128054 - Pool canopy

Pool Canopy 2

Service Center 8

176

(176IO) POOL CANOPY ENGLISH 4.875” X 7.25” 04/23/2022

SAVE THESE INSTRUCTIONS

Page 1

Parts Reference

NOTE: Drawings for illustration purpose only. May not reﬂ ect actual product. Not to scale.

176-*IO-R0-2304

INTEX® OWNER’S MANUAL

POOL CANOPY

READ AND FOLLOW ALL INSTRUCTIONS BEFORE USING THIS PRODUCT

REF. NO. DESCRIPTION QTY. SPARE PART NO.

1 Fiber glass rod joint 6 12964

2 Fiber glass rod A-1 8 13159

3 Fiber glass rod A-2 2 13160

4 Fiber glass rod B 3 12963B

5 Mounting clamp 4 12961

6 Canopy 1 12962

• Assemble and disassemble by adults only from outside of the pool. Never attempt to remove

the canopy while in the pool.

• Remove canopy and store properly when not in use or in the presence of strong winds,

thunderstorms, heavy rain or snow.

• Never place items on top of canopy or exert excessive force onto the frame when in use.

• Always closely supervise children who are in or near the pool at all times.

• Check that all canopy connections are secure prior to entering the pool.

• This product is intended to be used only for the purposes described in the manual.

FAILURE TO FOLLOW THESE WARNINGS AND THE ASSEMBLY AND USE INSTRUCTIONS

MAY RESULT IN SERIOUS INJURY, DROWNING OR PROPERTY DAMAGE.

WARNING

English

176

(176IO) POOL CANOPY ENGLISH 4.875” X 7.25” 04/23/2022

SAVE THESE INSTRUCTIONS

Page 2

General

• Choose where you want to install the canopy. It’s recommended to setup the

canopy on the west side of the pool in order to block more of the afternoon sun.

• No tools are required for the assembly. Two people are needed to setup this product.

• Make sure the pool is setup and ﬁ lled with water ﬁ rst.

• Never attempt to setup this product during strong winds, thunderstorms, heavy rain or

snow.

This canopy is designed and manufactured for Intex pool sizes:

Setup instructions

1) Spread out the canopy (6) with the sleeves facing up.

1.1

POOL POOL SIZE

METAL FRAME POOL

10’×30” (3.05m×76cm)

12’×30” (3.66m×76cm)

12’×33” (3.66m×84cm)

PRISM FRAME™ PREMIUM POOL

10’×30” (3.05m×76cm)

12’×30” (3.66m×76cm)

12’×39” (3.66m×99cm)

12’×48” (3.66m×1.22m)

PRISM FRAME™ RECTANGULAR

PREMIUM POOL

13’11/2”×6’63/4”×391/2” (4.00m×2.00m×1.00m)

13’11/2”×6’63/4”×48” (4.00m×2.00m×1.22m)

16’×8’×42” (4.88m×2.44m×1.07m)

PRISM FRAME™ OVAL PREMIUM

POOL

13’11/2”×6’63/4”×391/2” (4.00m×2.00m×1.00m)

16.6’×9’×48” (5.03m×2.74m×1.22m)

20’×10’×48” (6.10m×3.05m×1.22m)

ULTRA XTR™ RECTANGULAR

FRAME POOL

18’×9’×52” (5.49m×2.74m×1.32m)

24’×12’×52” (7.32m×3.66m×1.32m)

176

(176IO) POOL CANOPY ENGLISH 4.875” X 7.25” 04/23/2022

SAVE THESE INSTRUCTIONS

Page 3

2) Starting from one side at a time, place a ﬁ ber glass rod joint (1) in each opening

between the sleeves along the side.

3) Insert one “A-1” rod with the end without the metal coupling into the canopy sleeve

ﬁ rst. The end of the rod with the metal coupling shall be facing you.

4) Continue inserting 3 more “A-1” rods through the canopy sleeve making sure the “A-1”

rods are inserted into the metal coupling and through the ﬁ ber glass rod joint (1).

5) Slide one “A-2” rod into the sleeve making sure it’s inserted into the last “A-1” rod metal

coupling.

Note: Each side shall have 4 “A-1” rods and one “A-2” rod, and the rods shall be inserted

through all the ﬁ ber glass rod joints (1).

6) Repeat above steps 2 to 5 with the other side of the canopy sleeves.

7) Make sure the rods are inserted through all the ﬁ ber glass rod joints (1).

1.2

(4 x “A-1”)

(1 x “A-2”)

1.3

176

(176IO) POOL CANOPY ENGLISH 4.875” X 7.25” 04/23/2022

SAVE THESE INSTRUCTIONS

Page 4

42.1

8) Unfold and assemble the “B” rods together.

9) Slide the “B” rods through the short sleeves on the canopy and make sure the end of the

“B” rod is inserted into the respective ﬁ ber glass rod joint (1).

2.2

10) Insert the other end of the “B” rod into the ﬁ ber glass rod joint (1).

2.3

176

(176IO) POOL CANOPY ENGLISH 4.875” X 7.25” 04/23/2022

SAVE THESE INSTRUCTIONS

Page 5

10’(3.05m)

12’(3.66m)

3.1

11) According to the size of your round metal frame pool, attach the mounting

clamps (5) over the horizontal beams of the pool per diagram. Hand tighten the

clamps thumb screws.

12) Two people are needed to install the assembled canopy onto the mounting clamps. With

one person holding each end of the canopy rods, insert one side of the canopy rods into

the mounting clamps (5) ﬁ rst, then insert the other end of the canopy rods into the

mounting clamps (5). Move the mounting clamps position if needed.

13) Hook the canopy rope under the mounting clamp (5) and tighten the rope securely with

the rope buckles.

3.2

®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/Marcas

registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/

Intex Marketing Ltd. to/à/a/an Intex Development Co. Ltd., Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach,

CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in

der Europäischen Union durch/Intex Trading B.V., Ettenseweg 46, 4706 PB Roosendaal – The Netherlands • Distributed in the UK by

Unitex Service (UK) Limited, 21 Holborn Viaduct, London EC1A 2DY, UK.

www.intexcorp.com

176

(176IO) POOL CANOPY ENGLISH 4.875” X 7.25” 04/23/2022

SAVE THESE INSTRUCTIONS

Page 6

Maintenance and long term storage

1. Regularly check all components for sign of damage and straining. Replace

damaged components immediately.

2. Two people are needed for disassembly. Remove the canopy assembly from the frame

pool. CAUTION: When disassembling, hold the rod ﬁ rmly when disconnecting the rod

from the mounting clamp in order to prevent face or bodily injury.

3. Use a sponge and clean water to wipe away any soil or stains on the canopy.

4. Reverse the above setup instructions (see Fig. 4), and make sure all components are

completely dry before storage.

5. Store the canopy and accessories in a dry, temperature controlled, between 0º – 40ºC

(32º – 104ºF), storage location.

6. The original packing can be used for storage.

200

(200) SERVICE CENTER LIST 7.5” X 10.3” 07/05/2022

AUTHORIZED SERVICE CENTERS / SERVICES CONSOMMATEURS AGREES /

CENTROS DE ATENCIÓN AUTORIZADOS / AUTORISIERTE SERVICE CENTER /

CENTRI ASSISTENZA AUTORIZZATI / SERVICE CENTERS / CENTRO DE

SERVIÇOS AUTORIZADOS / GEAUTORISEERDE SERVICECENTRUMS /

AUTORYZOWANE CENTRA SERWISOWE / ОФИЦИАЛЬНЫЕ СЕРВИСНЫЕ

ЦЕНТРЫ / 委任されたサービスセンター /官方售后服务中心

For service questions or to order replacement parts, please contact the appropriate office listed below or visit www.intexcorp.com for answers to

most frequently asked questions.

Pour tout renseignement et commande de pièces détachées, contactez votre revendeur local de la liste ci-dessous ou visitez www.intexcorp.com

pour consulter la liste des questions les plus fréquemment posées.

Para preguntas sobre los servicios o para pedir piezas de repuesto, por favor contacte con la oficina apropiada indicada en la lista abajo indicada

o visite nuestra página web www.intexcorp.com para encontrar las respuestas a las preguntas más frecuentes.

Für Service-Fragen oder um Ersatzteile zu bestellen wenden Sie sich bitte an die entsprechende Vertretung oder besuchen Sie www.intexcorp.

com, dort finden Sie Antworten auf die am häufigsten gestellten Fragen.

Per avere maggiori informazioni riguardo la manutenzione, riparazione, ordinazione delle parti di ricambio contattate uno degli uffici elencati nella

lista sotto o visitate il sito www.intexcorp.com per consultare le risposte alle domande più frequenti.

Dit is de adressenlijst van alle Intex afdelingen. Voor vragen over service of het bestellen van onderdelen, gelieve contact op te nemen met het

adres in uw regiogebied. U kunt ook de website www.intexcorp.com bezoeken.

Para dúvidas ou pedir peças de reposição, por favor contate o escritório apropriado listado abaixo ou visite o site www.intexcorp.com para

resposta de questões comuns.

Hvis der er spørgsmål til produkterne eller man ønsker at bestille reservedele kan man kontakte et af de nedennævnte kontorer, eller besøge

www.intexcorp.com hvor man kan finde svar på hyppigt stillede spørgsmål.

W przypadku pytań lub zamówienia części skontaktuj się z odpowiednim biurem serwisowym z poniższej listy lub wejdź na stronę www.intexcorp.com.

При возникновении каких-либо вопросов по обслуживанию продукции, либо вопросов, связанных с приобретением запасных часте и

комплектующих, пожалуста, обращатесь в Сервисные Центры, указанным ниже. Так же Вы можете обратиться на сат www.intexcorp.

com для получения ответов на часто задаваемые вопросы.

当社の製品をお買い上げいただきありがとうございます。製品や部品のお問い合わせ、ご質問などは当社のウェブサイトでお調べください。

如有任何问题或要替换零件，请与下面所列出的相应地址联系或到访 www.intexcorp.com 咨询常见的问题。

200-***-R1-2307

• ALGERIA SARL NEW TOYS IMPORT & EXPORT

ZEA NO. 15 SETIF, ALGERIA

: 00213661141747

: 00213661523735

: +213 36 82 0051
