Knoll Pop Up User manual

Installation Instructions
June 2020
Pop Up™Easy Screen, Cardboard
Part No. 3AJ9004
1. Prepare
Clean worksurface with 50:50 IPA and water
mixture and allow to completely dry to ensure
best adhesion of the Velcro attachments on
the bottom of the screens.
2. Unpack
Remove set of 3-piece surround from shipping
box and separate the screen corners from the
back panel. The back panel can be found
inserted into one of the screen corner
assemblies.
3. Chose a configuration
The corner pieces are 23" x 29" and can be
configured in two ways on the worksurface: (A)
23”W x 29”L (A) or 29"W x 23"L (B). (Fig. 1)
Note: The screen corners are continuous on
one side and have a relief cut on the other
side. Corner screens are formed by folding the
corner panel in on itself to form a 90-deg angle
where the cutout section is inside, and the flat
edges are outside.
The back panel screen is red on one side and
brown on the other side. The user should
decide which color displays outward before
assembly. This is difficult to change after
assembly.
4. Assemble the first corner
+ Fold the corner screen to form a 90-degree
angle. (Fig. 2)
+ Peel off the backer on the Velcro tabs along
the 3” base of the corner screen. (Fig. 2)
+ Align the corner screen flush with the outer
edges of the worksurface. Press down firmly
to adhere the screen to work surface. (Fig. 3)
Hint: It is best to do this one side (two Velcro
tabs) at a time to ensure perfect alignment
with the worksurface.
Continued…
A
23" W x 29" L
B
29"W x 23"L
Worksurface
Fig. 1
Fig. 2
Fold to 90º
Peel off Velcro backers
Fig. 3
Worksurface

Installation Instructions
5. Assemble the back panel
Take back panel and fold to expose the color
of choice. Fold the back panel tight together
and slide it into the assembled corner, about
half way. (Fig. 4)
6. Assemble the second corner
+ Fold the remaining corner screen and with
two hands, fit the back panel into the
remaining corner screen just as was done in
steps 4 & 5. (Fig. 5)
+ Adjust the overlap between the two corners
and the back panel until the screen
surround assembly fits perfectly to the size
of the worksurface, being flush with the
outer edges.
+ Peel off the backer on the Velcro tabs along
the 3” base of the corner screen. (Fig 6.)
While maintaining alignment, press down
firmly to adhere the corner screen to
worksurface. Hint: It is best to do this one
side (Two Velcro tabs) at a time to ensure
perfect alignment with the worksurface.
Pop Up Easy Screen, Cardboard, continued
Fig. 4
Fig. 5
Fig. 6
Fold the back panel Slide into the
assembled corner,
about half way
Peel off Velcro backers
Fit the back panel into the
remaining corner screen
Page 2 of 2 Part No. 3AJ9004
