Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
2/16
Contents
1_ Document Information .....................................................................4
1_1 Evolution follow-up ........................................................................................ 4
1_2 Acronyms ....................................................................................................... 4
1_3 References..................................................................................................... 5
2_ Introduction......................................................................................... 5
3_ General Description............................................................................ 6
3_1 Product Overview........................................................................................... 6
3_1_1 Product type ................................................................................................................... 6
3_1_2 Product functionalities .................................................................................................... 6
3_2 Product Identification...................................................................................... 7
3_2_1 Product name ................................................................................................................. 7
3_2_2 Product hardware version .............................................................................................. 7
3_2_3 Product software versions .............................................................................................. 8
4_ Guidance...........................................................................................9
4_1 Initial Security Inspection................................................................................ 9
4_2 Installation Guide ........................................................................................... 9
4_3 PIN Confidentiality.......................................................................................... 9
4_4 Periodic Inspection and Maintenance............................................................10
4_5 Product Service Removal..............................................................................10
5_ Product Hardware Security............................................................ 11
5_1 Tamper Response Event...............................................................................11
5_2 Environment Conditions and Environmental Failure Protection.....................11
6_ Product Software Security............................................................. 12
6_1 Software Development Guidance..................................................................12
6_2 Account data protection.................................................................................12
6_3 Firmware, Software and Configuration Parameters Update ..........................12
6_4 Software Authentication ................................................................................12

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
3/16
6_5 Self-Tests......................................................................................................13
7_ System Administration..................................................................... 14
7_1 Configuration Settings ...................................................................................14
7_2 Default Value Update ....................................................................................14
8_ Key Management............................................................................ 14
8_1 Key Management Techniques.......................................................................14
8_2 Cryptographic Algorithms ..............................................................................14
8_3 Key Table......................................................................................................15
8_4 Key Replacement..........................................................................................15
8_5 Key Loading Policy........................................................................................16
9_ Roles and Services ........................................................................ 16

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
4/16
1_Document Information
1_1 Evolution follow-up
Revision
Type of modification
Date
1
Document creation 2017/11/06
2Document Update 2018/03/08
3Document Update 2019/05/02
4 Document Update 2020/05/26
5 Document Update 2020/06/11
6 Document Update 2020/06/22
7 Document Update 2020/06/24
8 Document update 2020/08/14
9 Document update 2022/01/25
10 Document update 2022/02/10
11 Document update 2022/03/14
1_2 Acronyms
AES Advanced Encryption Standard
DUKPT Derived Unique Key per Transaction
N/A Not Applicable
PED PIN Entry Device
PIN Personal Identification Number
RSA Rivest Shamir Adleman Algorithm
SHA Secure Hash Algorithm
TDES Triple Data Encryption Standard
ECDSA Elliptic curve digital signature algorithm

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
5/16
1_3 References
[1] ANS X9.24 Part 2: 2016, Retail Financial Services Symmetric Key Management Part 2:
Using Asymmetric Techniques for the Distribution of Symmetric Keys
[2] ANS X9.24 - 1: 2017, Retail Financial Services Symmetric Key Management Part 1: Using
Symmetric Techniques
[3] ANS X9.24 - 3: 2017, Retail Financial Services Symmetric Key Management Part 1: Unique
Key Per Transaction
[4] X9 TR-31 2018, Interoperable Secure Key Exchange Key Block Specification for Symmetric
Algorithms
[5] ISO 9564-1, Financial services — Personal Identification Number (PIN) management and
security — Part 1: Basic principles and requirements for PINs in card-based systems
[6] ISO 9564-2, Banking — Personal Identification Number management and security Part 2:
Approved algorithms for PIN encipherment
[7] PCI PTS POI Derived Test Requirements V5.1 – March 2018
[8] Ingenico Move/3500 Installation guide
[9] Ingenico ICO-OPE-01390, Package IP: Security guidance user’s guide
[10] Ingenico ICO-OPE-01391, Package SSL: Security guidance user’s guide
[11] Ingenico ICO-OPE-01935, Secure Reading and Exchange of Data security guidance
Notes:
[8] is delivered to the end user.
[9], [10], [11] are delivered to authorized software developers:
2_Introduction
This document addresses the proper use of the POI in a secure manner including information about
key-management responsibilities, administrative responsibilities, device functionality, identification and
environmental requirements.
The use of the device in an unapproved method, as described in the security policy, will violate the
PCI PTS v5.1 approval of the device.

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
6/16
3_General Description
3_1 Product Overview
3_1_1 Product type
The Move/3500 PED is a Point of Sale (POS) payment handheld device, to process credit and PIN-
based debit card transactions in an attended environment. The device can also be used as a desk
mounted device, when following the guidance as stated in the installation guide.
3_1_2 Product functionalities
The Move/3500 PED is equipped to handle all form of payment including:
− EMV chip & PIN,
− Chip & Sign
− Magstripe including JISII Tracks
− Contactless
It provides USB host/device, Wi-Fi, Network cellular, Bluetooth and Bluetooth Low Energy1
Figure 1: Move/3500
1The use of BLE Beacon interface shall respect guidance document [9]

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
7/16
3_2 Product Identification
3_2_1 Product name
The product name is visible on the front of the device (see figure 1).
The product name shall not be modified by the merchant or covered by a sticker.
3_2_2 Product hardware version
The product hardware version is printed on a label at the back of the device.
The label at the back of the device shall not be teared off, covered or altered.
Hardware
version number
Figure 2: Move/3500 product hardware identification
The full list of approved Hardware Version Number is available on the PCI PTS
website.

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
8/16
3_2_3 Product software versions
The software versions can be retrieved using the software menu.
To get this information on the device, select the following menu:
• “Control Panel”, then “Terminal information”.
• Select “Firmware PCI PTS” from the following configuration menu:
• Select “On display” from the following configuration menu:
The following items are displayed:
• “M1” is the reference of the firmware.
• “M3” is the reference of the “Open Protocols” module.
• “M4” is the reference of the “SRED” module.
Terminal information
Firmware PCI PTS [other]
Firmware PCI PTS
On display
[other]

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
9/16
4_Guidance
4_1 Initial Security Inspection
The merchant or acquirer must visually inspect the terminal for sign of tampering when received via
shipping, as it is described in the Installation Guide [8].
It is strongly advised that these checks are also performed on a regular basis after receipt and
installation.
For example, the merchant or acquirer should inspect the terminal to ensure that:
• There is no evidence of unusual wires that have been connected to any ports of the terminal,
or associated equipment, the chip card reader or any other part of the terminal.
• There is no shim device in the slot of the ICC acceptor
• The keypad is firmly in place
• No warning flashing message is displayed
• The terminal serial number (on the rear side label) corresponds to the inventory
Such checks would provide warning of any unauthorized modifications to or substitution of the
terminal, or suspicious behavior of individuals that have access to the terminal.
4_2 Installation Guide
An installation guide [8] including the following information is provided with the device:
• Equipment check list :
− Device,
− Cable and connectors,
− Documents
• Power and cable connections information,
• The main characteristics of the device (i.e. temperature, humidity, voltage)
• Safety recommendations,
• Security recommendations,
• Troubleshooting if the device does not work.
4_3 PIN Confidentiality
The device is designed to be used in attended environment.
It’s recommended that the position of the terminal must be in such a way to make cardholder PIN
spying infeasible.
The installation guide [8] provides instructions for the installation and use of the terminal in a secure
manner depending on the device environment.
Further recommendations about the installation of the terminal variants without privacy shield are
specified in the installation guide [8].
NEVER ask the customer to divulge their PIN Code.
With guidance message or logos, indicate to the cardholder to use his hands and/or his body to cover
up the keypad.
The cardholder shall be advised to ensure that he is not being overlooked when entering his PIN code.

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
10/16
4_4 Periodic Inspection and Maintenance
Information about periodic inspection is specified in the installation guide [8].
The merchant or acquirer should daily check that the keypad is firmly in place. Such checks would
provide warning of any unauthorized modification to the terminal, or suspicious behavior of the
terminal.
In the tampered state, the device displays a warning flashing message and further use of the device is
not possible. If such a message is observed, the merchant or acquirer must contact the device
helpdesk immediately, remove it from service and keep it available for potential forensics investigation.
The merchant or acquirer should also check that the installation/maintenance operations are
performed by a trusted person and log the maintenance operations, including name of the operator.
The merchant or acquirer should check if the ICC reader slot is damaged, such as abrasion, painting
and other machining marks or if there is any suspicious object like lead wire or any unknown object
inside ICC reader.
If such suspicious circumstances are observed, the merchant or acquirer shall stop using the device
immediately and contact the customer service to confirm the device has been tampered.
Figure 3: ICC reader slot
4_5 Product Service Removal
Sensitive data must be erased before refurbishing the device or removing it permanently from service.
The device shall go to tampered status, a state in which sensitive data are erased.
For example, disassembly of the device will lead to a tampered status.

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
11/16
5_Product Hardware Security
5_1 Tamper Response Event
The device contains tamper mechanisms that will trigger when a physical penetration attempt of the
device is detected. A merchant or acquirer can easily detect a tampered terminal:
− The numerical keyboard is locked,
− A flashing warning message is displayed.
Figure 4: Example of tamper message
Any physical penetration will result in a “tamper event”. This event causes the activation of tamper
mechanisms that make the device out of service.
There are two separate modes in which the device can be:
− Activated mode: the device is fully operational.
− Non-activated mode: the device is tampered, not operating and needs reactivation after
maintenance and security checks.
Information about the tamper events are also described in the installation guide [8].
If the device is in tampered state, the merchant or acquirer should contact the device helpdesk
immediately, remove it from service and keep it available for potential forensics investigation.
5_2 Environment Conditions and Environmental Failure Protection
The environmental conditions to operate the device are specified in the installation guide [8].
The security of the device is not compromised by altering the environmental conditions (e.g. subjecting
the device to temperature or operating voltages outside the stated operating ranges does not alter the
security).

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
12/16
6_Product Software Security
6_1 Software Development Guidance
When developing IP enabled applications, the developer must abide by the coding rules and best
practices described in the document [9], [10].
The following protocols and services are available on the device: TLS /SSL2, IP, DNS, SMTP,
POP3, DHCP, HTTP, HTTPS, SNTP, SOCKS, FTP, SFTP, WS/WSS, TCP/UDP, PPP.
This security guidance describes how protocols and services must be used/configured for each
interface that is available on the platform.
Note that SSL protocol is inherently weak and should be removed unless required on an interim basis
to facilitate interoperability as part of a migration plan.
When developing SRED applications, the developer must follow the guidance described in the
document [11].
The document provides security guidance for account data management and remote connection
authentication using cryptographic mechanisms.
When developing applications, the developer must follow the guidance described in the document
[11].
6_2 Account data protection
The device supports account data protection using format-preserving encryption (FPE). The FPE
method used are BPS and FF1.
The device also supports account data protection using standard TDES and standard AES.
The pass-through of clear-text account data is supported using whitelisting technique.
6_3 Firmware, Software and Configuration Parameters Update
Updates and patches can be loaded in the device. They are cryptographically authenticated by the
device. If the authenticity is not confirmed, the update or patch is rejected.
For the secure operation of the device, it is recommended to use the latest version of software
distributed
6_4 Software Authentication
Application code is authenticated before being allowed to run. The certificate and signature of the
application code is verified.
In case of incorrect signature or certificate, software is rejected. No action is expected from the end
user.
The certificate and signature are based on couples of ECDSA keys. The authenticity is guaranteed by
a certificate emitted by Ingenico.
2SSL is only allowed for non-web services. If web services are used, only TLS is allowed for web
interfaces.

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
13/16
6_5 Self-Tests
Self-tests are performed upon start up/reset and also periodically (i.e. at least once a day during the
normal use of the device). These tests are not initiated by an operator.
Self-tests include:
• Check of integrity and authenticity of the software
• Check of the security mechanisms for sign of tampering

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
14/16
7_System Administration
7_1 Configuration Settings
The device is functional when received by the merchant or acquirer. No security sensitive
configuration settings are necessary to be tuned by the end user to meet security requirements.
7_2 Default Value Update
The device is functional when received by the merchant or acquirer and there is no security sensitive
default value (e.g. admin password) that needs to be changed before operating the device.
8_Key Management
8_1 Key Management Techniques
The device implements different types of key management techniques:
• Fixed Key: a key management technique based on a unique key for each terminal as specified
in [2].
• Master Key/ Session Key: a method using a hierarchy of keys. The session keys are unique
per transaction as specified in [2].
• DUKPT: a key management technique based on a unique key for each transaction as
specified in [3].
8_2 Cryptographic Algorithms
The device includes the following algorithms:
• Triple DES (112 bits, 168 bits)
• AES (128, 192 and 256 bits)
• RSA (2048 bits)
• ECDSA (256, 384, 521 bits)
• SHA-256, SHA-384, SHA-512

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
15/16
8_3 Key Table
Key Name Purpose / Usage Algorithm Size
(Bits) Storage
Form
factor
loaded to
device In
Number
of
available
Key Slots
K_Root_CA
CA public keys for
certificate verification
ECDSA 521
Secure
unit
ROM 1
K_Sub_CA1
CA public keys for
certificate verification
ECDSA 521
Secure
unit
ROM 1
K_EE1_x3
CA public keys for
certificate verification
ECDSA 521
Secure
unit
ROM 1
K_TR31
Calculation of key
encryption and MAC
keys (according to
ANSI31)
TDES
TDES
AES
AES
AES
112
168
128
192
256
Secure
unit
Enciphere
d under
K_Key or
K_TR31
31
25
31
25
21
Key Encryption Key Key encryption
TDES
TDES
AES
AES
AES
112
168
128
192
256
Secure
unit
Enciphere
d under
K_Key or
K_TR31
31
25
31
25
21
Data encryption Key
Data encryption, MAC
calculation /
verification
DES
TDES
TDES
AES
AES
AES
64
112
168
128
192
256
Secure
unit
Enciphere
d under
K_Key or
K_TR31
42
31
25
31
25
21
PIN Encryption Key PIN encryption
TDES
TDES
AES
AES
AES
112
168
128
192
256
Secure
unit
Enciphere
d under
K_Key or
K_TR31
31
25
31
25
21
DUKPT2009 – IPEK Initial DUKPT Keys TDES 112 Secure
unit
Enciphere
d under
K_Key
2
DUKPT2009 – Pin Key Pin encryption TDES 112 Secure
unit
Derived
originally
from IPEK
42
DUKPT2009 – Data Key Data encryption TDES 112 Secure
unit
Derived
originally
from IPEK
42
3X is a numerical variable

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
16/16
Key Name Purpose / Usage Algorithm Size
(Bits) Storage
Form
factor
loaded to
device In
Number
of
available
Key Slots
DUKPT2009 – MAC Key
MAC calculation /
verification TDES 112 Secure
unit
Derived
originally
from IPEK
42
DUKPT2017 – IPEK Initial DUKPT Keys
AES
AES
AES
128
192
256
Secure
unit
Enciphere
d under
K_Key
1
DUKPT2017 – Pin Key Pin encryption
TDES
TDES
AES
AES
AES
112
168
128
192
256
Secure
unit
Derived
originally
from IPEK
32
DUKPT2017 – Data Key Data encryption
TDES
TDES
AES
AES
AES
112
168
128
192
256
Secure
unit
Derived
originally
from IPEK
32
DUKPT2017 – MAC Key
MAC calculation /
verification
TDES
TDES
AES
AES
AES
112
168
128
192
256
Secure
unit
Derived
originally
from IPEK
32
DUKPT2017 – HMAC
Key
HMAC calculation /
verification
HMAC
HMAC
HMAC
128
192
256
Secure
unit
Derived
originally
from IPEK
32
EMV_PK_MAC Key MAC Generation and
verification of EMV PK TDES 128 Secure
unit
Randoml
y
generate
d
31
EMV_PK_CA Key
CA public keys for
certificate verification
(EMV_Issuer_PK)
RSA 2048 Secure
unit
Received
from
bank host
1
EMV_Issuer_PK Key
Issuer public key for
certificate verification
(EMV_ICC_PK and
PIN_Cipher_PK ) and
EMV Data
authentication (SDA
case)
RSA 2048 Secure
unit
Received
from
CARD
1
EMV_ICC_PK Key
EMV Data
authentication (DDA
and CDA cases) and
PIN Encryption
RSA 2048 Secure
unit
Received
from
CARD
1
PIN_Cipher_PK Key Offline PIN Encryption RSA 2048 Secure
unit
Received
from
CARD
1

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
17/16
Key Name Purpose / Usage Algorithm Size
(Bits) Storage
Form
factor
loaded to
device In
Number
of
available
Key Slots
MC_MAC Key
MAC Generation and
verification of
MC_ECC_Payment_Sy
stem PK
TDES 128 Secure
unit
Randoml
y
generate
d
31
MC_Session_Cipher
Key
Encryption and
Decryption of Data AES 128 Secure
unit
Derived
from
MC_Kern
el_ECC
private
Key
1
MC_Session_Authent
Key Authentication of Data
AES 128 Secure
unit
Derived
from
MC_Kern
el_ECC
private
Key
1
MC_ECC_Payment_Sys
tem_PK Key
Verification of
MC_Issuer_ECC_PK
Key
ECC 256 Secure
unit
Received
from
bank host
5
MC_Kernel_ECC
Private Key
ECDH Establishment
and Generation of
MC_Session Keys
ECC 256 Secure
unit
Randoml
y
generate
d
5
MC_Kernel_ECC Public
Key ECDH Establishment ECC 256 Secure
unit
Randoml
y
generate
d
5
MC_Issuer_ECC_PK Key
Verification of
MC_ICC_ECC_PK Key ECC 256 Secure unit
Received
from
CARD
5
MC_ICC_ECC_PK Key Validation of blinding
factor ECC 256 Secure
unit
Received
from
CARD
5
8_4 Key Replacement
Any key should be replaced with a new key whenever the compromise of the original key is known or
suspected, and whenever the time deemed feasible to determine the key by exhaustive attack
elapses.
1 X is a numerical variable

ICO-OPE-04848-EN-V11
Move/3500 PCI PTS Security Policy
Public
Ingenico document - Please check document validity before using
18/16
8_5 Key Loading Policy
The device has no functionality that gives access to security sensitive services, based on roles. Such
services are managed through dedicated tools, using cryptographic authentication.
9_Roles and Services
The device has no functionality that gives access to security sensitive services, based on roles. Such
services are managed through dedicated tools, using cryptographic authentication.
