JUMO LOGOSCREEN 700 Reference guide

70653000T97Z001K000
V2.00/EN/00710320
JUMO LOGOSCREEN 700
Highly-Scalable Paperless Recorder
Brief Instructions

Contents
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3 Qualification of personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4 Acceptance of goods, storage, and transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.1 Checking the delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.2 Important information about storage and transport. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.3 Returning goods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.4 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.5 Identifying the device version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.5.1 Nameplate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1.5.2 Order details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.5.3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.5.4 Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
1.6 Content of the technical documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.6.1 Device documentation in printed form . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.6.2 Device documentation in the form of PDF files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.6.3 Documentation for optional software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
1.7 Device version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2 Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Brief description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.3 Display and control elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.4 Connection elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.1 General information on mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.2 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
3.3 Panel mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.4 Handling the front of the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.5 Terminal cover (accessories) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.6 Universal carrying case, compact (extra code 970) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.1 Installation notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2 Galvanic isolation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.3 Connection elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.4 Connection diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.4.1 Analog inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.4.2 Digital inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.4.3 Analog outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Contents
4.4.4 Digital inputs/outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.4.5 Relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.4.6 RS232/RS485 interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.4.7 Ethernet/PROFINET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.4.8 Voltage supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.1 Operating concept. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.1.1 Touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.1.2 LED displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.2 Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.2.1 Logon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5.2.2 Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.2.3 Parameterization. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.2.4 Device information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.2.5 Audit trail list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.2.6 Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.2.7 Calibrating the touchscreen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.3 Alarm and event menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5.3.1 Alarm list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.3.2 Event list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
5.4 Visualization menu (display) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5.4.1 Curve diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
5.4.2 Digital diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
5.4.3 Bar graph . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5.4.4 Text image. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
5.4.5 Report . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.4.6 Current batch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
5.4.7 Completed batch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
5.4.8 Process screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5.4.9 Counter/integrator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5.4.10 Comment text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.5 Text input dialog . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5.6 Flash manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5.7 Web server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5.8 Electronic signature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
6 Annex . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6.1.1 Analog inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
6.1.2 Digital inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
6.1.3 Analog outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
6.1.4 Digital inputs/outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
6.1.5 Relays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Contents
6.1.6 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
6.1.7 Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
6.1.8 Electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
6.1.9 Environmental influences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
6.1.10 Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
6.1.11 Approvals and approval marks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6.2 Buffer battery replacement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
6.3 China RoHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6.4 Barcode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
6.4.1 Batch control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
6.4.2 Texts and process values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Contents

7
1 Introduction
1 Introduction
1.1 Safety information
General
This manual contains information that must be observed in the interest of your own safety and to avoid
material damage. This information is supported by symbols which are used in this manual as indicated.
Please read this manual before starting up the device. Store this manual in a place that is accessible to
all users at all times.
If difficulties occur during startup, please do not intervene in any way that could jeopardize your warranty
rights!
Warning symbols
WARNING!
This symbol in connection with the signal word indicates that personal injury may occur if the respective
precautionary measures are not carried out.
CAUTION!
This symbol in connection with the signal word indicates that material damage or data loss will occur
if the respective precautionary measures are not taken.
CAUTION!
This symbol indicates that components could be destroyed by electrostatic discharge (ESD = Electro
Static Discharge) if the respective cautionary measures are not taken.
Only use the ESD packages intended for this purpose to return device inserts, assembly groups, or as-
sembly components.
Note symbols
NOTE!
This symbol refers to important information about the product, its handling, or additional benefits.
READ THE DOCUMENTATION!
This symbol, which is attached to the device, indicates that the associated documentation for the de-
vice must be observed. This is necessary to identify the nature of the potential hazard, and to take
measures to prevent it.
REFERENCE!
This symbol refers to additional information in other sections, chapters, or other manuals.
FURTHER INFORMATION!
This symbol is used in tables and indicates that further information is provided after the table.
&
DISPOSAL!
At the end of its service life, the device and any batteries present do not belong in the trash! Please en-
sure that they are disposed of properly and in an environmentally friendly manner.

1 Introduction
8
1.2 Intended use
The device is designed for use in an industrial environment as specified in the technical data. Other uses
beyond those defined are not viewed as intended uses.
The device has been manufactured in compliance with applicable standards and directives as well as
the applicable safety regulations. Nevertheless, improper use may lead to personal injury or material
damage.
To avoid danger, only use the device:
• For the intended use
• When in good order and condition
• When taking the technical documentation provided into account
Risks resulting from the application may arise, e.g. as the result of missing safety provisions or wrong
settings, even when the device is used properly and as intended.
1.3 Qualification of personnel
This document contains the necessary information for the intended use of the device to which it relates.
It is intended for staff with technical qualifications who have been specially trained and have the appro-
priate knowledge in the field of automation technology.
The appropriate level of knowledge and the technically fault-free implementation of the safety informa-
tion and warnings contained in the technical documentation provided are prerequisites for risk-free
mounting, installation, and startup as well as for ensuring safety when operating the described modules.
Only qualified personnel have the required specialist knowledge to correctly interpret and implement the
safety information and warnings contained in this document in specific situations.
1.4 Acceptance of goods, storage, and transport
1.4.1 Checking the delivery
• Ensure that the packaging and its contents are undamaged
• Check the delivery for completeness against the packing slip and order details
• Inform the supplier immediately if there is any damage
• Store damaged parts until clarification is received from the supplier
1.4.2 Important information about storage and transport
• Store the device in a dry, clean environment. Observe the admissible ambient conditions (see "Tech-
nical data")
• Protect the device from shock during transport
• The original packaging provides optimum protection for storage and transport
1.4.3 Returning goods
In the event of repair, return the complete device in clean condition.
Use the original packaging to return goods.
Accompanying letter for repair
Please include the completed accompanying letter for repair when returning goods.
Do not forget to state the following:
• Description of the application and
• Description of the error that has occurred

9
1 Introduction
The accompanying letter for repair (Supplementary sheet for product returns) can be downloaded online
from the manufacturer's website:
http://productreturn.jumo.info
Protection against electrostatic discharge (ESD)
(ESD = electrostatic discharge)
To prevent damage due to ESD, electronic modules or components must be handled, packaged, and
stored in an ESD-protected environment. Measures that protect against electrostatic discharge and elec-
tric fields are described in DIN EN 61340-5-1 and DIN EN 61340-5-2 "Protection of electronic devices
from electrostatic phenomena".
When returning electronic modules or components, please note the following:
• Pack sensitive components only in an environment providing protection against ESD. Workspaces
such as this divert electrostatic charges to ground in a controlled manner and prevent static charges
due to friction.
• Use only packaging intended specifically for ESD-sensitive assemblies/components. These must
consist of conductive plastics.
No liability can be assumed for damage caused by ESD.
CAUTION!
Electrostatic charges occur in non-ESD-protected environments.
Electrostatic discharges can damage modules or components.
For transport purposes, use only the ESD packaging provided.
1.4.4 Disposal
Disposing of the device
Disposing of the packaging material
The entire packaging material (cardboard packaging, inserts, plastic film, and plastic bags) is fully recy-
clable.
DISPOSAL!
Devices and/or replaced parts should not be placed in the refuse bin at the end of their service life as
they consist of materials that can be recycled by specialist recycling plants.
Dispose of the device and the packaging material in a proper and environmentally friendly manner.
For this purpose, observe the country-specific laws and regulations for waste treatment and disposal.

1 Introduction
10
1.5 Identifying the device version
1.5.1 Nameplate
The nameplate is affixed to the housing.
Contents
The nameplate contains important information. This includes:
Device type (Typ)
Compare the specifications on the nameplate with the order.
Identify the supplied device version using the order details (order code).
Part no. (TN)
The part no. uniquely identifies an article in the catalog. It is important for communication between the
customer and the sales department.
Fabrication number (F-Nr.)
The fabrication number indicates, among other things, the date of manufacture (year/week).
Example: F.-Nr = 0070033801219110006
The characters in question are digits 12, 13, 14, and 15 (from the left).
The device was therefore produced in the 11th week of 2019.
Description Designation on the
nameplate
Example
Device type Typ 706530/18-1124-25/260
Part no. TN 00123456
Fabrication number F-Nr. 0070033801219110006
Voltage supply - AC/DC 20 to 30 V, 48 to 63 Hz

11
1 Introduction
1.5.2 Order details
(1) Basic type
706530 Paperless recorder with the following interfaces: 1x Ethernet, 2x USB (1x host, 1x de-
vice), 1x RS232/485 interface, as well as a relay (changeover contact)
(2) Basic type extension
0 Without software package
1 With software package (setup program incl. USB cable, PC Evaluation Software
PCA3000, PCA Communication Software PCC; in conjunction with extra code "888"
as well with PC Security Manager PCS and PC Audit Trail Manager PCAT software)
(3) Language
8 Default setting (German/English)
9 Set according to customer specifications
(4) Option 1 (slot 1)a
0 Not used
1 Analog/digital: 3 analog and 6 digital inputs, 1 analog output
2 Analog(HI)/digital: 3 analog (HI)b and 4 digital inputs, 4 digital inputs/outputs
3 Analog: 6 analog inputs
(5) Option 2 (slot 2)a
0 Not used
1 Analog/digital: 3 analog and 6 digital inputs, 1 analog output
2 Analog(HI)/digital: 3 analog (HI)b and 4 digital inputs, 4 digital inputs/outputs (individu-
ally switchable)
3 Analog: 6 analog inputs
(6) Option 3 (slot 3)a
0 Not used
1 Analog/digital: 3 analog and 6 digital inputs, 1 analog output
2 Analog(HI)/digital: 3 analog (HI)b and 4 digital inputs, 4 digital inputs/outputs (individu-
ally switchable)
3 Analog: 6 analog inputs
(7) Option 4 (slot 4)a
0 Not used
4 Digital: 12 digital inputs/outputs (individually switchable)
5 Relay: 6 relay outputs (changeover contact)
(8) Voltage supply
23 AC110to240V +10/-15%, 48to63Hz
25 AC/DC20to30V, 48to63Hz
(9) Extra code 1
. Not used
260 Math and logic module (20 channels each)
221 Structured text (ST code)
(10) Extra code 2
. Not used
887 Manipulation detection with digital certificate
888 FDA 21 CFR Part 11 with digital certificate

1 Introduction
12
1.5.3 Scope of delivery
1.5.4 Accessories
(11) Extra code 3
. Not used
163 PROFINET IO device interface (incl. Ethernet)
879 AMS2750/CQI-9c
(12) Extra code, housing
. Not used
970 Universal carrying case, compactd
aSubsequent expansion is only possible in JUMO Central Services.
bAnalog inputs with increased electric strength (AC 300 V).
cFor the calibration certificate it is necessary to state the channels along with the thermocouple type
and the desired measuring points.
dThe extra code is only available in conjunction with voltage supply AC 110 to 240 V. The UL approval
does not apply. Use only for personnel with technical qualifications who have been specially trained,
and have the relevant knowledge in the field of automation technology! Specifications for ambient tem-
perature and for protection type are to be observed (see technical data)!
(1) (2) (3) (4) (5) (6) (7) (8) (9)a
aMultiple selection at positions 9 and 11 is possible. Specify extra codes one after the other, and sep-
arate them with commas.
(10) (11)a(12)
Order code / - -/,,,
Order example 706530 / 1 8 - 1 2 3 4 - 23 / 260 , 887 , 163 , 970
1 paperless recorder in the ordered version
1 quick start guide (brief instructions)
4 mounting elements
Description Part no.
Setup program 00645110
USB cable, A connector to Micro-B connector, length 3 m 00616250
PC Evaluation Software PCA3000 00431882
PCA communication software PCC 00431879
PC software package consisting of: setup program, PC Evaluation Software PCA3000,
PCA Communication Software PCC, PC Security Manager PCS, PC Audit Trail Man-
ager PCAT. Please specify all version numbers when placing follow-up orders.
00666817
USB flash drive, 2 GBa
aThe indicated USB flash drive has been tested and is designed for industrial applications. No liability
is assumed for other brands.
00505592
Activation for math and logic module (setup program required) 00716354
Activation for structured text (ST code; setup program required) 00716357
Activation, automatic printout (PCA3000) 00505548
TP-Link TL-WR710N (Wi-Fi router) 00658592
Sealable terminal cover 00712239
Relay (N/O contact) AC 230 V / 3 A for DIN rail 00515872

13
1 Introduction
1.6 Content of the technical documentation
The documentation for this device is addressed to plant manufacturers and users with appropriate tech-
nical expertise; it consists of the following documents.
1.6.1 Device documentation in printed form
70653000T97...
Quick start guide (brief instructions)
A hard copy of the quick start guide is part of the scope of delivery of the device.
The quick start guide describes the steps to take for mounting and electrical connection, as well as the
operation of the device. It also contains the order details and a list of technical data.
The quick start guide is an excerpt from the operating manual.
1.6.2 Device documentation in the form of PDF files
The following documents are available for download from the manufacturer's website. They also form
part of the scope of delivery of the optional software package.
70653000T10...
Data sheet
The data sheet contains general information about the device, the order details, and the technical data.
It forms the basis for selecting the device and making a purchasing decision.
70653000T90...
Operating manual
The operating manual contains full details on mounting, the electrical connection, operation, parameter-
ization, and the configuration of the device. In addition, it contains the order details and a list of technical
data.
In the case of the present device, the operating manual also describes the use of the setup program (PC
program) with which the device can also be configured.
70653000T92...
Modbus interface description
The interface description provides information on communication with other devices or superordinate
systems using the Modbus protocol (Modbus-RTU, Modbus-TCP).
In the case of the present device, the interface description also contains specifications on communica-
tion via Ethernet.
70653007T92...
PROFINET interface description
This document explains the use of the PROFINET interface, which can be used to integrate the device
into a PROFINET network as an IO device. A GSD file (GSDML) is available for the programming system
of the IO controller and describes the features of the device.
70653000T96...
ST editor manual
This document describes the application of the ST editor with which users can create their own applica-
tions in the PLC programming language "structured text" (ST) for the device. The document is intended
for users with relevant programming knowledge.
The ST editor is a component of the setup program.

1 Introduction
14
70653000T97...
Quick start guide (brief instructions)
The quick start guide is also available as a PDF file and has the same scope as the printed document.
1.6.3 Documentation for optional software
The following manuals in the form of PDF files are available for download from the manufacturer's web-
site. They also form part of the scope of delivery of the respective software.
B 709701.0 or 70970100T90...
PC evaluation software PCA3000
The operating manual describes the operating principle and the features of the PC evaluation software.
The PC evaluation software helps to visualize and evaluate the captured recording data (measurement
data, batch data, messages, etc.).
B 709702.0 or 70970200T90...
PCA communication software PCC
The operating manual describes the operating principle and the features of the PCA communication soft-
ware. The PCA communication software is responsible for the data transfer from a device or system to
a PC or to a network.
B 709703.0 or 70970300T90...
PC Security Manager software PCS
The operating manual describes the operating principle and the features of the PC Security Manager
software. PCS ensures that only authorized persons can gain access to the system components (device,
PC software) and sign electronic signatures in electronic documents. Only system administrators are
able to configure the Security Manager.
PCS is only available for devices with extra code 888.
B 709704.0 or 70970400T90...
PC Audit Trail Manager software PCAT
The operating manual describes the operating principle and the features of the PC Audit Trail Manager
software. PCAT documents actions performed in the PC software components which lead to modifica-
tions of files, user lists (rights files), device lists, etc. The different message types are: “Information”,
“Warnings”, and “Errors”. Audit trail recordings cannot be modified.
Device audit trail data is not shown in PCAT, only in PCA3000.
PCAT is only available for devices with extra code 888.
1.7 Device version
The device version of the paperless recorder can be determined through the software version (SW ver-
sion) of the device. The software version is displayed in the "Device info" menu (Main menu > Device
info > Versions > Basic device: SW version).
Structure of the software version number (SW version): 323.xx.yy
323 = basic version, xx = device version, yy = current version

15
2 Description
2 Description
2.1 Brief description
The JUMO LOGOSCREEN 700 paperless recorder is characterized by an intuitive, icon-based opera-
tion and visualization concept that makes it easy to operate.
Multiple versions of the JUMO LOGOSCREEN 700 are available for process data recording. The high
level of scalability allows for flexible adaptation to various customer requirements: from the device ver-
sion without measurement input (120 process values via interface) through to different device versions
with up to 18 measurement inputs (universal analog inputs), 3 analog outputs, 18 digital inputs, 24 indi-
vidually switchable digital inputs/outputs, and 7 relay outputs. The version with FDA-compliant data re-
cording fulfills all requirements according to 21 CFR Part 11.
In order to display the recorded data, the JUMO LOGOSCREEN 700 features various visualizations. In
addition, the user can use the setup program to create up to 10 separate process screens – with up to
100 objects per process screen – according to his individual requirements. For batch-based processes,
there are up to 5 special batch recordings available, which enable the storage of additional, batch-related
information. The extra code, "structured text" allows for the creation of individual measurement and re-
cording applications.
2.2 Block diagram
Setup program
PCC, PCA3000
PCS, PCAT
Software
Internal channels
20 math channels (optional)
20 logic channels
30 counters/integrators
8 high-speed counters
ST code (optional)
(optional)
Inputs/outputs
Options 1, 2, and 3:
- 3 analog inputs, 6 digital inputs,
1
- 6 analog inputs
each
analog output
- 3 analog inp. (HI), 4 digital inputs,
4 digital inputs/outputs
(2 inputs up to 12.5 kHz)
- 12 digital inputs/outputs
(2 inputs up to 12.5 kHz)
- 6 relay outputs (changeover)
or
or
Option 4:
or
Display/operation
JUMO LOGOSCREEN 700
Voltage supply
Display
Operation
14.5 cm (5.7”) TFT color screen
640 x 480 pixel,
65536 colors
Touchscreen (resistive)
As standard:
120 external analog inputs and
120 d and
74 external texts (64 batch texts,
10 event texts)
external igital inputs
Inputs via interface
As standard:
1 relay (changeover contact)
Relay output
AC 110 to 240 V +10/-15 %,
48 to 63 Hz
AC/DC 20 to 30 V, 48 to 63 Hz
Interfaces
As standard
1x Ethernet 10/100 MBit/s
1x USB host (flash drive)
1x USB device (setup)
Barcode scanner)
Optional:
1x PROFINET IO Device
:
1x RS232/RS485
(Modbus master/slave or
Internal memory: 1 GByte
(data transfer via interface
or USB flash drive)
Measurem.-data memory

2 Description
16
2.3 Display and control elements
(1) Touchscreen (TFT color screen)
Technical data:
chapter 6.1.7 "Screen", page 81
The screen appearance is described in the "Operation" chapter:
chapter 5.1.1 "Touchscreen", page 37
(2) Alarm LED
The LED is lit while an alarm is present.
(3) Power LED
The LED flashes after switching on the device until the startup process is completed. It is then per-
manently lit.
(4) USB host interface with cover
To remove the cover, take hold of the lug and pull it out.
CAUTION!
Protection type IP65 (front-side) only with closed USB host interface.
Protection type IP65 is only guaranteed with the available default cover of the USB host interface.
Only remove the cover to use the interface; then remount the cover immediately (the cover must be
flush with the front of the device).
2.4 Connection elements
The connecting elements on the rear of the device and the front-side USB host interface are described
in the "Electrical connection" chapter.
chapter 4.3 "Connection elements", page 25
(1)
(2)
(3)
(4)

17
3 Mounting
3 Mounting
3.1 General information on mounting
WARNING!
The device is not designed for use in potentially explosive areas.
Explosion hazard.
Only deploy the device outside of potentially explosive areas.
Mounting site
The device is designed for installation in a panel cut-out. The front of the device and housing have dif-
ferent protection types (see technical data).
Climatic conditions
The ambient temperature and the relative humidity at the mounting site must correspond to the technical
data. Aggressive gases and vapors have a negative effect on the operating life of the device. The mount-
ing site must be free from dust, powder, and other suspended solids.
Installation position
Any installation position may be chosen, however the screen view angle must be taken into consider-
ation (see technical data).
Technical data
chapter 6.1 "Technical data", page 75

3 Mounting
18
3.2 Dimensions
Device
Panel cut-out
Close mounting
Device with terminal cover (accessories)
6120.9 144
144
136
138 +1
138
+1
Distance between panel cut-outs Horizontal Vertical
Minimum clearance 20 mm 20 mm
Recommended distance (easier mounting of mounting elements) 50 mm 50 mm
128.1 147.6
20.2
109

19
3 Mounting
3.3 Panel mounting
CAUTION!
The front of the device and housing have different protection types!
The protection type IP65 (front-side) is only guaranteed if the seal is flush and even.
The four supplied mounting elements must all be used and must be distributed evenly as shown in
the figure.
3.4 Handling the front of the device
Cleaning
The front of the device (front foil) can be cleaned with standard detergents, rinsing and cleaning agents.
CAUTION!
The front of the device is not resistant to aggressive acids and lyes, scouring agents, and clean-
ing with a pressure cleaner.
Use of these media can cause damage.
Only clean the front of the device with suitable agents.
Operation
The screen (resistive touchscreen) can be operated by finger pressure or with a commercially available
touchscreen stylus.
12
Step Action
1 Insert the device into the panel cut-out from the front until the seal is flush with the panel.
2 Insert the mounting elements into the recesses of the housing (one element on each cor-
ner, see figure) and use a screwdriver to evenly clamp them against the rear side of the
panel with a torque of 1.0 Nm.

3 Mounting
20
CAUTION!
Sharp or hard objects are not suitable for operating the screen.
They can cause scratches and damage the front foil.
Only operate the screen with your finger or with a suitable stylus.
3.5 Terminal cover (accessories)
NOTE!
Observe the specifications on the maximum admissible conductor cross section when using the terminal
cover (see chapter 6.1.8 "Electrical data", page 81).
Step Action
1 Screw the spacer bolt (A) into the rear wall of the device.
2 Attach the terminal cover (B) to the rear wall of the device.
3 Screw the capstan screw (D) with locking washer (C) through the lug of the terminal cover
and into the spacer bolt.
4 If necessary attach the seal (not shown here).
A
B
CD
