Kohler 12879T User manual

所有的资料是按最新出版的产品资料编写而成。科勒
公司保留任何时候不经通知即可改变产品特性、包装
或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，请
把这些资料交给用户阅读。
BEFORE YOU BEGIN
All information is based on the latest product
information available at the time of publication. Kohler
Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time
without notice.
Please leave these instructions for the consumer. They
contain important information.
12879T 800mm滑动花洒支架
安装之前
INSTALLATION INSTRUCTIONS
安装说明书
800mm Slide Bar
安装尺寸 ROUGH-IN DIMENSIONS
1060261-2-B 1
822
700~750
108
50
200

1060261-2-B 2
Decide on a suitable position for the
slide bar avoiding buried cables and
pipes in the wall.
Drill two holes at the proper height in
the wall according to the recommended
dimension and plugs’ diameter.
Hammer plugs(1) into the holes. Secure
the bracket(3) on the wall with the
shorter screw(2).
Slide soap holder bracket(4) and
handspray bracket(5) onto the bar(6) as
illustrated. Slide the bar into the
bracket(3).
Place bracket(7) into bar, adjust it,
secure it on the wall with the longer
screw(8). Press on covers(9). Put the
soap holder(10) onto the soap holder
bracket.
在墙面上选择一个合适的位置，用于
安装滑动花洒支架。避开墙面内的电
线和管道。
根据标注的尺寸及胀塞直径，在墙面
适当高度打两个孔，将胀塞(1)分别装
入孔中。用短螺钉(2)将支架(3)固定于
墙上。
如图，将皂盘托架(4)，花洒挂架(5)装
到支杆(6)上。将支杆穿入支架(3)。
将支架(7)插入支杆，调整位置，用长
螺钉(8)将其固定于墙上。塞紧支架盖
(9)。将皂盘(10)安装到皂盘托架上。
保护罩需留在阀体上。
安装步骤 INSTALLATION
清洗说明 CLEANING INSTRUCTIONS
适用于所有加工处理过的表面：以中性肥皂水清洗
镀层表面，再以干净的软布彻底擦干整个表面，许
多清洁剂，比如氨水、去污粉及洁厕灵等，会对电
镀表面造成伤害，切忌使用。
有磨损性的清洁用具或清洁剂也不可使用于科勒牌
的水龙头及其配件上。
All Finishes: Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such
as ammonia, chlorine, toilet cleaner etc, which could
adversely affect the finish and are not recommended
for cleaning.
Do not use abrasive cleaners or solvents on Kohler
faucets and fittings.
UP
朝上
1800mm Slide Bar
**订购时请说明颜色编号
**Color code must be specified when ordering
SERVICE PARTS
零 件 图
12879T 800mm滑动花洒支架
1060261-2-B 3
1060259**
800mm Slide Bar
800毫米滑动花洒支架
1109471**
Handspray Bracket
花洒托架
1290879**
Escutcheon
装饰盖
1290879**
Escutcheon
装饰盖
1
3
2
3
6
5
4
9
10
9
8
7
1062738**
Soap Holder Bracket
皂盘托架
1062737**
Soap Holder
皂盘
