iWave iW-RainboW-G30D User manual

iW-RainboW-G30D
Quick Start Guide
Zynq Ultrascale+ MPSoC
(ZU7/ZU5/ZU4) SOM
Development Platform

Disclaimer
iWave Systems reserves the right to change details in this
publication including but not limited to any Product specification
without notice.
No warranty of accuracy is given concerning the contents of the
information contained in this publication. To the extent
permitted by law no liability (including liability to any person by
reason of negligence) will be accepted by iWave Systems, its
subsidiaries or employees for any direct or indirect loss or
damage caused by omissions from or inaccuracies in this
document.
Trademarks
Certification
iWave Systems Technologies Pvt. Ltd. is an ISO 9001:2015
Certified Company.
All registered trademarks, product names mentioned in this
publication are the property of their respective owners and used
for identification purposes only.

Introduction
Quick Start Guide (QSG)
This Quick Start Guide (QSG) is designed for users to quickly
understand the iW-RainboW-G30D-Zynq Ultrascale+ MPSoC
(ZU7/ZU5/ZU4) SOM Development Platform and start the
evaluation. It provides the instructions for setting-up the
Development Platform from the packed box.
Development Platform Description
g Zynq Ultrascale+ MPSoC (ZU7/ZU5/ZU4) with upto 504K
The iW- Rain b o W-G 3 0 D Z ynq Ult ra s c a le + MP S o C
(ZU7/ZU5/ZU4) SOM Development platform incorporates with
iWave's Zynq Ultrascale+ MPSoC based SOM and High
Performance carrier board with all necessary interface
connectors for developing an embedded application based on
Xilinx Zynq Ultrascale+ MPSoC.
Some Key Features of the Board Include:
Quick Start Guide
01
g 4GB PS DDR4 with ECC & 1GB PL DDR4
g 8GB eMMC Flash (Boot & OS storage)
g Standard SD Port
g Dual Gigabit Ethernet RJ45 Magjack
g PCIe x1 Port
g Display Port
g USB 3.0 Type C Port
g M.2 Connector for SATA
g SFP+ Connector
g SDI Video In & Video Out Connectors
g Dual FMC and Dual PMOD Connectors

This development platform is ESD
sensitive. Handle the product only in
accordance with the installation
instructions given in the manual.
Therefore ESD precautions should be
taken care during transport and
handling.
Safety
iW-RainboW-G30D-Zynq Ultrascale+
MPSoC SOM Development Platform is
designed by using RoHS2 and REACH
c o m p l i a n t c o m p o n e n t s a n d
manufactured on lead free production
process.
Check the local regulations for
disposal of electronic products before
disposing.
ESD Protection
Product Disposal
Environmental Compliance
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G30D
02
Must use a ESD ground strap or other
grounded source before unpacking or
handling the hardware.

Quick Start Guide
Step 1 - Unpacking
Remove the Development platform from antistatic cover and
place it above the ESD free area. Use anti-static pad/mat with
proper grounding to place the Development Platform. Don't
touch inside surface of the circuit board.
iW-RainboW-G28D
Quick Start Steps
Avoid using board in extreme dust, humidity and temperature
conditions. Also this development platform is not water proof.
Keep away from wet surface.
Package Box
Quick Start Guide
03
Quick Start Guide
iW-RainboW-G28D
iW-RainboW-G30D
Quick Start Guide
Zynq Ultrascale+ MPSoC SOM
Development Platform

Make sure that, below deliverables are received without any
physical damage.
12V,5A Power Supply
USB OTG Cable QSG
Development Platform
Step 2 - What's Inside The Box ?
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G30D
04
iW-RainboW-G30D
Quick Start Guide
Zynq Ultrascale+ MPSoC SOM
Development Platform

Step 3 - Download FTP Contents
Quick Start Guide
05
For FTP Credentials, Contact : [email protected]
All the technical resources of iW-RainboW-G30D Zynq
Ultrascale+ MPSoC (ZU7/ZU5/ZU4) SOM Development
platform is available in iWave FTP server.
iW-RainboW-G30D
Hardware
Datasheet-UserGuides
PCB-CAD Files
QuickStartGuide
SOM-HardwareUserGuide
DevKit-HardwareUserGuide
Fansink-Datasheet
SOM
DevKit
FPGA-Example-Design
Linux
Tools
FPGAUserGuide
ReleaseNotes
SoftwareUserGuide
Binaries
Patch
Integrated Design
IBERT Design
Heatsink-Datasheet
PCB-CAD Files
Mechanical Files
Compliance Report
MPSoC Name
SOM Part Number
Vivado Version
Documents
Software+FPGA
Hardware
iW-RainboW-G30D
FTP Folder Structure

Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G30D
06
Step 4 - Read Documents
Before moving to next step, one must go through all the
documents including Hardware User Guides and get familiar
about iW-RainboW-G30D Development platform.
Development Platform Documents:
■ Quick Start Guide (This document)
■ SOM Hardware User Guide
■ DevKit Hardware User Guide
■ Release Notes
■ Software User Guide
■ FPGA User Guide

Step 5 -Quick View-SOM
TOP View
BOTTOM View
1. JTAG Header
2. FAN Header
3. PMIC Programming Header
4. Boot Mode Switch
5. Zynq US+ MPSoC
1. Board to Board connector 1
2. Board to Board connector 2
Quick Start Guide
07

01. PMOD Connector 2
02. Board to Board Conn 1
03. PMOD Connector 1
04. JTAG Header
05. Board to Board Conn 2
06. PS IO Header
07. RESET Switch
08. ON/OFF Switch
09. Power Jack
10. Debug UART Connector
11. USB OTG Connector
12. GEM0 Ethernet Jack
13. GEM3 Ethernet Jack
14. Display Port
15. PS GTR Config Switch
16. SFP+ Connector
17. PCIe X1 Connector
18. SDI IN HD BNC Jack
19. SDI OUT HD BNC Jack
20. Standard SD Connector
21. USB Type C Connector
22. FMC Connector 1
23. CAN Header
24. FMC Voltage Select Switch
25. FMC Connector 2
26. RTC Battery Holder
27. M.2 SATA Connector
Step 6 - Quick View-Carrier Board
TOP View
BOTTOM View
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G30D
08

Step 7 - Setting-Up
On Board Switch Setting
Make sure that On-SOM Boot Mode Switch (SW1) is set for
eMMC boot as shown in below image.
SW1
(0 1 1 0)
1 - ON
0 - OFF
Quick Start Guide
09

Quick Start Guide
Install the driver for Debug Port in Host PC/Laptop using the
below link.
https://ftdichip.com/products/ft232rq/
Connect TypeA end of USB cable to PC and MicroB end of USB
cable to Development platform's Debug USB MicroAB
Connector (J5) as shown below.
iW-RainboW-G28D
Debug Port Setting
Setup the Debug Terminal parameters.
Baud Rate : 115200
Data bits : 8
Parity : None
Stop Bits : 1
Flow Control : None
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G30D
10

Step 8 - Power-ON the Development Platform
Connect the 12V power supply plug to the power connector (J4)
of the Development platform as shown below and switch ON
the power supply.
Warning :
1. Do not try to connect any other power supply other than supplied along
with the Development platform.
2. Do not plug or remove the Zynq Ultrascale+ MPSoC / FPGA SOM from
carrier board with live power.
3. Contact iWave if power status LEDs are not glowing or PS Error status LEDs
are glowing.
Once power is applied to the Development platform, the power
LEDs in Zynq Ultrascale+ MPSoC SOM and High Performance
carrier board will glow as shown in the below image.
Quick Start Guide
11

Debug Terminal
Step 9 - Test Environment setup
Once power is applied to the Development Platform as
explained in the previous section, boot messages being
displayed in the debug terminal of the PC/Laptop which is
connected to the Development platform. Press any key in
terminal immediately to see the command prompt of the Boot
loader or wait until OS boots.
After OS boots, Login prompt being displayed in the debug
terminal. Enter username and password as “root” to get the
Linux command prompt as shown below.
Quick Start Guide
iW-RainboW-G28D
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G30D
12

Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28D
Quick Start Guide
Heatsink + Fan Peel off Thermal pad sticker
Fix the heatsink in to SOM
with two screws
Connect the Fan cable
to SOM Fan Header
13
iW-RainboW-G30D Zynq Ultrascale+ MPSoC (ZU7/ZU5/ZU4)
SOM Development platform comes with Heatsink+Fan
attached to it. Makesure to power up the platform only with
Heatsink+Fan attached.
Below is the Heatsink+Fan integration procedure for
reference.
Heat Sink Integration

JTAG Connection to SOM :
Quick Start Guide
iW-RainboW-G28D
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G30D
14
iW-RainboW-G30D Zynq Ultrascale+ MPSoC (ZU7/ZU5/ZU4)
SOM Development platform Support JTAG interface in SOM
and Carrier Board for MPSoC/FPGA Programming and
debugging.
JTAG-HS2 Programming Cable
Part Number: 410-249
Example JTAG Cable which is tested with this Platform is
mentioned below.
JTAG Connection

JTAG Connection to Carrier Board :
15
Quick Start Guide

iWave’s Other Products
Product Name: Zynq 7000 SODIMM SOM
Processor: Xilinx Zynq 7000 SoC
RAM: 512MB DDR3*
Application: Industrial Automation,
Industrial Equipments, Machine Vision,
Control & Measurement.
Product Name: iMX8 SMARC SOM
Processor: NXP’s iMX8 QuadMax SoC
RAM: 8GB LPDDR4*
Application: Industrial Control Systems &
HMI, Portable Medical devices, Augmented
& Virtual Reality.
* RAM size is expandable. Contact iWave team for further details
Product Name: Zynq UltraScale+ MPSoC
(ZU5/ZU4/ZU3/ZU2) SBC
Processor: Xilinx’s Zynq US+ MPSoC
(2/3/4/5-EV/EG/CG)
RAM: 8GB PS DDR4* & 4GB PL DDR4*
Application: AI/ML, Industrial IoT, Human
Machine Interface, Advanced Driver
Assistance Systems.
iW-RainboW-G28DiW-RainboW-G28D
Quick Start Guide
iW-RainboW-G28D
iW-RaniboW-G28D
iW-RainboW-G28DiW-RainboW-G28D
iW-RainboW-G30D
16
Product Name: Zynq US+ MPSoC (11/17/19-
EG) SOM
Processor: Xilinx’s Zynq US+ MPSoC
(11/17/19-EG)
RAM: 4GB PS DDR4*
4GB Dual PL DDR4*
Application: Video Surveillance, Cloud
Computing, Artificial Intelligence/Machine
Learning, 5G Wireless,

13
Need More Help ?
iWave Systems Provides Technical Support to all Customers
Worldwide.
gEmail
Write your technical queries to [email protected]
gPhone
Call us on : [phone], 26781643, 26786245
gLive Chat
We provide Live Chat technical support to our customers.
Contact your iWave window to enable Live Chat support.
Warranty support for Hardware: 1 Year from iWave or iWave's
EMS partner.
Warranty & RMA
03
For Return Merchandise Authorization
(RMA),scan the QR code or go to :
https://www.iwavesystems.com/support/rma/
For Warranty terms & Registration, scan
the QR code or go to :
https://www.iwavesystems.com/support/
warranty/
iW-PRFUZ-UM-01-R2.0-REL2.0-QSG

USA
JAPAN
iWave Japan, Inc.
8F-B, Kannai Sumiyoshi Building,
3-29, Sumiyoshi-cho, Naka-ku, Yokohama,
Kanagawa, Japan.
Email: [email protected]
Ph: [phone], 26781643
Israel
Value Technologies Ltd.
P.O. BOX 3161, Tel-Mond, Israel
4060000
Tel: [phone]
Fax: [phone]
Email: [email protected]
FRANCE
EUROPE
iWave Europe.
International Sales and Marketing,
Europe.
Venkelbaan 55 2908KE Capelle
aan den Ijssel
Email: [email protected] Our Partners
Across The Globe
RUSSIA KOREA
J.S Communications
#913, Dojung Tower, Anyang-ro 115,
Manan-gu, Anyang-si, Gyeonggi-do, Korea
Tel : [phone]
Email: [email protected]
Headquarters: INDIA
iWave Systems Tech. Pvt. Ltd.
7/B, 29th Main, BTM Layout 2nd Stage,
Bengaluru-560076,India.
Ph: [phone], 26781643
Email: [email protected]
www.iwavesystems.com
FRANCE
EUROCOMPOSANT
1, rue Rene Caudron - BP 15
78960 Voisins-le-Bretonneux,
France
Tel: [phone]
Fax: [phone]
Email: [email protected]
Symmetron
Business-Park River City,
Leningradskoe Shosse 69,
Building 1, Moscow, Russia, 125445.
Tel: [phone]
Email: [email protected]
SWEDEN
Acte Solutions AB
Box 4115,
SE-171 04 Solna,
Sweden.
Tel: [phone] / 46
Email: [email protected]
GLOBAL
Arrow Electronics, Inc.
9201 East Dry Creek Road
Centennial, CO 80112 USA
NA: [phone]
[email protected]
EMEA: [phone]
[email protected]
Asia: [phone]
[email protected]
GLOBAL
Future Electronics
237 Hymus Blvd.,
Pointe Claire, Quebec,
Canada H9R 5C7.
Tel: [phone]
Email: [email protected]
EMEA: [phone]
[email protected]
Asia: [email protected]
GLOBAL
Mouser Electronics, Inc.
1000 North Main Street
Mansfield, Texas 76063,USA
Tel: [phone]
E-mail: [email protected]
TURKEY
ÖZDİSAN ELEKTRONİK A.Ş.
DES Sanayi Sitesi 104 Sokak A07
Blok No: 54-56 Upper Dudullu / Ümraniye
Istanbul - Turkey
Tel: [phone]
E-mail: [email protected]
UNITED STATES
iWave USA
1692 Westmont Ave., Campbell,
CA95008 USA
Ph: 408-206-5958
Email: [email protected]
Batenburg Adelco Electronics
Venkelbaan 55
2908 KE Capelle aan den Ijssei,
The Netherlands
Tel: [phone],
[phone]
Email: [email protected]
NETHERLANDS, BELGIUMONLINE
Digi-Key Corporation
701 Brooks Avenue South
Thief River Falls,
MN 56701-0677
Tel: [phone]
E-mail: [email protected]
Embedded Technologies, Inc
2870 Scott St, Suite 101,
Vista, CA USA,
Tel:[phone],
E-mail: [email protected]
SPAIN
Anatronic
Paseo de los Melancólicos, N° 9-2° A
28005 MADRID, Spain
Tel : [phone]
Email: [email protected]
