1 About this documentation
1 About this documentation
1.1 Purpose
This documentation is part of the device and includes all information to ensure that it is used safely and
as intended across all phases of the product lifecycle.
If you do not follow the documentation and safety information, this may result in risk to life and damage
to property due to improper use.
• Follow the documentation and the safety information and warnings.
• Store the document in its entirety, in an easily accessible location, and so that it can be read in full
at all times.
• Contact the manufacturer if you have any questions about the device and documentation.
1.2 Target group
This documentation is intended to be used by trained electrical, mechanical, and plant engineering per-
sonnel across all phases of the product lifecycle.
1.3 Definition of terms
1.4 Notes on trademark
• Android® is a registered trademark of Google LLC, 94043, Mountain View, US
• Apple® is a registered trademark of Apple Inc., Cupertino Calif., US
• Bluetooth® and the Bluetooth logo are registered trademarks of Bluetooth SIG, Inc. Kirkland WA
98033, US.
• IO-Link® and the IO-Link logo are registered trademarks of PROFIBUS Nutzerorganisation e.V.,
76131 Karlsruhe, DE.
1.5 Symbols
Use in the documentation Definition
Device, inline device, product Ultrasonic flowmeter
Medium, measurement medium, fluid Liquid
Transducer Ultrasonic converter, transducer, sensor
Product lifecycle Overall consideration of Product identification, ac-
ceptance of the goods, storage, mounting, connec-
tion, operation, troubleshooting, maintenance to
disposal
Volume flow, flow Totalized flow rate per time span
NOTE!
This symbol refers to important information about the product, its handling, or additional benefits.
NOTE!
This symbol is used in tables and indicates that further information is provided after the table.
?
REFERENCE!
This symbol refers to further information in other sections, chapters, or other manuals.

7
2 Safety
2Safety
2.1 Safe operation
This device is built based on current state-of-the-art technology and is safe to use. The device has been
tested and was shipped from the plant in perfect working order.
If you do not follow the measures to ensure safe operation, this may result in risk to life and damage to
property due to improper use.
• Only ever use the device for its intended purpose.
• Do not place the device and the process connections under mechanical strain.
• Systematically check that the process connections are leak-tight.
• Protect the device from electromechanical interference and UV radiation.
• Protect the device from the weather (when using outside).
• Only perform modifications and repairs to the device if expressly permitted by the documentation.
2.2 Intended use
The ultrasonic flowmeter measures the flow, temperature and optionally the pressure of conductive and
non-conductive liquid media.
The process values can be mapped via the process display, and issued to a higher-level system via the
outputs.
During operation, the admissible data and operating conditions specified in the legal documents and op-
erating manual must be observed.
2.3 Qualification of personnel
The personnel deployed must meet the following requirements in all phases of the product lifecycle:
• Trained electrical, mechanical, and plant engineering personnel.
• Members of personnel are familiar with this documentation and the safety information and warnings
it contains.
2.4 Hot media
Hot media may result in the device surfaces becoming hot and presenting a risk of injury.
• Allow the device and plant to cool down.
• Wear suitable protective equipment.
• Take into account alignment of the housing for electronic components.
"Alignment of the housing for electronic components", Page 21
• If required, install contact protection.
Usage Suitable Not suitable
Continuous measurement of the volume flow x
Conductive and non-conductive media x
Potentially explosive areas and safety applications x

2 Safety
8
2.5 Hazardous materials
Using hazardous materials as a medium may result in abrasive and corrosive damage to components
of the product that come into contact with the medium. The medium may leak and present a fire hazard
and a risk to health.
Carry out a risk assessment taking into consideration the safety data sheet for the relevant hazardous
substance for mounting, operation, maintenance, cleaning, and disposal:
• Comparison and systematic checking of the durability of the components of the product that come
into contact with the medium and the admissible environmental influences.
• Assessment of the risk to people and the environment.
• Assessment of the fire hazard due to the product materials, the admissible environmental influences,
and the voltage supply.
2.6 Declarations of conformity
Radio Equipment Directive (RED)
JUMO GmbH & Co. KG hereby states that the flowTRANS US W02 device complies with the Directive
2014/53/EU. The full text of the EU Declaration of Conformity is available at the following web address:
qr-406051-en.jumo.info.
Federal Communications Commission (FCC)
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions.
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Caution: Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.

9
3 Device Description
3 Devic e Descript ion
3.1 Design
3.2 Function
The transducers are on opposite sides of the measuring section and act as transmitters and receivers,
i.e. they convert the electrical energy into sound waves and the sound waves into electrical energy.
The electronic components supply power to the device, convert the raw signals into standard signals for
communicating with other systems (PLC, recorder, indicating device, etc.), and provide interfaces for dis-
playing measured values.
Function principle
Front view Rear view
(1) Measuring tube (4) Display (TFT display)
(2) Transducer (ultrasonic converter) (5) O-ring (seal for the process connection)
(3) Housing for electronic components (6) M12 plug connection (4-pole)
(3)
(5)
(6)
(2)
(1)
(2)
(4)
The ultrasonic flowmeter works
according to the runtime method.
This method measures the run-
times t1 and t2 required by the
sound to travel from transducer A
to transducer B and vice versa.
= Flow direction
Measuring section (sectional view)
The runtime differential Δt is di-
rectly proportional to the flow ve-
locity of the medium.
A
B
t0t1t2
Δt
Δt = t - t
21
BA
AB

3 Device Description
10
3.3 Nameplate
1 Manufacturer and address 9 Device ID
2 Nominal width 10 Voltage supply
3 Nominal pressure level ( Symbol for direct voltage)
4 EU conformity label 11 Medium temperature
5 UK conformity label 12 Product group number
6 FCC approval 13 Fabrication number
7 Observe device documentation! 14 Part no.
8 Measuring range 15 Fabrication number as a DMC code
36039 Fulda Germany
(2)(3) (4) (5)
(11) (13)
(7)(6)
(9) (12) (14)
(1)
(15)(10)
(8)
READ THE DOCUMENTATION!
This symbol, which is attached to the device, indicates that the associated documentation for the de-
vice must be observed. This is necessary to identify the nature of the potential hazard, and to take
measures to prevent it.

11
3 Device Description
3.4 Device ID
The device ID is shown on the nameplate ("Nameplate", Page 10) and identifies the device version.
A device description file (IODD) is assigned to each device ID.
The IODD is required for communication with the device via an IO-Link interface "IO-Link", Page 31.
Nominal width: DN 15 with low-flow calibration
Nominal width: DN 15
Nominal width: DN 20
Nominal width: DN 25
Nominal width: DN 32
Device ID Device version IODD
0x18403_ DN15LF flowmeter JUMO-184031-*.xml
0x1840B_ DN15LF flowmeter/pressure sensor 0 to 2.5 bar rel. JUMO-1840B1-*.xml
0x18413_ DN15LF flowmeter/pressure sensor -1 to +6 bar rel. JUMO-184131-*.xml
0x1841B_ DN15LF flowmeter/pressure sensor -1 to +10 bar rel. JUMO-1841B1-*.xml
0x18423_ DN15LF flowmeter/pressure sensor -1 to +16 bar rel. JUMO-184231-*.xml
Device ID Device version IODD
0x18483_ DN15 flowmeter JUMO-184831-*.xml
0x1848B_ DN15 flowmeter/pressure sensor 0 to 2.5 bar rel. JUMO-1848B1-*.xml
0x18493_ DN15 flowmeter/pressure sensor -1 to +6 bar rel. JUMO-184931-*.xml
0x1849B_ DN15 flowmeter/pressure sensor -1 to +10 bar rel. JUMO-1849B1-*.xml
0x184A3_ DN15 flowmeter/pressure sensor -1 to +16 bar rel. JUMO-184A31-*.xml
Device ID Device version IODD
0x18503_ DN20 flowmeter JUMO-185031-*.xml
0x1850B_ DN20 flowmeter/pressure sensor 0 to 2.5 bar rel. JUMO-1850B1-*.xml
0x18513_ DN20 flowmeter/pressure sensor -1 to +6 bar rel. JUMO-185131-*.xml
0x1851B_ DN20 flowmeter/pressure sensor -1 to +10 bar rel. JUMO-1851B1-*.xml
0x18523_ DN20 flowmeter/pressure sensor -1 to +16 bar rel. JUMO-185231-*.xml
Device ID Device version IODD
0x18583_ DN25 flowmeter JUMO-185831-*.xml
0x1858B_ DN25 flowmeter/pressure sensor 0 to 2.5 bar rel. JUMO-1858B1-*.xml
0x18593_ DN25 flowmeter/pressure sensor -1 to +6 bar rel. JUMO-185931-*.xml
0x1859B_ DN25 flowmeter/pressure sensor -1 to +10 bar rel. JUMO-1859B1-*.xml
0x185A3_ DN25 flowmeter/pressure sensor -1 to +16 bar rel. JUMO-185A31-*.xml
Device ID Device version IODD
0x18603_ DN32 flowmeter JUMO-186031-*.xml
0x1860B_ DN32 flowmeter/pressure sensor 0 to 2.5 bar rel. JUMO-1860B1-*.xml
0x18613_ DN32 flowmeter/pressure sensor -1 to +6 bar rel. JUMO-186131-*.xml
0x1861B_ DN32 flowmeter/pressure sensor -1 to +10 bar rel. JUMO-1861B1-*.xml
0x18623_ DN32 flowmeter/pressure sensor -1 to +16 bar rel. JUMO-186231-*.xml

12
4 Technical data
4 Technical data
4.1 Electrical data
4.2 Inputs
4.2.1 Reference conditions
4.2.2 Flow
Voltage supply DC 18 to 30 V SELV, PELV, Class 2
Current consumption ≤ 100 mA, with switching outputs ≤ 600 mA
Power consumption ≤ 10 W
Protection rating DIN EN 61140, Class III (protective low voltage )
Electrical safety The device must be equipped with an electrical circuit that meets the require-
ments of DIN EN 61010-1 with regard to "Limited-energy circuits".
Measurement medium Water
Medium temperature 23 °C (73 °F) ±5 K
Ambient temperature 23 °C (73 °F) ±5 K
Medium pressure 1 to 4 bar
Measuring tube Horizontal installation, compliance with the required inlet and outlet sections
Measuring range max
DN 15 with Low-flow calibration 60 l/min
DN 15 80 l/min
DN 20 210 l/min
DN 25 320 l/min
DN 32 520 l/min
Accuracya
Pulse output ≤ ±1.0% of the measuring range ±0.03% of the measuring range max
Current output Like pulse output, additionally ≤ ±0.1% of 16 mA
Voltage output Like pulse output, additionally ≤ ±0.1% of 10 V
Reproducibility ≤ ±0.5% of measured valuea±0.03% of the measuring rangemax
Temperature drift ≤ ±0.05% of measured valuea per 10 K temperature change (at -20 to +80 °C)
Response time t90 ≤2s
X = measuring range max (%)
Y = deviation from measured value
± (%)
aUnder reference conditions.
1
2
3
4
5
0
0 10 20 40 60 80 100
30 50 70 90 %
%
X
Y

13
4 Technical data
4.2.3 Temperature input
4.2.4 Pressure input (optional)
4.2.5 Digital input
4.3 Outputs
4.3.1 Analog output
Current output
Voltage output
Measuring range -40 to +125 °C
Accuracy ±2 K
Measuring range up to 16 bar relative
Accuracy
at 20 °Ca±0.4% MSPb
at -20 to +100 °Cc±1% MSP
aIncludes: linearity, hysteresis, repeatability, deviation of measuring range initial value, and measuring range end
value.
bMSP = measuring span.
cIncludes: linearity, hysteresis, repeatability, deviation of measuring range initial value, and measuring range end
value, thermal effect on measuring range start and measuring span.
Type Logic input (external voltage aupply)
Function Reset totalizer, start/stop batch, measured value suppression
Switching voltage VDI DC -30 V ≤ VDI ≤+60V
Protection Against polarity and voltage peaks
Internal resistance > 100 kΩ
Switching thresholds PLC level: logic level "0" < 7 V, logic level "1" > 15 V
Function Output of the flow process values, temperature or pressure (optional), output
of a signal for error message
Signal range 4 to 20 mA
Signal limits 3.8 to 20.5 mA
Error message 3.4 or 22 mA
Temperature influence 75 ppm/K
Burden ≤ 500 Ω
Burden influence ≤ ±0.02% per 100 Ω
Function Output of the flow process values, temperature or pressure (optional), output
of a signal for error message
Signal range DC 0 to 10 V
Signal limits DC 0 to 10.3 V
Error message DC 0 or 11 V
Temperature influence 75 ppm/K
Burden ≥ 2000 Ω
Burden influence ≤ ±15 mV

4 Technical data
14
4.3.2 Digital output
Switching output
Pulse output
Type Transistor output as switching output or pulse output (I/O Pin 1 only)
Protection Against polarity reversal, short circuiting and overload
Output signal Push-pull, PNP, NPN
Ampacity ≤ 200 mA
Voltage drop ≤ 3 V
Function
Output signal Limit value switch, batch active, batch error, device error
Limit value monitoring function
Input signals Flow, temperature or pressure (optional)
Configuration Hysteresis (NO contact/NC contact), window (NO contact/NC contact), switch-
on and switch-off delay
Switching points
For hysteresis function Configurable
For window function Configurable
Switch-on and switch-off delay 0 to 100 s
Function Output of the flow process value
Pulse frequency 0 to 10 kHz
Duty cycle 50%
Output value at nominal width Pulses per unit (configurable)
DN 15 (Low-flow calibration) 10000
DN 15 4800
DN 20 2850
DN 25 1875
DN 32 1150

15
4 Technical data
4.4 Interfaces
4.4.1 Bluetooth
4.4.2 IO-Link
4.5 Display
Communication Via (mobile) end device with JUMO smartCONNECT app
Authentication Via Bluetooth radio module and NFC tag
Connection status (configurable)
Permanently Active
Temporarily Restricted (via NFC)
Range 10 m under rerference conditions
Radio frequency
Bluetooth radio module 2.45 GHz
NFC tag 13.56 MHz
Max. transmission power
Bluetooth radio module 0 dBm
NFC tag -
smartCONNECT app
Function Transfer of configuration data and device information
System requirements
iOS device iPhone 7 or later (recommended) with iOS 13
Android device Android 8.0 or later
Communication Via end device with IO-Link master and device description file (IODD)
Communication interface IO-Link device V 1.1.2, downward compatible with V 1.0
Data transfer rate (baud rate) COM 3 (230.4 kBaud)
Max. cable length 20 m, unshielded
Min. cycle time 5 ms
Function Transfer of process data, configuration data and device information
Type TFT display
Size
Display area 35.04 × 28.03 mm
Screen size (diagonal) 1.77″
Resolution 128 × 160 RGB
Brightness 16 levels (configurable)
Rotation 0°, 90°, 180°, 270° (configurable)

4 Technical data
16
4.6 Environmental influences
4.7 Mechanical features
4.7.1 Materials
Admissible ambient temperature DIN 60068-2-1, DIN 60068-2-2
At a medium temperature ≤ 80 °C -20 to +60 °C
At medium temperature of
>80°C
-20to+45°C
Admissible storage temperature -20 to +60 °C
Climatic conditions DIN EN 60721-3-1, DIN EN 60721-3-3, DIN EN 60068-2-78
Climate class 3K6
Temperature range -20 to +55 °C
Relative humidity ≤ 100 % – Condensation on device outer shell
Protection type DIN EN 60529, EN 50102
IP65, IP67
Electromagnetic compatibility
(EMC)
DIN EN 61326-1, DIN EN 61326-2-3
Interference emission Class Ba
Interference immunity Industrial requirements
Vibration resistance DIN EN 60068-2-6, DIN EN 60068-2-27
Vibration resistance 5 g at 10 to 2000 Hz
Shock resistance 20 g over 11 ms
Pressure Equipment Directive 2014/68/EU
Group 1 fluids - DN ≤ 25 Sound engineering practice acc. to Art. 4, para. 3 i. c. w. Art. 4 para. 1c.i
Group 2 fluids - DN ≤ 32 Sound engineering practice acc. to Art. 4, para. 3 i. c. w. Art. 4 para. 1c.i
Group 1 fluids Sound engineering practice acc. to Art. 4, para. 3 i. c. w. Art. 4 para. 1c.ii
aThe product is suitable for industrial use as well as for households and small businesses.
Housing PA66-GF25
Display cover PMMA
Components in contact with the
medium
Measuring tube PPSU
Transducer PEEK
Seals
Process connection, transduc-
er
EPDM or FKM (optionally)
Approvals
Components in contact with the
medium
Drinking water certified materials (when using EPDM seals)

17
4 Technical data
4.7.2 Nominal pressure
4.7.3 Pressure loss diagram
Created under reference conditions "Reference conditions", Page 12.
4.8 Measurement media
Nominal pressure levels PN 16
X= Flow
max (%)
Y = Pressure loss (mbar)
0
50
100
150
200
250
0510 15 20 25 30 40 45 50
X
Y
mbar
35 %
DN 15
DN 25
DN 20
DN 15 low
DN 32
Medium type Conductive or non-conductive liquids
Viscosity ≤ 100 mPas
Foreign matter content
Solids ≤ 5 % vol
Gases ≤ 1 % vol
Medium temperature
Temperature range -20 to +95 °C
Within the accuracy specifica-
tions
-20to+80°C
Outside of the accuracy specifica-
tionsa
>80to95°C
aReturn to the accuracy specifications after cooling down.

4 Technical data
18
4.9 Dimensions
Nominal
width
ØDi [mm] P A [mm] B [mm] C [mm] L [mm]
DN 15 16.5 G 1″
120 80
43.5 160
DN 20 21.5 G 1 1/4″ 46 165
DN 25 27 G 1 1/2″ 49 175
DN 32 34 G 2″ 52.5 185
L
A
B
C
ØDi
P
flowTRANS US W02

19
5 Acceptance of goods, storage, and transport
5 Acceptance of goods, storage, and transport
5.1 Scope of delivery
5.2 Checking the delivery
• Ensure that the packaging and its contents are undamaged.
• Check the delivery for completeness against the packing slip and order details.
• Inform the supplier immediately if there is any damage.
• Store damaged parts until clarification is received from the supplier.
5.3 Storage
Improper storage may result in damage to the device.
• Store the device in a dry and dust-free environment.
• Observe the device storage temperature range.
5.4 Packaging and transport
If the device is not protected properly against external influences, it may become damaged during trans-
port.
• Transport the device in an impact-proof packaging solution that protects it against moisture and dirt.
• Also comply with the admissible storage temperatures while the device is being transported.
• Protect all electrical and mechanical connections from damage.
1× JUMO flowTRANS US W02 – Device in the ordered version, including calibration certificate
2× O-ring (seal for the process connection) in the ordered version
1× JUMO flowTRANS US W02 operating manual

20
6 Installation
6 Installation
6.1 Prepare installation
Requirements:
• Check the environmental influences to which the device will be exposed.
• De-energize the system and secure it against being switched on again.
• Stop medium circulation in the plant.
• Drain and flush the pipe.
• Wear suitable protective equipment.
• Correctly prepare the pipe for installation.
• Use only suitable tools when working on the device and plant.
Inlet and outlet sections
Installation position
To calm the flow in the pipeline,
the specified inlet and outlet sec-
tions are required at the very
least.
For increased accuracy, the inlet
and outlet sections can be made
longer.
DN = Nominal pipe width
= Flow direction
1× 90° manifold or T-piece 2× 90° manifolds
Pipe extension Pipe reduction
3× DN
5× DN
3× DN
5× DN
3× DN
5× DN
3× DN
5× DN
Mount the device in either the hor-
izontal or vertical pipe.
Requirements:
• The pipe around the transduc-
ers must be filled.
• The flow direction should be
upwards for vertical mounting.
• Avoid the formation of air bub-
bles in the pipe and right at
the device.
= Flow direction
Correct Incorrect
