Kohler Underscore K-1969-GCW User guide

Features
•Acrylic
•Bask™heated lumbar support with three temperature settings.
•Extra deep 27-1/2" (699 mm) soaking depth.
•122 BubbleMassage™airjets.
•Blower motor with 300 W heater, electronic user control, and
remote control.
•With Zones of Control™feature.
•Two raised corner seats, at 6-3/4" (171 mm) and 11-7/8" (302
mm) from bath floor.
•Chromatherapy
•Intended for drop-in or under-mount installation.
•Center drain.
•48" (1219 mm) x 48" (1219 mm) x 34" (864 mm)
Required Accessories
K-578 Not applicable
Codes/Standards
CSA B45.5/IAPMO Z124
ASTM E162
ASTM E662
UL 1795
KOHLER®One-Year Limited Warranty
See website for detailed warranty information.
Available Color/Finishes
Color tiles intended for reference only.
DescriptionCodeColor
White0
Biscuit96
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
2-18-2015 01:07
Underscore®
Cube BubbleMassage™Bath with Bask™
K-1969-GCW

24"
Notes
Required Electrical Service Measure your actual product for roughing-in
details.
One dedicated circuit required, protected with Class A
Ground-Fault Circuit-Interrupter (GFCI) or Residual Current Device
(RCD). Install this product according to the installation
guide.
220-240 V, 15 A, 50/60 HzBlower, Heated
Surface: Hot water supply should be 70% of capacity or
greater. Installations will vary.
Technical Information
All product dimensions are nominal.
Drop-in/UndermountInstallation:
CenterDrain location:
39-3/8" x 39-3/8" (1000 mm x 1000 mm)Basin area, bottom:
44-5/8" x 44-5/8" (1134 mm x 1134 mm)Basin area, top:
156 lbs (70.8 kg)Weight:
105 lbs/ft²(512.7 kg/m²)Minimum floor load:
27-1/2" (699 mm)Water depth:
171 gal (647.3 L)Water capacity:
Drop-in, 47" x 47" (1194 mm x 1194 mm)Cutout:
K-578Under-mount kit:
Blower: 220-240 V, 5 A, 50/60 Hz
Heated Surface: 120-220 V, 0.5 A, 50/60
Hz
Electrical rating:
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
www.kohler.com
2-18-2015 01:07
Underscore®
Cube BubbleMassage™Bath with Bask™
K-1969-GCW
