iWave FNS-8408 User manual

FNS-8408 User Manual
Thank you very much for your favor of our products! This manual describes the usage of the FNS-8408 and
amis to enable you quickly grasp the use of the product.
Version 1.0.1(3)
Date 8/9/2019
IWAVE COMMUNICATIONS Co.,Ltd
3F, 19th Bldg, No.1515 Gumei Road, Minhang District, Shanghai, China
To Costumers
添加标题
This document is copyright-protected by IWAVE COMMUNICATIONS Co.,Ltd. Laws in China and/or other
countries or areas protect the exclusive rights of the Company. The Company endeavors to achieve the
accuracy and completeness of this manual, but no warranty of accuracy or reliability is given. All the
specifications and designs are subject to change without notice due to continuous technological
development. No part of this manual may be copied, modified, translated, or distributed in any manner
without the prior written consent of the Company.
If you have any suggestions or would like to receive more information, please visit our website at:
http://www.iwavecomms.com, or email us [e-mail].
Copyright Information
1
www.iwavecomms.com

FNS-8408 User Manual
Contents
1. Introduction................................................................................................................................... 3
2. Package List................................................................................................................................... 3
3. Interfaces and Indicator Lights.................................................................................................... 4
4. Network Settings & Installation................................................................................................... 5
4.1. Network Configuration...................................................................................................5
4.2. Installation Steps.............................................................................................................5
5. Cables..............................................................................................................................................6
5.1. TTL Cables.........................................................................................................................6
5.2. Serial Data Format...........................................................................................................7
5.3. Ethernet Cables................................................................................................................7
6. Notice...............................................................................................................................................7
2
www.iwavecomms.com

FNS-8408 User Manual
1. Introduction
FNS-8408 is a short range (7~8km) point-to-point drone HD network downlink radio.
2.Package List
3
www.iwavecomms.com

FNS-8408 User Manual
3. Interfaces and Indicator Lights
ü3 LAN Ports for connecting with 4P Ethernet
cable
üEach LAN port has a LED light below. The
LED will flash when data is transmitting
through the port.
üTTL-serial cable connect with the 5P serial port for
signal transmitting(Vol: 3.3V)
üLED1 will be on when Tx and Rx are communicating
with each other successfully
üLED2 and LED3 are reserved for production testing
üSMA is for antenna connecting
üMicro USB is reserved for production testing
ü4P Power Input Connector (DC 7~18V)
üPower LED
üSMA is for antenna connecting.(Note: Antennas should
be in good connection before power on)
4
www.iwavecomms.com

FNS-8408 User Manual
4. Network Settings & Installation
4.1. Network Configuration
FNS-8408 units are working as wireless routers, the Tx and Rx connects two different network
segments: 192.168.1.X(Tx) and 192.168.2.X(Rx)
Default IP address:
Transmitter(Tx)
Receiver(Rx)
192.168.1.1
192.168.2.129
IP configuration
Tx
Rx
IP Address
192.168.1.X
192.168.2.X
Gateway
192.168.1.1
192.168.1.129
Mask
255.255.255.0
255.255.255.0
4.2.Installation Steps
①Connect antennas to Tx and Rx by antenna-cables
②Configure the IP/gateway/mask of devices which you connect with Rx and Tx (Such as IP Camera or PC)
according to Table 2
③Connect power source to Tx and Rx by power cables
④Power on Tx and Rx and external devices connecting with them
⑤After 10~20 seconds, if the wireless communication is established successful, LED1 on both units will be
on.
⑥If Tx and Rx are connected with serial devices. Please refer to 4.3 Serial Data Format for serial
voltage/data format configuration.
Table 2
Table 1
5
www.iwavecomms.com

FNS-8408 User Manual
5. Cables
5.1. TTL Cables
TTL Serial cable is for transmitting 3.3V TTL signals. One end is 5P JST eGH, the pin number is shown
as below.
Pin
Signal
1
TXD
2
RXD
3
3.3V output, max 500mA (power external device if necessary)
4
GND
5
Reserved
The other end is 3 dupont plugs with different color wire:
Color
Signal
Red
TXD
Yellow
RXD
Black
GND
6
www.iwavecomms.com

FNS-8408 User Manual
5.3. Ethernet Cable
One end is standard RJ45 and the other end is 4P JST eZH header
6. Notice
üBefore powering on, make sure all the antennas are in good connection. Because Powering on a unit
without antenna as a load, the PAs inside will be damaged
üTwo antennas on Tx or Rx should be kept at a distance. We commend 1meters or longer for Tx, 2
meters or longer for Rx.
If two antennas are not kept a proper distance, the wireless signal may become weaker and the
transmission range may be shorter.
7
5.2. Serial data format
Default Baud Rate
115200
Data Bits
8
Parity
No
Stop bit
1
Voltage
3.3V
