J D Williams 2 Drawer Entertainment Center User manual

Product size:
H415 x W978 x D388
2 Drawer Entertainment Center
Assembly instructions
Product Code : 033xx9422
MADE IN
GREAT BRITAIN

Warnings
2 Drawer Entertainment Center Assembly Instructions
Before you start
Important: Retain these instructions for future reference.
Unwrap all packaging materials and place the components
on top of the carton box or on a clean oor to prevent it
from scratching.
This product should only be used on rm level ground.
Keep small parts out of reach of children.
Do’s
Dont’s
Follow each assembly step in order to prevent incorrect
assembly.
Assemble on a clean soft surface to avoid damage.
Check the pack and make sure you have all the parts listed.
Ensure that this product is fully assembled as illustrated
before use.
Make sure all screws are fully tightened before use.
When you are ready to start, make sure that you have the
right tools, plenty of space and a clean, dry area for
assembly.
We do not recommend the use of power tools to
construct this product.
Do not sit or stand on the product.
Do not overtighten screws or bolts.
Do not use this product if parts are missing, damaged or
worn.
Number of people required to assemble
One person to assemble the unit and two people to lift the
unit into position.
Time to assemble
Tools required
notsupplied
Pozi (large)
notsupplied notsupplied
notsupplied
Pozi (Small)
supplied
2
60 minutes.

If you need help or have damaged or missing parts, call the Customer Helpline:
01709 534 123
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
[e-mail]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, SouthYorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)
2 Drawer Entertainment Center Assembly Instructions
3

2 Drawer Entertainment Center Assembly Instructions
Getting to know your product
4
1
2
6
3
5
4
7
7
8
11
12
13
10
14
11
12
13
10
9

2 Drawer Entertainment Center Assembly Instructions
Components supplied (not actual size)
5
70
80
90
100
110
0
10
20
30
40
50
60
mm
140
150
160
170
120
130
180
190
200
210
220
230
240
250
260
270
280
978 x 388 x 15
(1249)
Ref Dimensions(mm) Visual Qty
1
1
1
1
1
1
1
468 x 157 x 15
944 x 174 x 3
426 x 298 x 3
414 x 100 x 12
300 x 100 x 12
468 x 157 x 15
300 x 100 x 12
12
14
(623
xx 7002)
(622
xx 7002)
(624
xx 7005)
2
2
2
2
1
2
1
1
944 x 371 x 15
(0750)
2
400 x 386 x 15
400 x 386 x 22
(1247)
3
307 x 355 x 15
(1250)
(1248)
4
944 x 76 x 15
(9964)
5
464 x 355 x 15
(1252)
6
9
(1251)
8
(0754)
7
10
11
(9965)
13
(4472)
(760 00 1103)
(760 00 3004)
(760 00 3005)
(700 00 3510)
(690 00 1008)
Ref Visual QtyQty
1
J
12.0 x 11
C4
16
20
2
15.0 x 12
A
Ref Dimensions Visual Qty
22
26
5.0 x 35
B
E8
2
5.5 x 8
F
D
G
H
3.5 x 12
Fixtures and ttings supplied (actual size)
Fixtures and ttings supplied (not actual size)
L1
R1
2
Pair
2
Pair
L2
R2
(760 xx 7000)
(760 xx 7000)
(760 xx 7000)
(760 xx 7000)
(690 00 1075)
3.5 x 45
(760 00 1012)
2.0 x 25
(684 00 4501)
(770 00 1006)
6.0 x 30
K
(640 xx 1127)
2
3.5 x 18
I2
(700 00 2021)

2 Drawer Entertainment Center Assembly Instructions
6
12
34
5
B
notsupplied
Pozi (large) 5.0 x 35
B x4
C
C
12.0 x 11
C x4
notsupplied
Pozi (large)
Your furniture is assembled using a cam lock and dowel
system. This system combines a quick and easy
assembly with strength and a clean nish. Screw the
cam dowel into the panel in the positions shown.
Take care to ensure that the dowel is straight,
and is inserted the full length of the threaded
section.
Insert the cam lock into the face of the panel in the
positions shown.
Ensure that the cam arrow points towards the edge
with the hole as shown; this allows the head of the
cam dowel to locate properly in the cam lock.
a
b
Using a hand screwdriver, turn the cam
clockwise until hand tight. This will take less
than one full turn and will tighten the cam on
the dowel, pulling the panels together
to create a tight joint. Then using the bolts
provided place the handle on to the front
of the drawer front, then turn clockwise to
tighten until secure.
C
B
B
Connect the drawer sections together by inserting
the wooden dowels (already located) in the back
drawer section to the left and right hand drawer
sections
C
B
10
11
10
11
12
8
SLIDE!
10
13
8
11
12
Plain chipboard
surface to the underside
REPEAT ON REMAINING DRAWER
K x2
I x2 3.5 x 18

2 Drawer Entertainment Center Assembly Instructions
7
7
7
L2
F
F
You will need to
repeat this step on
both sides of the
drawer section.
Pozi (large) 3.5 x 12
Fx12
notsupplied
R2 x2 &L2 x2
13
12
8
10
11
F
6
B
B
B
B
B
B
notsupplied
Pozi (large) 5.0 x 35
B x6
1
REPEAT ON REMAINING DRAWER

2 Drawer Entertainment Center Assembly Instructions
8
8
9
15.0 x 12
A x2
3
notsupplied
Pozi (large) 5.0 x 35
B x6
2
7 x 2
6
5.5 x 8
E x2 L1 x1
3.5 x 12
Fx1
1ST
Wheel
E
1.
15.0 x 12
A x16
B
B
B
B
B
B
1ST
Wheel
E
1.
F
2.2.
A
A
Ensure you attach the runners into the correct holes, as shown on the illustration below.
Once you have attached the front of the runner, align the runner and attach the back of
the runner with another E screw into the corresponding hole.
L1
L1
A
A
A
A
A
A
A
A
A
A
A
A

2 Drawer Entertainment Center Assembly Instructions
9
10
14
11
15.0 x 12
A x2
notsupplied
Pozi (large) 5.0 x 35
B x6 5.5 x 8
Ex2 R1 x1
3.5 x 12
Fx1
Ensure you attach the runners into the correct holes, as shown on the illustration below.
Once you have attached the front of the runner, align the runner and attach the back of
the runner with another E screw into the corresponding hole.
A
B
B
A
BB
B
B
1ST
Wheel
E
1.
F
2.
R1
R1
4
5
A
A
B
H
H
B
15.0 x 12
A x2
notsupplied
Pozi (large) 5.0 x 35
B x2 H x2 6.0 x 30

2 Drawer Entertainment Center Assembly Instructions
10
12
14
13
notsupplied
Pozi (large)
Now turn divider panel over.
notsupplied
Pozi (large)
1ST
Wheel
E
1.
F
2.
L1
L1
5.5 x 8
E x2 R1 x1
3.5 x 12
Fx1
5
5
B
B
5.0 x 35
B x2 5.5 x 8
Ex2 L1 x1
3.5 x 12
Fx1
1ST
Wheel
E
1.
1ST
Wheel
E
1.
F
2.
R1
R1

notsupplied
Pozi (large)
notsupplied
Pozi (large)
notsupplied
Pozi (large)
2 Drawer Entertainment Center Assembly Instructions
11
14
14
16
A
B
15
4
7
7
5
5
7

notsupplied
Pozi (large)
notsupplied
Pozi (large)
2 Drawer Entertainment Center Assembly Instructions
12
17
14
18
D
D
3.5 x 45
D x2
4
6
4
3
2
A 2nd person will be
required to hold the
plinth (6) until the
end panel is attached.

notsupplied
Pozi (large)
notsupplied
Pozi (large)
2 Drawer Entertainment Center Assembly Instructions
13
19
14
20
Before securing the back it is necessary to square up
the unit. You can do this by measuring between
XX-XX and YY-YY ensuring these are the same
(DIAG 1). If they not (DIAG 2). Apply slight pressure
as indicated (DIAG 3) until they are the same.
DIAG 1 DIAG 2 DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
YY
XX
YY
XX
G x10
supplied
1
3
4
14

Turn the unit upright.
Tilt the assembled drawer as shown
to attach the drawer to the already
located runners.
