Kingfisher KI021-1 User manual

KI021-1 OPTICAL TALK SET
USER MANUAL

KI021-1 Talk Set is used for duplex voice
communication over a single optical fiber, during
installation, testing, measurements, or maintenance
work with fiber optic lines and networks, when
technicians have to communicate to each other by
voice over optical fiber.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 1 of 14

Record of Issues
If you have any suggestions for improvement to this document,
please contact the author at Kingfisher International.
Issue No. Issue Date Comments Issue Author
00
01 May 2017 Alex Skrebniow
02 December 2017 Alex Skrebniow
Disclaimer
The contents of this publication are subject to change without
notice. All efforts have been made to ensure the accuracy of this
publication. Notwithstanding, Kingfisher International Limited
does not assume responsibility for any errors nor for any
consequences arising from any errors in this publication.
Information in this manual is given in good faith for the benefit
of the user. It cannot be used as the basis for claims against
Kingfisher International or its representatives, if accidental
damage or inconvenience results from use or attempted repair
of the equipment.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 2 of 14

Introduction
KI021-1 Talk Set features
•Full duplex voice communication via a single fiber;
•Sound and screen indication for income call;
•Low battery level indication;
•Excellent dynamic range;
•Small size;
•High reliability;
•Headsets with microphones provided;
•Fixed or changeable optical adaptors.
About this manual
This manual describes the KI021-1 Talk Set (hereinafter referred
as Talk Set) design and operations with it, and assumes that the
user is adequately qualified in fiber optics maintenance. The
images in this manual can insignificantly differ from your Talk
Set.
Copyright 2017 © Kingfisher International Pty. Ltd. All rights
reserved.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 3 of 14

1. SAFETY

While working with fiber optics equipment and
live optical fiber, avoid laser exposure to the
eye. Although the laser signal power is
comparatively low, it can still cause eye
damage. Besides, you cannot actually see the
laser light, because it is infrared, which means
you cannot tell if there is light present by
looking at it.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 4 of 14

2. KI021-1 TALK SET
PACKAGE
Name Quantity Comments
Optical Talk Set KI021-1 1
Headset with microphone 1
Changeable optical adaptors:
FC, SC, ST, LC
To be specified in
the order form
Interface cable USB-А -
miniUSB-В
1
User manual 1
Soft carry case, carry strap 1
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 5 of 14

3. GETTING STARTED
3.1. Before calling
To switch the device on, press and hold the [ ON/OFF ]button
( ) at the bottom-left corner for longer than 3 sec. After
switching on the Talk Set screen first shows the current date and
time, and then shows the initial menu with the [ F1, F2, F3 ]
button functions at the bottom of the screen.
Before calling, connect the fiber to the Talk Set via the optical
adaptor at the top of the device. Before connecting, make sure
that the fiber connector is compatible with the adaptor. If not,
change the adaptor or connect a patch cord with a suitable
connector. We also strongly advise to clean the fiber before
connecting with the help of a special optical fiber connector
cleaner.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 6 of 14

Then plug in the headset with a microphone via the connector at
the bottom of the Talk Set.
3.2. Charging your Talk Set
As a rule, the Talk Set comes to the customer with the battery
charged (see the Battery level indicator at the top left corner of
the screen). If the device will not switch on or the battery level is
low ( ), charge the battery using the power unit supplied.
The battery is charged via the mini-USB port at the bottom of the
device. While the battery is charging, the LED indicator is on,
and the charging sign ( ) appears at the top-left corner of the
screen. The indicator goes off when the battery is fully charged.
Usual time for charging the battery is about 4-6 hours if the Talk
Set is off.
3.3. Setting up your Talk Set
To make your operation with the Talk Set more convenient, you
can set the following parameters:
Table 1. KI021-1 Talk Set settings
Param
eter
Value Description
A.OFF OFF, 15 min, 30
min, 45 min
Time the Talk Set switches off after
the last button press
SOUND Key ON, Key OFF Sound for buttons pressed ON or
OFF
TIME HH:MM Current time
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 7 of 14

DATE DD.MM.YY Current date
To enter the Settings mode, press the [ SETTINGS ]button. As a
result, the Settings screen shown below appears, with the active
parameter blinking:
To change the active parameter value, press the [ < ]and [ > ]
buttons. To jump to the next parameter, press the [ MODE ]
button.
3.4. Screen illunination
To operate in dark, press to illuminate the screen.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 8 of 14

4. CALLING
To start a call, press [ F1 ](CALL). As a result, the Outcoming
Call message shows onscreen, the [ F1 ]button changes its name
to (CANCEL), and the name of the [ F2 ]button disappears. You
can also hear the calling signal in the headset.
If optical signal level is enough for communication, the
receiving device screen shows the Incoming Call message and
emits the intermittent buzz sound. You can also hear the
incoming call signal in the headset.
To receive an incoming call, press [ F1 ](CALL) or [ F2 ]
(ANSWER). As a result, on both screens the Talk message
appears, the [ F1 ]button changes its name to (CANCEL), and the
name of the [ F2 ]button disappears. Now you can talk over the
device.
To terminate a call, press [ F1 ](CANCEL) on any device.
If the two Talk Sets get connected in the VOICE mode, the Talk
message appears on both screens as a result. However, if the
signal becomes too weak, the No Sync message appears
onscreen. If the signal continues to fade, the Outcoming Call or
Incoming Call message appears onscreen. When the signal
restores to a sufficient level, communication re-establishes
automatically.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 9 of 14

5. MAINTENANCE AND
STORAGE
We strongly advise charging your Talk Set battery only with the
power unit provided. Power units from other devices are not
recommended.
Store your Talk Set in the original package at ambient
temperature of -25o- +55oC, with relative humidity of 95% or
lower at 25o. After the package is removed, store the Talk Set at
ambient temperature of -10o- +35oC, with relative humidity of
80% or lower at 25oC.
If your Talk Set was subjected to temperature below 0oC for long
time, keep it at normal conditions for 2 hours or more before
switching on.

If you plan to store your Talk Set for long time,
charge the battery at about 50-70% first.
DOÊNOT store your device with the battery
completely discharged, because it may reduce
the battery life.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 10 of 14

6. WARRANTY
Kingfisher International KI021 Optical Talk Set is guaranteed
against defective components and workmanship for a period of
2 years from the date of delivery, unless specifically stated in the
original purchase contract or agreement. This warranty
excludes optical connectors or incorrect use. Opening the
instrument will invalidate the warranty. Liability is limited
solely to repair of the equipment.
KINGFISHER INTERNATIONAL PTY LTD
720 Springvale Road, Mulgrave, Victoria 3170 Australia
Phone: [phone] Fax: [phone]
E-mail: [email protected]
Website: http://www.kingfisherfiber.com
Technical data is subject to change without notice as part of our
program of continuous improvements. Therefore please verify
critical parameters before ordering.
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 11 of 14

Appx A: Declaration of
Conformity
Kingfisher International
KI021-1 OPTICAL TALK SET Issue 02 Page 12 of 14

Appx B: Talk Set
Specifications
Table 2. KI021-1 Talk Set Specifications
Communication Duplex
Dynamic range >40 dB
Fiber type Single-mode
Wavelength 1550 nm
Optical fiber
connector
FC, ST, SC or LC (customizable)
Battery life 30 hours in the reception/transmission
mode
Charger input, AC 110-240 V
Charger output, DC 5 V, 1 A
Charging current 0.4 A
Charging time 4-6 hours if the Talk Set is off
Dimensions 188 х 86 x 35 mm
Weight 0.4 kg
