Impex MARCY TC-6000 User manual

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
TC-6000
Retain This
Manual for
Reference
100614
OWNER'S
MANUAL
MARCY®
POWER STATION
TC-6000
IMPEX®INC.
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................... 1
IMPORTANT SAFETY NOTICES..................................................................... 2
HARDWARE IDENTIFIER.....…....................................................................... 4
ASSEMBLY INSTRUCTIONS........................................................................... 5
EXPLODED DIAGRAM………………………………………………………………9
PARTS LIST......................................................................................................10
WARRANTY.................................................................................................…. 11
ORDERING PARTS.......................................................................................…11
BEFORE YOU BEGIN
Thank you for selecting the MARCY TC-6000 by IMPEX®INC. For your safety
and benefit, read this manual carefully before using the machine. As a
manufacturer, we are committed to provide you complete customer satisfaction. If
you have any questions, or find there are missing or damaged parts, we guarantee
you complete satisfaction through direct assistance from our factory. To avoid
unnecessary delays, please call our TOLL-FREE customer service number. Our
Customer Service Agents will provide immediate assistance to you.
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]
1

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply whenever
you operate a piece of exercise equipment. Be sure to read the entire manual before you
assemble or operate your machine. In particular, note the following safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
CARE AND MAINTENANCE
1. Inspect and tighten all parts before using the machine.
2. The machine can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
3. Maximum user’s weight: 300 lbs.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35
OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS
BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY
FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE
USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
2

WARNING LABEL PLACEMENT
The warning label shown here has been placed on the Stabilizer. If the labels are missing or illegible, please
call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown.
3

HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler or scale to measure the size.
4

ASSEMBLY INSTRUCTION
Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches
NOTE: It is strongly recommended that two or more people assemble this machine to avoid
possible injury.
STEP 1 (See Diagram 1)
A.) Do not tighten all Bolts until instructed to do so.
B.) Attach the Lower Vertical Frame (#2) to the Rear Stabilizer (#8). Secure it with four M10 x ¾”
Allen Bolts (#20), four Ø ¾” Lock Washers (#28), and four Ø ¾” Washers (#24).
C.) Attach the Left Stabilizer (#4) to the Lower Vertical Frame. Secure it with four M10 x ¾” Allen
Bolts (#20), four Ø ¾” Lock Washers (#28), and four Ø ¾” Washers (#24). Repeat the same
procedure to install the Right Stabilizer (#5) to the Lower Vertical Frame.
D.) Securely tighten all Bolts.
E.) Use the Level Knob (#17) under the Left and Right Stabilizer to stabilize the equipment.
DIAGRAM 1
5

STEP-2 (See Diagram 2)
A.) Attach the Upper Vertical Frame (#1) onto the Lower Vertical Frame (#2). Secure it with six
M10 x ¾” Allen Bolts (#20) and six Ø ¾” Washers (#24).
B.) Attach the Right Dip Support (#6) to the Upper Vertical Frame. Secure it with two M10 x ½”
Allen Bolts (#19). Do not over tighten the Bolt. Make sure the Dip Support is able to fold
up.
C.)Thread the Vertical Support (#10) onto the Right Dip Support.
D.)Repeat B & C to install the Left Dip Support (#7).
E.) Attach the Upper Frame (#3) onto the Upper Vertical Frame. Secure it with four M10 x 2 7/8”
Allen Bolts (#21), eight Ø ¾” Washers (#24), and four M10 Aircraft Nuts (#26).
F.) Insert the Chin-up Bar (#9) to Upper Frame from both ends. Secure each Chin-up Bar with
one M5 x ¼” Allen Bolt (#27).
G.)Fold up the Left & Right Dip-Support when doing Chin-up exercises.
6

DIAGRAM 2
7

STEP 3 (See Diagram 3)
A.) Attach the Backrest Pad (#11) to Upper Vertical Frame (#1). Secure it with two M10 x 6
¾” Allen Bolts (#22) and two Ø ¾” Washers (#24).
B.) Attach the Arm Pad to Left and Right Dip Support (#6 & #7). Secure each Arm Pad with
two M8 x 3 ½” Allen Bolts (#23) and two Ø 5/8” Washers (#25).
C.)Thread the Cable (#13) into Upper Frame (#3) and Rear Stabilizer (#8) to stabilize the
equipment. DIAGRAM 3
8

EXPLODED DIAGRAM
9
