Installation and Care Guide
Lavatory


1154408-X2-C ©2017 Kohler Co.
K-17151X K-17652X
K-17650X

1154408-X2-C 2 Kohler Co.

Thank You for Choosing Kohler Company
Thank you for choosing Kohler. Kohler craftsmanship oers you a rare
combination of proven performance and graceful sophistication that will
satisfy you for years to come. The dependability and beauty of your Kohler
product will surpass your highest expectations. We’re very proud of our
products here at Kohler and we know you will be too.
Please take a few minutes to review this manual before you start installation. If
you encounter any installation or performance problems, please don’t hesitate
to contact us. Our phone numbers and website are listed on back cover.
All information in this manual is based upon the latest product information
available at the time of publication. At Kohler, we constantly strive to improve
the quality of our products. We reserve the right to make changes in product
characteristics, packaging or availability at any time without notice.
Thank you for choosing Kohler Company.
  

 

  

 


 

Kohler Co. 3 1154408-X2-C

Important Information
Before You Begin
CAUTION: Risk of personal injury or product damage. Handle with
care. Product can break, chip, or cause injury if handled carelessly. Get
help lifting the lavatory.
CAUTION: Risk of personal injury. This pedestal lavatory is heavy.
Do not aempt to lift or install the pedestal lavatory without assistance.
¨Observe all local plumbing and building codes.
¨Prior to installation, unpack the new lavatory and inspect it for damage.
Return the lavatory to its protective carton until you are ready to install it.
¨ The walls and the oor must be square, plumb, and level.
¨Fixture dimensions are nominal and conform to tolerances established by
Standards TIS.
IMPORTANT NOTICE TO INSTALLERS!: Please leave these instructions for
the consumer. They contain important information.
In addition to installation procedures, this manual contains important care and
cleaning. Please retain for future reference.
NOTE: Some installation parts might not be provided.
NOTE: The product pictured in the installation steps may dier from the model
being installed.
 
 

 
 


1154408-X2-C 4 Kohler Co.




 

¨ 
¨ 

¨ 
¨ 
Tools/

Kohler Co. 5 1154408-X2-C
Roughing-In For Wall-Mount Lavatory

Dimensions are approximate. Unit: mm
 
1/2" Hot/นํ�าร้อน 1/2" Cold/นํ�าเย็น
1-1/2" OD
เส้นผ่าศูนย์กลาง
ø10 Anchor holes/รูพุก
ø35
70
309
225
ø44 485
600
502
280
590
K-17151X
55 182
305 300
102 102

1154408-X2-C 6 Kohler Co.
Roughing-In For Semi-Pedestal Lavatory

Dimensions are approximate. Unit: mm
 
426
1/2" Hot/นํ�าร้อน 1/2" Cold/นํ�าเย็น
Finished Wall/ผนัง
ø10 Anchor Holes/รูพุก
1/2" OD
เส้นผ่าศูนย์กลาง
Finished Floor/พื �น
280
171
182
240
230
ø35
ø44
70
314
225
485
600
509
590
K-17652X
80
51
313

Kohler Co. 7 1154408-X2-C
Roughing-In For Pedestal Lavatory

Dimensions are approximate. Unit: mm
 
150
182
240
102
865
280
600
509
590
K-17560X
ø44
70
314
225
485
51
ø35
313
1/2" Hot/นํ�าร้อน 1/2" Cold/นํ�าเย็น
ø10 Anchor Holes/รูพุก
Finished Wall/ผนัง
Finished Floor/พื �น
1-1/2" OD
เส้นผ่าศูนย์กลาง

1154408-X2-C 8 Kohler Co.
Install Wall-Mount Lavatory

 
  

Prepare The Site/
NOTE: Install the 1/2” water supply lines and 1-1/2” drain piping according to
the roughing-in information.
IMPORTANT: Roughing-in may vary by product type. To avoid potential
issue, verify all related product rough-in information prior to install.
1
3 5
2


 

4



Drill 10 mm. anchor holes at
the two marked locations.

Mark the centerline on the floor.
Insert anchores. Install the faucet and
drain to the lavatory.
Insert studs and
tighten the nuts.

Kohler Co. 9 1154408-X2-C
Install Semi-Pedestal Lavatory

1
3
2


Mark the centerline on the wall
and floor.
Insert anchores.


Drill 10 mm. anchor holes
at the four markedlocations.
5


6


4



Install the faucet and
drain the lavatory.
Install the faucet and
drain the lavatory.
Install the semi-pedestal to the wall with washers
and nuts.

1154408-X2-C 10 Kohler Co.
Install Pedestal Lavatory

1
3
2


Mark the centerline on the wall
and floor.


Drill 10 mm. anchor holes
at the four marked locations.
5


Gently lift up the front of the lavatory and hold it
at that position.
While the lavatory is being held up, place
the pedestal underneath the lavatory.
Gently lower the lavatory down onto the pedestal.
Fully tighten the nuts.
6




4



Insert anchores. Install the faucet
and drain to the
lavatory.
Insert studs. Do not
tighten the nuts at
this time.
Gently lifft up the front of the lavatory and hold
it at that position.
While the lavatory is being held up, place
the pedestal underneath the lavatory.
Gently lower the lavatory down onto
the pedestal. Fully tighten the nuts.

Kohler Co. 11 1154408-X2-C
Care and Cleaning
For best results, keep the following in mind when caring for your product:
• Carefully read the cleaner product label to ensure the cleaner is safe for use
on the material.
• Always test your cleaning solution on an inconspicuous area before applying
to the entire surface.
• Wipe surfaces clean and rinse completely with water immediately after
cleaner application. Rinse and dry any overspray that lands on nearby
surfaces.
• Do not allow cleaners to sit or soak on the surface.
• Use a soft, dampened sponge or cloth. Never use an abrasive material such as
a brush or scouring pad to clean surfaces.
• Be careful not to leave staining materials in contact with the surface for
extended periods of time.
• The ideal cleaning technique is to rinse thoroughly and blot dry any water
from the surface after each use.

 

•   

• 

• 

• 
• 

• 
• 
 
