JTS IN264 User manual

2
IN
4
6
REMOSET
IN
4
2
6
R
SET ▲
▲
REMOSET
SET ▲
▲
AF
RF
AF
RF
Music
LifeINFINITY
UHF PLL Dual Channel Diversity Wireless System
* The system is of the innovative design to allow changing the
transmitter’s frequency by long-distance .
* IN264R with band width of 36 MHz.
* Preset 6 groups, maximum 23 channels in one group.
* Operation distance from 200~480 meters.

ank you for choosing the JTS wireless system. In order to obtain the best eciency from the system,
you are recommended to take a few minutes to read this instruction manual carefully.

1. Important Caution
2. Features
3. Specication
3-1 UHF PLL Dual Channel Diversity Receiver // IN264R
3-2 UHF PLL Handheld Transmitter // IN264TH
3-3 UHF PLL Body-Pack Transmitter // IN264TB
3-4 Optional Condenser Microphone
4. Part Identication & Accessories
4-1 UHF PLL Dual Channel Diversity Receiver // IN264R
4-2 UHF PLL Handheld Transmitter // IN264TH
4-3 UHF PLL Body-Pack Transmitter // IN264TB
4-4 Optional Condenser Microphone
4-5 Accessories
5. Connection
6. Operation
7. Recommendation
8. Important Notice
1
1
2
2
2
3
3
6
6
7
8
9
13
14
15
22
24
INDEX

1
Music
INFINITY
Life
1. Important Caution
2. Features
Always makes all connections before plugging the unit into an AC power outlet.•
Do not leave the device in a place neither with high temperature nor high humidity.•
Always do not handle the power cord with wet hands!•
Keep the devices away from re and heat sources.•
Pair the ID codes of the transmier and the receiver to have proper function.•
JTS IN264 wireless microphone system is designed with the world rst RF remote seing func-
tion (REMOSET). A user can set the receiver with desired frequency and press the “REMOSET”
Key; then the transmier will automatically be set. e operation distance can reach 10 meters. is
brings great convenience to sound engineers during live performance.
IN264 is of 36MHz bandwidth to render 23 transmiers work simultaneously. It provides
great convenience to large venue.
A new capsule has been developed for IN264TH . e capsule, SAM-8W, is designed for large
venue with hundreds of thousands wa power. e SAM-8W delivers vivid details of vocal and
instruments.
e IN264 is of stylish industry design. Yet JTS bombproof quality remains as always.

2
IN
4
6
2
3. Specication
3-1 UHF PLL Dual Channel Diversity Receiver // IN264R
3-2 UHF PLL Handheld Transmitter // IN264TH
Frequency Preparation......
Remoset......................................
Carrier Frequency Range
S/N Ratio...................................
T.H.D..............................................
Display...........................................
Display Contents...................
Controls.......................................
Audio Output Level.............
AF Output Impedance.......
Squelch..........................................
Operation Voltage.................
Output Connector................
Dimension(m/m).................
PLL Synthesized Control
Radio Frequency : 2.4GHz
Eective distance: 10m
502~960 MHz
>105dB
<0.6%@1KHz
LCD
Channel, Antenna A/B, Mute Display, RF/AF Level Meter,
Low baery, ID Number
Power On/O, Frequency Up/Down, Lock-on, ID Pairing,
Remoset
0dB / -10dB / -20dB
600Ω
Pilot Tone & Noise Mute
12-18 VDC, 800 mA
2 XLR Balanced Sockets / 1 Ø6.3mm unbalanced phone jack
420mm(W) * 44mm(H) * 211mm(D)
Frequency Preparation...........
Carrier Frequency Range.....
RF Outputs....................................
Stability...............................................
Frequency Deviation...............
LCD Display..................................
Controls............................................
Spurious Emissions...................
Audio Frequency Response
Baery.................................................
PLL Synthesized Control
502~960 MHz
10mW / 50mW
(Depend on Local Regulation)
±10KHz
±48KHz
Channel, Baery Fuel Gauge, ID Number
Power On/O, AF Level, Frequency Up/Down,
Lock-on Mode,ID Pairing
<-50 dBC
50~16,000 Hz
UM3, AA 1.5V*2

3
Music
INFINITY
Life
3-3 UHF PLL Body-Pack Transmitter // IN264TB
3-4 Optional Condenser Microphone
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-501
4P Mini XLR
100~15,000 Hz
Cardioid
-60±3 dB
2.2kΩ
130dB
Ø10.1mm(W)
* 26.4mm(H)
21.5g
CM-201
4P Mini XLR
60~15,000 Hz
Omni-directional
-60±3 dB
2.2kΩ
130dB
Ø5mm(W)
* 9mm(H)
20.7g
CM-125
4P Mini XLR
50~18,000 Hz
Omni-directional
-53±3 dB
4.4kΩ
130dB
Ø4mm(W)
* 11mm(H)
7g (cable excluded)
Lavaliere Microphone
Frequency Preparation............
Carrier Frequency Range......
RF Outputs......................................
Stability................................................
Frequency Deviation................
LCD Display...................................
Controls.............................................
Input connector............................
Spurious Emissions....................
Audio Frequency Response
Baery..................................................
PLL Synthesized Control
502~960 MHz
10mW / 50mW
(Depend on Local Regulation)
±10KHz
±48KHz
Channel, Baery Fuel Gauge, ID Number
Power On/O, AF Level,
Frequency Up/Down, PAD, Gain Control,
ID Pairing, Lock-on Mode
4P mini XLR
<-50 dBC
40~18,000 Hz
UM3, AA 1.5V*2

2
IN
4
6
4
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-225
4P Mini XLR
50~18,000 Hz
Omni-directional
-53±3 dB
4.4kΩ
130dB
155mm(W)
* 134mm(H)
* 157mm(D)
17g (cable excluded)
CX-504
4P Mini XLR
30~18,000 Hz
Cardioid
-68±3 dB
680Ω
130dB
285mm(W)
* 55mm(H)
* 111.3mm(D)
56.3g
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Dimension(mm)..............
Net Weight............................
CM-204
4P Mini XLR
60~15,000 Hz
Omni-directional
-60±3 dB
2.2kΩ
130dB
125mm(W)
* 134mm(H)
* 157mm(D)
32.9g
CM-204U
4P Mini XLR
30~18,000 Hz
Cardioid
-68±3 dB
680Ω
130dB
205mm(W)
* 134mm(H)
* 157mm(D)
38.4g
CM-204UL
801C3 (3 pin mini XLR)
801C4 (4 pin mini XLR)
801CS (3.5 stereo plug)
100 ~ 18,000Hz
Cardioid
-75±3 dB
1.5kΩ
120dB
125mm(W)
* 134mm(H)
* 157mm(D)
18g (cable excluded)
Headset Microphone

5
Music
INFINITY
Life
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Good For.................................
Model No...............................
Connector..............................
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
Good For.................................
CX-500
4P Mini XLR
20~20,000 Hz
Omni-directional
Condenser
-58±3dB
1.5kΩ
130 dB
Violin
CX-508W
4P Mini XLR
50~18,000 Hz
Cardioid
-67±3 dB
220Ω
130 dB
Winds
CX-500F
4P Mini XLR
50~18,000 Hz
Omni-directional
Condenser
-58±3dB
1.5kΩ
130 dB
Flutes
CX-520
4P Mini XLR
50~18,000 Hz
Electret Condenser
-78±3dB
600Ω
148 dB
Harmonica
CX-516W
4P Mini XLR
50~18,000 Hz
Cardioid
-67±3 dB
220Ω
130 dB
Accordion
Compatible Instrument Microphone
Model No...............................
Connector..............................
Option Connector...........
Frequency Response......
Polar Paern..........................
Sensitivity (at 1000Hz)
Impedance.............................
Max. SPL for 1% THD
CM-801/CM-804i
801C4 (4 pin mini XLR)
801C3 (3 pin mini XLR)
801CS (3.5 stereo plug)
60~15,000 Hz
Omni-directional
-64±3 dB
1.8kΩ
130dB
CM-8015/CM-825i
801C4 (4 pin mini XLR)
801C3 (3 pin mini XLR)
801CS (3.5 stereo plug)
50~18,000 Hz
Omni-directional
-53±3 dB
1.2kΩ
130dB
Ear-hook Microphone

2
IN
4
6
6
REMOSET
IN
4
2
6
R
SET ▲
▲
REMOSET
SET ▲
▲
AF
RF
AF
RF
10
11
12
4. Parts Identication & Accessories
4-1 UHF PLL Dual Channel Diversity Receiver // IN264R
Rear panel
BNC antenna connector
Power Supply Jack (12-18V/800mA): for connecting the power supply unit
Squelch adjuster: to adjust radio signal level of both channels
Mixed AF Output (6.3mm jack, unbalanced): for connection to a balanced input,
e.g. of a mixer or amplier
Balanced XLR Output: for connection to the balanced input, e.g. of a mixer or an
amplier
Output Level Aenuation(-10dB,-20dB): to aenuate the balanced XLR output
level by 10dB,20dB
Front panel
Power Switch
Channel Select: Up buon
Channel Select: Down buon
Channel Select: Set buon
LCD Panel
REMOSET Key: press it to send a desired channel data to a transmier
1
1
4
66
7
2
22
5
8
3
5 5
6
9
12 121011 11 997 78
44
3 3

7
Music
INFINITY
Life
LCD Display
Baery Tray
Set buon: set the conguration of handheld transmier
Up buon: select the seings of transmier
Down buon: select the seings of transmier
Power and Mute Switch
LCD Panel of the Handheld Transmitter
Baery status: display baery status
Group & Channel: there are 6 groups, maximum 23
channels in one group.
AF
RF
LCD Panel of the Receiver
AF Level: display the strength of audio signal
RF Level: display the strength of radio signal
Antenna Status: the receiver will automatically select an antenna with stronger signal level
Low baery indicator: display the low baery status of its transmier
Group & Channel: there are 6 groups, maximum 23 channels in one group.
4-2 UHF PLL Handheld Transmitter // IN264TH
19
21
25
23
20
24
22
14
15
17
13
16
18
13
16
14
17
15
25
24
21
23
22
19
18
20

2
IN
4
6
8
-20 -6 0
SET+
-
SET+
-
- -
IN
4
2
6
TB
IN
4
2
6
TB
LCD Display
Baery Tray
Set buon: set the conguration of bodypack transmier
Up buon: select the seings of transmier
Down buon: select the seings of transmier
4 Pin mini XLR mic. input
Power Switch
Pad: -20dB, -6dB, 0dB
LCD Panel of the Body-Pack Transmitter
Baery status: display baery status
Group & Channel: there are 6 groups, maximum 23
channels in one group.
4-3 UHF PLL Body-Pack Transmitter // IN264TB
35
34
33
26
27
29
30
31
32
28
27
26
28
29
31
32
33
30
-
IN
4
2
6
TB
35
34

9
Music
INFINITY
Life
Clip
4 Pin Mini XLR
Windscreen
4-4 Optional Condenser Microphone
38
38 38 38
37
37
Lavaliere Microphone // CM-501 / CM-201 / CM-125
CM-501 CM-201 CM-125
36
36
36 36

2
IN
4
6
10
Gooseneck
Headband
4 Pin Mini XLR
Windscreen
CM-204 CM-204U
CM-225 CX-504
40
40 40
40
40
40
42
42 42
42
42
42
39
39
39
39
39
39
41
41
CM-204UL
Standard :
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
Headset Microphone // CM-204 / CM-204U / CM-204UL / CM-225 /
CX-504

11
Music
INFINITY
Life
Boom
Adjustable Headband
Adjustable ear hook
Detchable Cable
Cable Clip
Windscreen
4 Pin Mini XLR
3 Pin Mini XLR
3.5 Stereo Plug
Ear-hook Microphone // CM-801 / CM-804i / CM-8015 / CM-825i
48
50
50
49
51
51
45
47
49
46
43
44
CM-825i 47
48
43
45
46
44
Option
Option
CM-801
47
48
43
45
46
CM-804i 47
48
43
45
46
44
CM-8015
47
48
43
45
46

2
IN
4
6
12
57
Gooseneck
Clip
Bracket
Volume Control
Windscreen
4 Pin Mini XLR
55
56
57
54
53
56
56
52
CX-508WCX-520
CX-500F
CX-500
CX-516W
53
52
52
56 56
52
54
Compatible Instrument Microphone // CX-500 / CX-500F / CX-520 /
CX-508W / CX-516W
53
55

13
Music
INFINITY
Life
4-5 Accessories
AC/DC adaptor
Switching Power Supply(100V~240V , 50~60Hz)
Linear Power Supply (220V , 50Hz)
Linear Power Supply (220V , 60Hz)
Screwdriver
RM-12 Rack mount kit
AF output cable (with Ø6.3 plug at both ends)
GC-80/GC-100 Guitar Cable
GC-80L/GC-100L Guitar Cable
62
62
63
63
61
61
Option
Option
Option
Option
Option
A
B
C
59
59
60
60
58
58
A
B C

2
IN
4
6
14
5. Connection
5-1 Receiver // IN264R
(1) Connect to the subsequent unit (e.g. mixer, or amplier)
Connect one end of a proper AF cable to the AF Output or Balanced XLR Output socket
, then plug another end to the “MIC IN” input socket of a mixer or a amplier (Step 1 for
Figure 1)
(2) Connect the power supply unit
Plug in one end of AC/DC adaptor cable to Power Supply Jack in the rear panel of
receiver, and plug another end into an AC outlet
(Step 2 for Figure 1)
Caution
To prevent accidental disconnection of the plug of the power supply unit from the jack, lead
the cable around the hook for strain relief .
11
10
8
57
MIXER
AUDIO OUTPUT
DC INPUT
Figure 1
2
1

15
Music
INFINITY
Life
6. Operation
6-1 Set up the system
(1) Turn on the power of the receiver
Switch the “Power Switch” to “ON”. e “LCD Panel” and “REMOSET” Key
will light up.
(2) Turn on the power of the transmier
Press the “Power Switch” . e “LCD Display” will light up.
(3) Mute Function ( for IN264TH )
Aer the transmier’s power is on, short pressing the “Power Switch “
will mute the microphone. Press the “Power Switch” again will re-activate the microphone.
Notice: You have to hold the “Power Switch” for 3 seconds in order to turn o the transmier.
(4) Install the antennas in a vertical position
6-2 Set up ID code
In order to match one receiver to only one transmier, IN264 is designed with“ ID code”. If
and only if both ID codes of a receiver and a transmier match each other, the “REMOSET”
function works. ere are 100 ID codes available.
Receiver
(1) Press “Set” buon for 3 seconds, LCD Panel will start ashing.
(2) Press “Set” twice to enter “ID Code” seing window. (Figure 2)
(3) Press “ Up ” or “ Down ” buon to select a distinct ID code from “id 0” to “id 99”
(4) Aer seing, press “Set” again to save the seings.
23 18 2632
51 6
4
Figure 2
SET ▲
▲
2 3

2
IN
4
6
16
Handheld and BodyPack transmitter
ID code ON/OFF setting
(1) Press “Set” buon for 3 seconds, LCD Panel will start ashing.
(2) Press “Set” a couple of times until “ID Code ON/OFF” seing window shows.
(3) Press“ Up ” or “ Down ”buon to select between “ ID ON “ and “ ID OFF “.
(4) Aer seing, press “Set” again to save the seings.
Caution
When ID code is o (idOFF), the transmier will accept any synchronization from any
receiver.
ID code selecting
(1) Press “Set” buon for 3 seconds, LCD Panel will start ashing.
(2) Press “Set” a couple of times until “ID Code” seing window shows.
(3) Press“ Up ” or “ Down ”buon to select a distinct ID code from “ id 0” to
“id 99 “. (Figure 3)
(4) Aer seing, press “Set” again to save the seings.
20
20
28
28
Figure 3
3”
SET+
-
IN
4
2
6
TB
-
3”
21
21
22
22
29
29
30
30

17
Music
INFINITY
Life
6-3 Synchronize the channel
(1) Press “Set” buon fon the receiver for 3 Seconds, the group (G) in the “Group & Channel”
area will ash. (Figure 4)
(2) Press “ Up ” or “ Down ” buon to select a desired group
(3) Press “Set” again and the Channel (CH) in the “Group & Channel” area will ash.
(4) Press “ Up” or “ Down” buon to select a desired channel.
(5) Aer seing, press “Set” again to save the seings.
(6) Press “REMOSET” to synchronize the channel of a transmier. (Figure 5)
(7) If the channel of the transmier fails to change, the “REMOSET” key will keep ashing.
Notice 1: e transmier has to be set to “synchronization on (SYnOn)” in order to allow the
receiver to synchronize.(Handheld and body Pack Seing List p.17 )
Notice 2 : When seing the channel, system will automatically avoid the channel used by the
other channel.
6-4 Check system status
(1) Antenna Status: the receiver will automatically select an antenna with stronger signal
reception and highlight that antenna (Figure 6)
(2) Baery indicator: the receiver’s baery indicator will show the same gauge as the transmiers.
If the transmier is under low baery status, the receiver LCD backlight will be on amber.
17
6
15
Figure 4 Figure 5
REMOSET
SET ▲
▲
AF
RF
SET ▲
▲
AF
RF
Figure 6
AF
RF
Figure 7
AF
RF
2 3
4
