INNOVAPLAS Self-Latching User manual

SELF-LATCHING ASSEMBLY WITH FIESTA
Contents of Self-Latching box SKU # 9600
WARNING
REV: 11/12/10
x2
x4
Do not dive or jump from step or ladder.
Use BATTERY operated tools to avoid electric shocks.
Install step on flat surface, following the manufacturers
instructions.
Remove step from pool during freezing climate season.
Manufacturer cannot be held responsible for injuries caused
by abusive use of product.
Ask your city about specific regulations that apply to your
above-ground pool and ladder.
x2
use small locking
pliers / vice grip or a
wrench 7/16''
Sand
50 lbs
(not included)
Sand
Required tools and supplies (not included)
A weather resistant padlock is
recommended.
A
Security strap
x2
115-014 (3/4 IN.)
x12
115-010
x2
105-005
x2
115-018 (2 1/2 in.)
x2
SCREW BAG 140-016
PG. 1
Contents of Fiesta box # 1001
x2
x2 x4
x8
105-012
105-005
x8 x8
115-010
115-015 (1 1/2 in.)
x8
x12
115-014 (3/4 in.)
115-018 (2 1/2 in.)
x2
SCREW BAG 140-008
x2
x8
115-014 (3/4 in.)
x8
105-012
105-005
x8 x8
115-010
1) Insert the four
posts into the post
ends and secure
them in place with
the screws provided.
2) Insert the platform
over the 2 rear posts.
Do not secure yet.
3) Insert the large handrails
securing them with the
screws provided.
370 Lajeunesse St,
St-Jérome (Québec),
Canada J7Y4E5

BC
E
REV. 11/12/10
1 Year on the
Self-Latching
System and Fiesta.
1 year on the hardware.
D
1) Insert the 2 posts into
the rear holes of the step.
2) Force the posts to a
vertical position flush with
the rear surface and
secure in place with the
bolts and nuts provided.
3) Insert the post covers.
1) Insert the post covers
into the small handrails.
Slide the handrails over the
4 posts. Secure in place
using the screws provided.
2) Finish the assembly by
securing the platform to the
posts with the screws
provided.
115-010
x2
WARNING
LOCK THE DOOR TO THE
STEP WITH A PADLOCK
WHEN THE POOL IS NOT
IN USE TO PREVENT
DROWNING AND
UNAUTHORIZED ENTRY.
MANUFACTURER
WARRANTY
105-005
x2
1) Slowly submerge the
Step in the pool. Make
sure you do not damage
the liner in the process.
Sand
50 lbs
1) Insert the
sandbag
under the
first step.
x8
115-014 (3/4 in.)
x4
G
F
Security strap
x2
1) Once the step is in the pool
secure the platform to the top
seat (see illustration) using the
two straps provided.
115-018 (2 1/2 in.)
x2
OPTIONAL:
Once the pool step has been
completely assembled and
secured to the pool, attach the 2
screws supplied through the
platform to the top seat of your
pool to provided a more rigid
assembly.
115-014 (3/4 in.)
PG. 2
370 Lajeunesse St,
St-Jérome (Québec),
Canada J7Y4E5
