J D Williams Manhattan LO838 Series User manual

Assembly Instructions - Please keep for future reference
Width - 42.0cm
3 Door Storage Cabinet
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 35.0cm
Height - 117.7cm
Rev A - 24/06/19
011 xx 9437
MADE IN
GREAT BRITAIN

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and separate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
End Panel x 2
(117.7x35cm)
1495
Shelf x 4
(39x34.8cm)
1491
Door Panel x 3
(36.6x38.4cm)
1493
Back Panel
(117.2x41.6cm)
1496

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components - Fittings
Note: The quantities below are the correct amount to complete the assembly, In some cases more
fittings may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Bradawl
Eye protection
(when using a
hammer)
Hingeplate x 6
Code 653006000
Screw x 16
Code 690001075
ABC
E
D
I
G
HJ
Screw x 12
Code 690001008
Fully cranked 26mm
hinge x 6
Code 652001120
18mm bolt x 6
Code 700002021
KM
L Bracket x 1
Code 760001901
12mm Screw x 2
Code 690001099
Handle x 3
Code 643003506
Panel pin x 32
Code 760001012
Panel pin guide x 1
Code 684004501
Cover cap x 16
N
Door Stopper x 3
Code 680362030

Exploded View
4
1495
1495
1491
1491
1491
1493
1493
1491
1493
1496

Assembly Instructions
5
Step 1
Attach hinges and
handles to the doors
a: Insert hinges
into holes, ensure
the hinge is straight
(90 degree angle).
b: Before securing the
hinges , we recommend
you pre - mark the doors
using a bradawl.
G
Bradawl
c: Secure hinges to
doors using screws .
G
B
d: Secure handle to
doors using bolts
Repeat on the other doors.
C
I
G
G
x6
B
x12
C
x6
I
x3
1493
1493
1493
1493
I
A
B
C
D
90
Correct
98
Incorrect
G
G
C
C
B
B
B
B
B
B

Assembly Instructions
6
Step 3
A
x8
Secure shelf panels to
end panel.
Locate screws through
holes in end panel
and screw into holes in
shelf panel .
1491
1495
A
A
A
A
A
A
1495
1491
1491
1491
A
Step 4
Secure shelf panels to
end panel.
Locate screws through
holes in end panel
and screw into holes in
shelf panel .
1491
1495
A
A
x8
1491
A
A
1491
1491
1491
1495
1491
Step 2
Fitting door stop on the
shelf panel.
Insert plastic door stop
into one of the shelf panels
as shown.
Repeat on another 2 shelf
panels.
1491
N
1491
N
N
x3
x3
Bottom of unit
Finished edges to the oor
Bottom of unit
Panels with door stop
Hole towards
this side

Assembly Instructions
7
Step 6
Step 5
DIAG 1 DIAG 2 DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
Measure to
external corners
IMPORTANT!
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
Ensure a tape
measure is used
to square unit up.
E
J
E
x32
J
x1
Secure back panel
Use the panel pin guide
when locating the panel
pins. This will hold the
panel pins vertical and
ensure the correct
distance from the edge.
Squaring up the unit.
XX
YY
YY
XX
1496

Assembly Instructions
8
Step 8
a: With help, slot door
hinges onto hinge plates.
Ensure screw on hinge
slides into the slot on
hingeplate.
See Diagrams 1, 2 and 3.
Hanging doors
b: Tighten screw shown
to lock hinges in
position.
See ‘Hinge adjustment’
page if the doors
need adjusting.
A
B
1495
B
Ensure the underside of screw
B slides into slot on hingeplate.
Diagram 1
B
Hinge correctly attached to
hingeplate.
Diagram 2
B
Hinge incorrectly attached to
hingeplate.
Diagram 3
1493
H
x6
Step 7
Fitting hinge plates
to the end panel.
Attach hinge plates to
the end panel as
shown.
Please note that the doors
can be hung at either side
of the unit.
1495
H
H
H
H
H
H
H
H
1495

Assembly Instructions
9
Step 9
a: To move doors up
or down: loosen screws
shown and move doors
to suit.
Re-tighten screws.
Hinge adjustment
b: To move doors in or
out: loosen screw
shown and move doors
to suit.
Re-tighten screws.
c: To move doors left
or right: loosen or
tighten screw as shown.
Be careful not to fully
unscrew.
A
B
C

Assembly Instructions
10
Step 10
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
With help move the
unit into position.
Warning:
2 people required.
Lift with care.
Warning:
D
x1
K
x2
IN ORDER TO PREVENT OVERTURNING
THIS PRODUCT MUST BE USED WITH
THE WALL ATTACHMENT DEVICE
PROVIDED
Serious or fatal crushing injuries can occur from
furniture tipping over. To help prevent topple over:
An attachment device is provided with your
product. However you will need to source
suitable fixings for your wall type. If in doubt,
please consult a qualified trades person.
Always ensure the wall to be drilled is free
from hidden electrical wires, water and gas
pipes.
Use the wall attachment device provided.
Never allow children to climb or hang on
drawers, doors or shelves.
Place heaviest items in the lower drawers
or shelves.
Unless specifically designed to accomodate,
do not set TV’s or other heavy objects on
top of this product.
Never open more than one drawer at a time.
WARNING
Use the cover caps
to conseal exposed
fittings.
Using the 16 cover caps
provided, conceal the
exposed screws by
placing these caps over
them.
M
M
M
M
M
M
M
M
M
M
x16

Assembly Instructions
Congratulations! Your unit is complete.
Important Information
If you need help or have damaged or missing parts, call the Customer Helpline:
01709 534123 8am - 4.30pm (Monday toThursday)
8am - 2.30pm (Fridays)
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
[e-mail]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)
