Paymen Terminals
WireLess
With Ingenico, secure and speedy mobile payment becomes a reality. ur wireless products
enable merchants to offer customers true payment convenience – even on the go.
Perfect for accepting payment in places such as restaurants, bars, stadiums as well as
delivery operations, our battery-powered payment devices deliver the exceptional
performance and high-end functionality merchants need to maximize revenue and
improve customer service.
From transportable or portable options, to a choice of Bluetooth, WiFi and GPRS
communications, Ingenico’s battery-powered wireless solutions enable merchants to
undertake mobile transactions in any environment. From pay-at-table, to taking fares-
on-the-move, payment at the point of service becomes simplicity itself.
WireLess
Mdem Bluet th Wi-Fi GPRS Cntactless Bi metrics
NAME i7310 EFT930 P i7780 EFT930 B i7810 EFT930 W i7910 i7910+ EFT930 G EFT930 B
Con ac less
EFT930 G
Con ac less BIO930 P BIO930 B BIO930 G
Pr cess r Type ARM 7 ARM 9 & ARM 7 ARM 7 ARM 9 & ARM 7 ARM 7 ARM 9 & ARM 7 ARM 7 ARM 7 ARM 9 & ARM 7 ARM 9 & ARM 7 ARM 9 & ARM 7 ARM 9 & ARM 7 ARM 9 & ARM 7 ARM 9 & ARM 7
Speed 29 MHz 200 MIPS & 50 MIPS 29 MHz 200 MIPS & 50 MIPS 29 MHz 200 MIPS & 50 MIPS 29 MHz 58 MHz 200 MIPS & 50 MIPS 200 MIPS & 50 MIPS 200 MIPS & 50 MIPS 200 MIPS & 50 MIPS 200 MIPS & 50 MIPS 200 MIPS & 50 MIPS
Mem ry AM/Flash (in MB) 2/4 or 2/8 8/16 or 16/16 2/4 or 2/8 8/16 or 16/16 2/4 or 2/8 16/16 2/4 or 2/8 2/4 or 2/8 8/16 or 16/16 8/16 or 16/16 8/16 or 16/16 8/32 8/32 16/32
MMC optional optional loptional optional optional optional optional optional optional l l l
Rem vable Mem ry SD Card optional loptional optional optional optional l l l
µSD Card
Cmmunicati n M de
Infra red l l
Dial-up Modem lllwith base Modem optional with base Modem optional optional with base Modem with base Modem with base Modem l l
Ethernet with base Ethernet optional with base Ethernet with base Ethernet
Wi-Fi l l
Bluetooth l l l l
GP S l l l l l
SAM 1 to 3 2 or 4 1 to 3 4 1 to 3 2 or 4 1 to 2 1 to 2 2 or 3 4 2 or 3 4 4 3 + 1 SIM
Card Readers Smart Card 1 1 or 2 1 2 1 1 or 2 1 1 1 or 2 1 1 2 2 2
Magstripe Track 1/2/3 Track 1/2 or 1/2/3 Track 1/2/3 Track 1/2 or 1/2/3 Track 1/2/3 Track 1/2 or 1/2/3 Track 1/2/3 Track 1/2/3 Track 1/2 or 1/2/3 Track 1/2 or 1/2/3 Track 1/2 or 1/2/3 Track 1/2 Track 1/2 Track 1/2
Display
Graphic 128 x 64 l l l l l l l l l l l l
2 lines x 16 characters
Backlit l l l l l l l l l l l
Yellow/Green l l l l l l l l l l l l
White
TFT Color QVGA 320 x 240 pixels l l
Fast Wake up l l l
Keyb ard
Number of keys 18 16 18 16 18 16 18 18 16 16 16 16 16 16
Navigation keys 3 6 3 6 3 6 3 3 6 6 6 2 2 2
Backlit l l l l l l l l l l l l l l
Privacy Shield optional optional optional optional optional
Buzzer l l l l l l l l l l l l l l
Thermal Printer Lines/second 12 l/s 18 l/s 12 l/s 18 l/s 12 l/s 18 l/s 12 l/s 12 l/s 18 l/s 18 l/s 18 l/s 18 l/s 18 l/s 18 l/s
C nnecti ns n terminal
S232 l l optional optional l
USB Host
USB Slave
Mini USB Host l l l l l l l l l
Mini USB Slave l l l l l l l l l
Base Type Modem Modem
or Ethernet
Bluetooth-Modem
or Bluetooth-
Modem-Ethernet
Bluetooth-Modem
or Bluetooth-Ethernet
or Bluetooth-
Modem-Ethernet*
Charger
or Modem
Charger
or Modem
cacapa+
(optional)
cacapa+
(optional)
Charger
or Modem
Bluetooth-Modem
or Bluetooth-Ethernet
or Bluetooth-
Modem-Ethernet*
Charger
or Modem Modem Bluetooth-Ethernet Modem
C nnecti ns n base
Power supply l l l l l l l l l
Line in l l l l l l l l
Phone out optional optional optional optional optional optional l l
S232 2 1 or 2 2 1 or 2 2 1 or 2 1 or 2 1 or 2 1 or 2 1 2 1
USB Slave optional
on base Modem loptional on base Modem
optional
on base Modem loptional on base Modem l
P wer Supply Car charger l l l l
Travel charger l l l l
Batteries NiMH loptional optional optional optional optional l l l
Li-Ion loptional l l l l l l l l l
Size (in mm) Terminal L 209 x l 96 x H 60 L 180 x l 79 x H 57 L 209 x l 96 x H 60 L 180 x l 79 x H 57 L 209 x l 96 x H 60 L 180 x l 79 x H 57 L 209 x l 96 x H 60 L 209 x l 96 x H 60 L 180 x l 79 x H 58 L 180 x l 79 x H 58 L 180 x l 79 x H 58 L 180 x l 79 x H 58 L 180 x l 79 x H 58 L 180 x l 79 x H 58
Base L 910 x l 350 x H 202 L 140 x l 80 x H 23 L 910 x l 350 x H 202 L 140 x l 80 x H 23 L 910 x l 350 x H 202 L 140 x l 80 x H 23 L175 x l 100 x H44 L175 x l 100 x H 44 L 140 x l 80 x H 23 L 140 x l 80 x H 23 L 140 x l 80 x H 23 L 140 x l 80 x H 23 L 140 x l 80 x H 23 L 140 x l 80 x H 23
Weight (in gr) Terminal 600 360 600 465 600 410 600 600 410 465 410 460
Base 150 100 300 100 200 125 100 100 100 100 100 100 100 100
Cust mizati n
Lens optional optional optional optional optional optional optional optional optional optional optional optional optional optional
Printer cover flap optional optional optional optional optional optional optional optional optional
Casing optional optional optional optional optional optional optional optional optional optional optional optional optional optional
Envir nment Operating temperature -5 to +40°C +5 to +45°C -5 to +40°C +5 to +45°C -5 to +40°C +5 to +45°C -5 to +40°C -5 to +40°C +5 to +45°C +5 to +45°C +5 to +45°C +5 to +45°C +5 to +45°C +5 to +45°C
Storage temperature -20 to +70°C -20 to +55°C -20 to +70°C -20 to +55°C -20 to +70°C -20 to +55°C -20 to +70°C -20 to +70°C -20 to +55°C -20 to +55°C -20 to +55°C -20 to +55°C -20 to +55°C -20 to +55°C
elative humidity, non condensing 20% to 90%
without condensation
85% HR at +40°C 20% to 90%
without condensation
85% HR at +40°C 20% to 90%
without condensation
85% HR at +40°C 20% to 90%
without condensation
20% to 90%
without condensation
85% HR at +40°C 85% HR at +40°C 85% HR at +40°C 85% HR at +40°C 85% HR at +40°C 85% HR at +40°C
PCI PED Online & offline l l l l l l l l l l l l l l
New New New
www.ingenico-us.com
E-B -WI ELESS-USA-JAN09

Performance
Ingenico’s wireless terminals offer all the ingredients necessary
for speedy mobile payment. With cost-effective WLAN options,
our reliable and secure wireless solutions feature fast encryption
processing to make the entire payment process efficient,
easy and cost-effective. Ingenico’s unique platform maximizes
application flexibility and reduces approval costs while its fast
printer allows very rapid transactions.
Design/Ergonomics
Compact, light weight and easy-to-use, Ingenico’s wireless
terminals make customer-facing payment simplicity itself.
Featuring large backlit displays, colour display on the EFT930G
and B, fast easy-loading printers, long magnetic stripe readers
and extensive battery life, our solutions are designed to work
as hard as you do. Drop and spill resistant, they perform in even
the most demanding environments.
Communication
With faultless 24/7 communications a must, Ingenico’s wireless
terminal solutions deliver transaction integrity and security
through the widest variety of connectivity interfaces. Our terminals
are equipped with an unparalleled array of communication
technologies, including: fast modem, GP S, Bluetooth and WiFi.
To deliver increased performance and convenience, merchants
can choose to use a contactless EMV payment option which
supports mobile phone Near Field Communications (NFC)
payment.
Security
A world leader in secure transaction and payment systems,
Ingenico’s payment terminals are all EMV and PCI PED approved.
Our industry proven High Secure Core (HSC) as well as our 32-bit
ISC security co-processor support powerful encryption (including
SA, DES AND 3DES) to provide the assurance of secure data and
application management. Our products have all the necessary
tools to provide secure WiFi ( WEP, WPA or WPA2) and IP/Internet
(SSL V3, etc.) communications.
Software development
By enabling the integration of a host of additional applications and
service into its terminals - including loyalty programs, pre-paid,
and language or currency options - Ingenico allows merchants
and banks to generate significant incremental revenues. In
addition to offering world’s most extensive library of value added
applications - over 800 - our uniquely scalable operating system
creates the ideal environment on which to rapidly build and
deploy EMV e-payment solutions as well as bespoke new
solutions, tailored specifically to the customer’s needs.
Field Services
To reduce total cost of ownership and enable merchants and
banks to maximize their terminals investments, Ingenico provides
a comprehensive range of terminal and software update and
management services…both remotely and in the field. Fully
certified professions and local language helpdesk personnel
operate in every one of our regions, ensuring Ingenico is on
hand to support customers 24 hours a day, seven days a week,
365 days of the year.
WireLess
EFT930 P
i7310
EFT930 W
i7910
i7910+
i7780
EFT930 B
i7810
EFT930 G Contactless
EFT930 B Contactless
BIO930 P
BIO930 B
BIO930 G
EFT930 G
New
New New
