CONTENTS
START HERE! 4
Insert the batteries in the remote control 4
Set the time and date 4
Program the receiver 7
DIRECT CONTROL 9
Choose channels 9
Functions 10
PROGRAMMING 12
Grouping 12
Choose group 13
Random on/off 13
Delay shut off 14
Timer programming 15
Programming example 18
Deactivate Timer program 21
Activate Timer program 21
OTHER FUNCTIONS 21
Key sound and background
lighting on/off 21
Key lock on 22
Key lock off 22
Language selection 23
RECEIVER 24
Dimmer receiver (fig 2) 24
On/off receiver (fig 3) 25

3
TECHNICAL DATA 27
Remote control 27
Dimmer receiver 27
On/off receiver 27
REMEMBER 28
Installing the wall bracket for
the remote control 29
LCD DISPLAY 30
Remote control (fig 7) 30
Dimmer receiver (fig 8) 30
On/off receiver (fig 9) 30
COMPONENT LAYOUT 32
Remote control (fig 1) 32
Dimmer receiver (fig 2) 32
On/off receiver (fig 3) 32

4
START HERE!
Insert the batteries in the remote
control
1. Open the battery cover on the back.
2. Insert three AAA/LR03/AM4/ batteries
3. Close the battery cover.
1. Press [FUNCTION]
2. Press [9]
Set the time and date

5
3. Select time format. You can choose
between 12 and 24 hour display.
To change between
12 or 24 hour display,
press [UP]
Press [SET] to continue.
3.1 24 hour display.
Enter the time, for
example, 15.00. Press
[1],[5],[0],[0]
3.2 12 hour display.
Enter the time, for ex-
ample, 3.00 AM. Press
[0],[3],[0],[0], [DOWN]
For 3.00 PM, press
[0],[3],[0],[0],[UP]

6
4. State the day of the
week. Press [UP] or
[DOWN] to change the
day of the week.
Sunday (SUN)
Monday (MON)
Tuesday (TUE)
Wednesday (WED)
Thursday (THU)
Friday (FRI)
Monday- Friday (M-F)
Saturday- Sunday (S-S)
Complete week (ALL)
5. Press [SET] to continue.

7
Program the receiver
The receivers must be programmed
to recognise signals from the remote
control. Each receiver corresponds to
a channel on the remote control. Up to
10 channels/receiver can be program-
med.
1. Place the receiver in the wall socket.
2. Press [FUNCTION] on
the remote control.

8
3. Press [6]
4. Select channel (1-10),
for example, 1. Press
[1]
5. Press down one of the
buttons on the receiver
within 10 seconds. The
red lamp on the receiver
starts to flash to ac-
knowledge the receiver
has received the signal
from the remote control.
6. Press [FUNCTION] on
the remote control.
If you have several
receivers, repeat steps
1-6 choosing other
channels. (Up to 10
channels)

9
Choose channels
1. To choose one or more
channels (receiver)
press [CH]
2. Choose, for example,
receiver 2 by pressing
[2]. The chosen chan-
nels are shown on the
top row of the remote
control display.
3. If you want to control
several receivers at the
same time, for exam-
ple, receivers 1 and 2,
press [CH] followed by
[1] and [2]
4. To clear the chosen
channels press [CH]
again.
5. To choose all 10 chan-
nels press [CH] once
again.
DIRECT CONTROL

10
Functions
1. Switching on and off.
1.1 Choose the channel/s.
1.2 Press [ON] to
switch on.
1.3 Press [OFF] to
switch off.
2.1 Choose the channel/s.
2.2 Press [UP] to increase
the brightness.
2.3 Press [DOWN] to
reduce the brightness.
3 Set the brightness.
3.1 Choose the channel/s.
3.2 Press [LEV]
3.3 Choose brightness 1-9,
for example 5.
Press [5]
2. Dimmer. Increase or decrease the
brightness. (Only applies to receivers
with the dimmer function.)
NOTE: Energy saving bulbs do not work.

11
4. Gradual on/off or
instant on/off.
4.1 Press [FUNCTION]
followed by [1] to
switch between
gradual on/off and
instant on/off.
In gradual mode the
lights are switched on
and off with increasing
respective decreasing
brightness.
In instant mode the
lights are switched on
and off instantly.

12
Grouping
Instead of choosing channels one by
one you can group and name different
channels, e.g. living-room, bedroom,
hall, etc.
PROGRAMMING
1. Select group number,
for example, 1, by
pressing [GRP]
followed by [1]
Scroll between the
groups by pressing
[UP] or [DOWN]
2. Press [SET] to state the
group names. Use the
number keys to enter
letters and [UP] and
[DOWN] to move the
cursor. A maximum of
10 characters can
be used.
3. Press [SET] to confirm
the name.
4. State which channels
should belong to the
group, for example
channels 2, 3 and 8 by
pressing the corre-
sponding number keys.

13
5. Press [SET] to save the
group.
You can edit the groups
by carrying out steps
1-5 to write over or
change them.
Choose group
1. Select group number,
for example, 1, by
pressing [GRP] followed
by [1]
Scroll between the
groups using [UP] or
[DOWN]
Random on/off
This function switches chosen lights on
and off at random time intervals.
1. Select the channel/s or
group.
2. Press [FUNCTION] fol-
lowed by [3]. The func-
tion is confirmed by the
light being switched off
if it was on or switched
on if it was off. An R on
the LCD display on the
receiver indicates the
function is active.

14
The function is deactivated by new
commands to the chosen channels
using the remote control, pressing
keys on the receiver or if the receiver
is removed from the wall socket.
Delay shut off
The function switches off the chosen
lights after a predefined time. You set
directly by channel/s or by group.
Channel/s:
1. Press [CH] followed by
the number.
2. Press [FUNCTION] fol-
lowed by [2]
3. State the length of the
delay you would like,
for example after 15
minutes.
The time can be stated
between 1-99 minutes.
NOTE! Pressing the key
again deactivates the
function.
Group:
1. Press [GRP] followed by
the number.

15
2. Press [FUNCTION]
twice followed by [2]
3. State the length of the
delay you would like,
for example after 15
minutes.
The time can be stated
between 1-99 minutes.
NOTE! Pressing the
key again deactivates
the function.
Timer programming
1. Press [PROG]
2. Select the program
number (01-16). Press
[0],[1] for program 1.
The display shows
EMPTY if the chosen
program has not pre-
viously been program-
med. If it has been
preprogrammed the
program settings are
shown.

16
3. Press [SET] to continue.
4. State the time when
you would like the
command to be ex-
ecuted, for example,
6 PM.
To state AM/PM press
[UP] or [DOWN]
5. Select the day by press-
ing [UP] or [DOWN]
Sunday (SUN)
Monday (MON)
Tuesday (TUE)
Wednesday (WED)
Thursday (THU)
Friday (FRI)
Monday- Friday (M-F)
Saturday- Sunday (S-S)
Complete week (ALL)
6. Press [SET] to continue.
7. Choose the channel/s.
For example, press [2]
for channel 2.
8. Press [SET] to continue.

17
9. Select the command
On = Press [ON]
Random on/off = Press
[ON] once again.
Off = press [OFF]
Preset brightness =
Press [LEV] followed by
a number for the level
(1-9).
10. Press [SET] to save the
program.
11. You can scroll between the programs
by pressing [UP] or [DOWN]

18
Programming example
The example shows the following: Switch
on (instant) a light connected to receiver/
channel 1 at 18.00 on Saturdays and
Sun-days. Switch off the same light at
clock 23.00 on Saturdays and Sundays.
Each ACTION requires a program, i.e.
this example will need two programs
saved as PROG 01 and PROG 02.
Switch on:
[PROG]
[0],[1]
[1],[8],[0],[0]
[SET]
[DOWN] X times
[SET]

19
[SET]
[SET]
[ON]
Switch off:
[1]
[PROG]
[0],[2]
[2],[3],[0],[0]
[SET]

20
[DOWN] X times
[SET]
[SET]
[1]
[SET]
[OFF]
