  9. kd frames 7515-TB-C User manual

kd frames 7515-TB-C User manual

Manufactured by
Coffee Table
30” TOP RAILS
T-2 2
T-13 4
16” LEGS
PARTS LIST
Knockdown Frameworks, Inc. warrants all of its products for five years against any defects that are due to faulty materials or workmanship. We will promptly correct such
defects by repair or replacement, at our option, without charge. This warranty covers product defects only and will expire five years after date of purchase by the original
consumer purchaser, with proof of purchase required.
This warranty does not apply to damage caused by and resulting from misuse, neglect, accident, or improper operation, maintenance, storage, transportation, or handling
of the product. This warranty is for the original consumer purchaser for residential use only and does not apply if the product is used in any commercial application (such as
rental property). This warranty does not cover any incidental or consequential damages. If you feel that you have a claim under this warranty, please contact the store from
which it was purchased. If this is not possible, call 800-543-3393 for advice on handling your claim.
T-5 4
14” LEG CONNECTORS
T-6 5
15” TOP SLATS
T-7 2
15” CONNECTOR SLATS
12
T-5
T-9
Push (2) T-5 Leg Connectors
into the holes on (2) T-9
Legs.
Repeat for the other side.
Secure the Leg Connectors
to the Legs using
(4) Wood Screws (H-20).
H-20
2 - 1/2” BOLTS
H-21 4
H-3 4
CROSS DOWELS
8
1
H-4 2” WOOD SCREWS
H-10 “Z” WRENCH
8
H-20 1 - 1/2” WOOD SCREWS
T-15 2
30” SHELF RAILS
T-12 4
13” SHELF SLATS
T-2 TOP RAILS (2)
T-13 LEGS (4)
T-5 LEG CONNECTORS (4)
T-6 TOP SLATS (11)
T-7 CONNECTOR SLATS (2)
T-15 SHELF RAILS (2)
T-12 SHELF SLATS (7)
394 Dairy Pak Rd. • Athens, GA 30607
kdframes.com • [email protected]
Instructions for
sku# 7515-TB-C
3
Please retighten
screws after
30 days.
Attach the Legs to the
Table Top and Shelf using
(8) Wood Screws H-4.
H-4
Assemble the Shelf by
pushing (4) Shelf Slats
T-12 into the holes on the
(2) Shelf Rails T-15.
6
Flip Table Top over
so that the holes in
the face of the
Connector Slats are
facing down.
To begin assembling the Table Top, find the Top Rails T-2,
the Connector Slats T-7, and the Top Slats T-6.
The Top Rails have holes along one face, note that they are
closer to one edge. Turn one Top Rail so that the holes are
closer to the bottom edge.
The Connector Slats have two holes in one face, turn them
so that these holes are facing up. Rotate each Connector
Slat so that the board with no holes or dowels is on the
outside, as shown in the diagram to the right.
First attach both Connector Slats to one of the Top Rails and
secure each using 2-1/2” Bolts H-21 and Cross Dowels H-3.
Then insert all five Top Slats.
To attach the other Top Rail, begin by
aligning the hole and dowel at the very
end while keeping the other end of the
Top Rail angled slightly away. Hold the
Top Rail so that this first dowel remains
just inside the first hole, and then align
each subsequent pair of dowls in order.
H-3
H-21
4
5
NOTE: THESE DIAGRAMS DO NOT SHOW THE
SAME NUMBER OF SLATS THAT ARE A PART OF
YOUR PRODUCT.
