Knoll SL-Base User manual

Islands Collection by Knoll
®Installation Instruction
Islands Collection by Knoll
®
March 19, 2020
Part Number: 6TD00037
Sheet 1
6td00037_1.ai
6td00037_hardware.ai
A
E F G
B C D
H J K
M N
L
HARDWARE LIST
6TD4010201
SCR,T-F,FL,1/4-20X5/8
6TD4001101
TOP MOUNT
6TD40076XX
LEG
6TD40078XX
WIRE MANAGER LEG
6TD40035
GLIDE PAD
6TD40088
GLIDE
6TD40117N
CASTER
6TD40117B
CASTER W/ BRAKE
1B53307XX
WORKSURFACE STIFFNER
6TD40123XX
WIRE MANAGER COVER
5122218
SCR,TRP#14x7/8
5134102
SCR,FLP#14x1-1/4
4A2200396_EG
SCR,T-F,FL,1/4-20X1-3/4
SL-Base (Straight Leg) Table Assembly
Reference Number: 6TD00037
E
H
J or K or L
Threaded end
F or G
D
C
Tools Needed
Drill gun
1. Assembly of SL table leg
(see Fig. 1)
1.1 Align the glide pad, item (H), to the
threaded end of leg, item (F) or (G), and
secure into place using 2 (D) screws.
1.2 Assemble the glide or caster, item (J), (K),
or (L), into the threaded hole of the leg
assembly.
1.3 Reorient the leg assembly so that the
glide pad is facing downwards and the
open end is facing up.
1.4 Align the top mount, item (E), to the open
end of the leg assembly and secure into
place using 4 (C) screws.
Note: Please see Fig. 1A for fastening
sequence. Ensure all screws are fully
seated.
1.5 Repeat the above steps for the remaining
legs, item (F), and SL wire manager
column legs , item (G).
Fig. 1
Fig. 1A
Fastening sequence
1
3
4
2
THREADED
END

Islands Collection by Knoll
®Installation Instruction
Islands Collection by Knoll
®
March 19, 2020
Part Number: 6TD00037
Sheet 2
SL-Base (Straight Leg) Table Assembly
Reference Number: 6TD00037
2. Installation of assembled legs
with worksurface
(see Fig. 2)
2.1 Lay worksurface upside down on a soft
non scratching surface, rectilinear
worksurface shown for example.
2.2 Center and align each leg over the
provided pilot holes and attach using 10
(A) screws for each leg.
Note: Be sure to not over tighten screws into
worksurface. Overtightening the screw
can cause the hole to strip.
Optional (when stiffener is provided)
2.3 Orient stiffener (M) as per Fig. 2A.
Note: Open end of stiffener (M) goes
toward middle of worksurface.
2.4 Center the stiffener over the provided
pilot holes, attach stiffener (M) to the
worksurface using (B) screws.
Screw (B) quantity will vary
depending on stiffener (M) size, use
all provided pilot holes.
Worksurfaces 48"-78" wide require
1 stiffener (M).
Worksurfaces over 78" wide require
2 stiffener (M).
3. Installation of wire manager
cover
(see Fig. 3)
3.1 Orient and align wire manager cover (N)
with wire manager leg (G) as per Fig. 3.
Cut-out positioned at the end with the
caster/glide.
3.2 Press cover (N) onto leg (G) to engage
snap-on feature.
6td00037_2.ai
Worksurfaces up to 78"W
requires only one stiffener
Example using clamp-on electrical unit
Fig. 3
Fig. 2A
Fig. 2
Complete product
AM
B
N
G
