In-situ MP TROLL 9500 User manual

Multi-Parameter TROLL 9500
OPERATOR’S MANUAL
January 2009
Multi-Parameter
Water Quality TROLL®
For Sales & Service Contact
2650 E. 40th Ave. • Denver, CO 80205
Phone [phone] • Fax [phone]
1-800-833-7958
www.geotechenv.com

Copyright © 2001 – 2009 by In-Situ Inc. All rights reserved.
Revision history Beta draft September 23, 2005
Initial release, October 28, 2005
Rev. 001, April 6, 2006
Rev. 002, November 2006
Rev. 003, April 2007
Rev. 004a, September 2007
Rev. 005, April 2008
Rev. 006, September 2008
Rev. 007, January 2009
This document contains proprietary information which is protected by copyright. No part of this document may be photocopied, reproduced, or translated to
another language without the prior written consent of In-Situ Inc.
Mailing & Shipping Address: Phone: [phone]
In-Situ Inc. Fax: [phone]
221 E. Lincoln Ave. Internet: www.in-situ.com
Fort Collins, CO 80524 Support Line: 800 446 7488
USA (US & Canada)
The information in this document is subject to change without notice. In-Situ Inc. has made a reasonable effort to be sure that the information contained herein is
current and accurate as of the date of publication.
In-Situ Inc. makes no warranty of any kind with regard to this material, including, but not limited to, its fitness for a particular application. In-Situ will not be liable
for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
In no event shall In-Situ Inc. be liable for any claim for direct, incidental, or consequential damages arising out of, or in connection with, the sale, manufacture,
delivery, or use of any product.
Images in this manual have been selected for illustration; actual images may vary from those shown.
In-Situ and the In-Situ logo, Win-Situ, TROLL, BaroTROLL, HERMIT, RuggedReader, RuggedCable, and RDO are trademarks or registered trademarks of
In-Situ Inc. Microsoft, Windows, Windows Vista, Internet Explorer, Excel, and ActiveSync are trademarks or registered trademarks of Microsoft Corporation.
Teflon and Delrin are registered trademarks of E. I. DuPont de Nemours and Company. Viton is a registered trademark of DuPont Dow Elastomers. Kellems is
a registered trademark of Hubbell Inc. NIST is a registered trademark of the National Institute of Standards and Technology. Alconox is a registered trademark of
Alconox Inc. Other brand names and trademarks are the property of their respective owners.

0095110 rev. 007 01/09
Multi-Parameter
Water Quality TROLL®
TROLL 9500 Operator’s Manual III
Contents
1 INTRODUCTION................................................ 1
General Description of the MP TROLL 9500 ...................................... 1
How to Use This Manual..................................................................... 1
Conventions ............................................................................... 2
Unpacking and Inspection .................................................................. 2
Serial Number ............................................................................ 2
To Our Customers . . .......................................................................... 2
What We Provide................................................................................ 3
Warranty Provisions ................................................................... 3
Firmware & Software Upgrades................................................. 3
How to Contact Us.............................................................................. 3
To Obtain Repair Service (U.S.) ........................................ 3
Outside the U.S................................................................. 3
Certification......................................................................................... 3
Cleaning Guidelines............................................................................ 4
2 COMPONENTS & FEATURES................................ 5
System Description ............................................................................ 5
Standard Features .............................................................................. 5
Optional Features ............................................................................... 5
Cables ................................................................................................ 6
RuggedCable™ ......................................................................... 6
Cable Desiccants ....................................................................... 7
Communication Cables.............................................................. 7
Power Components ............................................................................ 7
Internal Power............................................................................ 7
External Power .......................................................................... 7
Water Quality Accessories ................................................................. 8
Installation Accessories ...................................................................... 9
Control Software ................................................................................. 9
Product Specifications ...................................................................... 10
3 GETTING STARTED...........................................12
Provide Power .................................................................................. 12
Install Sensors .................................................................................. 13
Install the Software .......................................................................... 14
Win-Situ 4 ............................................................................... 14
USB TROLL Com Drivers ........................................................ 14
Pocket-Situ 4 ........................................................................... 14
Win-Situ Sync .......................................................................... 14
Connect the Hardware...................................................................... 14
TROLL 9500 to TROLL Com.................................................... 14
TROLL Com to Computer ........................................................ 14
Twist-Lock Cable Connections................................................. 15
Establish Communication with the MP TROLL 9500 ........................ 16
Set the Real-Time Clock................................................................... 16
Quick-Cal the Basic Water-Quality Sensors ..................................... 17
Calibrate the Extended Sensors ....................................................... 20
Set Up Custom Pressure/Level Measurements................................ 20
Set Up to Log Data (Set Up a Test) .................................................. 21
Complete the Setup .......................................................................... 21
4 CONTROL SOFTWARE...................................... 22
Launching the Software .................................................................... 22
Win-Situ 4 ................................................................................ 22
Pocket-Situ 4............................................................................ 22
The User Interface ............................................................................ 23
The Navigation Tree................................................................. 23
Software Functions ........................................................................... 24
Configuring the Port ................................................................. 24
Establishing Communication with the MP TROLL 9500........... 24
New Connection.............................................................. 24
Existing Connection ........................................................ 24
Displaying Device Information ................................................. 24
Upgrading Firmware and Features .......................................... 25
Editing the Device Properties................................................... 26
Setting a Device Name ...................................................26
Setting the Real-Time Clock............................................ 26
Setting Battery Information.............................................. 26
SDI-12 and ASCII Mode Preferences ............................. 26
Choosing Measurement Units and Other Preferences ............ 27
Choosing Pressure Display & Conversion Options.................. 28
Logging Data (Adding a Test)................................................... 29
Taking “Manual” Readings ....................................................... 29
Extracting and Viewing Data.................................................... 30
Deleting Data from Instrument Memory ................................... 30
Exiting the Software.......................................................................... 30
Win-Situ 4 ................................................................................ 30
Pocket-Situ 4............................................................................ 30
5 PROFILING .....................................................31
Profiler Features ............................................................................... 31
Starting the Profiler ........................................................................... 31
Graphing Profiler Data ...................................................................... 32
Profiling Dissolved Oxygen............................................................... 32
Profiling Pressure or Depth............................................................... 32
Profiling Turbidity .............................................................................. 32

0095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
CONTENTS
IV
Customizing the Profiler.................................................................... 34
Changing the Channels Displayed.................................. 34
Changing Measurement Units ........................................ 34
Changing the Sample Rate ............................................. 34
Starting in Profiler Mode.................................................. 34
Logging Profiler Data ........................................................................ 34
To Stop Logging ...................................................................... 34
Retrieving Logged Profiler Data............................................... 34
Exiting the Profiler............................................................................. 34
6 LOGGING DATA.............................................. 35
Adding a Test to a Device: The Test Wizard ..................................... 35
Test Setup Parameters............................................................. 36
1. Test Name (Optional) ..................................................36
2. Parameters to Include ................................................. 36
3. Measurement Schedule ............................................. 36
4. Measurement Interval .................................................37
5. Start Mode................................................................... 37
Ending Setup ........................................................................... 37
More on Measurement Schedules.................................................... 37
Linear ...................................................................................... 37
Event ....................................................................................... 37
Linear Average......................................................................... 38
Other Test Operations....................................................................... 39
Starting a Manual Start Test..................................................... 40
Stopping a Test ........................................................................ 40
Retrieving Logged Data ........................................................... 40
Deleting Tests........................................................................... 41
Cloning a Test .......................................................................... 41
Transferring Files from a PDA to a Desktop PC ............................... 42
Viewing Logged Data........................................................................ 43
Selecting Data in the Data Folder ............................................ 43
Graphing Data .................................................................................. 44
Changing the Data Display ............................................................... 45
Transferring Data to Excel from Win-Situ 4 ...................................... 45
Printing Data in Win-Situ 4................................................................ 45
Saving Text Files from Win-Situ 4 ..................................................... 45
7 MONITORING PRESSURE (WATER LEVEL) .......... 46
Why Monitor Pressure? .................................................................... 46
The Pressure Sensor........................................................................ 46
Factory Calibration................................................................... 46
Operating Principle .................................................................. 47
Non-Vented (Absolute) vs. Vented (Gauged) Sensors............. 47
Pressure vs. Depth vs. Level ................................................... 47
Zeroing the Pressure Sensor............................................................ 47
Setting up Pressure Measurements: The Parameter Wizard ........... 48
Pressure Setup Choices .......................................................... 48
1. Name (Optional)................................................................... 48
2. Display Mode ....................................................................... 48
3. Converting Pressure to Depth or Level................................ 49
Conversion Using Specific Gravity.................................. 49
Conversion Using Density, Latitude, and Elevation......... 49
4. Level Reference................................................................... 49
Reference Time............................................................... 49
Quick Summary of Pressure Setup .................................................. 50
Installation for Pressure/Level Measurement ................................... 51
Securing the Cable .................................................................. 51
Stabilization Time..................................................................... 51
Twist-Lock Hanger Installations ............................................... 51
Installation Tips for Level/Depth/Pressure Monitoring..... 51
Correcting Absolute Pressure Readings for Barometric Pressure.... 52
Manual Barometric Pressure Compensation ........................... 52
Using the MP TROLL’s Barometric Pressure Sensor...... 52
Using a Second Unit and a Spreadsheet ........................ 52
Automatic Barometric Pressure Compensation ...................... 52
Collecting Barometric Pressure Data for Reference ....... 52
Collecting PSIA Data ....................................................... 52
Using the Baro Wizard .................................................... 52
Recalibration Recommendations...................................................... 53
8 MONITORING TEMPERATURE........................... 54
Why Monitor Temperature?............................................................... 54
The Temperature Sensor .................................................................. 54
Role of the Sensor in Calibration ............................................ 55
Software Functions ........................................................................... 55
References ....................................................................................... 55
9 MONITORING BAROMETRIC PRESSURE ............. 56
What is Barometric Pressure? .......................................................... 56
Why Monitor Barometric Pressure?.................................................. 56
The Barometric Pressure Sensor ..................................................... 56
Collecting Accurate Measurements without Vented Cable ............... 56
Pressure vs. Elevation ............................................................. 57
10 MONITORING WATER QUALITY: OVERVIEW ..... 58
Why Monitor Water Quality?............................................................. 58
The Sensors ..................................................................................... 58
Basic Sensor Set ..................................................................... 58
Installing Sensors..................................................................... 59
Removing Sensors................................................................... 60
Calibration Overview......................................................................... 60
Traditional Calibration .............................................................. 60
Quick Calibration...................................................................... 61
Out of the Box .......................................................................... 61
Default Coefficients.................................................................. 61
Preparing to Calibrate....................................................................... 61
Calibration Kits ........................................................................ 61
The Calibration Cup ................................................................. 61
Effect of Temperature on Calibration........................................ 62
Rinsing ..................................................................................... 62
Stirring...................................................................................... 62
Calibration Procedures ..................................................................... 62
After Calibration ................................................................................ 62
Calibration History.................................................................... 63
How Often to Calibrate ............................................................ 64
How to Check if a Sensor is Still in Calibration ........................ 64
When to Replace a Sensor ...................................................... 65
References ....................................................................................... 65
11 PH............................................................... 66
What Is pH? ..................................................................................... 66
Why Measure pH? .................................................................. 66
The pH Sensor ................................................................................. 66
Sensor Installation ............................................................................ 67

0095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
CONTENTS
V
Calibration ........................................................................................ 67
Overview .................................................................................. 67
Nominal vs. Stable .......................................................... 68
Calibration Solutions ................................................................ 68
Recommended Calibration Frequency .................................... 68
pH Quick Cal............................................................................ 68
Traditional pH Calibration Procedure....................................... 68
Recommended Calibration Order for pH and ORP.................. 68
Resetting Default Coefficients.................................................. 70
Sensor Slope and Offset.......................................................... 70
Units and Calculated Measurements................................................ 70
Usage Recommendations and Cautions .......................................... 70
Sensor Care and Handling .............................................................. 71
Sensor Removal ...................................................................... 71
Maintenance/Inspection/Cleaning............................................ 71
Replacing the Filling Solution .................................................. 71
Replacing the Junction............................................................. 71
Storage ................................................................................... 71
References ....................................................................................... 71
12 CONDUCTIVITY ..............................................72
What Is Conductivity? ....................................................................... 72
Why Measure Conductivity? .................................................... 72
How is Conductivity Measured?............................................... 72
The Conductivity Sensors ................................................................ 72
Sensor Installation ............................................................................ 73
Calibration......................................................................................... 73
Overview .................................................................................. 73
Nominal vs. Stable .......................................................... 73
Calibration Solutions (Primary Standards)............................... 73
Calibrating with Other Solutions...................................... 73
Recommended Calibration Frequency .................................... 73
Conductivity Quick Cal............................................................. 74
Traditional Conductivity Calibration Procedure ........................ 74
Using a Conductivity Meter as a Secondary Standard ............76
Entering a Cell Constant Manually........................................... 76
Units and Calculated Measurements................................................ 76
Basic Unit: AC ................................................................. 76
Specific Conductance (SC) ............................................. 76
Total Dissolved Solids (TDS)........................................... 77
Resistivity ....................................................................... 77
Salinity............................................................................. 77
Usage Recommendations and Cautions .......................................... 77
Conductivity and Temperature ................................................. 77
Sensor Care and Handling ............................................................... 77
Sensor Removal ...................................................................... 77
Maintenance/Inspection/Cleaning............................................ 77
Storage .................................................................................... 77
References ....................................................................................... 77
13 DISSOLVED OXYGEN ..................................... 78
What is Dissolved Oxygen?.............................................................. 78
Why Measure Dissolved Oxygen? .......................................... 78
Polarographic Measurement of Dissolved Oxygen........................... 79
The Polarographic Dissolved Oxygen Sensor .................................. 79
Theory of Operation ................................................................. 79
Sensor Conditioning................................................................. 79
Sensor Installation ............................................................................ 79
Fill the Membrane Module ...................................................... 79
Install the Sensor in the MP TROLL 9500................................ 80
Condition a Newly Installed Sensor ........................................ 80
Calibration........................................................................................ 80
Overview .................................................................................. 80
Nominal vs. Stable .......................................................... 81
Calibration Solutions & Equipment .......................................... 81
Recommended Calibration Frequency .................................... 81
Dissolved Oxygen Calibration Tips .......................................... 81
Dissolved Oxygen Quick Cal ................................................... 81
Traditional Dissolved Oxygen Calibration Procedure............... 81
Usage Recommendations and Cautions .......................................... 86
Attaching the Stirrer ........................................................86
Starting the Stirrer ........................................................... 86
Sensor Care and Handling ............................................................... 87
Sensor Removal ...................................................................... 87
Maintenance/Inspection ........................................................... 87
Replacing the Membrane Module ............................................ 87
Sensor Life............................................................................... 87
References ....................................................................................... 88
Optical Measurement of Dissolved Oxygen...................................... 89
The RDO Optical Dissolved Oxygen Sensor .................................... 89
The RDO Sensor and Salinity ......................................... 89
Unpack the RDO Cable connect Sensor ................................. 89
Unpack the RDO Direct connect Sensor ................................. 90
Installing the RDO Sensor CAP ............................................... 90
INstalling the RDO Sensor....................................................... 90
Calibration......................................................................................... 91
Overview .................................................................................. 91
Nominal vs. Stable .......................................................... 91
Calibration Solutions ................................................................ 92
Recommended Calibration Frequency .................................... 92
Traditional 2-Point Calibration.................................................. 92
Oxygen Saturation Point .......................................................... 92
Zero Oxygen Point ................................................................... 93
Barometric Pressure Options .......................................... 93
Finalize the Calibration ............................................................ 94
Status indicators: ............................................................ 94
Clean-up.......................................................................... 95
Units and Calculated Measurements................................................ 95
Usage Recommendations and Cautions .......................................... 95
Salinity............................................................................. 95
Sensor Care and Handling ............................................................... 95
Biofouling ................................................................................. 95
Cleaning the Sensor Cap ................................................ 96
Cleaning the Optical Window (Perform only if changing the
cap) ........................................................................ 96
Cleaning the Sensor Body ..............................................96
Storage............................................................................ 96
Replacing the Sensor Cap .............................................. 96

0095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
CONTENTS
VI
14 OXIDATION-REDUCTION POTENTIAL................ 97
What is ORP? .................................................................................. 97
Why Measure ORP? ................................................................ 97
The pH/ORP Sensor ......................................................................... 97
Sensor Installation ............................................................................ 98
Calibration......................................................................................... 98
Overview .................................................................................. 98
Calibration Solutions ................................................................ 98
Recommended Calibration Order for pH and ORP.................. 99
Traditional ORP Calibration Procedure.................................... 99
Resetting Default Coefficients................................................ 100
Sensor Offset ......................................................................... 100
Units and Calculated Measurements.............................................. 100
Recommended Calibration Frequency ........................................... 100
Normalization to Standard Hydrogen Electrode Values.................. 100
Usage Recommendations and Cautions ........................................ 101
Sensor Care and Handling ............................................................. 101
Sensor Removal .................................................................... 101
Maintenance/Inspection/Cleaning.......................................... 101
Replacing the Filling Solution ................................................ 101
Replacing the Junction........................................................... 101
Storage .................................................................................. 101
References ..................................................................................... 101
15 AMMONIUM .............................................. 104
What is Ammonium ? ..................................................................... 104
Why Measure Ammonium? ................................................... 104
The Ammonium Sensor .................................................................. 104
Sensor Preparation ................................................................ 104
The Nitrogen Cycle ................................................................ 104
Sensor Installation ................................................................. 105
Calibration....................................................................................... 105
Overview ................................................................................ 105
Calibration Solutions .............................................................. 105
Recommended Calibration Frequency .................................. 106
Preparing to Calibrate ............................................................ 106
Ammonium Calibration Procedure ......................................... 106
Sensor Slope and Offset........................................................ 108
Units and Calculated Measurements.............................................. 108
Usage Recommendations and Cautions ........................................ 108
pH ...................................................................................... 108
Temperature ........................................................................... 108
Conductivity ........................................................................... 108
Potential Interferences ........................................................... 108
Sensor Care and Handling ............................................................. 109
Sensor Removal .................................................................... 109
Maintenance/Inspection/Cleaning.......................................... 109
Storage .................................................................................. 109
References ..................................................................................... 109
16 CHLORIDE ................................................... 110
What Is Chloride? ........................................................................... 110
Why Measure Chloride? ........................................................ 110
The Chloride Sensor....................................................................... 110
Sensor Preparation ................................................................ 110
Sensor Installation ................................................................. 110
Calibration........................................................................................111
Overview .................................................................................111
Calibration Solutions ...............................................................111
Recommended Calibration Frequency ...................................111
Preparing to Calibrate .............................................................111
Chloride Calibration Procedure.............................................. 112
Sensor Slope and Offset........................................................ 114
Units and Calculated Measurements.............................................. 114
Usage Recommendations and Cautions ........................................ 114
pH Effects .............................................................................. 114
Potential Interferences ........................................................... 114
Sensor Care and Handling ............................................................. 114
Sensor Removal .................................................................... 114
Maintenance/Inspection/Cleaning.......................................... 114
Storage .................................................................................. 114
17 NITRATE ..................................................... 115
What Is Nitrate ? ............................................................................. 115
Why Measure Nitrate? ........................................................... 115
The Nitrate Sensor.......................................................................... 115
Sensor Preparation ................................................................ 116
Sensor Installation ................................................................. 116
Calibration....................................................................................... 116
Overview ................................................................................ 116
Calibration Solutions .............................................................. 117
Recommended Calibration Frequency .................................. 117
Preparing to Calibrate ............................................................ 117
Nitrate Calibration Procedure................................................. 117
Sensor Slope and Offset........................................................ 119
Units and Calculated Measurements.............................................. 119
Usage Recommendations and Cautions ........................................ 119
Temperature ........................................................................... 119
Potential Interferences ........................................................... 120
Sensor Care and Handling ............................................................. 120
Sensor Removal .................................................................... 120
Maintenance/Inspection/Cleaning.......................................... 120
Storage .................................................................................. 120
References ..................................................................................... 120
18 TURBIDITY .................................................. 121
What Is Turbidity? ........................................................................... 121
Why Measure Turbidity? ........................................................ 121
How Is Turbidity Measured? .................................................. 121
The Turbidity Sensor....................................................................... 122
The Turbidity Wiper......................................................................... 122
Wiper Installation ................................................................... 123
Wiper Movement.................................................................... 123
Manual Wipe .......................................................................... 124
Wiper Guidelines and Precautions......................................... 124
Calibration....................................................................................... 124
Factory Calibration................................................................. 124
Field Calibration ..................................................................... 124
Calibration Solutions .............................................................. 124
Recommended Calibration Frequency .................................. 125
Turbidity Calibration Procedure.............................................. 125
Resetting Default Coefficients................................................ 128
Sensor Slope and Offset........................................................ 128
Units and Calculated Measurements.............................................. 128
Usage Recommendations and Cautions ........................................ 128
Common Interferences .......................................................... 128
Profiling Turbidity ............................................................................ 128
Logging Turbidity Data.................................................................... 128

0095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
CONTENTS
VII
Sensor Care.................................................................................... 128
Inspection/Maintenance/Cleaning.......................................... 128
Wiper Maintenance......................................................................... 129
References ..................................................................................... 129
19 SDI-12 OPERATION ......................................130
SDI-12 Requirements ..................................................................... 130
Wiring.............................................................................................. 130
Connections.................................................................................... 130
SDI-12 Support ............................................................................... 130
Sensor Identification .............................................................. 131
Sensor Verification ................................................................. 131
Making SDI-12 Measurements ....................................................... 131
Redundant Logging (Win-Situ 4 and SDI-12) ................................. 132
Extended (ISCO) Commands ......................................................... 132
Reference ....................................................................................... 132
SDI-12 V 1.3 Command Set .................................................. 133
20 LOW-FLOW MONITORING ............................135
Preparation ..................................................................................... 135
RDO Sensor Preparation ....................................................... 135
Prepare the Flow Cell ............................................................ 135
Start the Software ........................................................................... 136
Launch the Flow-Sense Wizard...................................................... 136
Verify Unit Preferences .......................................................... 136
Flow-Sense Wizard Input....................................................... 137
Saving the Low-Flow Data or Template .......................................... 138
Output ............................................................................................. 139
Export to Excel Option .................................................................... 139
Using a Custom Excel Template ............................................ 139
21 CARE & MAINTENANCE ................................ 141
Replacing Batteries ........................................................................ 141
O-Ring Seals .................................................................................. 141
Lubrication ............................................................................. 141
Replacement.......................................................................... 142
General Cleaning............................................................................ 142
Storage ........................................................................................... 142
Sensor Storage ..................................................................... 142
Twist-Lock Connectors........................................................... 142
22 TROUBLESHOOTING.....................................143
Troubleshooting Connections ......................................................... 143
Troubleshooting Data Collection (Tests) ......................................... 143
Troubleshooting Sensors ................................................................ 144
Troubleshooting Calibration ........................................................... 144
APPENDIX........................................................145
Electronic Drift and Device Recalibration ....................................... 145
Determining Density ....................................................................... 145
GLOSSARY .......................................................147

1
Multi-Parameter
Water Quality TROLL®
TROLL 9500 Operator’s Manual 0095110 rev. 007 01/09
General Description of the Mp troll
9500
Your new Multi-Parameter TROLL 9500 water quality probe uses
the latest sensor and electronics technology to provide a robust,
durable, and user-friendly instrument.
The MP TROLL 9500 logs data from up to 7 water-level and
water-quality sensors, as well as built-in temperature and baro-
metric pressure sensors. Many custom options and versions are
available, so your instrument may not look exactly like those we
have chosen to illustrate in this manual.
The MP TROLL 9500 provides the convenience of a labora-
tory-quality measurement instrument for field use, providing true
in-situ monitoring of water level and water quality.
how to Use this ManUal
This operator’s manual is designed as both a start-up guide and
a permanent reference for the features, uses, and applications of
the Multi-Parameter TROLL 9500.
Section 1: Introduction to this Operator’s Manual and to In-Situ
Inc.; contacting us for warranty and repair issues
Section 2: Description of components and features of the Multi-
Parameter TROLL 9500
Section 3: Getting Started: setting up the software, connecting
for the first time, Quick-Calibrating the sensors, and a summary
overview of the setup to start collecting data
Section 4: Control Software: Win-Situ®4 and Pocket-Situ 4
Section 5: Profiling
Section 6: How to set up tests and start logging data; extracting
data to your PC; viewing and graphing data
1 introDUction
Section 7: Monitoring Pressure (Water Level): Info on the two basic
types of pressure sensors; setting up the pressure channel to obtain
the most accurate readings for your altitude and latitude; how to
display data as you wish to see it
Section 8: Temperature
Section 9: Barometric Pressure
Section 10: An overview of monitoring water quality with the MP
TROLL 9500: Sensor installation and calibration, software options,
calibration reports
Section 11: pH
Section 12: Conductivity
Section 13: Dissolved Oxygen: Polarographic (Clark cell)
RDO®Optical Dissolved Oxygen
Section 14: Oxidation-Reduction Potential (ORP)
Section 15: Ammonium
Section 16: Chloride
Section 17: Nitrate
Section 18: Turbidity
Section 19: SDI-12 Operation
Section 20: Low-Flow Monitoring
Section 21: Care and Maintenance advice
Section 22: Troubleshooting: Look here first if you have problems
making connections or calibrating . . .
The manual includes a Glossary and a comprehensive Index

20095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
CONVENTIONS
Throughout this operator’s manual you will see the following symbols.
The check mark highlights a tip about a convenient feature
of the MP TROLL 9500
The exclamation point calls your attention to a requirement
or important action that should not be overlooked
Typical usage questions and answers that we hope will help you gain
a better understanding of your new Multi-Parameter TROLL 9500
and simplify its setup and operation
UnpackinG anD inspection
Your MP TROLL 9500 was carefully inspected before shipping. Check
the instrument for any physical damage sustained during shipment.
Notify In-Situ and file a claim with the carrier if there is any such dam-
age; do not attempt to operate the instrument.
Please save packing materials for future storage and shipping of your
MP TROLL 9500. The shipping boxes have been performance-tested
and provide protection for the instrument and its accessories.
Accessories may be shipped separately and should also be inspected
for physical damage and the fulfillment of your order.
SERIAL NUMBER
The serial number is located on the large label on the Multi-Param-
eter TROLL 9500 body, and also on a small label inside the battery
compartment. The serial number is programmed into the instrument
and displayed when the instrument is connected to a PC running Win-
Situ 4 or Pocket-Situ 4. We recommend that owners keep a separate
record of this number. Should your Multi-Parameter TROLL 9500 be
lost or stolen, the serial number is often necessary for tracing and
recovery, as well as any insurance claims. If necessary, In-Situ main-
tains complete records of original owner’s names and serial numbers.
Serial numbers of the water-quality sensors are stored in sensor
memory and displayed in the software when sensors are installed.
to oUr cUstoMers . . .
Thank you for your purchase of an In-Situ product. We are glad
you chose us and our products to help you with your environmental
monitoring needs. In-Situ Inc. has been designing and manufactur-
ing world-class environmental monitoring instrumentation for over 25
years in the Rocky Mountains of the United States. As it was in the
beginning, our expectation is that this product will provide you with
many trouble-free years of use. To that end, we pride ourselves on
delivering the best customer service and support possible—24 hours
a day, 7 days a week. We believe that this level of commitment to
you, our customer, is imperative in helping you ensure clean, safe
groundwater and surface water resources across the globe. We
also understand the need for accurate, reliable assessments and we
continue to make significant investments in Research and Develop-
ment to ensure that we deliver the latest product and technological
innovations to support your needs.
Whether you are gathering information about your body of water for
a few moments, or over a period of years, you can rely upon us to
provide you with a quality product and outstanding customer support
at a fair price and have that product delivered to you when and where
you need it.
We want your experience with In-Situ Inc. to be pleasant and profes-
sional, whether you are renting from us, or purchasing from us. We
would be pleased to hear from you and learn more about your needs,
and your experiences with our products. Again, we thank you for
choosing In-Situ Inc. and we look forward to serving your needs now,
and in the future.
Bob Blythe, President and CEO
In-Situ Inc.
[email protected]
Section 1: introduction

30095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
what we proviDe
WARRANTY PROVISIONS
In-Situ Inc. warrants the Multi-Parameter TROLL 9500 for one year,
RDO sensors for three years, and other sensors for 90 days from date
of purchase by the end user against defects in materials and work-
manship under normal operating conditions. To exercise this warranty
contact Technical Support at the phone or e-mail address listed below
for a return material authorization (RMA) and instructions. Complete
warranty provisions are posted on our website at www.In-Situ.com.
Maintenance & calibration plans as well as extended warranties are
available. Contact your In-Situ representative for complete informa-
tion.
FIRMWARE & SOFTWARE UPGRADES
From time to time In-Situ may make available enhanced versions of
firmware and software to its customers over the Internet.
Visit our website at www.in-situ.com to download the latest firmware
and software.
how to contact Us
Technical Support: 800 446 7488
Toll-free 24 hours a day in the U.S. and Canada
Address: In-Situ Inc.
221 East Lincoln Ave.
Fort Collins, CO 80524
USA
Phone: [phone]
Fax: [phone]
Internet: www.in-situ.com
e-mail: [email protected]
To Obtain Repair Service (U.S.)
If you suspect that your Multi-Parameter TROLL 9500 is malfunction-
ing and repair is required, you can help assure efficient servicing by
following these guidelines:
1. Call or e-mail In-Situ Technical Support ([email protected]).
Have the product model and serial number handy.
2. Be prepared to describe the problem, including how the instru-
ment was being used and the conditions noted at the time of the
malfunction.
3. If Tech Support determines that service is needed, they will ask
that your company pre-approve a specified dollar amount for repair
charges. When the pre-approval is received, Tech Support will as-
sign an RMA (Return Material Authorization) number.
TIP: Please keep your RMA number for future
reference.
4. Clean the Multi-Parameter TROLL 9500 and cable. Decontaminate
thoroughly if it has been used in a toxic or hazardous environment.
See the cleaning guidelines and form on the following page.
If an instrument returned for servicing shows evidence of
having been used in a toxic or hazardous environment,
Customer Service personnel will require written proof of
decontamination before they can service the unit.
5. Carefully pack your Multi-Parameter TROLL 9500 in its original
shipping box, if possible. Include a statement certifying that the
instrument and cable have been decontaminated, and any support-
ing information.
6. Mark the RMA number clearly on the outside of the box with a
marker or label.
7. Send the package, shipping prepaid, to
In-Situ Inc.
ATTN: Repairs
221 East Lincoln Ave.
Fort Collins, CO 80524
USA
The warranty does not cover damage during transit. We recommend
the customer insure all shipments. Warranty repairs will be shipped
back prepaid.
Outside the U.S.
Contact your international In-Situ distributor for repair and service
information.
certification
The MP TROLL 9500 complies with all applicable directives per the
CE and FCC and was tested to the EN 61326 / FCC specifications
Section 1: introduction

4
TROLL 9500 Operator’s Manual 0095110 rev. 007 01/09
cleaninG GUiDelines
Please help us protect the health and safety of our employees by
cleaning and decontaminating equipment that has been subjected to
any potential biological or health hazards, and labeling such equip-
ment. Unfortunately, we cannot service your equipment without such
notification. Please complete and sign the form below (or a similar
statement certifying that the equipment has been cleaned and decon-
taminated) and send it along to us with each downhole instrument.
• Werecommendagoodcleaningsolution,suchasAlconox®, a
glassware cleaning product available from In-Situ (Catalog No.
0029810) and laboratory supply houses.
• Cleanallcabling.Removeallforeignmatter.
• Cleancableconnector(s)withaclean,drycloth.Donotsubmerge.
If an instrument is returned to our Service Center
for repair or recalibration without a statement
that it has been cleaned and decontaminated,
or in the opinion of our Service Representatives
presents a potential health or biological hazard,
we reserve the right to withhold service until
proper certification has been obtained.
Alconox is a registered trademark of Alconox Inc.
Company Name____________________________________________Phone ________________________
Address ________________________________________________________________________________
City __________________________________ State ________________ Zip _______________________
Instrument Type___________________________________ Serial Number ___________________________
Contaminant(s) (if known) __________________________________________________________________
_______________________________________________________________________________________
Decontamination procedure(s) used __________________________________________________________
_______________________________________________________________________________________
Cleaning verified by________________________________________ Title ___________________________
Date_______________________________
Decontamination & Cleaning Statement
Section 1: introduction
• Cleantheprobebody—includingthenosecone,restrictor,cable
head, and protective caps. Remove all foreign matter.
• Removeandcleanallremovablesensors.Rinsewithdeionizedor
distilled water after cleaning.

5
Multi-Parameter
Water Quality TROLL®
TROLL 9500 Operator’s Manual 0095110 rev. 007 01/09
systeM Description
The Multi-Parameter TROLL 9500 is a compact, modular system with
a range of components to customize the instrument to various ap-
plications and operational modes. Components include the instrument
body with a host of options, sensors, cables, external power acces-
sories, and consumable items.
stanDarD featUres
• 47mm(1.85in)diameter
• corrosion-resistantPVChousingwithtitaniumsetscrews
• 316Lstainlesssteelowrestrictor/sensorbuard
• Viton®seals
• Fastdatasampling
• Continuousreal-timereadings(proling)
• User-replaceableoff-the-shelfD-cellalkalinebatteries,orIn-
Situ–supplied 3.6V lithium D-cell batteries
• Fullysubmersible
• RS485communications
• Low-powermicroprocessor
• Permanentlyinstalled,factory-calibratedtemperaturesensor
• Permanentlyinstalled,factory-calibratedbarometricpressure
sensor, for use on vented cable
• Temperature-compensatedreal-timeclock
• Easy-to-useWin-Situ®4 control software for setup, download-
ing, text and graphical data display
• Opticallyisolatedcommunicationsignals
• Cableavailableinstandardandcustomlengthsofventedor
non-vented polyurethane, Halogen-free polyurethane, or Tefzel®
• Externalpowercapable
optional featUres
• ProlerandProfessionalfeaturesets,bothavailableinXP with
extended parameter capability
• SmartSensorsforwaterqualitymeasurements—removable,
replaceable, field-calibrated
• BasicSensorsincludeDissolvedOxygen(polarographic),
pH, combination pH/ORP, Low Conductivity, High Conductiv-
ity
• TheExtendedSensorsetincludesAmmonium,Chloride,
Nitrate, Turbidity, RDO®Optical Dissolved Oxygen
• Pocket-Situfull-featuredcontrolsoftwareforelduseona
PDA—take continuous real-time readings, calibrate, program,
and download logged data from multiple MP TROLLs
• RuggedReader®handheld PDA
• Temperature-compensatedventedornon-ventedpressure
sensor, available in several ranges, permanently installed and
factory-calibrated
• Permanentlyinstalled,factory-calibratedturbiditysensor
• Integraldataloggingcapability—upto4megabytesashdata-
storage memory (about a million individual readings)
• Fastdatadownloads
• Upto16-testcapacity;linear,event,andlinearaveragemea-
surement schedules
• SDI-12orRS485interface—orboth
• Flow-Senselow-owsamplingsoftwareforautomatedsampling
and report creation
• Optionalaccessoriesincludelow-owowcell,user-service-
able turbidity wiper, battery-powered magnetic stirrer for use in
stagnant water
• Instrumentnetworkingandtelemetry
2 coMponents & featUres

60095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
cables
Several basic cable types are used in the MP TROLL 9500 system:
• RuggedCable™,TPU-jacketed(ThermoplasticPolyUrethane)
• ventedornon-vented
• Halogen-Freeventedornon-vented(LSZH-rated,low
smoke zero halide)
Vented cable is recommended for applications where
accurate barometric pressure measurement is required—for
example when calibrating dissolved oxygen, or for
measuring DO in percent saturation.
• VentedTefzel®*cable
• Stainless steel suspension wire for use when cable venting is not
required (e.g., with an absolute pressure sensor)
• Communicationcablesforprogrammingthedevice/downloading
the logged data
RuggedCable™
Cable includes conductors for power and communication signals, a
strength member, and a Kellems®grip to anchor the MP TROLL 9500
securely. Available in standard and custom lengths.
Uphole and downhole ends are identical bayonet-type
Twist-Lock connectors that mate with the TROLL 9500
body, TROLL Com communication cable, desiccants, and
other accessories.
Vented cable is designed for use with vented pressure/
level sensors (gauged measurements). The cable vent
tube insures that atmospheric pressure is the reference
pressure applied to the pressure sensor diaphragm.
Vented cable also enables proper functioning of the inter-
nal barometric pressure sensor, and improves dissolved
oxygen readings.
Non-vented cable may be used with non-vented pressure/
level sensors (absolute measurements), or instruments
without a pressure sensor.
Section 2: componentS & FeatureS
MP TROLL 9500
Sealed Body
Sealed Battery Compartment
Twist-Lock Connector
Stainless steel Restrictor —
provides generous openings for
circulation of environmental water,
unscrews for installation/removal of
sensors
Acetal Nose Cone minimizes sedi-
ment buildup and protects the front
end from bottoming out on a hard
surface; removable for installation of
optional accessories
RuggedCable
* FEP = fluorinated ethylene propylene, the generic equivalent of DuPont Teflon®.

70095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
CABLE DESICCANTS
Small Desiccant
Clear cap of indicating silica gel desiccant seals the uphole
end of the RuggedCable during use; protects the cable vent
tube and device electronics from condensation. The desic-
cant is blue when active. It will absorb moisture from the
top down and for best results should be replaced before the
entire volume has turned pink. Replacements are available
from In-Situ Inc. or your distributor.
Large Desiccant
The high-volume desiccant pack may last up to 20 times
longer than the small desiccant in humid environments. It
attaches to the RuggedCable in the same way. Refill kits are
available from In-Situ Inc. or your distributor.
Accessory Catalog No.
Small desiccant (3)................................................................. 0052230
Large desiccant, plastic connector ......................................... 0053550
Large desiccant, titanium connector....................................... 0051810
Large desiccant refill kit.......................................................... 0029140
COMMUNICATION CABLES
Comm cables interface between the TROLL 9500 and a desktop/lap-
top PC or handheld PDA for profiling, calibrating, programming, and
downloading. Both types include 0.9 m (3 ft) polyurethane cable,
external power input jack, and vent
with replaceable membrane.
TROLL Com (Cable Connect)
Connects a TROLL 9500’s Rug-
gedCable to a serial or USB port;
Weatherproof, withstands a temporary
immersion (IP67).
TROLL Com (Direct Connect)
Connects a TROLL 9500 directly to a serial or
USB port. A good choice for permanent connec-
tion to a PC, or for programming a non-vented
TROLL 9500 that will be deployed without Rug-
gedCable. Not designed for field use.
Accessory Catalog No.
RS232 TROLL Com, Cable Connect...................................... 0056140
RS232 TROLL Com, Direct Connect...................................... 0056150
USB TROLL Com, Cable Connect ......................................... 0052500
USB TROLL Com, Direct Connect ......................................... 0052510
power coMponents
The MP TROLL 9500 operates in 2 power modes
• internalpower
• externalAClinepower
INTERNAL POWER
The MP TROLL 9500 uses:
• twostandard1.5ValkalineDcells,OR
• two3.6VlithiumDcells—recommendedforusewithanRDO
optical dissolved oxygen sensor, and with a turbidity wiper
Use only Saft LSH-20 3.6V lithium D cells. Use of any other
lithium battery will void the product warranty.
EXTERNAL POWER
A single MP TROLL 9500 can run exclusively on power supplied from
a 9 -12 VDC line power supply connected to a 90-264 VAC input.
When line power is enabled, the TROLL shuts down the battery regu-
lator, thus preserving the internal batteries. All TROLL Com models
include an external power input jack.
Accessory Catalog No.
AC Adapter 9V........................................................................ 0031880
Replacement batteries, alkaline (1)........................................ 0042020
Lithium battery (2) kit ............................................................. 0048230
TIP: Battery life is dependent upon temperature, cable
length, and how often the device is recording measure-
ments.
Section 2: componentS & FeatureS
RS232
or USB
connector
Vent
External
power input
Twist-Lock
connector

80095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
water QUality accessories
Basic Sensors Catalog No.
pH .......................................................................................... 0059510
pH/ORP ................................................................................. 0059520
Low Conductivity ................................................................... 0033210
High Conductivity ................................................................... 0033220
Polarographic Dissolved Oxygen .......................................... 0032870
Extended Sensors Catalog No.
Nitrate .................................................................................... 0032050
Ammonium ............................................................................ 0032060
Chloride ................................................................................. 0032070
RDO Optical Dissolved Oxygen sensor
for use with pressure and/or turbidity sensor, sub-4”.............. 0085070
RDO Optical Dissolved Oxygen sensor
without pressure and/or turbidity sensor, sub-2”..................... 0084310
Turbidity Wiper........................................................................ 0044510
Battery-Powered Magnetic Stirrer .......................................... 0042210
Calibration Kit Catalog No.
Quick-Cal: 4 x 250 mL (for calibrating Basic Sensors) .......... 0033250
Dissolved Oxygen: 1 liter DI water, 500 mL Na2SO3.............. 0032110
RDO bubbler cal kit for 0085070 sensor ................................ 0048580
RDO bubbler cal kit for 0084310 sensor ................................ 0080830
Polarographic DO bubbler cal kit............................................ 0095150
Conductivity: 147 µS, 1413 µS, 12890 µS, DI water .............. 0032090
Low Conductivity: 2 each 147 µS, 1413 µS .......................... 0032630
High Conductivity: 2 each 12890 µS, 58670 µS..................... 0032640
pH: 1 each pH 4, pH 7, pH 10, DI water................................. 0032080
ORP: 1 liter Zobell’s Solution ................................................. 0032100
pH/ORP: 1 each pH 4, pH 7, pH 10, Zobell’s Solution ........... 0032120
Nitrate: 1 each 14, 140, 1400 ppm, DI water.......................... 0032130
Low Nitrate: 2 each 14, 140 ppm............................................ 0032650
High Nitrate: 2 each 140, 1400 ppm....................................... 0032660
Ammonium: 1 each 14 ppm, 140 ppm, 1400 ppm, DI water .. 0032140
Low Ammonium: 2 each 14, 140 ppm ................................... 0032670
High Ammonium: 2 each 140, 1400 ppm ............................... 0032680
Chloride: 1 each 35.5, 355, 3545 ppm, DI water.................... 0032150
Low Chloride: 2 each 35.5, 355 ppm...................................... 0032690
High Chloride: 2 each 355, 3545 ppm.................................... 0032700
Calibration Solution Catalog No.
Na2SO3(Sodium Sulfite) for DO Cal, 500 mL......................... 0017670
Conductivity, 147 µS............................................................... 0032560
Conductivity, 1413 µS............................................................. 0020680
Conductivity, 12890 µS........................................................... 0020690
Conductivity, 58670 µS........................................................... 0032580
pH 4........................................................................................ 0006370
pH 7........................................................................................ 0006380
pH 10...................................................................................... 0006390
ZoBell’s Solution (ORP).......................................................... 0032210
Nitrate, 14 ppm as N............................................................... 0032520
Nitrate, 140 ppm as N............................................................. 0032230
Nitrate, 1400 ppm as N........................................................... 0032240
Ammonium, 14 ppm as N....................................................... 0032510
Ammonium, 140 ppm as N..................................................... 0032260
Ammonium, 1400 ppm as N................................................... 0032270
Chloride, 35.5 ppm ................................................................. 0032500
Chloride, 355 ppm .................................................................. 0032290
Chloride, 3545 ppm ................................................................ 0032300
Turbidity, 10 NTU polymer suspension, 500 mL..................... 0033070
Turbidity, 100 NTU polymer suspension, 500 mL................... 0033100
Turbidity, 1000 NTU polymer suspension, 500 mL................. 0033120
Turbidity, 1800 NTU polymer suspension, 500 mL................. 0033140
Maintenance/Service/Replacement Parts Catalog No.
Sensor insertion tool............................................................... 0042310
Sensor removal tool................................................................ 0042110
Cal cup, PVC.......................................................................... 0041440
Replacement wiper head ....................................................... 0044520
Wiper pad replacement kit...................................................... 0044530
Lithium battery kit (2 “D” cells, 3.6V ea.) ................................ 0048230
Calibration Kits (four liters
unless otherwise noted)
Individual Calibration Solutions
(one liter unless otherwise noted)
Section 2: componentS & FeatureS

90095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
Section 2: componentS & FeatureS
MP TROLL 9500 Maintenance kit (o-rings, lubricant, dust caps,
sensor port plugs).............................................................. 0095100
MP TROLL 9500 Maintenance kit (o-rings, lubricant, dust caps,
sensor port plugs) for use with 0085070 RDO sensors..... 0095100
DO sensor service kit, 1-mil membranes................................ 0033200
DO sensor service kit, 2-mil membranes................................ 0033440
RDO Sensor Cap replacement kit .......................................... 0084230
RDO Maintenance kit (sensors purchased before 09/08) ...... 0048250
RDO Foil replacement kit (sensors purch. before 09/08) ....... 0048500
pH & pH/ORP Reference Filling Solution (60 mL).................. 0056900
pH & pH/ORP Reference Junction kit..................................... 0059620
pH & pH/ORP Sensor Storage Solution (500 mL).................. 0065370
installation accessories
• Twist-LockHanger:stainlesssteelhangertosuspendanon-
vented TROLL 9500, Level TROLL, or Baro TROLL while taking
data; no venting, no communication capabilities
• CableExtender:connectstwolengthsofRuggedCable
• Wellcaps,lockingandvented
• WellDocks:top-of-wellsupportfor2”,4”,or6”well
• SDI-12adapter:powerandsignalmanagementforSDI-12com-
munication
Accessory Catalog No.
Twist-Lock Hanger.................................................................. 0051480
Cable Extender....................................................................... 0051490
Locking Wellcap, 2” ............................................................... 0020360
Locking Wellcap, 2” vented ................................................... 0020370
Locking Wellcap, 4” ............................................................... 0020380
Locking Wellcap, 4” vented ................................................... 0020390
Top-of-well installation ring ................................. WELLDOCK2”, 4”, 6”
SDI-12 adapter ...................................................... 0095200, 0095210
Flow Cell (sub-2 in)................................................................. 0044710
Flow Cell (sub-4 in)................................................................. 0057600
Twist-Lock Hanger Cable Extender Locking Wellcap
Well Dock
SDI-12 Adapter
control software
Win-Situ®4 enables communication between the MP TROLL 9500
and a desktop or laptop PC.
Win-Situ provides instrument control for calibration, profiling, direct
readings, data logging, data extraction, data viewing (text and graphi-
cal interface), choice of units and other custom display options, bat-
tery/memory usage tracking, interface to networks and telemetry.
System requirements: Microsoft®Windows®2000, Windows XP, or
WindowsVista™;InternetExplorer(IE)5.0orlater,andaCD-ROM
drive.
Pocket-Situ 4 provides Win-Situ’s features and functions on a field-
portable platform. Requirements: In-Situ RuggedReader®or other
supported PDA running Microsoft Pocket PC (Windows Mobile®)
2003 or later, with a serial communications port for connection to the
TROLL 9500, and at least 16 megabyte capacity for data storage (SD
card, CF card, or the device’s built-in non-volatile memory).
For installation and file exchange, Pocket-Situ requires the following
installed on an office desktop or laptop computer:
• Microsoft®ActiveSync®
• Win-Situ4
• Optional:Win-SituSync(orPocket-Sync4,earlierversionof
Win-Situ Sync)

10
TROLL 9500 Operator’s Manual 0095110 rev. 007 01/09
proDUct specifications
WettedMaterials* PVC,titanium,Viton®, acetal, 316L SS
OperatingTemperature* -5°Cto50°C(23°Fto122°F)
StorageTemperature* -40°Cto80°C(-40°Fto176°F)
PressureRating* 350psi(246m,807ft)
Dimensions 47 mm (1.85 in) dia, x 57.7 cm (22.7 in)
long
with RDO adapter 88.4 mm (3.48 in) dia, 57.7 cm (22.7 in)
long
Weight (without cable) 1.4 Kg (3.1 lbs)
Power
Battery type 2 standard alkaline D-cells (1.5 V), or
2 lithium D cells (approx. 3.6 V)
External power input 9-12 VDC (optional)
Data Sampling
Memorytype/size(memory 4megabytesashdatastorage,about
-equipped models) 1,000,000 individual readings
Fastest linear logging rate 5 seconds (10 seconds with RDO)
Profiling speed 2 seconds
Communications RS485
Computer interface RS232
Software
Win-Situ®4 Desktop/laptop PC with Microsoft®Win-
dows®2000 SP2 or later (Windows XP,
WindowsVista™),InternetExplorer5.0
or later, serial com port, CD-ROM drive,
16-64 Mb RAM
Pocket-Situ 4 In-Situ RuggedReader®or other sup-
ported handheld PDA running Microsoft
Pocket PC (Windows Mobile®) 2003 or
later
Cable
Jacket options Polyurethane, halogen-free (HF) polyure-
thane, Tefzel®
Conductors 6 conductors, 24 AWG, polypropylene
insulation
Diameter 6.7 mm (0.265 in)
Connector Titanium, 18.5 mm (0.73 in) O.D.
Break strength 127 kg (280 lb)
Minimum bend radius 2X cable diameter (13.5 mm, 0.54 in)
Weight Vented, regular & HF: 14 kg/300 m (32.3
lb/1000 ft)
Non-vented, regular & HF: 16 kg/300 m
(35.6 lb/1000 ft)
Vented Tefzel®: 23kg / 300m (52 lb /1000 ft)
Factory-Installed Sensors
Pressure/level
Type Media-isolated piezoresistive silicon
strain gauge
Range 15 psig (0-11 m, 0-35 ft)
30 psia/psig (0-21 m, 0-69 ft)
100 psia/psig (0-70 m, 0-231 ft)
300 psia/psig (0-210 m, 0-692 ft)
Accuracy better than ± 0.1% FS
Resolution 1 mm
Temperature
Type Platinum resistance thermometer
 Range -5°Cto50°C(23°Fto122°F)
 Accuracy ±0.1°C
 Resolution 0.01°C
Barometric pressure
Type Piezoresistive silicon pressure sensor
Range 0-16.5 psia (854 mm Hg, 33.6 in Hg)
Accuracy ± 0.3% FS (2.54 mm Hg, 0.1 in Hg)
Resolution 0.1 mm Hg, 0.01 in Hg
Turbidity
 Type Nephelometer,90°lightscattering,870
nm LED, solid-state
Range 0-2000 NTU
Accuracy ± 5% or 2 NTU (whichever is greater)
Resolution 0.1 NTU
Turbidity Wiper
Pressure Rating 350 psi (246 m, 807 ft)
 OperatingTemp. 0°Cto50°C
Basic Sensors
Conductivity
Type 4-cell conductivity, AC drive
Operating Range
Low Range sensor 5 µS/cm to 20,000 µS/cm
High Range sensor 150 µS/cm to 112,000 µS/cm
Accuracy
Low Range sensor ± 0.5% or 2 µS/cm (whichever is greater)
when calibrated in region of interest.
High Range sensor ± 0.5% + 2 µS/cm between 150 µS/cm
and 112,000 µS/cm when calibrated in
region of interest. From 70 to 150 µS/cm
& 112,000 to 200,000 µS/cm ± 2% + 4
µS/cm typical
Resolution Range-dependent
Pressure Rating 350 psi (246 m, 807 ft)
 OperatingTemp. -5°Cto50°C(23°Fto122°F)
Section 2: componentS & FeatureS
* Base unit = MP TROLL 9500 & factory-installed sensors

11
TROLL 9500 Operator’s Manual 0095110 rev. 007 01/09
pH
Type Glass sensing bulb, single-junction
electrode, replaceable ceramic junction,
refillable reference electrolyte
Range 0 to 12 pH units
Pressure Rating 350 psi 246 m, 807 ft
Operating Temp. 0°C to 50°C (32°F to 122°F)
Accuracy ± 0.1 pH unit
Resolution 0.01 pH unit
pH/ORP
Type Glass sensing bulb, platinum wire, single-
junction electrode, replaceable ceramic
junction, refillable reference electrolyte
Range ± 1400 mV, 0 to 12 pH
Pressure Rating 350 psi 246 m, 807 ft
Operating Temp. 0°C to 50°C (32°F to 122°F)
Accuracy ± 4 mV, ± 0.1 pH unit
Resolution 1 mV, 0.01 pH unit
Dissolved Oxygen (polarographic)
Type Clark polarographic
Range 0 to 20 mg/L, 0 to 200% saturation
Pressure Rating 350 psi (246 m, 807 ft); submersion &
retrieval at up to 4 ft per second
Operating Temp. -5°C to 50°C (23°F to 122°F)
Accuracy ± 0.2 mg/L
Resolution 0.01 mg/L
Extended Sensors
Dissolved Oxygen (optical, RDO)
Type Optical, fluorescence quenching
Range 0 to 20 mg/L, 0 to 450% saturation
Pressure Rating 300 psi
Operating Temp. 0°C to 40°C (32°F to 104°F)
Accuracy ± 0.1 mg/L @ 0-8 mg/L
± 0.2 mg/L @ 8-20 mg/L
Resolution 0.01 mg/L
Section 2: componentS & FeatureS
Ammonium (NH4
+)
Type PVC membrane sensing element, double
junction Ag/AgCl reference half-cell,
reference electrolyte gel
Range 0.14 to 14,000 ppm N (0.1 to 18,000 ppm
NH4
+)
Pressure Rating 20 psi (14 m, 46 ft)
Operating Temp. -5°C to 40°C (23°F to 104°F)
Accuracy ± 10%
Resolution 0.01 ppm
Chloride (Cl–)
Type Solid-state sensing electrode, double
junction Ag/AgCl reference half-cell,
reference electrolyte gel
Range 0.35 to 35,500 ppm Cl (2 to 35,000 ppm
Cl–)
Pressure Rating 100 psi (70 m, 231 ft)
Operating Temp. -5°C to 50°C (23°F to 122°F)
Accuracy ± 15%
Resolution 0.01 ppm
Nitrate (NO3
–)
Type PVC membrane sensing element, double
junction Ag/AgCl reference half-cell,
reference electrolyte gel
Range 0.14 to 14,000 ppm N (0.4 to 62,000 ppm
NO3
–)
Pressure Rating 20 psi (14 m, 46 ft)
Operating Temp. -5°C to 40°C (23°F to 104°F)
Accuracy ± 10%
Resolution 0.01 ppm
Typical Battery Life @ 20°C
Battery type
Installed sensors
Sample Interval
15 min.
2 alkaline D-cells
Pressure, temperature, baro, turbidity
Pressure, temperature, baro, turbidity, pH/ORP, conductivity, RDO, DO
Pressure, temperature, baro, turbidity, pH/ORP, conductivity, RDO
127 days
85 days
90 days
2 lithium D-cells
Pressure, temperature, baro, pH/ORP, conductivity, RDO, turbidity, no wiper
270 days

12
Multi-Parameter
Water Quality TROLL®
TROLL 9500 Operator’s Manual 0095110 rev. 007 01/09
This section provides a quick overview of the initial steps necessary to
get the Multi-Parameter TROLL 9500 ready to take measurements.
You will need—
• Power
• Sensors
• Software
• Cable
TROLL Com communication cable for deployment
• CalibrationKit—oneforeachsensortobecalibrated,orthe
QuickCal Kit for the Basic Sensor set (pH, ORP, polarographic
D.O., Conductivity)
proviDe power
TIP: When the unit ships with a Polarographic Dissolved
Oxygen sensor installed, alkaline batteries are pre-installed
in the device to power the D.O. sensor and keep it
conditioned.
Install batteries in the Multi-Parameter TROLL 9500 as
follows:
1. Unscrew and remove the battery compartment
cover. Slide it up over the cable (if attached).
3 GettinG starteD
2. Insert two D-size batteries negative side first, positive side up.
3. Replace the battery compartment cover and tighten to compress
the o-ring seals.
Screw the cover down firmly to compress the o-rings and
create a waterproof seal. When properly assembled, the o-
rings will not be vsible.
TIP: The MP TROLL 9500 uses standard off-the-shelf 1.5V
alkaline D-cells.
Alternatively, you may use Saft LSH-20 3.6V lithium D cells.
Use of any other lithium battery will void the product
warranty.

13 0095110 rev. 007 01/09
TROLL 9500 Operator’s Manual
install sensors
Basic water-quality sensors—pH or pH/ORP, polarographic D.O.,
Conductivity—may arrive installed in the instrument’s sensor ports.
Proceed to Install Software if there are no additional sensors to be
installed.
Install sensors in the Extended Sensor Set and any sensors shipped
separately as follows:
TIP: The RDO®Optical Dissolved Oxygen sensor has
special installation requirements. Please refer to the RDO
Quick Start guide, or see Section 13 of this operator’s
manual for complete information.
1. Remove the restrictor or Cal Cup from the front end of the MP
TROLL 9500.
This allows access to the sensor block depicted in the drawing
below.
There are four sensor ports, 1 – 4, plus a permanently installed
pressure and/or turbidity sensor or plug.
sensor
removal
tool
2. Remove the sensor’s protective cap or storage bottle and set aside
for future storage of the sensor. If the connector end is covered
with a cap, remove it also.
3. Remove any moisture or dirt from the area around
the port where you will install the sensor, then use
the sensor removal tool to remove the plug from the
port. Retain the plug for use when with fewer than 4
removable sensors installed.
4. Remove any moisture or dirt from the port connector with a clean
swab or tissue.
5. Check lubrication of the sensor o-rings.
The sensor o-rings require generous lubrication before
installation. New sensors will be lubricated at the factory. If
the o-rings appear dry, apply a silicone lubricant before
installation.
6. Align the mark on the side of the sensor with the mark on the cor-
rect port (see diagram), or visually align the sensor connector pins
with the port connector pins.
If the sensing element is at the end of the sensor, be careful
to handle the sensor by the sides. Use the insertion tool to
press the sensor into the port at step 7.
7. Press the sensor firmly into the port until you feel it
dock with the connector at the bottom.
When the sensor is properly inserted, a small gap (the
width of the sensor removal tool) remains between the
instrument body and the widest part of the sensor, for
ease of removal.
After installing a polarographic D.O. sensor, we recommend
conditioning it for 2-4 hours, preferably overnight, before
calibrating. For more on D.O. sensor conditioning, see
Section 13.
sensor
insertion
tool
Section 3: GettinG Started
Cable
connector Body Restrictor
Battery com-
partment
Conductivity
Pressure/Turbid-
ity (or plug)
Temperature
D.O. (polarographic)
or ammonium
or chloride
or nitrate
pH/ORP
or RDO
or pH
or ammonium
or chloride
or nitrate
RDO
or pH
or ammonium
or chloride
or nitrate
or turbidity wiper
End view of sensor block
Alignment mark
End view with the RDO cable
connect sensor plugged into ports
1 or 3
End view with the RDO direct con-
nect sensor plugged into ports 3 and
covering ports 2 and 5.
