ITW SuperFlow Guide

Prior to connecting the inflator to
hose, wrap threads (1/4 NPT) with
Teflon tape. Screw on inflator until
tight.
Set compressor regulator to
appropriate settings (see chart
on back). Additional assistance is
available from an ITW Shippers
representative.
Position the air bag at least 1”
above the floor to keep if from
rubbing in transit.
Squeeze trigger to begin inflation.
When air blows out of the back of
the inflator, desired pressure has
been achieved.
Remove inflator and attach valve
cap. Ensure that cap is tightly
secured.
Create a bulkhead. The air bag is
properly installed when Zebra
stripes touch lading. If stripes show,
and you can read the warning
“if you can read this, the void is
too large”, deflate air bag and
reduce the void.
To deflate, simply unscrew cap
and gently press blue flapper to
release air.
Place air bag into container.
Weight of additional air bags will
complete deflation process.
SuperFlow Safety
& Operation Instructions
Airbags for Damage Prevention
TM
Airbags for Damage Prevention
As discussed few minutes ago, please find
attached the version of the superflow in-
struction sheet I was talking you about. See
below instructions
1: Please replace ISO logo with the one at-
tached to this email.
2: Change the document ID to: RSFGI / 0606
3: Send me the revised version for approval
4: Send high resolution file of this revised
version to Lewisburg Printing.

Do’s:
Use filter and regulator on air line.
Position the air bag approximately 1” above the
floor to keep it from rubbing in transit.
Position the air bag in the void, flush with the rear
edge of the load. No part of the air bag should
stick out beyond the edge of the load.
Protect the air bag when inflating. Avoid sharp
objects and pinch points. Use cardboard and/or
plywood to protect air bag on both sides whenever
possible.
Always wear safety glasses with side shields that
conform to ANSI standard Z87.1 or EN166.
Do’s and Don’ts for using ITW Shippers Products’ SuperFlow inflation system
Don’ts:
NEVER use inflator as blowgun for cleaning.
NEVER obstruct rear vacuum opening while
inflating.
DO NOT point inflator towards face or body.
DO NOT use folded air bags in voids.
DO NOT use air bag as a leveling device.
DO NOT use air bags between the top of the
load and the trailer roof.
DO NOT place air bags between the load and
trailer door.
DO NOT use paper air bag in wet environment.
Warning: Failure to follow these instructions could result in serious personal injury and/or product damage.
Input Pressure Insert #1 Output Insert #2 Output
40 psi
50 psi
60 psi
70 psi
80 psi
90 psi
100 psi
110 psi
120 psi
0.5 lbs
0.7 lbs
1.0 lbs
1.1 lbs
1.3 lbs
1.5 lbs
1.8 lbs
2.0 lbs
2.3 lbs
Insert #2 Output
*Only for type 400 air bags.
1.0 lbs
1.4 lbs
1.6 lbs
2.0 lbs
2.3 lbs
2.9 lbs
3.5 lbs*
4.0 lbs*
N/A
1.0 lbs
1.4 lbs
1.6 lbs
2.0 lbs
2.3 lbs
2.9 lbs
3.5 lbs*
4.0 lbs*
N/A
*Only for type 400 air bags.
TSFGI / 0606
