
........................................................ 19
................................................. 19
...................................................... 20
................................................................ 21
............................................................... 21
............................................... 21
........................................ 21
...................................... 22
....................................... 22
...................................................... 22
............................................................. 22
..................................................... 23
....................................... 23
...................................... 23
.............................. 23
........................... 24
............................. 25
.......................................... 26
....................................................... 28
...................................................... 28
..................................................... 29
...................................................... 29
........................................................ 30
....................................................... 30
.......................................................... 30
................................................... 31
......................................................... 32
.......................................................... 33
................................................ 33
.......................................................... 33
.......................................... 34
......................................... 34
......................................... 35
.................................................... 36
......................................................... 36
차례p.iv
2.1 LCD 표시 형태 설정
2.2 Buzzer Status
2.3 Output Mode
2.4 LED Buzzer Control
2.5 RF PIN Input
2.6 Key Output Type Setting
3 Setup Menu F3
4 NOT USE
4.1 Firmware Version
4.2 Memory Test
4.3 Output Test
4.4 LCD Test
4.5 키 패드 테스트
4.6 Reader Test
4.7 Input / DIP Switch Test
4.8 Communication Test
13 Appendix
1 Default Values for Parameters
14 FCC REGISTRATION INFORMATION
15 RMA Request
..................................................... 37
......................................................... 37
......................................................... 38
.................................................... 38
.......................................................... 39
................................................ 39
.......................................................... 39
............................................................... 40
...................................................... 40
......................................................... 41
.......................................................... 41
............................................................. 42
......................................................... 42
.......................................................... 43
.................................................. 43
................................................... 44
......................................................... 45
.............................................. 45
.................................... 46
..................................................... 47
Safety Information 1
p.1
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIE
D SERVICE PERSONNEL.
This symbol indicates that dangerous voltage consisting a risk of electric shock is pres
ent within this unit.
This exclamation point symbol is intended to alert the user to the presence of importa
nt operating and maintenance (servicing) instructions in the literature accompanying the ap
pliance.
WARNING
To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
WARNING
1. Be sure to use only the standard adapter that is specified in the specification sheet. Usin
g any other adapter could cause fire, electrical shock, or damage to the product.
2. Incorrectly connecting the power supply or replacing battery may cause explosion, fire,
electric shock, or damage to the product.
Safety Informationp.2
3. Do not connect multiple controllers to a single adapter. Exceeding the capacity may cau
se abnormal heat generation or fire.
4. Securely plug the power cord into the power receptacle. Insecure connection may caus
e fire.
5. When installing the controller, fasten it securely and firmly. The fall of controller may ca
use personal injury.
6. Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or container
s filled with water on top of the controller. Doing so may cause personal injury due to fi
re, electric shock, or falling objects.
7. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or el
ectric shock.
8. If any unusual smells or smoke come from the unit, stop using the product. In such case,
immediately disconnect the power source and contact the service center. Continued us
e in such a condition may cause fire or electric shock.
9. If this product fails to operate normally, contact the nearest service center. Never disass
emble or modify this product in any way. (SAMSUNG is not liable for problems caused
by unauthorized modifications or attempted repair.)
10. When cleaning, do not spray water directly onto parts of the product. Doing so may ca
use fire or electric shock.
CAUTION
1. Do not drop objects on the product or apply strong blows to it. Keep away from a locat
ion subject to excessive vibration or magnetic interference.
2. Do not install in a location subject to high temperature (over 50°C), low temperature (b
elow -30°C), or high humidity. Doing so may cause fire or electric shock.
3. If you want to relocate the already installed product, be sure to turn off the power and
then move or reinstall it.
4. Remove the power plug from the outlet when there is a lighting storm. Neglecting to d
o so may cause fire or damage to the product.
5. Keep out of direct sunlight and heat radiation sources. It may cause fire.
6. Install it in a place with good ventilation.
7. Avoid aiming the controller directly towards extremely bright objects such as sun.
8. Apparatus shall not be exposed to dripping or splashing and no objects filled with liqui
ds, such as vases, shall be placed on the apparatus.
9. The Mains plug is used as a disconnect device and shall stay readily operable at any tim
e.
p.3IMPORTANT SAFETY INSTRUCTIONS
1IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s ins
tructions.
8. Do not install near any heat sources such as radiators, heat registers, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two bla
des and a third grounding prong. The wide blade or the third prong is provided for you
r safety. If the provided plug does not fit into your outlet, consult an electrician for repla
cement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenie
nce receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or sol
d with the apparatus.
13. Unplug this apparatus when a card is used. Use caution when moving the cart/ apparat
us combination to avoid injury from tip-over.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparat
us has been damaged in any way, such as power supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the apparatus has been expo
sed to rain or moisture, does not operate normally, or has been dropped.
General 2
p.4
The Star RFK505 (iPASS IPK505, IDTECK SRK505) is an elegant looking and built in an 10cm
(4”) read range PIN & Proximity Card Reader with keypad and LCD display.
The Star RFK505 displays current time on the LCD and has back lighting on the keypad that
ensures you successful operation. The Star RFK505 allows you to access door with proximity
card and personal PIN numbers. Three LEDs (in the front panel) of green, yellow and red, ins
ide Piezo Buzzer sound and LCD will guarantee you accurate and reliable system operation.
Features 3
p.5
●125KHz Proximity / PIN Reader
●PSK Modulation
●Read Range: Up to 4 inch (10cm)
●Network Communication via RS232 / RS422 / TCP/IP (Optional Internal TCP/IP Module R
equired)
●26bit Wiegand, 4/8bit Burst for PIN Output Format
●16 Numeric Keypads with Back Lighting
●Current Time Display on the LCD
●Dual Tamper Switches
●Reverse Polarity Protection
●Compatible Controller:
●(26bit Wiegand) iMDC, iCON100, iTDC, Third Party Controller, Standalone Controller
●(34bit Wiegand) iMDC, iCON100SR, iTDCSR, Third Party Controller, Standalone Controll
er
RFK505 Built-in 125KHz (4”) Proximity Reader
IPK505 ASK[EM] Format
Built-in 125KHz (4”) Proximity Reader
SRK505 Built-in 13.56MHz (4”) Contactless Smart Card Reader
Specifications 4
p.6
Model RFK505 / IPK505 / SRK505
Read Rang
e
RFK505 IDK50 / IMC125: Up to 2 inch (5cm)IDC80 / IDC170: Up to 4 i
nch (10cm)
IPK505 IPK50: Up to 2 inch (5cm)IPC80 / IPC170: Up to 4 inch (10cm
)
SRK505 ISK50 / IHC80 / IMC135: Up to 2 inch (5cm)SDC80: Up to 4 in
ch (10cm)
Time (Card) 30ms
Power / Current DC 12V / Max.150mA
Communication RS232 / RS422 /
TCP/IP (Optional Internal TCP/IP Module Required)
Baud Rate 9,600bps (default)/ 4,800bps/ 19,200bps
38,400bps/ 57,600bps/ 115200bps (Selectable)
Output Fo
rmat
RFK505/IPK505 26bit Wiegand, 4/8bit Burst for PIN
SRK505 34bit Wiegand, 4/8bit Burst for PIN
LCD Character LCD (2Linges x 16Char) / 2.62” x 0.55” (65.6mm x
13.8mm) Screen
Keypad 16 Key Numeric Keypad with Back Lighting
LED Indicator 7 Array LED Indicators (Red, Green and Yellow on the front a
nd back panel)
Beeper Piezo Buzzer
Operating Temperature LCD 0 to +50C (+32 to +122F)
RF Reader -35 to +65C ( -31F to +149F )
Operating Humidity 10% to 90% Relative Humidity Non-Condensing
p.7
Color / Material Dark Pearl Gray / Polycarbonate
Dimension (W x H x T) 161.5mm x 134mm x 48.5mm
(6.36” x 5.28” x 1.9”)
Weight 547g (1.21lbs)
Identifying Supplied Parts 5
p.8
Please unpack and check the contents of the box. If any of these parts are missing, please co
ntact your distributor or service center. (Optional accessories, if purchased, may be included
in the Gift Box)
Product Overview 6
p.9
1Functions
Current Time Display on the LCD
The Star RFK505 (iPASS IPK505 / IDTECK SRK505) displays card reading status, card n
umber and current time on the LCD.
Setting Changes
The Star RFK505 manages output mode setting, external buzzer control and external
LED control.
Keypad
If the Star RFK505 is not connected to a host PC, the integrated keypad and LCD displ
ay module can be used for the entire programming process.
2Product Explanation
Product Overviewp.10
2.1 Front Panel Description
1 LCD Display:
LCD module displays Star RFK505 status.
2 System Operation Status LED:
When the power is applied to the unit, the red LED is turned on.
During the reader transmits card data to the controller, the green LED is turned on.
When temper switch is operated, yellow LED is turned on.
3 10 Numeric Key pad:
You can operate the unit manually by using the key pad.
4 Function Key pad:
The unit has four Function keys ([F1], [F2], [F3], [F4]).
5 Card Reading Status LED:
When a card is read, the card reading status LED turns on green.
p.11Product Explanation
2.2 Back Panel Description
1 Initialization Switch
This switch is used to initialize Star RFK505. For initialization, press down this switch a
nd then keep it for more than 2 seconds. Refer to ‘8.2 System Initialization’ for more d
etails.
2 Communication Display LED
# 3, 4(yellow, green) LED will twinkle during RS232, RS422 and TCP/IP communicatio
n.
If the LAN is connected normally during TCP/IP communication, green LED will turn o
n. But in the collision status, the #2 LED (red) turns on.
3 Tamper Switch
If someone takes off installed Star RFK505 on the wall by force, the tamper switch is a
ctivated then buzzer makes sound.
Product Overviewp.12
3Wire Color Table
IO PORT NAME SIGNAL NAME COLOR CODED
POWER (CON7)
Main Power(+12V) DC +12V Red
Power Ground GND Black
OUTPUT/INPUT (CON4) (Not use)
EXTRA READER PORT (CON5)
Wiegand Data0(IN) DATA0 Pink
Wiegand Data1(IN) DATA0 Cyan
OUTPUT (CON5)
TTL Output1 DATA0 Output Orange with White Stripe
TTL Output2 DATA1 Output Brown with White Stripe
OK Signal Out Not use Green with Red Stripe
Error Signal Out Not use Blue with Red Stripe
Tamper Switch Out Tamper Switch Out Yellow with White Stripe
RS232 INTERFACE (CON2)
RS232-TX TXD Black with White Stripe
RS232-RX RXD Read with White Stripe
Ground GND Black
RS422 INTERFACE (CON3)
p.13Wire Color Table
RS422-TX(-) TX(-) Yellow
RS422-TX(+) TX(+) Gray
RS422-RX(-) RX(-) Blue
RS422-RX(+) RX(+) Brown
TCP/IP Communication (CON6)
TCP/IP Communication 8PIN Connecter Module
IO PORT NAME SIGNAL NAME COLOR CODED
Installation Checkpoints & Tips 7
p.14
Installing the Star RFK505 (iPASS IPK505, IDTECK SRK505) is an easy task. It can be installed
with common hand tools and readily available communications wires. This section provides i
nformation about wiring, wire runs and other information to make the installation quick an
d easy.
1Check Point before Installation
1.1 Selection of Cable
System installation cabling will be configured as follow:
p.15Check Point during Installation
1.2 Recommended Cable Type and Permissible Length Cable
Reference Description Cable Specification Maximum Distance
① Controller Power (DC12V)
DC Power → Controller
Belden #9409, 18 AWG
2 conductor, unshielded
30m
②1Reader (Power and Data)
RFK505 → Controller
Belden #9512, 22 AWG
4 conductor, shielded
150m
Belden #9514, 22 AWG
8 conductor, shielded
③ Door Contact
Exit Button
Sensor Input
Input → Controller
Belden #9512, 22 AWG
4 conductor, shielded
300m
Belden #9514, 22 AWG
8 conductor, shielded
④ Door Lock, Alarm Device
Lock (Alarm) → Controller
Belden #9409, 18AWG
2 conductor, unshielded
300m
⑤ RS232 Cable
Converter → Host P.C.
Belden #9829, 24 AWG
2-twisted pair, shielded
15m
⑥ RS485 Cable
Controller → Converter
Controller → Controller
Controller → RFK505
RFK505 → RFK505
RFK505 → Converter
Belden #9829, 24 AWG
2-twisted pair, shielded
1,200m
RS422 Cable
Controller → Converter
Controller → Controller
Controller→ RFK505
RFK505 → RFK505
RFK505 → Converter
Belden #9830, 24 AWG
3-twisted pair, shielded
2Check Point during Installation
1 Requires thicker wire if you connect the reader with high current consumption.
Installation Checkpoints & Tipsp.16
2.1 Termination Resistors
Termination resistors are used to match impedance of the network to the impedance of the
transmission line being used. When impedance is mismatched, the transmitted signal is not
completely absorbed by the receiver and a portion of signal is reflected back into the transmi
ssion line.
The decision whether or not to use termination resistors should be based on the cable lengt
h and data rate used by the communication system.
For example, if you use 9,600 baud rate and 1,200m length of cable, the propagation veloci
ty of cable is 0.66 x speed of light (This value is specified by the cable manufacturer), if we a
ssume the reflections will damp out in three round trip up and down the cable length, the tr
ansmitted signal will stabilize 18.6us after the leading edge of a bit. Since the data bit is cap
tured in the middle of the bit which is approximately 52us after the leading edge of a bit. Th
e reflection stabilizing time 18.6us is much before the center of the bit therefore the termin
ation resistors are not required.
However, if you install the cable to maximum length, the impedance of cable and network is
mismatched and the transmitted signal is overlapped by the reflected signal. In this case, it is
recommended to add termination resistors to the end of the receiver lines. A 120Ω resistor c
an be used for termination resistor in parallel between the receiver lines “A” and “B” for 2 wir
es RS485 system or “RX+” and “RX-” for 4 wires RS422 system. A termination resistor of less
than 90Ω should not be used and no more than 2 terminations should be used in one netw
orking system.
2.2 How to Connect Termination Resistors
Termination Resistors for 2 Wire RS485 Communication System
