Kohler Components EX28096K-4 User manual

INSTALLATION INSTRUCTIONS
1483418-H2-A 1
EX28096K-4 Single Control Lavatory Faucet - LeverEX28096K-4 Single Control Lavatory Faucet - Lever
COMPONENTS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves the
right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. If possible, install this faucet before installing the lavatory.
3. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
4. Observe local plumbing codes.
5. Shut off the water supplies to the fitting.
HANDLE OPERATION
Lift the handle gently. Turn clockwise for hot water, turn counter-clockwise for cold water.
ROUGH-IN DIMENSIONS
1483418-H2-A 4
SERVICE PARTS
COMPONENTS
**Color code must be specified when ordering.
1477827**
3002558
3009021
837056**
1477826**
834704
1228834
3016159
1477834**
833730
1477840**
1249005
1477841
65874
1477842
1292073
1151264
1477843
1167318
1483414
1258880
1016869
1483463
1115706
1115710
1115726
35~55
Ø63
146
G1˝ 1/4
52
G3/8˝
166530
140
15~24
Ø48
Ø32~Ø38
45 Max.
45 最大 67~86
81
6
20
Ø42
11
56
93
46°

INSTALLATION CHECKOUT
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc. which could adversely
affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
INSTALLATION
How to Install the Drain
Install the waste(9) with foam ring(10) into
the drain hole.
Install the seal(11), secure and tighten the
drain body(12) to the waste by hand.
Chamfer Side Up
Adjust the drain body to enable the ball
lever(13) and lift rod(8) to engage.
Insert the waste stopper kit(14) into the
waste.
Insert the ball lever into the drain body
and through the stopper hole(15).
Make sure that the ball lever engages
with the waste stopper kit and adjust the
waste stopper screw(16) if required.
Tighten the ball lever retaining nut(17)
by hand.
13
14
16
17
15
How to Install the Lift Rod Kit
Attach the connector(18) onto the ball
lever(13) and lift rod(8). Tighten the
connector retaining screw with a suitable
screwdriver.
Connect the drain body to the drain outlet.
18
13
8
1483418-H2-A 3 1483418-H2-A 2
How to Install the Faucet
If need to take off the hoses(1) to repair,
reinstall and tighten them by hand.
Install the mounting studs(2) into the
faucet(3) bottom. Slide the escutcheon(4)
over the hoses and mounting studs until
it is put into the faucet bottom.
Insert the faucet assembly into the hole
of the lavatory until the escutcheon
contacts the deck.
From underside of the lavatory, place the
washers(5, rubber washer is on the top)
onto the mounting studs. Position the
faucet．Tighten the nuts(7) with tool(6) to
secure the faucet.
Insert the lift rod(8) to the hole at the rear
of the faucet.
Attach the hoses to water supplies.
The hose with “COLD” label should be
connected to cold water.
9
9
11
12
10
3
4
6
8
2
7
1
5
22
21
20
19
Ensure all connections are tight.
Ensure the handle is in the off position.
Turn on the drain and main water supply,
and check for leaks. Repair as needed.
Uninstall the screw(20) with hex wrench
(19). Remove the aerator(22) with tool
(21). Turn on the faucet. Run hot and cold
water through the spout for about one
minute to remove any debris. Check for
leaks. Remove any debris from the
aerator. Shut off the faucet. Reinstall the
aerator. Tighten the screw.
