Kohler Elosis 18055T-B-CP User manual

所有的资料是按最新出版的产品资料编写而成。
科勒公司保留任何时候不经通知即可改变产品特
性、包装或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，
请把这些资料交给用户阅读。
Elosis Sensor Faucet
安装之前
Kohler China Investment Co.,Ltd
Manufacturer:Shanghai Kohler Electronic Technology Co., Ltd.
No.1955, Fengxiang Road. Baoshan Area, Shanghai, PRC Post code: 200444
18055T-B-CP 黛诗台盆感应龙头-直流电(冷热混合型)
18057T-B-CP 黛诗台盆感应龙头-直流电(单冷型)
18075T-B-CP 黛诗台盆感应龙头-交流电(冷热混合型含交流电源盒)
18076T-B-CP 黛诗台盆感应龙头-交流电(冷热混合型)
18077T-B-CP 黛诗台盆感应龙头- 交流 电(单冷型含交流电源盒)
18078T-B-CP 黛诗台盆感应龙头-交流电(单冷型)
1248536-T01-C
1
1.一定要先彻底冲洗供水管以清除管道中的杂质,
使用水源为自来水或可供饮用水。
2. 请勿将强力及冲击施于产品，以免造成故障，
引起漏水。
3. 安装、清洁龙头时，切勿损伤感应窗口表面，
以免造成故障。
4. 如果是安装新的洗面盆，可将水龙头和排水组
件先安装好到面盆上。
5. 对于直流龙头，安装时注意电池的正负极不能
装反，电池盒盖要拧紧，防止电池受潮。
6. 对于交流龙头，安装时务必按照说明书的要求
正确连接导线，龙头安装完毕后才可向电源盒供
电。
7. 一个交流电源盒最多可供两个感应龙头。
8. 交流电的总电源必须有合适熔断丝加以保护。
9. 请勿使产品感应窗口靠近强紫外线或电磁场。
10. 为保证龙头正常工作，请务必安装连接组件。
11. 对于冷热混水龙头，先将连接热水的角阀关
闭，以免烫伤。
12. 修理面盆时，用黑色电工胶布粘住感应窗口。
NOTES:
注意事项:
All information is based on the latest product information
available at the time of publication, Kohler Co. reserves the
right to make changes in product characteristics, packaging,
or availability at any time without notice. Please deliver these
instructions for the consumer. They contain important
installation, maintenance and cleaning information.
1. Flush the water supply pipes thoroughly to remove debris.
Faucet is designed for tap water or potable water.
2. Do not attack the faucet with rough strength to avoid being
damaged.
3. Do not damage the surface of sensing window when
installing or cleaning the faucet.
4. For new installations, install the faucet and drain to the
lavatory before installing the lavatory.
5. As for DC type faucets, please pay special attention to
insert direction matches battery poles. Tighten the battery
cover completely to prevent its exposure to moisture.
6. As for AC type faucets, strictly follow indicated instructions
to perform electric connection. Only provide electric supply
to power box after the installation is completed.
7. One AC/DC transformer for max.two faucets.
8. Electrical source must equipped with suitable fuse to
protect AC/DC transformer unit from damage.
9. Do not put the faucet near strong ultraviolet or
electromagnetic field.
10.To ensure faucet proper operation, please install
connectors.
11.For faucet with temperature mixer, please turn off valve
before connecting to hot water to avoid scalding.
12.Cover the sensing window with black tape when
repairing lavatories.
BEFORE YOU BEGIN
科勒（中国）投资有限公司
制造商：上海科勒电子科技有限公司
中国上海宝山区丰翔路1955号 邮编：200444

BEFORE YOU BEGIN(Continued)
安装之前（续）
2
1248536-T01-C
13. 维修交流龙头时，必须断开交流电源并关闭
水源。
13.Turn off the electrical source and shut down water
supply before servicing faucet.
1. 手伸到出水口下方感应范围
内（感应距离随面盆、周围的情
况而自动调节），水龙头出水。
手离，0.5～1秒，水龙头自动止
水。
使用说明 OPERATION INSTRUCTIONS
2. 冷热混水龙头水温调节：先
关闭热水角阀，再将冷水角阀旋
至冷水最大状态，再缓慢打开热
水角阀，以免烫伤。如冷水水压
大，打开全部热水角阀后，仍无
合适水温，请再缓慢减少冷水出
水量，直至水温使用舒适。
1. Put your hand in the sensing -range, the
faucet should turn on. The faucet should turn off
after removal within 0.5~1 second. The sensing
distance will be adjusted automatically per the
condition of the lavatory and surrounding
environment.
2. Adjust the water temp for faucet with
temperature mixture: turn off hot water valve
first, and then turn on the water and adjust to full
cold, slowly turn on hot water valve to avoid
scalding. If cold water pressure is high and
unable to gain proper comfortable water temp
even hot water valve is fully open, turn down
cold water capacity slowly until water temp is
comfortable for use.
建议搭配脸盆
RECOMMENDATION OF MATCHING
LAVATORY
K-2297 凯瑟琳台下脸盆
K-2889T 维克长方形台下盆
K-2215T-M拉蒂纳台下脸盆
K-2949T 拂朗台下脸盆
K-2319 贝卡夫台下盆
K-2211T 卡斯登台下脸盆
K-2940T 温蒂斯台下脸盆
K-99184T 乔司 21''椭圆形台下盆
K-2881T 维克椭圆形台下脸盆
K-2883 维克圆形台下脸盆
K-2768T-1 皓 台下盆
K-18572T-1 瑞琦一体化盆
K-18571T-1 瑞琦一体化盆
K-2297 Kathryn® Undercounter Lavatory
K-2889T Verticyl® Rectangular Undercounter Lavatory
K-2215T-M Ladena® Undercounter Lavatory
K-2949T Forefront™ Undercounter Lavatory
K-2319 Bancroft® Undercounter Lavatory
K-2211T Caxton® Undercounter Lavatory
K-2940T Vintage®Undercounter Lavatory
K-99184T Chalice™ Undercounter Lavatory
K-2881T Verticyl®Oval Undercounter Lavatory
K-2883 Verticyl® Round Undercounter Lavatory
K-2768T-1 Karess Undercounter Lavatory
K-18572T-1 Reach™ Vanity Top
K-18571T-1 Reach™ Vanity Top

注意：
如果使用非推荐的脸盆，可能会产生溅
水在脸盆外面等情况。
建议搭配脸盆（续）
RECOMMENDATION OF MATCHING
LAVATORY(Continued)
1248536-T01-C
3
NOTE:
Water spraying out of countertop might happen when
countertop out of the recommendation list is selected.
K-2979-1 纽英伦一体化台盆
K-2749T 拂朗长方形一体化台盆
K-11479-VC1 拂朗半嵌入式脸盆
K-2196T-1 斑宁登修边式台上脸盆
K-2979-1 Tresham™ Vanity Top
K-2749T Forefront™ Vanity Top
K-11479-VC1 Forefront™ Semi-Recessed Lavatory
K-2196T-1 Pennington® Self-rimming Lavatory
安装尺寸(毫米) ROUGH-IN DIMENSIONS（mm）
18055T-B-CP
黛诗台盆感应龙头-直流电（冷热混合型）
18057T-B-CP
黛诗台盆感应龙头-直流电（单冷型）
142 142
111 111

Drain
排水组件
φ41.2
φ54
φ31.75
226
φ66.5
72
54
AC/DC Transformer
(Not contained in 18076T-B-CP, 18078T-B-CP, need purchasing )
交流电源盒
(18076T-B-CP、18078T-B-CP需另购)
Output: DC6V
输出:
直流电压6V
Input: AC220V
输入:
交流电压220V
安装尺寸(毫米)(续） ROUGH-IN DIMENSIONS(mm)
(Continued)
142 142
111 111
AC/DC Transformer
交流电源盒
AC/DC Transformer
交流电源盒
18076T-B-CP
黛诗台盆感应龙头-交流电（冷热混合型）
18078T-B-CP
黛诗台盆感应龙头-交流电（单冷型）
4
1248536-T01-C
18075T-B-CP
黛诗台盆感应龙头-交流电（冷热混合型含交流电源盒）
18077T-B-CP
黛诗台盆感应龙头-交流电（单冷型含交流电源盒）

INSTALLATION
安装步骤
一龙头与面盆的安装固定
将固定螺杆(2)安装到水龙头(1)底部
处。再把垫片(3)套在固定螺杆上。并
嵌入水龙头底部的盘槽中。然后将电
源线(7)和进水软管(8)穿过安装孔，从
面盆下方将固定橡胶垫片(4)固定金属
垫片(5)和固定螺母(6)对齐固定螺杆向
上套入。调整水龙头电源线及进水软
管的位置。用扳手拧紧固定螺母以便
把水龙头固定在面盆上。
How to Install the Faucet
技术参数
电源：直流 4节5号碱性电池(LR06×4)
交流 电压220V,频率50/60Hz
检测时间：小于0.5秒
关阀延时：0.5～1秒
感应距离：自动调节
流量：水压为0.3MPa 时，流量不大于2.0L/min
超时用水控制：超时用水1分钟，自动止水。
环境温度：1～55
进水温度：0.5～71
适用水压：0.05～
0.86MPa
PARAMETERS
Power: DC 4 pieces of AA size alkaline batteries
AC 220V, 50/60Hz
Senser Duration: Less than 0.5s
Shut-off Delay: 0.5~1s
Sensing Distance: Automatic adjustment
Flow Rate: No more than 2.0L/min at 0.3MPa.
Overtime Flowing Control: Automatically stop flushing when
the faucet senses an object for more than 1 minute
continuously
Ambient Temperature: 1~55℃
Supply Water Temperature: 0.5~71℃
Supply Water Pressure: 0.05~0.86MPa
℃
℃
1
2
43
65
78
如何安装水龙头
二 安装控制组件
拧下控制盒盖(10)螺钉(11)，打开控制
盒(9)，根据安装尺寸图（图一）在墙
壁合适的位置钻孔，打入膨胀管
(12)，使控制盒紧贴墙面，再用螺钉
(13)将其固定在墙壁上。
注意：控制盒长边端需竖直放置，出
水口位置可根据需要左右调整。
将软管(16)一端与三通进水软管组件
(17)连接，另一端与控制组件(15)进水
口连接，再将出水口与龙头出水软管
(14)连接，三通进水软管组件另外两端
与角阀(18)连接。
对于单冷龙头，将软管一端与滤网接头
(19)相连，另一端与角阀连接即可。
9
11
10
图一
13
12
1248536-T01-C
5
1. Fasten faucet on lavatory:
Install the stud (2) to the underside of the
faucet (1). Slide the gasket (3) over the
stud, and then seat the gasket in the groove
on the underside of the sprout. Cross power
cord (7) and water inlet hose (8) through
mounting hole, slide rubber washer (4),
metal washer (5) and nut (6) onto the stud
from under the sink. Adjust faucet power
cord and water inlet hose position, fasten nut
to secure faucet on lavatory mounting
surface by wrench.
2. Install Control Assy.
Unscrew valve cover (10) screw (11)
by screwdriver, open valve cover
(9). Determine proper mounting location
per rough –in (Fig 1), then punch
expansion tube (12) in. Place valve box
against the wall and then secure control
valve assembly on the wall by bolts (13).
Note: place the long end of control box
upright, water outlet position shall be
adjusted left/right based on requirements.
Connect hose (16) to Tee water inlet
hose assembly(17), and then connect
water outlet with faucet water outlet
hose (14). Connect Tee water inlet hose
other two ends with valve (18).
For cold water faucet, connect hose
to the cylinder(19) and then connect
with valve.

四 如何安装排水组件
旋下排水器盘片(22），在其底
面沿周围涂上一圈密封油灰。把
排水本体(23)由底下插入面盆。
How to Install the Drain
22
23
24
把尾管(25)接上存水弯(26)，尾管
需插入存水弯25mm到55mm之
间。
Connect the tailpiece(25) to the
trap(26). The tailpiece should extend
25mm to 55mm into the trap.
25
26
把排水器盘片(22)旋入排水本体
(23)。从下方用手拧紧锁紧螺母
(24)，去除多余的油灰。
注意： 在锁紧螺母(24)拧紧后，
不可再调整排水本体的位置，否
则将会破坏油灰密封。
Apply plumbers putty
涂油灰
1. 取出电池盒组件， 旋松螺钉(20),
按电池盒盖(21)上的正负极标示装
入4节5号电池，紧锁电池盒盖的螺
钉。
注意：电池极性不能装反，新旧电
池不能混用。
2. 将所有导线根据对应的颜色连接
上，再将电池盒组件放在控制组件
内空旷处，合理调整位置，将合盖
根据安装方向用螺钉紧固在控制盒
上。
对于交流龙头，除对应的导线连接
到交流电源盒输出端上，其余安装
方式一致。
三 安装电池组件
15
16
14
17
18
20
21
6
1248536-T01-C
Screw the drain flange (22) off from
drain assembly. Apply plumbers putty
around the bottom circle. Insert drain
body (23) into lavatory from the
underside.
Screw the drain flange (22) into drain
body (23). Tighten the locknut (24)
manually from the underside.
Note: Remove excessive putty. Note:
after tighten locknut (24), do not adjust
drain body position, otherwise putty seal
might be damaged.
注意：
1、请勿将进水口与出水口混淆；
2、进水口处滤网组件不能漏装；
3、出水口处平垫不要漏装。
Note:
1.Do not mix water inlet with water outlet.
2.No missing screen assembly on water
inlet.
3.No missing flat washer on water outlet.
3. Install battery assembly
1. Take battery box out, loose screws
(20), insert 4 pieces of AA battery
per +/- pole indication (21) on
battery box cover. Fasten battery
box cover screws.
Note: no reversed battery
polarity. Do not mix new and used
batteries together.
2. Connect power cords with
corresponding color wires, then place
battery box assembly to empty space
within control assembly then fasten
control box by screws based on
installation direction. For AC faucet,
except corresponding cords connect to
AC/DC transformer output, other
installation methods are identical.
4.
19
混水(Mixer): 18055T-B-CP, 18075T-B-CP,
18076T-B-CP
单冷(Cold):18057T-B-CP, 18077T-B-CP,
18078T-B-CP

如何安装交流电源盒
AC/DC transformer
交流电源盒
接220V交流电
Connect AC 220V
Faucet
感应龙头
Switch
开关
Wire Tube
穿线管
一个交流电源盒供一个感应龙头
(仅限于交流感应龙头)
一个交流电源盒供两个感应龙头
Connect to
electrical Source
接交流电源
注意：禁止将交流AC220V接入直流DC接线端。
Connect to
Faucet
接感应龙头
Connect to
electrical Source
接交流电源
Connect to
Faucet
接感应龙头
AC/DC transformer
交流电源盒
接220V交流电
Connect AC 220V
Faucet
感应龙头
Faucet
感应龙头
Switch
开关 Wire Tube
穿线管
1248536-T01-C
7
HOW TO INSTALL THE AC/DC
TRANSFORMER ( FOR AC
TOUCHLESS FAUCET ONLY)
One AC/DC transformer supply one touchless faucet
One AC/DC transformer supply two touchless faucets
Note: connect AC 220V electrical source directly to DC connector is not allowed.
注：18076T-B-CP、18078T-B-CP交流电源盒需另购。 Not contained in 18076T-B-CP, 18078T-B-CP, need
purchasing

直流连接线采用导体标称截面积 mm 的电线。
请严格按照上图进行连接。
0.3
1.电源盒 (背面有不干胶)应安装在干燥，不会被水
淋湿、浸泡的位置。根据需要客户自备穿线管及
连接线。穿线管安装在墙内。建议交流电源线采用
带绝缘和护套层的电线，导体标称截面积 0.5mm ;
2. 排线完毕后，应检查并确保所有排、接线无误，
再分别连接电源盒AC接线端与排线管内交流接线
端，以及电源盒DC接线端(黑橙线接头)与龙头的
电源线接插件（从阀盒内引出的电线），最后打
开AC电源，龙头进入2分钟自动调距阶段，此过
程龙头不会出水。
2
2
8
1248536-T01-C
1.Power unit (sticker on the back) should be installed at
a dry place and avoid showering, soaking from water.
Customer prepare wire tube and wire according to
requirement. Wire tube should be mounted into the
wall. Suggested wire: AC connection wire adopts
wires with protecting layer or sleeve and the section
should be ≥ 0.5mm². The section of DC connection wire
should be ≥ 0.3mm². the connection pattern must
follow the illustrations above.
2.After wire layout finished, check and repair if needed.
Then connect AC connector to AC connector within
FPC pipe, DC connector (black-orange) on electrical
box to faucet power cord connector (wire from valve
box). Finally turn on AC power source, faucet enter
auto sensing distance adjusting phase about 2min. The
faucet will not work during this period.

如何转换成恒温阀感应龙头
(若用户另购 恒温阀16294T-3-CP,
具体安装详见其说明书 )
接感应龙头
Connect Sensor Faucet
注：三通、角阀请用户自备。
墙面
Wall
恒温阀
thermostatic valve
角阀
Stop Valve
角阀
Stop Valve
三通
Tee
三通
Tee
出水口
Outlet 三通
Tee
进热水
hot
进冷水
cold
墙面
Wall
1. 感应指示灯的各种闪烁情况
感应指示灯是使用者了解感应龙头有效、唯一
的途径。所以明白了感应指示灯闪烁所代表的
含义，可以正确使用感应龙头，
INSTALLATION CHECKOUT
CLEANING INSTRUCTIONS
IMPORTANT CONSUMER INFORMATION
清理说明
适用于所有加工处理过的表面，以中性肥皂水清
洗镀层表面，再以干净的软布彻底擦干整个表
面。许多清洁剂，比如氨水，去污粉及洁厕灵
等，会对电镀表面造成伤害，切忌使用。
有腐蚀性的清洁剂或溶剂不可使用于科勒的水龙
头及其配件上。
用户须知
安装结果检查
检查并确保所有衔接处都已拧紧，打开排水系统
和主要供水源，检查并修理有漏水的接口。
1248536-T01-C
9
Check and ensure that all connections are tight. Open the
drain. Turn on main water supply and check for leaks.
Repair leakage when necessary.
Appliable for all finishes: clean the finish with a mild soap.
Wipe entire surface completely dry with a clean soft cloth.
Most cleaners may contain chemicals, such as ammonia,
chlorine, toilet cleaner etc. which could adversely affect the
finish and are not recommended for cleaning. Do not use
abrasive cleaners or solvents on Kohler faucets and
fittings.
1. Different Indicator Flashing Indication
HOW TO CHANGE TO THERMOSTATIC
SENSOR FAUCET (If users purchased the
thermostatic valve 16294T-3-CP, please refer to
the installation guide 16294T-3-CP)
MIN 50mm
Note: Please prepare the tee and stop valve accordingly.
The indicator is the only and effective way to learn the
faucets working conditions. So the users can use the
sensor faucet correctly with knowing the meaning of the
sensor indicator's flashing.

用户须知（续）
如图示:
(1) 快速闪烁，代表感应龙头正处于通电后
的两分钟自动调节阶段。期间，安装者、使
用者不得干扰其自动调节，感应范围内不要
放置物体。
(2) 间隔6秒钟闪烁一次（直流版本），表
示电池即将使用完，请更换电池。
(3) 间隔2秒钟连续闪烁：若直流感应龙头,
代表龙头电池耗尽，已停止工作，等待使
用者更换电池;若交流感应龙头，表示为两
种情况：一种为刚刚停电；另一种为在交
流供电正常的情况下，则电源盒直流接线
端接触不良。
(4) 在正常工作情况下，当有物体被感应
时，龙 头出水，感应指示灯闪烁一次。
IMPORTANT CONSUMER INFORMATION
(Continued)
2. 超时出水控制
连续在感应状态下使用约一分钟，龙头自动止水。
自动止水后，手或物体离开感应范围后，再次进
入感应范围内，龙头正常工作，否则无反应。
指示灯
Indicator Light
3.清洗过滤系统 Clean the Filtration System
该感应龙头的控制组件内已包含了过
滤装置。如管内杂质过多或水质较
差，长期使用会引起出水情况不良。
请按以下步骤清洗过滤装置：
2 将控制组件进水口处软管拧下，取出
滤网组件，用水冲洗完毕后，重新装
入。
10
1248536-T01-C
As shown:
(1) Quick flashing means the faucet is in the
period of adjusting sensing distance after power
on for 2 minutes. During these 2 minutes, please
do not disturb auto adjustment, no objects shall be
put in the sensing range.(2) The indicator flashes
every 6s (DC type) indicates that the unit is
out of battery and ceases working. please replace
batteries.
When the faucet works for about continuous 1 minute, the
faucet will stop flushing automatically. After that, objects
must be removed from the sensing range. Then the water
will flow when objects enter into the sensing range again.
Otherwise, the faucet will not work.
2. Timeout setting
1 关闭角阀。
The touchless faucet control assembly include
filtration device. Poor water outflow shall be
caused by excessive impurities inside the hose
or poor water quality after long time use. Please
clean filtration device per following steps:
Turn off stop valve.
Pull hose from control assembly water inlet,
take filter screen assembly out. Reinstall screen
after clean by water.
(3) The indicator flashes every 2s: as for DC type
faucets, this indicates the unit is out of battery and
ceases working. Please replace batteries. For AC
faucet, it indicates two possibilities: one is that
the unit is just out of battery; or poor DC terminal
contact under normal AC power supply.
(4) Under normal condition, the water will flow and
the indicator will flash once when objects are
detected. (The indicator does not flash when
faucet stops flowing.)
3.
滤网组件
1.
滤网组件 2.
混水(Mixer): 18055T-B-CP,
18075T-B-CP, 18076T-B-CP
单冷(Cold):18057T-B-CP,
18077T-B-CP, 18078T-B-CP
(龙头关闭，感应指示灯不闪烁）

常见故障排除
以下部分故障现象可通过指示灯闪烁情况识别。（参考“感应指示灯的各种闪烁情况”）
现 象 原 因 处理方法
无电池或电池装反(直流电)
无电源或接线有误(交流电)
感应范围内有其它物体
感应窗口较脏
接线端未插好、插错
不出水
（感应指示灯不闪烁）
感应指示灯闪烁
不出水
感应指示灯闪烁
出水量小
约1分钟以内不止水
（感应指示灯不闪烁）
刚装机完毕
角阀关闭
过滤装置堵塞
起泡器堵塞
角阀是否彻底打开
起泡器堵塞
过滤装置堵塞
水压太低
打开角阀
清洗起泡器
清洗过滤装置
检查供水系统
等待2分钟
打开角阀
清洗过滤装置
清洗起泡器
检查电池
检查总电源和接线情况
移开物体
清洁窗口
检查接线端
TROUBLE SHOOTING
Some trouble symptoms can be identified by the indicator's flashing.
Symptoms Probable Causes Corrective Action
No battery or battery wrongly installed
No power supply or wrong connection
Object in sensing range
Dirt on the sensing window
The connector does not connect well
No water flow while
the indicator flashes
Keep water running within 1
minute while indicator does
not flash
Open the angle valve
Clean Aerator
Clean filter
Check the water supply system
Check the batteries
Check the power supply and the conncetion
Remove the object
Clean the sensing window
Check the connector
感应指示灯每2秒快速
闪烁1次而不出水
电池耗尽(直流电)
刚刚停电(交流电)
直流或交流接线端接触不良(交流电)
更换电池
检查总电源
重新连接接插件
No water flow
(Indicator not flashing)
The indicator flashes once
every 2 seconds and the
water doesn't flow out.
Low water flow while the
indicator does not flash
Object in sensing range Remove object
感应范围内有物体 移开物体
（Refer to "Note of the Indicator Flashing"）
如按以上操作仍未解除故障，请与销售商或科勒(中国)投资有限公司联系。
除安装更换电池外，请勿随意拆卸龙头其它部件。
Batteries are out of power
Power shut-down
DC or AC connector may not connect well
Replace batteries
Check the power supply
Reconnect the connector of AC/DC transformer
Wait for 2 minutes
Open the angle valve
Clean filter
Clean Aerator
11
1248536-T01-C
The stop valve is not open completely
The Aerator is blocked
The filter is blocked
The supply water pressure is low
Just finishing installation
The stop valve is closed
The filter is blocked
The Aerator is blocked
Please contact with distributor or Kohler China Investment Co., Ltd., if the trouble remains after above-mentioned actions are
taken.Please do not disassemble the other parts of the faucet freely except installing and replacing batteries.

零 件 图
12 1248536-T01-C
1035611 -SP-CP
Drain
排水组件
20152015
Battery , Alkaline
(Largess)
碱性电池（赠品）
1068120-SP
Connection Wire Kit
(Only for 18075T-B-
CP,18077T-B-CP)接
头线组件
（仅用于18075T-B-CP,
18077T-B-CP）
16305T-NA AC/DC
Transformer
18075T-B-CP,18077T-B-CP)
(Only for
交流电源盒
(仅用于18075T-B-CP,
18077T-B-CP)
2.5mm Hex Wrench
2.5mm
1260965-SP
控制组件
AssyControl
1097741-SP
Diaphram Assy
1260896-SP
Assy Valve Cover
阀盒盖组件
1080021-SP
Diaphragm Assy
动膜
1045458-SP
Valve Cover
阀盖
1229694-SP
Body Valve
主体
ACL-2305003-SP
Diaphragm Base
动片
1150400-SP
BATTERY BOX ASSY
电池盒组件
1140049-SP
Braide Hose
进水管
1115768-SP
Assy. Solenoid
电磁阀组件
1045460-SP
Spring
动膜压簧
1098135-SP
Valve Core Assy
主阀芯组件
1205250-SP
Nut, Valve
六角吊紧螺母
1250366-SP
Inlet Hose
进水软管
836664-SP
Installation Assy.
安装组件
1240569-SP-CP
Spout Bottom
龙头下壳
1240568-SP-CP
Spout Top
龙头上盖
1247714-SP
Circlip
单耳卡箍
1247711-SP
Sensor Assy.
探头盒组件
1244425-SP
Pipe Connection
管接头
1159733-SP-CP
Aerator
起泡器
1080023-SP
Piston
动膜支架
Elosis Sensor Faucet
Cylinder Filter Assy.
接头滤网组件
1205940-SP
FILTER ASSY
滤网组件
(仅用于18057T-B-CP,
18077T-B-CP, 18078T-B-CP)
1260117-SP
(Only for 18057T-B-CP,
18077T-B-CP, 18078T-B-CP)
三通进水软管组件
(仅用于18055T-B-CP, 18075T-B-CP, 18076T-B-CP)
1240574-SP
Tee, Inlet Assy.
(Only for 18055T-B-CP, 18075T-B-CP, 18076T-B-CP)
Kohler China Investment Co.,Ltd
Manufacturer:Shanghai Kohler Electronic Technology Co., Ltd.
No.1955, Fengxiang Road. Baoshan Area, Shanghai, PRC Post code: 200444
科勒（中国）投资有限公司
制造商：上海科勒电子科技有限公司
中国上海宝山区丰翔路1955号 邮编：200444
