Kohler K-18571T User manual

REACH
INSTALLATION INSTRUCTIONS
VANITY TOP
K-18571T, K-18572T
-1-
, 2009
Copyright Kohler China Ltd., 2009
·
·
·
Observe all local plumbing and building codes.
Prior to installation, unpack the new lavatory and inspect it
for damage. Return the lavatory to its protective carton
until you are ready to install it.
All information in these instructions are based the latest
product information available at the time of publication.
Kohler China reserves the right to make changes in
product characteristics, packaging, or availability at any
time without notice.
Make sure that the wall and floor are square
and plumb to ensure proper installation.
IMPORTANT:
·
·
·
ORDERING INFORMATION
REACH Vanity Top 105 .....................................K-18571T
REACH Vanity Top 70 .......................................K-18572T
105............................................K-18571T
70 ..............................................K-18572T
REQUIRED MATERIALS/
(NOT SUPPLIED)
TOOLS
·
·
·
·
·
·
·
Level
Drill with bit6mm
14mm wrench
Framing square
Channel lock pliers
Tape measure
Pencil
·
·
·
·
·
·
·
6mm
14mm
528137
ROUGHING-IN DIMENSIONSROUGHING-IN DIMENSIONS
UNIT: mm
:
K-18571T
45
35
70
235
65
150
1055
770
70
235
135
350 500
415
1119169-T01-A

-2-
Install the Basin
Note! The lavatory tops must be installed on a cabinet or
matching metal stand (refer to Installation and User Guide
packed with the cabinet or stand for installation details).
Recommend Kohler metal square leg or Kohler bathroom
furniture for support or decoration.
!
(
)
!
·
76mm
·Rough-in the supplies and the drain piping.
The supply stop handles cannot extend more than
76mm from the finish wall when in the open position.
NOTE:
·
·
10mm
()
, 65-
75mm
1. 2 3
2.
·
·
Drill two 10mm hanger bolt holes at the marks on the wall.
The nylon anchors is needed for concrete wall (supplied).
Mount hanger bolts to the wall so approximately 65-75mm
of each bolt remains exposed.
1. Height dimensions marked in fig. 2 and fig. 3 could
be adjusted per your the vanity height or the actual
height of the console leg.
2. Other fastening devices of sufficient size and
strength may also be used.
NOTE:
K-18572T
Fig.#1
1
45
35
70
230
65
150
700
360
70
230 135
500
350
415
Attachment
Bolt (x2)
Wall Plug
550mm
Waste
Outlet Waste
630mm
805mm
80mm
REACH VANITY TOP 105
K-18571T
105
K-18571T
770mm
Fig.#2
2
1119169-T01-A

-3-
360mm
REACH VANITY TOP 70
K-18572T
70
K-18572T
Attachment
Bolt (x2)
Wall Plug
550mm
Waste
Outlet Waste
630mm
815mm
80mm
·· Install the faucet and drain to the lavatory according to the
manufacture's instructions.
·
·
·
·
·Carefully place the lavatory against the wall, so the
hanger bolts extend through the lavatory holes.
·
·
·
Level the lavatory.
Install the cap nuts and washers, and tighten until snug.
Do not
overtighten the cap nuts.Overtightening may cause
damage to the product.
Clean the lavatory top.
CAUTION: Risk of product damage.
·
·Put the sealant around the back wall attached surface of
the lav evenly.
Fig.#3
3
Apply Silicone sealant
along this face
Washer Nut
Offset Nut
Fig.#4
4
1119169-T01-A

-4-
1.
2.
3.
4.
Install the Plumbing
1. Install the drain in accordance with the manufacturer s
instructions.
Make sure a watertight seal exists on all
basin drain connections.
Provide access to the plumbing connections
for future plumbing maintenance.
2. Connect the hot and cold water supplies.
3. Open the hot and cold water valves, and check the supply
connections for leaks.
4. Run water into the basin, and check the drain connections
for leaks.
Caution!
Caution!
,
Fig.#5
5
IMPORTANT CONSUMER INFORMATIONIMPORTANT CONSUMER INFORMATION
CARE AND CLEANING
To keep your lavatory looking new, make sure you rinse it out
thoroughly after each use. on this
product, as they will scratch and ruin the surface. Stubborn
stains, paint, or tar can be removed with turpentine or paint
thinner.
DO NOT USE ABRASIVES
Caution! Risk of product damage.
Many cleaners contain abrasive and chemical substances,
and should not be used for cleaning stainless steel, enamel,
plated or plastic fittings.
These finishes should be cleaned using a mild washing up
detergent or soap solution, rinsed and then wiped dry with a
soft clean cloth.
