Jøtul F 620 B User manual

1
Cat. no 10063602-P00 Jøtul AS, April. 2023
OPERATING INSTRUCTIONS
Jøtul AS,
P.O. Box 1411
N-1602 Fredrikstad,
Norway
intl.jotul.com
Since 1853
Jøtul F 620 B, P, LB, B HT

2
Attention! Use this approval label when the stoves has been installed (only for UK). Cut off
the bottom part and replace the label already attached with this one.
It is important that the lot + pin number is viewable.
Note: An approved CO monitor should be installed in the same room as the appliance.

3
CONTENTS
RELATIONSHIP TO THE
AUTHORITIES ..................................4
TECHNICAL DATA .............................4
SAFETY..............................................5
FIRE PREVENTION MEASURES..................................5
FLOOR ........................................................................5
WALLS .......................................................................5
CEILING ......................................................................5
JØTUL F 620 B: DIMENSIONAL DIAGRAM AND
ASSEMBLY DISTANCES............................................... 6
JØTUL F 620 P: DIMENSIONAL DIAGRAM AND
ASSEMBLY DISTANCES............................................... 7
JØTUL F 620 LB: DIMENSIONAL DIAGRAM AND
ASSEMBLY DISTANCES............................................... 8
JØTUL F 620: MINIMUM DISTANCE TO
COMBUSTIBLE WALL................................................. 9
JØTUL F 620: MINIMUM DISTANCE TO
COMBUSTIBLE WALL PROTECTED BY APPROVED
FIREPROOF WALL ....................................................10
INSTALLATION................................11
CHIMNEY AND FLUE PIPE........................................11
PRIOR TO INSTALLATION .........................................12
DISMANTLING PARTS ..............................................13
INSTALLATION JØTUL F 620 B - OUTSIDE AIR
BOTTOM ..................................................................14
INSTALLATION JØTUL F 620 B - OUTSIDE AIR REAR19
INSTALLATION JØTUL F 620 P - OUTSIDE AIR
BOTTOM ..................................................................22
INSTALLATION JØTUL F 620 P - OUTSIDE AIR REAR26
INSTALLATION JØTUL F 620 LB - WITHOUT OUTSIDE
AIR CONNECTION....................................................30
INSTALLATION JØTUL F 620 LB - OUTSIDE AIR
BOTTOM ..................................................................31
INSTALLATION JØTUL F 620 LB - OUTSIDE AIR
BOTTOM ..................................................................32
INSTALLATION JØTUL F 620 LB - OUTSIDE AIR REAR
..................................................................................33
DISMANTLING INTERNAL PARTS ............................35
INSTALLATION OF INTERNAL PARTS........................37
DAILY USE .......................................40
ODOURS WHEN USING THE FIREPLACE FOR THE
FIRST TIME ...............................................................40
ADJUSTING VENTS...................................................40
“TOP DOWN” LIGHTING THE FIRE..........................40
ADDING FIREWOOD................................................40
EXTERNAL AIR SUPPLY.............................................40
WOOD CONSUMPTION...........................................42
WARNING AGAINST OVERHEATING .......................42
REMOVING ASH.......................................................42
OPERATION UNDER DIFFERENT WEATHER
CONDITIONS ...........................................................42
CONDENSATION ......................................................42
THE CHIMNEY’S FUNCTION ....................................42
MAINTENANCE..............................43
CLEANING THE GLASS ............................................43
CLEANING AND REMOVING SOOT .........................43
SWEEPING THE FLUE PIPE TO THE CHIMNEY.........43
CHECKING THE FIREPLACE......................................43
EXTERNAL MAINTENANCE......................................43
RECYCLING PACKAGING ..........................................43
RECYCLING THE FIREPLACE .....................................43
OPERATIONAL PROBLEMS ͳ
TROUBLESHOOTING......................44
OPTIONAL EXTRAS ........................44
JØTUL F 620 Cast Iron side LeBP .........................44
JØTUL F 620 Cast Iron side Right BP .......................44
JØTUL F 620 Convecon kit side FR/FL (same no.
both sides) ...............................................................44
JØTUL F 620 Convecon kit rear.............................44
Cover outside air F 620 B ........................................44
Ash Lip F 620............................................................44
WARRANTY TERMS .......................45

4
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certicate/
The appliance can be used in a shared ue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Lot no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Eciency
Klasse II
Classication
Standard
Flue gas temperature
Room heater red by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC SP
EN
Lot no. Pin.
RELATIONSHIP TO THE
AUTHORITIES
The installaon of a fireplace must be carried out in compliance
with naonal laws and regulaons.
The process of installing the product must be in compliance with all
local ordinances, including those that refer to naonal and European
standards. The fireplace must always be installed in compliance with
naonal laws and regulaons. Always contact your local fire safety
office about current regulaons before installing your fireplace.
Read the Installaon instrucons with technical data and the
General informaon and maintenance manual carefully before
starng assembly/installaon.
A rang plate made of a heat-resistant material comes with
the product. This provides informaon on idenficaon and
documentaon of the product.
TECHNICAL DATA
Material Cast iron
Surface treatment Black paint
Type of fuel Wood
Max. log length 60 cm
Recommended log length 20-33cm
Smoke outlet Top
Flue pipe dimension Ø 150 mm
External air connecon Alu. flex- Ø80 / Ø100 mm
Weight Jøtul F 620 B: 215 kg
P: 206 kg
LB: 173.5 kg
B HT: 255 kg
Oponal extras Convecon set side, Cast
iron side, Cast iron rear
Product dimensions, clearances See dimension sketches
under the chapter
“Safety”.
Technical data in accordance with BS EN 13240 / NS 3058
Nominal heat output 8.5 kW
Flue gas volume 8.6 g/s
Chimney draught, EN 13240 12 Pa
Recommended negave pressure in
smoke outlet
16-18 Pa
Efficiency 77% @ 8.7 kW
CO emissions (13% O2)0.073%
CO emissions (13% O2)913 mg/Nm3
NOx (13% O2)90 mg/Nm3
OGC (13% O2)45 mg C/Nm3
Air consumpon 7.0 litres/sec.
Chimney temperature, EN 13240 2700C
Dust (13% O2)19 mg/Nm3
Parcle emission NS 3059 2.56 g/kg
Fuel consumpon 2.64 kg/h
Max. kindling amount 3.5 kg
Nominal kindling amount 2.1 kg (4 pieces)
Operaon Intermient*
*Intermient operaon means normal use of a fireplace, i.e. add
more fuel as soon as the fire has burned down to embers.
Performance declaraon and declaraon
of conformity can be found on Jøtul’s
website.
Register your fireplace at www.jotul.com
to get a 25-year guarantee.
The serial number and year are
marked on a label on all our
products. Write this number in the
place indicated in the Installaon
instrucons.
This serial number must always be
quoted when contacng your dealer
or Jøtul.

5
SAFETY
NB: To guarantee opmal performance and safety, Jøtul
recommends that its stoves are fied by a qualified installer (see
www.jotul.com for a complete list of dealers).
Any modificaons to the product by the distributor, installer
or consumer may result in the product and safety features not
funconing as intended. The same applies to the installaon of
accessories or oponal extras not supplied by Jøtul. This may also
be the case if parts that are essenal to the funconing and safety
of the fireplace have been disassembled or removed.
In all these cases, the manufacturer is not responsible or liable for
the product and the right to make a complaint becomes null and
void.
FIRE PREVENTION MEASURES
There is a certain element of danger every me you use your
fireplace. The following instrucons must therefore be followed:
The minimum safety distances when installing and using the
fireplaces are given in the figures on the following pages.
• Ensure that furniture and other combusble materials are not
too close to the fireplace. Combusble materials must not be
placed within 1,000 mm of the fireplace opening.
• Allow the fire to burn out. Never exnguish the flames with
water.
• The fireplace becomes hot when lit and may cause burns if
touched.
• Only remove ash when the fireplace is cold. Ash can contain
hot embers and should therefore be placed in a non-flammable
container.
• Ash should be placed outdoors or be emped in a place where
it will not pose a potenal fire hazard.
In case of a fire in the chimney:
• Close all openings and valves.
• Keep the door to the firebox closed.
• Call the fire department.
• Ensure that the fireplace and the chimney are inspected and
given a green light by a professional before you start to use the
fireplace again aer an outbreak of fire.
FLOOR
Foundaons
You must make sure that the foundaon is suitable for the fireplace.
See “Technical Data” for specified weight.
We recommend the removal of any flooring that is not aached to
the foundaon (“floang floors”) beneath the installaon.
Requirements for protecon of combusble
floors under the fireplace
The product can be installed directly on a combusble floor that
is covered by a sheet of metal or other non-flammable material.
Recommended thickness is a minimum of 0.9 mm).
The funcon of a floor plate is to protect the floor and flammable
materials against embers. Jøtul recommends that floor covering
made of flammable material, such as linoleum, carpets, etc., be
removed from under the floor plate.
The floor plate must comply with naonal laws and regulaons.
Contact your local building authories regarding restricons and
installaon requirements.
For Norway: Minimum 300 mm in front of the door and width at
least the same as the door.
WALLS
• Place the product in such a way that it is possible to clean the
stove, the flue pipe and the chimney passage.
• Ensure that furniture and other combusble materials are not
too close to the fireplace.
• Make sure that furniture and other household items are not so
close as to get dried up by the stove.
Distance to walls made of combusble material – see the figures on the
following pages.
The distances relate to a shielded flue pipe/semi-insulated pipe.
The fireplace can be installed with an uninsulated flue pipe. In this case,
the flue pipe must be CE marked and the pipe’s declared distance to
flammable materials must be taken into consideraon.
Combusble wall protected by firewall
Distance to combusble wall protected by firewall – see the figures
on the following pages.
Requirements for firewall
The firewall must be at least 110 mm thick and made of brick,
concrete or lightweight concrete. Other materials and structures
with sasfactory documentaon may also be used, e.g. 50 mm Jøtul
Firewall.
Non-flammable materials refer to materials that cannot burn, e.g.
bricks, les, concrete, mineral wool, various silicate plates, etc. Bear
in mind that a short distance to non-flammable walls can result in
the drying out and discolouraon of paintwork, as well as lead to
the formaon of cracks.
CEILING
There must be a minimum distance of 750 mm between the
fireplace and a ceiling made of a combusble material above the
fireplace.

6
JØTUL F 620 B
JØTUL F 620 B: DIMENSIONAL DIAGRAM AND ASSEMBLY DISTANCES
Minimum clearance from furniture/combusble materials
Minimum distance to ceiling
Hole in wall for outside air connecon Ø80 / Ø100
Hole in floor for outside air
connecon Ø80 / Ø100
Min. dimensions for floor plate
X/Y = in compliance with naonal laws and regulaons

7
  


 

 







 


!
!! !!!
!
!! !!!
!!!
     
!!! !
!!!! !!!


 



 








3
JØTUL F 620 P
JØTUL F 620 P: DIMENSIONAL DIAGRAM AND ASSEMBLY DISTANCES
Minimum clearance from furniture/combusble materials
Minimum distance to ceiling
Hole in wall for outside air connecon
Ø80 / Ø100
Hole in floor for outside air connecon
Ø80 / Ø100
Min. dimensions for floor plate
X/Y = in compliance with naonal laws and regulaons

8
   

  






  

 


""" !"


"""!"""""
 
"

 ""!""  "
"""
 "" !""  "
"""
 

 
  
 

 
















 











 
JØTUL F 620 LB
JØTUL F 620 LB: DIMENSIONAL DIAGRAM AND ASSEMBLY DISTANCES
Minimum clearance from furniture/combusble materials
Min. dimensions of base
Min. dimensions of base
Min. dimensions of base with extended side
Minimum distance to ceiling
Hole in wall for outside air connecon Ø80 / Ø100
Hole in floor for outside air
connecon Ø80 / Ø100
Min. dimensions for floor plate
X/Y = in compliance with naonal laws
and regulaons

9
100
297
567
900364
-
P
JØTUL F 620: MINIMUM DISTANCE TO COMBUSTIBLE WALL
With semi-insulated chimney/shielded flue pipe all the way down to the product Combusble wall
F 620: Minimum distance to combusble wall
F 620 B / F 620 P / F 620 LB / F 620 B HT - With retrofied cast iron side F 620 B / F 620 P / F 620 LB / F 620 B HT - With retrofied cast iron side and convecon kit side
- With retrofied convecon kit rear
FR
Convecon kit side
FL
Convecon kit side Convecon kit rear
F 620: MIN. DISTANCE TO COMBUSTIBLE WALLF 620: MIN. DISTANCE TO COMBUSTIBLE WALLF 620: MIN. DISTANCE TO COMBUSTIBLE WALL

10

/// ///


 
 
  

 

////////////////
 /++)%'&+)+/*+(")&/*!
 


 

  


//!&/-*+&/+!$/)&&)/- /*#.+++/-/ '#"&+/)&&%,)/
/// ////
  


  
  
 
 









   




 
+&($! &/)&&%,)/



 
 
 




+&($! &/)&&%,)/


  



 
 



  

 

  
  



// )&&/)/- /


// )&&%,)//#(!+$//!/%&,$&/
   










$&&$+/)&&%,)/



$&&$+/)&&%,)/
   
 
  
 






  




    






 

JØTUL F 620: MINIMUM DISTANCE TO COMBUSTIBLE WALL PROTECTED BY APPROVED
FIREPROOF WALL
F 620: Minimum distance to combusble wall protected by approved fireproof wall
External fireproof wall External fireproof wall
F 620 B / F 620 P / F 620 LB / F 620 HT - With retrofied cast iron side
Integrated firewall Integrated firewall
Combusble wall Firewall (See Chapter 3.3 in the manual)

11
INSTALLATION
CHIMNEY AND FLUE PIPE
• The fireplace can be connected to a chimney and flue pipe approved for solid fuel fireplaces with flue gas temperatures as specified in “Technical
Data”. If a steel chimney is used, this must be marked with T 400 and G for soot fire tesng.
• The cross-secon of the chimney must be at least as large as that of the flue pipe: Ø150 mm flue pipe- 177 cm2.
• Several solid fuel stoves can be connected to the same chimney system if the chimney cross secon is adequate.
• The specified distance to combusble materials applies to this stove.
• Use a CE approved flue pipe and/or steel chimney.
• Take into account the distance from the flue pipe to combusble materials.
• The chimney must be connected in accordance with the installaon instrucons of the chimney supplier.
• Before a hole is made in the chimney, the fireplace should be test-mounted in order to correctly mark the posion of the fireplace and the hole
in the chimney. See “Dimensional diagram and assembly distances” for your stove for minimum dimensions.
• Use a flue pipe bend with a sweep hatch to allow sweeping.
• Numerous flue bends (and flue bends of many degrees) can affect the draught in the chimney. The same can occur in the case of long horizontal
lengths. Please note that it is extremely important for connecons to have a degree of flexibility. This is to prevent any movement in the
installaon leading to the formaon of cracks.
• For recommended chimney draught, see “Technical Data”. For flue pipe dimensions, see “Technical Data”.
NB: The minimum recommended chimney length is 3.5 m. If the draught is too strong, a flue pipe damper can be installed and used to reduce the
draught.
When installing a flue pipe damper, this must be of the type that does not close the flue pipe fully. The damper must be easy to operate, and must
have a free opening of at least 20 cm2, or 3% of the flue pipe’s cross-secon if this is larger. The posion of the damper must be visible when
operang the stove. If a draught regulator is installed, the requirement regarding the free cross-secon does not apply, although the unit must be
easily accessible for cleaning.

12
PRIOR TO INSTALLATION
• Before installing the fireplace, check it carefully for any signs of damage
• The product is heavy! Ask someone to help you when posioning and installing it. We recommend using a liing device.
• Make sure that furniture and other household items are not so close as to get dried up by the stove.
Remove the transport brackets
• The standard product comes in two packages. One contains the fireplace itself, the other contains the base or pedestal in cast iron.
• Remove screws from the brackets to release the burn chamber from the pallet.
• The burn chamber must be laid on its back to secure the base. Before doing this, loose parts should be dismantled. Dismantling is presented
on page 34.
• Exercise cauon when dismantling the parts.

13
1
23
4
5
6
1. Log retainer
2. Inner boom grate
3. Inner boom
4. Rear burn plate
5. Baffle plate
6. Exhaust deflector
PRESS HERE TO NAVIGATE TO DISMANTLING INTERNAL PARTS
DISMANTLING PARTS

14
F 620 Base
1
2
INSTALLATION JØTUL F 620 B - OUTSIDE AIR BOTTOM

15
F 620 Base
5
3 4
INSTALLATION JØTUL F 620 B - OUTSIDE AIR BOTTOM

16
F 620 Base
6
7
INSTALLATION JØTUL F 620 B - OUTSIDE AIR BOTTOM

17
F 620 Base
8
9
INSTALLATION JØTUL F 620 B - OUTSIDE AIR BOTTOM

18
F 620 Base
1110
12
!
Min.
100mm
INSTALLATION JØTUL F 620 B - OUTSIDE AIR BOTTOM

19
F 620 Base
1
2 3
INSTALLATION JØTUL F 620 B - OUTSIDE AIR REAR

20
F 620 Base
6
4 5
INSTALLATION JØTUL F 620 B - OUTSIDE AIR REAR
