KEBCO COMBIVERT F5 User manual

COMBIVERT
GB INSTRUCTION MANUAL Encoder Interface
Channel 1 HTL without inverted signals
Channel 2 variable
Mat.No. Rev.
DLF5ZEM-K070 1A

Table of Contents
GB - 3
1. Safety Instructions ........................................................................................ 4
1.1 Validity................................................................................................................4
1.2 Quali󰘰cation........................................................................................................4
2. Product Description....................................................................................... 5
2.1 General...............................................................................................................5
2.2 Material number .................................................................................................5
2.3 Scope of delivery (option or replacement delivery) ............................................5
2.4 Mechanical installation .......................................................................................6
3. Description of the Interface........................................................................... 6
3.1 Voltage supply....................................................................................................6
3.2 Channel 1 ...........................................................................................................7
3.2.1 Speci󰘰cations .....................................................................................................7
3.2.2 Description of X3A..............................................................................................7
3.2.3 Assignment of X3A.............................................................................................8
3.2.4 Input signals .......................................................................................................8
3.2.4.1 Signal tracks A and B .........................................................................................8
3.2.4.2 Evaluation of the Zero Signal .............................................................................9
3.2.5 Encoder breakage recognition ...........................................................................9
3.2.6 Connection of the encoder ...............................................................................10
3.2.6.1 Encoder cable at terminal strip X3A .................................................................10
3.2.7 Encoder cable ..................................................................................................10
3.2.8 Encoder line length...........................................................................................10
3.2.9 Tested encoders...............................................................................................11
3.3 Channel 2 .........................................................................................................11
4. Start-up ....................................................................................................... 11
5. Error Messages........................................................................................... 11

GB - 4
Safety Instructions
1. Safety Instructions
Prior to performing any work on the unit the user must familiarize himself with the unit. This includes especially
the knowledge and observance of the safety and warning directions. The pictographs used in this instruction
manual have following meaning:
Danger Refers to danger of life by electric current.
Warning Refers to possible danger of injury or life.
Note Refers to tips and additional information.
1.1 Validity
The information contained in the technical documentation, as well as any user-specic advice in spoken and
written and through tests, are made to best of our knowledge and information about the application. However,
they are considered for information only without responsibility. This also applies to any violation of industrial
property rights of a third-party.
Inspection of our units in view of their suitability for the intended use must be done generally by the user.
Inspections are particularly necessary, if changes are executed, which serve for the further development or
adaption of our products to the applications (hardware, software or download lists). Inspections must be re-
peated completely, even if only parts of hardware, software or download lists are modied.
Controlling by
the user
Application and use of our units in the target products is outside of our control and
therefore lies exclusively in the area of responsibility of the user.
Use under spe-
cial conditions
The used semiconductors and components of KEB are developed and dimensi-
oned for the use in industrial products. If the KEB COMBIVERT is used in ma-
chines, which work under exceptional conditions or if essential functions, life-sup-
porting measures or an extraordinary safety step must be fullled, the necessary
reliability and security must be ensured by the machine builder.
1.2 Qualication
All operations serving transport, installation and commissioning as well as maintenance are to be carried
out by skilled technical personnel (observe IEC 364 or CENELEC HD 384 or DIN VDE 0100 and national
accident prevention rules!). According to this manual qualied staff means those who are able to recognise
and judge the possible dangers based on their technical training and experience and those with knowledge
of the relevant standards and who are familiar with the eld of power transmission (VDE 0100, VDE 0160
(EN 50178), VDE 0113 (EN 60204) as well as the appropriate regulations for your area.
Danger by high
voltage
KEB electronics components contain dangerous voltages which can cause death
or serious injury. In operation, drive converters, depending on their degree of
protection, may have live, uninsulated, and possibly also moving and hot surfaces.
In case of inadmissible removal of the required covers, of improper use, wrong
installation or maloperation, there is the danger of serious personal injury and
damage to property.

Safety Instructions
GB - 5
2. Product Description
Figure 1: Incremental encoder HTL without inverted signals on channel 1
For housing size D and E
X3A
Channel 1
X3B
Channel 2
X3B X3A
Channel 2 Channel 1
see material number without inverse signals
2.1 General
Each of the interface cards delivered by KEB include two interfaces. As there are numerous
different combinations available each interface will be described by means of separate
instructions. The instruction covers the installation of the interface card, the connection as
well as the start-up of a suitable encoder. Further information and the parameter adjust-
ments are described in the application manual for the inverter/servo.
2.2 Material number
xM F5 K81 X X X X
Term of deli-
very 0 installed Z Option, spare part
Interface S TTL-output 4029 T TTL-input 4028
F5 Series
applicable for housing size 1M D, E (circuit board 1M.F5.280-xxxx see above)
2.3 Scope of delivery (option or replacement delivery)
•Encoder interface
•two instruction manuals
• xing bolt
•packing material

GB - 6
Safety Instructions
2.4 Mechanical installation
All kind of works on the inverter may be carried out by authorized personnel in accordance
with the EMC and safety rules only.
•Switch inverter de-energized and await capacitor discharge time
•Pull off operator
• Remove plastic cover
• Remove xing bolt
•Fix interface board beginning from the socket connector straightly
• Screw in xing bolt
•Attach plastic cover
3. Description of the Interface
3.1 Voltage supply
Figure 1: Setting the encoder voltage by the DIL switch S1
15Vdc24Vdc

Safety Instructions
GB - 7
Figure 3.1 Voltage supply of encoder interfaces
Uint 24 VDC Internal voltage supply of the COM-
BIVERT (Imax 120 mA). X2A
X3A
X3B
5V
24V
5V
Uint
15V
Uext
15/24V
S1
Iint
Current Iint reduces itself by draw current at
the 5 V-output, as well as at the 15V-output in
accordance with the following formula:
5 V x I5V
I24V = Iint - –––––––––
Uint
5 V x I5V
I24V = Iint - –––––––––
Uint
Uext
Control terminal strip (X2A) of the COM-
BIVERT with external voltage supply 24…30
Vdc. / max. 1 A
15/24 V Voltage output of encoder interfaces X3A for
encoder supply.
5 V
Voltage output for encoder supply (Imax
300 mA). 5V are obtained from the 24V vol-
tage.
24 V Voltage supply of encoder interfaces X3B for
encoder supply.
3.2 Channel 1
3.2.1 Specications
Interface type Incremental Encoder Input
Input signals HTL 15…30 V without inverse signals
Inputs / tracks A+, B+, N+
Output Voltage output 15/24 V for encoder supply
Particularities Encoder breakage recognition for all signals
Limiting frequency 100 kHz
Increments per revolution 1…16383 inc (recommendation 2500 inc for speed upto
2400 rpm
Input resistance 3.9kΩat24Vinputvoltage
Max. line length
50 m, the value is additionally limited by the signal fre-
quency, cable capacity and supply voltage (see chap-
ter „encoder line length").
3.2.2 Description of X3A
Version plug in terminal block
Terminals 8
Tightening torque 0.22…0.25
permissible cable cross-section 0.14…1.5mm²
Stripping length 7 mm

GB - 8
Safety Instructions
Terminal assign-
ment changed
The pin assignment has changed in relation to the previ-
ous version.
3.2.3 Assignment of X3A
Figure 3.2.3 Description of terminal strip X3A


PIN Name Description
1 A+ Encoder track A HTL signal+
2 – n.c.
3 B+ Encoder track B HTL signal+
4 – n.c.
5 N+ Zero track HTL signal+
6 – n.c.
7 15/24V switchable voltage supply for encoder
8 COM Reference potential for signals and voltage supply
3.2.4 Input signals
3.2.4.1 Signal tracks A and B
In case of HTL-encoder interface the signals A+ and B+ are rectangular signals with a
phase-angle displacement by 90 degrees. The inverted signals will be generated internally
and does not need to be provided by the encoder.
Signal tracks A+ and B+





 
 



Safety Instructions
GB - 9
3.2.4.2 Evaluation of the Zero Signal
The zero impulse is required to determine valid position points. In case of pure speed con-
trols the signal does not need to be connected. In the following signal sequence the maxi-
mum permissible length of the zero impulse of the encoder is visible. The zero signal will
be acquired if A+ ,B+ and N+ are at high level. By that there is only one valid position point
which is independent from the travel direction.
Evaluation of the Zero Signal





3.2.5 Encoder breakage recognition
For a monitoring of the encoder and the encoder cable the signal tracks and the zero track
are monitored. Input N+ must be connected with input 15/24 V if the connected encoder
shouldnothaveazerotrack.Themonitoringforchannel1willbeswitchedon/o󰘯withpa-
rameter Ec.42 (in the past Ec.20). The recognition of encoder breakage triggers an „error"!
encoder 1“ (value 32), if the voltage at the signal input is smaller than 6 V.
Parameter r/w Enter prog.
Ec.42 Encoder alarm mode yes no no
Dependent on Ec.42 „Error! Encoder 1“ (value 32) or a warning is triggered, if the permis-
sible signal levels are fallen below.
Setting range Setting Meaning
0
1
Encoder monitoring off
1 Encoder monitoring on
2 Encoder monitoring on (open-loop off)
3 Warning

GB - 10
Safety Instructions
3.2.6 Connection of the encoder
3.2.6.1 Encoder cable at terminal strip X3A
• Encoder cable double-shielded and twisted in pairs
• Connect exterior shielding at both ends to PE/GND
• Connect interior shieldings at one side to COM
• Do not connect exterior and interior shielding
•N+isonlyrequiredforposifunction
Figure 3.3.3 Connection of the encoder
Motor encoder plug Socket X3A














Name PIN PIN Name Core color
A+ 5 1 A+ green
COM 10 8 COM yellow
B+ 8 3 B+ blue
COM 10 8 COM red
N+ 3 5 N+ gray
COM 10 8 COM pink
Uin 12 7 15/24 V brown
COM 10 8 COM white
Housing - – PE inverter shielding
3.2.7 Encoder cable
KEB encoder cables are corresponding to the following specication:
Signal lines 3 x (2 x 0,14mm²)
Supply lines 2 x 0,5 mm²
Particularities trailing capable, oil-resistant
Temperature range constant up to 80 °C
Color green RAL 6018
3.2.8 Encoder line length
The maximum line length of the encoder cable is 50 m. It results from the voltage drop of the
supply line. The value is calculated as follows:
Encoder cable length = U - Umin
––––––––––
Imax • 2 • R
max. encoder current Imax: see encoder description
Supply voltage U: 15 V 24 V
minimum input voltage Umin: see encoder description
KEB encoder cable resistance R: 0,036 Ω/m at 0,5 mm²

Safety Instructions
GB - 11
3.2.9 Tested encoders
The following encoder can be used dependent on the interface and the control:
Manufacturer Type Encoder type
Heidenhain • ROD 436 HTL-Incremental Encoder
However, this does not restrict the use of rotary encoder with same specications of other
manufacturers.
3.3 Channel 2
The description of input X3B is depending on the used encoder interface. It is described in
a separate manual.
4. Start-up
After the installation or exchange of an encoder interface some adjustments of the inverter/
servo software have to be done before operation:
•Switch on inverter
•Select application mode
•Select parameter Ec.00 and control whether value „27: Inc. encoder input HTL termi-
nal block with alarm“ is entered. The displayed value has to be conrmed by „ENTER“
in any case.
•Select Ec.01 and adjust increments per revolution.
•Select Ec.42 (Ec.20 upto V2.8) and adjust the encoder breakage recognition depen-
dent on the case of operation.
5. Error Messages
Error messages and their meaning are described in the application manual.
Error „E.hYb“ can be reset by a Power-On-Reset. Error „E.EncC“ can by writing
on parameter ec.00 and additional also be reset by a Hardware-Reset or Bus-
Reset (control word) since software version 4.1.

KEB Antriebstechnik Austria GmbH
Ritzstraße 8 • A-4614 Marchtrenk
fon: [phone] • fax: [phone]
net: www.keb.at • mail: [email protected]
KEB Antriebstechnik
Herenveld 2 • B-9500 Geraadsbergen
fon: [phone] • fax: [phone]
mail: [email protected]
KEB Power Transmission Technology (Shanghai) Co.,Ltd.
No. 435 QianPu Road, Songjiang East Industrial Zone,
CHN-201611 Shanghai, P.R. China
fon: [phone] • fax: [phone]
net: www.keb.cn • mail: [email protected]
KEB Antriebstechnik Austria GmbH
Organizační složka
K. Weise 1675/5 • CZ-370 04 České Budějovice
fon: [phone] • fax: [phone]
net: www.keb.cz • mail: [email protected]
KEB Antriebstechnik GmbH
Wildbacher Str. 5 • D–08289 Schneeberg
fon: [phone] • fax: [phone]
mail: [email protected]
KEB España
C/ Mitjer, Nave 8 - Pol. Ind. LA MASIA
E-08798 Sant Cugat Sesgarrigues (Barcelona)
fon: [phone] • fax: [phone]
mail: [email protected]
Société Française KEB
Z.I. de la Croix St. Nicolas • 14, rue Gustave Eiffel
F-94510 LA QUEUE EN BRIE
fon: [phone] • fax: [phone]
net: www.keb.fr • mail: [email protected]
KEB (UK) Ltd.
6 Chieftain Buisiness Park, Morris Close
Park Farm, Wellingborough GB-Northants, NN8 6 XF
fon: [phone] • fax: [phone]
net: www.keb-uk.co.uk • mail: [email protected]
KEB Italia S.r.l.
Via Newton, 2 • I-20019 Settimo Milanese (Milano)
fon: [phone] • fax: [phone]
net: www.keb.it • mail: [email protected]
KEB Japan Ltd.
15–16, 2–Chome, Takanawa Minato-ku
J–Tokyo 108-0074
fon: [phone] • fax: [phone]
mail: [email protected]
KEB Korea Seoul
Room 1709, 415 Missy 2000
725 Su Seo Dong, Gang Nam Gu
ROK-135-757 Seoul/South Korea
fon: [phone] • fax: [phone]
mail: [email protected]
KEB RUS Ltd.
Lesnaya Str. House 30, Dzerzhinsky (MO)
RUS-140091 Moscow region
fon: [phone] • fax: [phone]
net: www.keb.ru • mail: [email protected]
KEB Sverige
Box 265 (Bergavägen 19)
S-43093 Hälsö
fon: [phone] • fax: [phone]
mail: [email protected]
KEB America, Inc.
5100 Valley Industrial Blvd. South
USA-Shakopee, MN 55379
fon: [phone] • fax: [phone]
net: www.kebamerica.com • mail: [email protected]
© KEB
Mat.No. DLF5ZEM-K070
Rev. 1A
Date 10/2011
More and newest addresses at http://www.keb.de
Karl E. Brinkmann GmbH
Försterweg 36-38 • D-32683 Barntrup
fon: [phone] • fax: [phone]
net: www.keb.de • mail: [email protected]
KEB worldwide…
