Kohler 10-Jet K-1005-H2 Assembly instructions

Homeowners Guide
10-Jet Hydro-Massage System
Mproduct numbers are for Mexico (i.e. K-12345M)
Los números de productos seguidos de Mcorresponden a México
(Ej. K-12345M)
Français, page “Français-1”
Español, página “Español-1”
K-1005-H2 K-1015-H2, K-1016-H2
1032108-5-D

Important Information
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRICAL SHOCK, OR INJURY TO PERSONS
READ AND FOLLOW ALL INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING: When using electrical products, basic precautions should always be followed,
including the following:
DANGER: Risk of personal injury. To reduce the risk of injury, do not permit children to use this
product unless they are closely supervised at all times
WARNING: Risk of personal injury. To avoid injury, exercise care when entering or exiting the
unit.
WARNING: Risk of electric shock. Do not permit electric appliances (such as a hair dryer, lamp,
telephone, radio, or television) within the enclosure.
WARNING: Risk of hyperthermia. People using medications and/or having an adverse medical
history should consult a physician before using this product.
Use this product only for its intended purpose as described in this manual. Do not use attachments not
recommended by the manufacturer.
Never drop or insert any object into any opening. Keep small objects such as bath toys and bathing
accessories out of the product while the unit is running.
Do not operate this product without the guard (cover) over the suction fitting.
This installation must have two Class A Ground-Fault Circuit-Interrupters (GFCIs) or Residual Current
Devices (RCDs). The GFCIs or RCDs protect against line-to-ground shock hazard. Use two 220/240 V, 20 A,
50/60 Hz dedicated services; one for the pumps and controls, and another for the heater. Such a GFCI or
RCD should be provided by the installer and should be tested on a routine basis.
To test the GFCI or RCD, press the test button. The GFCI or RCD should interrupt power. Press the reset
button. Power should be restored.
If the GFCI or RCD fails to operate in this manner, the GFCI or RCD is defective. If the GFCI or RCD
interrupts power to the bath without the test button being pressed, a ground current is flowing, indicating
the possibility of an electric shock. Do not use.
Disconnect the product and have the problem corrected by a qualified service representative before using.
WARNING: The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia. Prolonged immersion in hot water may induce hyperthermia. Hyperthermia occurs
when the internal temperature of the body reaches a level several degrees above the normal body
temperature of 98.6°F (37°C). The symptoms of hyperthermia include an increase in the internal
temperature of the body, dizziness, lethargy, drowsiness, and fainting. The effects of hyperthermia
include: (a) failure to perceive heat, (b) failure to recognize the need to exit the bath, (c)
unawareness of impending hazard, (d) fetal damage in pregnant women, (e) physical inability to
exit the bath, and (f) unconsciousness resulting in the danger of drowning.
IMPORTANT! Flush the system twice a month or more depending upon usage, as described in the ″Care
and Cleaning″section.
Do not allow the water temperature in the product to exceed 104°F (40°C).
Do not use shampoo, soap or bubble bath in the product water. You can freely use shampoo and soap for
showering before you fill the footbath basin.
1032108-5-D 2 Kohler Co.

Important Information (cont.)
This product has been listed by Underwriter’s Laboratories, thus ensuring safety for you and your family.
This product also conforms to rigid ANSI and IAPMO standards set with the plumbing industry.
Thank You For Choosing Kohler Company
Thank you for choosing Kohler Company. Your Kohler Company product reflects the true passion for design,
craftsmanship, artistry, and innovation Kohler Company stands for. We are confident its dependability and
beauty will surpass your highest expectations, satisfying you for years to come.
All information in this guide is based upon the latest product information available at the time of
publication. At Kohler Company, we strive to fulfill our mission of improving the level of gracious living for
each person who is touched by our products and services. We reserve the right to make changes in product
characteristics, packaging, or availability at any time without notice.
Please take a few minutes to review this guide. Pay special attention to the care and cleaning instructions.
Kohler Co. 3 1032108-5-D

Lighted User Keypad
Available modes will be illuminated in blue. Active modes will be illuminated in green.
Power Turns the whirlpool pump on and off.
Outer Ring Rotate the outer ring to the desired mode. The selected mode will flash blue.
Heater Automatically engages when the power icon is selected. Rotate the outer ring until the
heater mode is flashing, then press OK to turn the heater off. Press OK again to turn the
heater back on.
Chromatherapy
Specific Color Rotate the outer ring to select this mode, then press OK. Press the up or down arrow to select a color, then press OK again.
OK Activates the desired mode.
Waterfall Mode Rotate the outer ring to select this mode, then press OK. Press the up or down arrow icons
to increase or decrease the water flow. The indicator bar will display the water flow volume.
Bodyjet Mode Rotate the outer ring to select this mode, then press OK. Press the up or down arrow icons
to increase or decrease the water flow. The indicator bar will display the water flow volume.
Up Arrow Increases the water flow.
Down Arrow Decreases the water flow.
Indicator Bar Displays the water flow volume.
Individual Jets Press 1, 2, 3, 4 or 5 to activate desired sets of bodyjets.
Chromatherapy
Cycle Rotate the outer ring to select this mode, then press OK. The chromatherapy lights will automatically and continuously cycle through eight colors. One cycle through all eight
colors takes approximately one minute.
1
2
3
4
5
Waterfall
Mode
Activates Mode
Selected
Chromatherapy-
Specific Color
Chromatherapy
Cycle
Heater
Power
On/Off
Decreases
Flow
Increases
Flow
Bodyjet
Mode
Individual
Jets
Lighted User Keypad
Indicator Bar
1032108-5-D 4 Kohler Co.

Operation
Please read and follow these steps carefully so you can safely enjoy the benefits of your hydro-massage
system.
Before Use
Remove all loose bathing items (such as soap bars, shampoo bottles and washcloths) from the direct
water path. Make sure nothing is resting on the waterfall ledge.
Remove your eyeglasses or contact lenses and any loose jewelry before entering the enclosure.
Operation
WARNING: Risk of personal injury. Always stand off to the side of the bodyjets when you turn on
the hydro-massage system or switch the waterflow from one component to another. The stream of
water can be very powerful.
NOTE: Do not allow shampoo, soap, or bubble bath to the enter the foot bath basin. If desired, shower
using shampoo and soap before filling the footbath basin with water.
Close the enclosure door securely.
Fill the foot bath basin with tempered water (not to exceed 104°F (40°C)) to a level at least 3″(7.6
cm) above the top of the suction cover. Use your hand to check the water temperature in the basin
before activating hydro-massage system.
Press the power icon on the lighted user keypad to turn the hydro-massage system on. After several
seconds, water will begin flowing at the lowest water pressure setting. The chromatherapy lights
and bodyjets 2, 3, and 4 will activate.
Allow the water to flow for several seconds to regulate the water temperature, then enter the foot
bath basin.
Gradually increase the water flow by pressing the up arrow on the lighted user keypad.
NOTE: After 20 minutes of continuous use, the hydro-massage system will automatically shut off. To
reactivate the system, step to the side, then press the power icon on the lighted user keypad. Reenter the
basin area.
If you wish to use the hydro-massage system after it has automatically shut down, simply step to
the side and press the power icon on the keypad to restart the system.
Press the power icon on the lighted user keypad a second time to turn off the waterfall.
Waterfall
Adjustable
Seat
Suction
Cover
Foot Bath
Basin
Keypad
Tower With
Bodyjets
Kohler Co. 5 1032108-5-D

Care and Cleaning
Flush Hydro-Massage System
NOTE: Sanitize your system by flushing it twice a month or more, depending upon usage. To do this:
•Fill the footbath basin with hot water to a level 3″(7.6 cm) above the top of the suction cover.
•Add two teaspoons of low-foaming dishwasher detergent and 1/2 cup (115 ml) of household bleach
to the water.
•Run the hydro-massage system for 5 to 10 minutes with all ten bodyjets running at the same time.
Turn off the system and drain the water.
•Fill the footbath basin with cold water to a level 3″(7.6 cm) above the top of the suction cover. Run
the hydro-massage system for an additional 5 to 10 minutes with all ten bodyjets running. Drain the
basin and wipe dry with a clean, soft cloth.
For best results, keep the following in mind when caring for your KOHLER product:
Exterior Surfaces
•Use mild soap and water to clean the unit. Wipe the entire surface dry with a clean, soft cloth.
Many cleaners contain harsh chemicals, such as ammonia, which can adversely affect the finish and
are not recommended.
•Do not use abrasive cleansers or solvents on the unit.
Walls and Basin
•Various wall and basin materials require different cleaners and cleaning methods. Follow the care,
cleaning and maintenance instructions furnished by the wall and basin material suppliers and
manufacturers.
Door
NOTE: For door enclosures not manufactured by Kohler Co.: Follow the care and cleaning instructions
furnished by the door enclosure manufacturer.
•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.
•Wipe surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring
pad to clean surfaces.
For detailed cleaning information and products to consider, visit www.kohler.com/clean. To order Care &
Cleaning information, call 1-800-456-4537.
One-Year Limited Warranty
ONE-YEAR LIMITED WARRANTY
KOHLER plumbing products are warranted to be free of defects in material and workmanship for one year
from date of installation.
Kohler Co. will, at its election, repair, replace or make appropriate adjustment where Kohler Co. inspection
discloses any such defects occurring in normal usage within one (1) year after installation. Kohler Co. is not
responsible for removal or installation costs. Use of in-tank toilet cleaners will void the warranty.
To obtain warranty service contact Kohler Co. either through your Dealer, Plumbing Contractor, Home
Center or E-tailer, or by writing Kohler Co., Attn.: Customer Care Center, 444 Highland Drive, Kohler, WI
53044, USA, or by calling 1-800-4KOHLER (1-800-456-4537) from within the USA and Canada, and
001-877-680-1310 from within Mexico.
IMPLIED WARRANTIES INCLUDING THAT OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE ARE EXPRESSLY LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY. KOHLER CO. AND/OR SELLER DISCLAIM ANY LIABILITY FOR SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some states/provinces do not allow limitations on how
long an implied warranty lasts, or the exclusion or limitation of special, incidental or consequential damages,
so these limitations and exclusions may not apply to you. This warranty gives you specific legal rights. You
may also have other rights which vary from state/province to state/province.
1032108-5-D 6 Kohler Co.

One-Year Limited Warranty (cont.)
This is Kohler Co.’s exclusive written warranty.
One-Year Warranty
KOHLER CO.
It is recommended that at the time of purchase, you verify that all accessories and components are complete
in this package.
This Kohler product is warranted to be free of defects in material and workmanship for one (1) year from the
date of purchase as shown on the invoice or receipt.
1. Kohler Co. will only service its commercialized products through its authorized distributors.
2. To obtain warranty service, please present the invoice and corresponding warranty.
3. Through its authorized distributors, Kohler Co. promises to repair the defective product or provide a new
replacement or an equivalent model (in those cases that the model has been discontinued) when the product
is beyond repair, without any charge to the consumer.
4. The time of repair will not exceed six (6) weeks commencing on the date the product is received.
5. It is recommended that the consumer save the invoice or receipt as additional protection, as it may
substitute the warranty in the case that there is a discrepancy in the validity of the warranty.
EXCEPTIONS AND RESTRICTIONS
The Warranty will not be valid in the following cases:
1. When the product is not operated in accordance with the instructions concerning use and operation set
forth in the owner’s manual or installation instructions, and when the recommendations and warnings
included are not observed.
2. When the product has been modified or dismantled partially or totally; or has been used in a negligent
fashion and as a consequence has suffered damages attributable to the consumer, individual, or hardware not
authorized by Kohler Co.
3. This warranty does not cover the damages as a result of disaster such as fire or acts of God, including
flooding, earthquake, or electric storms, etc. To obtain a list of distributors in your area where you can
exercise your rights under this warranty, please call 001-877-680-1310.
KOHLER CO., KOHLER, WI 53044 U.S.A.
IMPORTER:
INTERNACIONAL DE CERÁMICA, S.A.B. DE C.V.
AV. CARLOS PACHECO NO. 7200
CHIHUAHUA, CHIH., MEXICO C.P. 31060
TEL: [phone]
Troubleshooting
This troubleshooting guide is for general aid only. A Kohler Authorized Service Representative or qualified
electrician should correct any electrical problems. For warranty service, contact your dealer or wholesale
distributor.
Kohler Co. 7 1032108-5-D

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
1. Unit does not start or
stop. A. No power to pump/receptacle/keypad. A. Set/Reset GFCI or RCD. Check wiring. Refer to installer/dealer.
B. Harness is blocked. B. Remove blockage.
C. Keypad disconnected from
pump/control box. C. Reconnect keypad and/or wiring harness.
D. Keypad doesn’t work. D. Replace keypad. Refer to
installer/dealer.
E. Not enough water in footbath
basin. E. Fill basin 3″(7.6 cm) over top of suction cover.
F. Motor/pump assembly does not
work. F. Replace motor/pump assembly. Refer to installer/dealer.
G. Control does not work. G. Replace control. Refer to
installer/dealer.
2. Water flow surges. A. Not enough water in footbath
basin. A. Fill basin 3″(7.6 cm) over top of suction cover.
B. Suction is blocked. B. Remove obstruction.
C. Harness is blocked. C. Remove blockage.
3. Motor starts, all bodyjets
are not functioning. A. Bodyjet is blocked. A. Remove blockage.
B. Bodyjet butterfly valve wiring
loose or damaged, or butterfly
valve is faulty.
B. Identify source of fault and
correct or replace wiring or
butterfly valve. Check all wiring.
Refer to installer/dealer.
C. Not enough water in footbath
basin (pump cavitates). C. Fill basin 3″(7.6 cm) over top of suction cover.
D. Keypad does not work. D. Replace keypad. Refer to
installer/dealer.
E. Control does not work. E. Replace control. Refer to
installer/dealer.
4. Motor starts, waterfall
does not function. A. Waterfall is blocked. A. Remove blockage.
B. Waterfall wiring loose/damaged
or butterfly valve is faulty. B. Identify source of fault and correct or replace wiring or
butterfly valve. Refer to
installer/dealer.
C. Not enough water in footbath
basin (pump cavitates). C. Fill basin 3″(7.6 cm) over top of suction cover.
D. Keypad does not work. D. Replace keypad. Refer to
installer/dealer.
E. Control does not work. E. Replace control. Refer to
installer/dealer.
5. Waterfall lights do not
work. A. Loose or damaged wiring. A. Identify source and correct. Refer to installer/dealer.
B. Power supply for lighting does
not work. B. Replace lighting supply box in tower. Refer to installer/dealer.
6. Unit stops automatically
before 18 minutes. A. GFCI or RCD has tripped. A. Set/Reset GFCI or RCD.
B. Motor overheated and protection
device activated. B. Check for restricted air space around pump box, motor vent
blockage, suction/harness
blockage. Correct and allow
motor to cool.
7. Unit does not stop
automatically after 22
minutes.
A. Timer mechanism accidentally
deactivated. A. See Service Manual. Refer to installer/dealer.
1032108-5-D 8 Kohler Co.

Troubleshooting (cont.)
Symptoms Probable Causes Recommended Action
8. Noisy operation. A. Not enough water in footbath
basin. A. Fill basin 3″(7.6 cm) over top of suction cover.
B. Band straps (if applicable) on the
pump are not cut. B. Cut band straps.
9. Remote control (not
inlcuded) does not work. A. Remote not programmed. A. Re-program remote following instructions.
Kohler Co. 9 1032108-5-D

Service Parts
94821
O-Ring
1080774
Union Assy
1032112
Heater Subassembly
1018965
Adapter
73518
Plug
93685
Housing
65886
Gasket
A
**Finish/color code must be specified when ordering.
SEAT
96708
Flange
65054**
Screw
1003065
Suction Flange
Removal Tool
65226**
Plug
CORNER
1011398**(Colored Finishes)
65061** (Metal Finishes)
Suction Cover
94821
O-Ring 1080774
Union Assy
94675
Screw 32572
Washer
52878
Washer
94501
Frame
94822-D
Screw
94504
Slide
94506
Pin
94503**
Rod
94494**
Seat
94822-A
Screw
94505
Spring
94673
Screw
34064**
Handle
33357**
Screw 52680
Washer
94502
Bracket
SEAT
1032108-5-D 10 Kohler Co.

1003065
1018965
Adapter
1018965
Adapter
73518
Plug
93685
Housing
96708
Flange
65226**
Suction Plug
65054**
Screw
65886
Gasket
ALCOVE
K-1015-H2
1032122
Harness Subassembly
(K-1015-H2)
1032130 (K-1016-H2)
Harness Subassembly
94821
O-Ring
1012855
Nut
1019719
Connector
94821
O-Ring
94821
O-Ring
SEAT
SEAT
A
A
1080774
Union Assy
1080774
Union Assy
To Heater
Housing
To Suction
Harness
Suction Cover
1011398** (Colored Finishes)
65061** (Metal Finishes)
Suction Flange
Removal Tool
**Finish/color code must be specified when ordering.
Kohler Co. 11 1032108-5-D

1033675
Heater 1032545
1010675
O-Ring
1010677
Screw
1010548
Volute
94821
O-Ring
94821
O-Ring
1012653
Adapter
1012653
Adapter
1012916
Nut w/Screws
1010673
Seal
90154
Nut
1016960
Impeller
1018663
Control
1019447-A
Isolation Mount
1016958
Motor
1010676
Cover
1016957
Pump
61845-K
Copper Grounding Wire
93893
Cover
60320
Screw
93892-A
Electrical Box 67065
Ground Lug
1033678
Screw
93003
Strain Relief
(1-1/4"/3.2 cm)
1018964
Bracket
1019432
Carriage Bolt
90153
Locknut
65157
Nut
1020677
Gasket
1013453
Spring
1023381
Wrench
1013452**
Dial Trim
1020678-G
1013499
Housing
91639
O-Ring
1013497-G
Decal
See below for
cover/circuit
board detail.
Cover/Circuit Board
(w/Wrench)
(2-1/4"/5.7 cm)
1019445-M
Stud
1019445-F
Spacer
1019444-F
**Finish/color code must be specified when ordering.
1022495
Pump Nut Wrench
Housing
1015008
Plug/Wire Assembly
61776
Lock Washer
91639
O-Ring
1032108-5-D 12 Kohler Co.

B
67944-A
Nut
67944-B
Coupling
94078**
Flange
94160
Gasket
94143
Jet Spacer
94110
O-Ring
94308
Screw
1015024
Wire Harness
50506
Screw
50506
Screw
63149
Screw
1016466
Motor
96956
Butterfly
93456
Screw
93450**
End Cap
65331
Coupling
91828
Seal
91828
Seal
93434
Pin Hinge
93450**
End Cap
93456
Screw
96954-A**
96953**
Fascia
96955-A**
Jet & Valve Kit
Jet & Valve Kit
96952-A
Accumulator
96951
TOWER
To service motor,
butterfly, or jets,
see below.
Waterfall
Ledge 94853
Tube
To service motor,
butterfly, or jets,
see below.
**Finish/color code must be specified when ordering.
Kohler Co. 13 1032108-5-D

95031-A
Box
69307
Screw
93448
Plate
93458
Screw Washer
Washer
69472
65218
60980
O-Ring
94821
O-Ring
B
A
96921-A
Bulkhead
93448
Plate
93458
Screw
69472
Washer
65218
Washer
1030880
Bushing
TOWER
MOUNTING
HARDWARE
1019932
Chromatherapy Lights
**Finish/color code must be specified when ordering.
1012821
Light Housing
1010618
Elbow
1032108-5-D 14 Kohler Co.

**Finish/color code must be specified when ordering.
1023091**
Cap
1013471**
Stand
1013464-A
Decal
1022253-A**
Remote
1013822-A**
Remote w/Stand
93836
93838
93839
94853
Tube (w/Couplings)
(1/2")
(1")
(1-1/2")
(1-1/4")
Kohler Co. 15 1032108-5-D

94362
Wrench
62728
Allen Wrench
94749
Balldriver
1015694**
Seal
1015695**
Common Jamb
91225-D
Screw
94334**
Jamb
96882**
Handle
94823-B
Screw
92363-A**
Screw
94350**
Bumper
94367**
Clamp
94678**
Cap
94351
Gasket
91223-A**
Screw
92364-C**
Screw
94577**
Left Wall Jamb
94356**
94330-L**
94369-L**
91225-B
Screw
94822-A
Screw
94567**
Support
92363-A**
Screw
96886
Socket
See next page for
center panels and
header detail.
Right Hand Side Panel
(Includes 94343-B
Wiper)
Left Hand Side
Panel (Includes
94343-BWiper)
Right Wall
Jamb
**Finish/color code must be specified when ordering.
Corner Enclosure
94343-B
Wiper
94343-B
Wiper
1032108-5-D 16 Kohler Co.

96919**
Deflector
52557
Screw
94295**
Header
95035**
Deflector
96918**
Frame
90554
Nut
94825**
Back Stop
95048
Screw
94826**
Cap
95032**
Guide
94305-L**
Panel
96877-L**
Panel
94306-L**
Panel
95035**
Deflector
95023
Deflector
95023
Deflector
95033**
Guide
95033**
Guide
96918**
Frame
96918**
Frame
96918**
Frame
94711**
Stop
52557
Screw
94296
Bracket
64212
Washer
94822-A
Screw
94343-A
Wiper
Center Panels and Header
95032**
Guide
94354
Roller
1018808
Screw
94347
Bushing
1016436
Roller Screw Kit
94347
Bushing
**Finish/color code must be specified when ordering.
Corner Enclosure
Kohler Co. 17 1032108-5-D

1015694**
Seal
94337**
Jamb
92364-B**
Screw
94822-B
Screw
94822-C
Screw
94822-A
Screw
94552**
Expander
1015695**
Common Jamb
91225-D
Screw
94365**
Jamb
94350**
Bumper
94367**
Clamp
94678**
Cap
94351
Gasket
94362
Wrench
62728
Allen Wrench
94749
Balldriver
92364-C**
Screw
92363-A**
Screw
92363-A**
Screw
96882**
Handle
94822-C
Screw
92364-B**
Screw
96886
Socket
See next page for
center panels and
header detail.
94823-B
Screw
**Finish/color code must be specified when ordering.
Alcove Enclosure
1032108-5-D 18 Kohler Co.

96919**
Deflector
52557
Screw
94295**
Header
94354
Roller
95035**
Deflector
96918**
Frame
90554
Nut
94825**
Back stop
95048
Screw
94826**
Cap
95032**
Guide
95033**
Guide
94305-L**
Panel
94304-L**
Panel
94306-L**
Panel
95035**
Deflector
95033**
Guide
96918**
Frame
96918**
Frame
96918**
Frame
1018808
Screw
94347
Bushing
1016436
Roller Screw Kit
94711**
Stop
52557
Screw
94296
Bracket
64212
Washer
94822-A
Screw
94343-A
Wiper
94347
Bushing
Center Panels and Header
Alcove Enclosure
95032**
Guide
**Finish/color code must be specified when ordering.
Kohler Co. 19 1032108-5-D

Guide du propriétaire
Système d’hydromassage à 10 jets
Renseignements importants
CONSIGNES RELATIVES AUX RISQUES
D’INCENDIE, D’ÉLECTROCUTION OU DE
BLESSURES CORPORELLES
LIRE ET SUIVRE TOUTES LES INSTRUCTIONS
CONSERVER CES INSTRUCTIONS
AVERTISSEMENT : Lors de l’utilisation des produits électriques, des précautions de base
devraient toujours être observées, incluant ce qui suit:
DANGER : Risque de blessures corporelles. Afin de réduire les risques de blessures, ne jamais
permettre à un enfant d’utiliser cet appareil sans surveillance.
AVERTISSEMENT : Risque de blessures corporelles. Pour éviter les blessures corporelles, entrer et
sortir de l’unité avec précaution.
AVERTISSEMENT : Risque d’électrocution. Ne pas raccorder des appareils électriques (tels que
sèche-cheveux, lampes, téléphones, radios ou télévisions) à une trop courte distance.
AVERTISSEMENT : Risque d’hyperthermie. Les personnes sous médicaments ou qui sont en
observation médicale doivent consulter leur médecin avant d’utiliser cet appareil.
Utiliser ce produit uniquement pour l’usage pour lequel il a été prévu tel que décrit dans ce manuel. Ne pas
utiliser des fixations non recommandées par le fabricant.
Ne jamais faire tomber ou insérer d’objet quelconque dans les ouvertures. Ne pas laisser de petits objets ou
des jouets pour le bain dans la baignoire à hydromassage lorsque celle-ci est en marche.
Ne pas utiliser cet appareil sans ses protecteurs (couvercles) sur ses raccords d’aspiration.
L’installation électrique doit avoir deux Disjoncteurs de Fuite de Terre (GFCI) ou des appareils de courant
résiduel (RCDs). Les GFCI ou les RCD protègent contre une électrocution par la mise à la terre. Utiliser deux
alimentations dédiées de 220240 V, 20 A, 50/60 Hz; une pour les pompes et les contrôles, et l’autre pour le
chauffe-eau. De tels disjoncteurs GFCI ou RCD devraient être fournis par l’installateur et vérifiés
régulièrement.
Appuyer sur le bouton de test pour tester les disjoncteurs GFCI ou RCD. Le GFCI ou RCD devraient couper
le courant. Appuyer sur le bouton de ré-initialisation. L’alimentation devrait être restituée.
Si les disjoncteurs GFCI or RCD ne fonctionnent pas de cette façon, l’un ou l’autre est défectueux. Si les
disjoncteurs GFCI ou RCD stoppent l’alimentation électrique à la baignoire sans que le bouton test ne soit
utilisé, il y a donc un court circuit.indiquant la possibilité de choc électrique. Ne pas utiliser.
Débranchez l’unité et la-faire vérifier par un Technicien Qualifié avant de l’utiliser.
AVERTISSEMENT : La consommation d’alcool, de drogues ou de médicaments peuvent
augmenter considérablement le risque fatal d’hyperthermie. Une immersion prolongée dans l’eau
chaude peut provoquer l’hyperthermie. L’hyperthermie a lieu lorsque la température corporelle
interne atteint plusieurs degrés au dessus de la temperature normale de 98,6°F (37°C). Les
symptômes d’hyperthermie comprennent la hausse de la température corporelle, l’étourdissement,
Kohler Co. Français-1 1032108-5-D
