INNOVAPLAS THE TUX User manual

REV. 14/01/2016 PN: 110-0022 PG:1
2257 route 139
Drummondville, Québec
J2A 2G2
1 year on pool step.
1 year on hardware.
MANUFACTURER WARRANTY
WWW.INNOVAPLAS.COM
WARNING
Install the step on a flat surface.
Do not jump or dive from the step.
Remove the step from water when temperatures drop below freezing.
In winter, the step should be stored in an area protected from snow.
Never lift the step by its handrails.
Use BATTERY operated tools to avoid electric shock near water.
Ensure no corrosive materials are added to the step or harware kit.
The step must be installed per manufacturer’s instructions.
File off all stripped or sharp edges before assembly to avoid injuries
and liner damage.
The manufacturer is not responsible for damages or injuries caused
by improper installation or use of product.
To ease the installation of handrails and bolts, use a screwdriver to
line up the holes.
THETUX INGROUNDPOOLSTEP
Sand
Contents of accessory box
Step Shell (not included)
Required tools (not included)
SCREW KIT 140-0017
x1 x3
x2 x3
105-012
105-005
115-011 (2 in.)
115-010 (1 in.)
.
Use 7/16"
wrench
Use a cordless drill
with a 5/16" drill bit.
Sand
50 lbs

REV. 14/01/2016 PN: 110-0022 PG:2
2257 route 139
Drummondville, Québec
J2A 2G2
WWW.INNOVAPLAS.COM
1 year on pool step.
1 year on hardware.
MANUFACTURER WARRANTY
B
C
A
1) Place the sand bags into the
underside of the step. Immerse the
assembly into water.
THETUX INGROUNDPOOLSTEP
SableSable
60 lbs
Sable
60 lbs
sand
50 lbs
To prevent injuries, use a
minimum of two individuals
to move the assembly into
the pool once the sand bags
are inside the step.
WARNING
1) Fasten the arm in
place with pool manufacturer
recommended screws and inserts.
2) Drill two holes through
the handrail to secure
the support arm in place.
3) Secure the support arm
in place with the nut and
bolt included.
USE APPROPRIATE
FASTENERS AS
SPECIFIED BY THE
POOL MANUFACTURER.
(SCREWS NOT INCLUDED)
x1 x1
105-005
Use a cordless drill with
a 5/16" drill bit.
115-010 (1 in.)
1) Slide the support arm onto the
handrail prior to installation.
2) Insert the nuts and washers in
place.
3) Secure the handrails in place with
the two screws provided.
x2
x2
x2
105-012
105-005
115-011 (2 in.)
